Proposal for resolving quantized Landau orbits via elastic XUV scattering

Sabrina Meyer1,*, Joris Sturm1, Christina Schröder1, Stephen Hughes2, Andreas Knorr1, and Lara Greten1,2,†

  • *Contact author: meyer@tu-berlin.de
  • †Contact author: lara.greten@queensu.ca
PDF

Phys. Rev. B 113, 165421 – Published 21 April, 2026

DOI: https://doi.org/10.1103/hq91-75kb

Abstract

Electrons in a two-dimensional electron gas under a strong perpendicular magnetic field undergo cyclotron motion, whose quantization yields discrete Landau levels and quantized Larmor radii. The magnetic length—the Larmor radius of the smallest Landau orbit—is only tens of nanometers for fields of a few tesla. We propose a method to probe the spatial structure of Landau orbits via scattering with extreme ultraviolet radiation, whose wavelength naturally matches this scale. Starting from a microscopic Hamiltonian, we derive the far-field spectrum emitted by the optically induced current density. The Landau orbit contributions in the spectrum are suppressed due to scattering at the sample geometry. However, normalizing to the zero-magnetic-field reference defines a Landau-level scattering spectrum that isolates Landau orbit information from the full spectrum. A projection onto Laguerre polynomials allows for reconstructing the probability density distributions of individual Landau-level wave functions, featuring radial maxima at the quantized Larmor radii. This way, we propose an experimental method to determine details of the Landau orbits.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (53)

  1. T. Ando, A. B. Fowler, and F. Stern, Electronic properties of two-dimensional systems, Rev. Mod. Phys. 54, 437 (1982).
  2. K. v. Klitzing, G. Dorda, and M. Pepper, New method for high-accuracy determination of the fine-structure constant based on quantized Hall resistance, Phys. Rev. Lett. 45, 494 (1980).
  3. D. C. Tsui, H. L. Stormer, and A. C. Gossard, Two-dimensional magnetotransport in the extreme quantum limit, Phys. Rev. Lett. 48, 1559 (1982).
  4. L. Schubnikow and W. J. De Haas, A new phenomenon in the change of resistance in a magnetic field of single crystals of bismuth, Nature (London) 126, 500 (1930).
  5. D. Weiss, K. V. Klitzing, K. Ploog, and G. Weimann, Magnetoresistance oscillations in a two-dimensional electron gas induced by a submicrometer periodic potential, Europhysics Letters (EPL) 8, 179 (1989).
  6. L. Landau, Diamagnetismus der metalle, Z. Phys. 64, 629 (1930).
  7. M. O. Goerbig, P. Lederer, and C. M. Smith, Competition between quantum-liquid and electron-solid phases in intermediate Landau levels, Phys. Rev. B 69, 115327 (2004).
  8. H. T. Takahashi, Landau level spectroscopy by optical angular momentum, Ph.D. thesis, Open University of Japan, 2020.
  9. O. Ciftja, Detailed solution of the problem of Landau states in a symmetric gauge, Eur. J. Phys. 41, 035404 (2020).
  10. K. Hashimoto, T. Champel, S. Florens, C. Sohrmann, J. Wiebe, Y. Hirayama, R. A. Römer, R. Wiesendanger, and M. Morgenstern, Robust nodal structure of Landau level wave functions revealed by Fourier transform scanning tunneling spectroscopy, Phys. Rev. Lett. 109, 116805 (2012).
  11. Bence Bernáth, P. Gogoi, A. Marchese, D. Kamenskyi, H. Engelkamp, D. Arslanov, B. Redlich, P. C. M. Christianen, and Jan C. Maan, Nonlinear terahertz transmission spectroscopy on Ga-doped germanium in high magnetic fields, Phys. Rev. B 105, 205204 (2022).
  12. P. A. Wolff, Thomson and Raman scattering by mobile electrons in crystals, Phys. Rev. Lett. 16, 225 (1966).
  13. A. Fainstein, T. Ruf, M. Cardona, V. I. Belitsky, and A. Cantarero, Electronic and acoustic-phonon inter-Landau-level Raman scattering in GaAs/AlxGa1−xAs multiple quantum wells, Phys. Rev. B 51, 7064 (1995).
  14. H. L. Cui, V. Fessatidis, and P. Vasilopoulos, Inelastic light scattering from a modulated two-dimensional electron gas in magnetic fields, Phys. Rev. B 52, 13765 (1995).
  15. D. X. Nguyen and D. T. Son, Probing the spin structure of the fractional quantum Hall magnetoroton with polarized Raman scattering, Phys. Rev. Res. 3, 023040 (2021).
  16. A. Pinczuk, B. S. Dennis, L. N. Pfeiffer, K. W. West, and E. Burstein, Inelastic light scattering by the two-dimensional electron gas: Fractional quantum Hall regime and beyond, Philos. Mag. B 70, 429 (1994).
  17. R. E. Slusher, C. K. N. Patel, and P. A. Fleury, Inelastic light scattering from Landau-level electrons in semiconductors, Phys. Rev. Lett. 18, 77 (1967).
  18. J. Worlock, A. Pinczuk, Z. Tien, C. Perry, H. Störmer, R. Dingle, A. Gossard, W. Wiegmann, and R. Aggarwal, Spectroscopy of Landau transitions of two-dimensional electron gases, Solid State Commun. 40, 867 (1981).
  19. T. D. Rhone, J. Yan, Y. Gallais, A. Pinczuk, L. Pfeiffer, and K. West, Rapid collapse of spin waves in nonuniform phases of the second Landau level, Phys. Rev. Lett. 106, 196805 (2011).
  20. D. Richards, Inelastic light scattering from inter-Landau level excitations in a two-dimensional electron gas, Phys. Rev. B 61, 7517 (2000).
  21. S. Luin, V. Pellegrini, A. Pinczuk, B. S. Dennis, L. N. Pfeiffer, and K. W. West, Resonant Rayleigh scattering from bilayer quantum Hall phases, Phys. Rev. Lett. 97, 216802 (2006).
  22. V. Bisti, A. Zhuravlev, and L. Kulik, Resonant Rayleigh scattering by 2DES in high magnetic field, Physica B 460, 245 (2015).
  23. R. Z. Vitlina, L. I. Magarill, and A. V. Chaplik, Light scattering by a 2D electron system with spin-orbit interaction in a strong magnetic field, J. Exp. Theor. Phys. 117, 1131 (2013).
  24. L. V. Kulik, K. Ovchinnikov, A. S. Zhuravlev, V. E. Bisti, I. V. Kukushkin, S. Schmult, and W. Dietsche, Resonant Rayleigh scattering as a probe of spin polarization in a two-dimensional electron system, Phys. Rev. B 85, 113403 (2012).
  25. V. Bellani, F. Rossella, M. Amado, E. Diez, K. Kowalik, G. Biasiol, and L. Sorba, Circularly polarized resonant Rayleigh scattering and skyrmions in the ν=1 quantum Hall ferromagnet, Phys. Rev. B 83, 193307 (2011).
  26. K. Dini, O. V. Kibis, and I. A. Shelykh, Magnetic properties of a two-dimensional electron gas strongly coupled to light, Phys. Rev. B 93, 235411 (2016).
  27. M. Morgenstern, J. Klijn, C. Meyer, and R. Wiesendanger, Real-space observation of drift states in a two-dimensional electron system at high magnetic fields, Phys. Rev. Lett. 90, 056804 (2003).
  28. R. Roldán, J.-N. Fuchs, and M. O. Goerbig, Spin-flip excitations, spin waves, and magnetoexcitons in graphene Landau levels at integer filling factors, Phys. Rev. B 82, 205418 (2010).
  29. Z. F. Ezawa and G. Tsitsishvili, Quantum Hall ferromagnets, Rep. Prog. Phys. 72, 086502 (2009).
  30. J. K. Jain, Composite fermion theory of exotic fractional quantum Hall effect, Annu. Rev. Condens. Matter Phys. 6, 39 (2015).
  31. M. Ismail, Analytic properties of complex Hermite polynomials, Trans. Am. Math. Soc. 368, 1189 (2016).
  32. N. Rohringer, Introduction to the theory of x-ray matter interaction, arXiv:1811.12052.
  33. J. D. Jackson, Classical Electrodynamics, 3rd ed. (Wiley, Hoboken, NJ, 2009).
  34. G. Dixit, O. Vendrell, and R. Santra, Imaging electronic quantum motion with light, Proc. Natl. Acad. Sci. 109, 11636 (2012).
  35. W. Vogel and D.-G. Welsch, Quantum Optics, 3rd ed. (Wiley-VCH, Weinheim, 2006).
  36. M. O. Scully and M. S. Zubairy, Quantum Optics (Cambridge University Press, Cambridge, England, 1997).
  37. I. D. Vagner, T. Maniv, and E. Ehrenfreund, Ideally conducting phases in quasi two-dimensional conductors, Phys. Rev. Lett. 51, 1700 (1983).
  38. K. Oldham, J. Myland, and J. Spanier, An Atlas of Functions (Springer US, New York, NY 2009).
  39. W. Demtröder, Electrodynamics and Optics, Undergraduate Lcture Notes in Physics (Springer International Publishing, Cham, 2019).
  40. A. C. Ipsen, New Bessel identities from Laguerre polynomials, arXiv:1203.5961.
  41. H. Wang, T. Zhang, and X. Zhou, Dark-field spectroscopy: Development, applications and perspectives in single nanoparticle catalysis, J. Phys.: Condens. Matter 31, 473001 (2019).
  42. B. I. Halperin, Quantized Hall conductance, current-carrying edge states, and the existence of extended states in a two-dimensional disordered potential, Phys. Rev. B 25, 2185 (1982).
  43. Y. Avishai, Y. Hatsugai, and M. Kohmoto, Persistent currents and edge states in a magnetic field, Phys. Rev. B 47, 9501 (1993).
  44. S. Ahn and S. Das Sarma, Density-dependent two-dimensional optimal mobility in ultra-high-quality semiconductor quantum wells, Phys. Rev. Mater. 6, 014603 (2022).
  45. D. Kim, S. Kim, D. Lee, S. Liang, F. Tay, M. J. Manfra, D.-S. Kim, and J. Kono, Terahertz Landau polaritons in nano-slots: Ultrastrong coupling under extreme spatial confinement, in 2023 48th International Conference on Infrared, Millimeter, and Terahertz Waves (IRMMW-THz) (IEEE, Montreal, QC, Canada, 2023), pp. 1–2.
  46. T. Champel and S. Florens, Local density of states in disordered two-dimensional electron gases at high magnetic field, Phys. Rev. B 80, 161311(R) (2009).
  47. T. Champel, S. Florens, and M. E. Raikh, Nonlocal correlations of the local density of states in disordered quantum Hall systems, Phys. Rev. B 83, 125321 (2011).
  48. M. E. Raikh and T. V. Shahbazyan, Anomalous tunneling in a strong magnetic field and smooth random potential: The universal distribution of the localization lengths, Phys. Rev. B 51, 9682 (1995).
  49. B. Krummheuer, V. M. Axt, T. Kuhn, I. D'Amico, and F. Rossi, Pure dephasing and phonon dynamics in GaAs- and GaN-based quantum dot structures: Interplay between material parameters and geometry, Phys. Rev. B 71, 235329 (2005).
  50. S. Meyer, Dataset for: Proposal for resolving quantized Landau orbits via elastic XUV scattering, Zenodo (2026), doi:https://doi.org/10.5281/zenodo.18695029
  51. E. Zeidler (ed.), Springer-Taschenbuch der Mathematik: Begründet von I.N. Bronstein und k.A. Semendjaew weitergeführt von G. Grosche, V. Ziegler und D. Ziegler herausgegeben von E. Zeidler (Springer Fachmedien Wiesbaden, Wiesbaden, 2013).
  52. A. H. MacDonald, Influence of Landau-level mixing on the charge-density-wave state of a two-dimensional electron gas in a strong magnetic field, Phys. Rev. B 30, 4392 (1984).
  53. H. C. A. Oji and A. H. MacDonald, Magnetoplasma modes of the two-dimensional electron gas at nonintegral filling factors, Phys. Rev. B 33, 3810 (1986).
