Femtosecond versus nanosecond magnetization dynamics in ultrathin ferromagnetic bilayers

Anulekha De1,*, Christopher Seibel1,†, Sanjay Ashok1, Paul Herrgen1, Akira Lentfert1, Laura Scheuer1,2, Georg von Freymann1,3, Philipp Pirro1, Baerbel Rethfeld1 et al.

Martin Aeschlimann1

  • *Contact author: ade@rptu.de
  • †Contact author: cseibel@rptu.de
PDF

Phys. Rev. B 112, 144407 – Published 2 October, 2025

DOI: https://doi.org/10.1103/d7vt-jlkg

Abstract

We investigate the magnetization dynamics of an ultrathin Co (1.5 nm)/Py (1.5 nm) bilayer system from femtosecond (fs) to nanosecond (ns) timescales. Magnetization dynamics in the fs timescales is characterized as a highly nonequilibrium regime due to an ultrafast reduction of magnetization by laser excitation. On the other hand, the dynamics in the ns timescales is characterized as a close-to-equilibrium regime involving the excitation of coherent magnons. We demonstrate that the interfacial interaction between the Co and Py layers in these two nonequilibrium regimes across the timescales is dynamic and simultaneously influences the magnetization loss in the fs timescales and the magnon dynamics in the ns timescales. On ultrafast (fs) timescales, comparison between time-resolved magneto-optical Kerr effect (TR-MOKE) measurements and temperature-based μT model simulations reveals that the bilayer exhibits demagnetization dynamics intermediate between those of its individual layers. When driven far from equilibrium by ultrashort laser pulse excitation, the magnetization dynamics of the individual Co and Py layers appear to remain decoupled and evolve independently in the initial stages of the ultrafast response. On the other hand, in the ns regime, the two individual layers of the bilayer precess together at the same frequency in a coupled manner as one effective single layer. These results improve our understanding of magnetization dynamics across timescales in ultrathin exchanged-coupled ferromagnetic bilayers and provide valuable insights for the design of high-frequency and energy-efficient spintronic device concepts.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (65)

  1. E. Beaurepaire, J.-C. Merle, A. Daunois, and J.-Y. Bigot, Ultrafast spin dynamics in ferromagnetic nickel, Phys. Rev. Lett. 76, 4250 (1996).
  2. B. Koopmans, M. van Kampen, J. T. Kohlhepp, and W. J. M. de Jonge, Ultrafast magneto-optics in nickel: Magnetism or optics?, Phys. Rev. Lett. 85, 844 (2000).
  3. J.-Y. Bigot, M. Vomir, and E. Beaurepaire, Coherent ultrafast magnetism induced by femtosecond laser pulses, Nat. Phys. 5, 515 (2009).
  4. M. Krauß, T. Roth, S. Alebrand, D. Steil, M. Cinchetti, M. Aeschlimann, and H. C. Schneider, Ultrafast demagnetization of ferromagnetic transition metals: The role of the Coulomb interaction, Phys. Rev. B 80, 180407(R) (2009).
  5. B. Koopmans, F. D. Longa, G. Malinowski, D. Steiauf, M. Fähnle, T. Roth, M. Cinchetti, and M. Aeschlimann, Explaining the paradoxical diversity of ultrafast laser-induced demagnetization, Nat. Mater. 9, 259 (2010).
  6. G. Malinowski, F. D. Longa, J. H. H. Rietjens, P. V. Paluskar, R. Huijink, H. J. M. Swagten, and B. Koopmans, Control of speed and efficiency of ultrafast demagnetization by direct transfer of spin angular momentum, Nat. Phys. 4, 855 (2008).
  7. M. Battiato, K. Carva, and P. M. Oppeneer, Superdiffusive spin transport as a mechanism of ultrafast demagnetization, Phys. Rev. Lett. 105, 027203 (2010).
  8. M. van Kampen, C. Jozsa, J. T. Kohlhepp, P. LeClair, L. Lagae, W. J. M. de Jonge, and B. Koopmans, All-optical probe of coherent spin waves, Phys. Rev. Lett. 88, 227201 (2002).
  9. B. Koopmans, J. J. M. Ruigrok, F. Longa, and W. J. M. de Jonge, Unifying ultrafast magnetization dynamics, Phys. Rev. Lett. 95, 267207 (2005).
  10. S. Mukhopadhyay, S. Majumder, S. N. Panda, and A. Barman, Investigation of ultrafast demagnetization and Gilbert damping and their correlation in different ferromagnetic thin films grown under identical conditions, Nanotechnology 34, 235702 (2023).
  11. S. Ashok, J. Hoefer, M. Stiehl, M. Aeschlimann, H. Christian Schneider, B. Rethfeld, and B. Stadtmüller, Signatures of ballistic and diffusive transport in the time-dependent Kerr-response of magnetic materials, New J. Phys. 27, 063001 (2025).
  12. A. De, K. Dutta, S. Mondal, S. Barman, Y. Otani, and A. Barman, Magnonic crystals with complex geometry, Phys. Rev. B 103, 064402 (2021).
  13. A. De, S. S. P. K. Arekapudi, L. Koch, F. Samad, S. N. Panda, B. Böhm, O. Hellwig, and A. Barman, Magnetic configuration driven femtosecond spin dynamics in synthetic antiferromagnets, ACS Appl. Mater. Interf. 14, 13970 (2022).
  14. G. P. Zhang, W. Hübner, G. Lefkidis, Y. Bai, and T. F. George, Paradigm of the time-resolved magneto-optical Kerr effect for femtosecond magnetism, Nat. Phys. 5, 499 (2009).
  15. S. Ashok, C. Seibel, S. T. Weber, J. Briones, and B. Rethfeld, Influence of diffusive transport on ultrafast magnetization dynamics, Appl. Phys. Lett. 120, 142402 (2022).
  16. G. P. Zhang and W. Hübner, Laser-induced ultrafast demagnetization in ferromagnetic metals, Phys. Rev. Lett. 85, 3025 (2000).
  17. J. Walowski, G. Müller, M. Djordjevic, M. Münzenberg, M. Kläui, C. A. F. Vaz, and J. A. C. Bland, Energy equilibration processes of electrons, magnons, and phonons at the femtosecond time scale, Phys. Rev. Lett. 101, 237401 (2008).
  18. M. Vomir, L. H. F. Andrade, L. Guidoni, E. Beaurepaire, and J.-Y. Bigot, Real space trajectory of the ultrafast magnetization dynamics in ferromagnetic metals, Phys. Rev. Lett. 94, 237601 (2005).
  19. F. Dusabirane, K. Leckron, B. Rethfeld, and H. C. Schneider, Interplay of electron-magnon scattering and spin-orbit induced electronic spin-flip scattering in a two-band Stoner model, arXiv:2304.14978.
  20. M. Fähnle, J. Seib, and C. Illg, Relating Gilbert damping and ultrafast laser-induced demagnetization, Phys. Rev. B 82, 144405 (2010).
  21. W. Zhang, Q. Liu, Z. Yuan, K. Xia, W. He, Q.-F. Zhan, X.-Q. Zhang, and Z.-H. Cheng, Enhancement of ultrafast demagnetization rate and Gilbert damping driven by femtosecond laser-induced spin currents in Fe81Ga19/Ir20Mn80 bilayers, Phys. Rev. B 100, 104412 (2019).
  22. S. Mukhopadhyay, P. K. Pal, S. Manna, C. Mitra, and A. Barman, Laser fluence tunable spin transport and ultrafast demagnetization in BiSbTe1.5Se1.5/Co20Fe60B20 bilayers, Phys. Rev. B 109, 024437 (2024).
  23. M. Aeschlimann, A. Vaterlaus, M. Lutz, M. Stampanoni, and F. Meier, Ultrafast thermomagnetic writing processes in rare-earth transition-metal thin films, J. Appl. Phys. 67, 4438 (1990).
  24. I. Radu, K. Vahaplar, C. Stamm, T. Kachel, N. Pontius, H. A. Dürr, T. A. Ostler, J. Barker, R. F. L. Evans, R. W. Chantrell, A. Tsukamoto, A. Itohm, A. Kirilyuk, T. Rasing, and A. V. Kimel, Transient ferromagnetic-like state mediating ultrafast reversal of antiferromagnetically coupled spins, Nature (London) 472, 205 (2011).
  25. R. Medapalli, I. Razdolski, M. Savoini, A. R. Khorsand, A. Kirilyuk, A. V. Kimel, T. Rasing, A. M. Kalashnikova, A. Tsukamoto, and A. Itoh, Efficiency of ultrafast laser-induced demagnetization in GdxFe100−x−yCoy alloys, Phys. Rev. B 86, 054442 (2012).
  26. V. López-Flores, N. Bergeard, V. Halté, C. Stamm, N. Pontius, M. Hehn, E. Otero, E. Beaurepaire, and C. Boeglin, Role of critical spin fluctuations in ultrafast demagnetization of transition-metal rare-earth alloys, Phys. Rev. B 87, 214412 (2013).
  27. M. J. G. Peeters, Y. M. van Ballegooie, and B. Koopmans, Influence of magnetic fields on ultrafast laser-induced switching dynamics in Co/Gd bilayers, Phys. Rev. B 105, 014429 (2022).
  28. B. Liu, H. Xiao, and M. Weinelt, Microscopic insights to spin transport–driven ultrafast magnetization dynamics in a Gd/Fe bilayer, Sci. Adv. 9, eade0286 (2023).
  29. W. Zhang, W. He, X.-Q. Zhang, Z.-H. Cheng, J. Teng, and M. Fähnle, Unifying ultrafast demagnetization and intrinsic Gilbert damping in Co/Ni bilayers with electronic relaxation near the Fermi surface, Phys. Rev. B 96, 220415(R) (2017).
  30. E. Kneller and R. Hawig, The exchange-spring magnet: A new material principle for permanent magnets, IEEE Trans. Magn. 27, 3588 (1991).
  31. E. E. Fullerton, J. S. Jiang, M. Grimsditch, C. H. Sowers, and S. D. Bader, Exchange-spring behavior in epitaxial hard/soft magnetic bilayers, Phys. Rev. B 58, 12193 (1998).
  32. D. C. Crew, K. J. Kennewell, M. J. Lwin, R. C. Woodward, S. Prasad, and R. L. Stamps, Optic and acoustic modes measured in a cobalt/permalloy exchange spring bilayer using inductive magnetometry, J. Appl. Phys. 97, 10A707 (2005).
  33. K. J. Kennewell, M. Kostylev, N. Ross, R. Magaraggia, R. L. Stamps, M. Ali, A. A. Stashkevich, D. Greig, and B. J. Hickey, Magnetization pinning at a Py/Co interface measured using broadband inductive magnetometry, J. Appl. Phys. 108, 073917 (2010).
  34. J. Deng, A. Tan, J. Li, C. Hwang, and Z. Q. Qiu, In-plane spin reorientation transition in Co/Py bilayers grown epitaxially on vicinal Cu(001), J. Magn. Magn. Mater. 408, 193 (2016).
  35. A. Fraile Rodríguez, L. J. Heyderman, F. Nolting, A. Hoffmann, J. E. Pearson, L. M. Doeswijk, M. A. F. van den Boogaart, and J. Brugger, Permalloy thin films exchange coupled to arrays of cobalt islands, Appl. Phys. Lett. 89, 142508 (2006).
  36. A. Haldar, C. Banerjee, P. Laha, and A. Barman, Brillouin light scattering study of spin waves in NiFe/Co exchange spring bilayer films, J. Appl. Phys. 115, 133901 (2014).
  37. M. Salaheldeen, L. Martínez-Goyeneche, P. Alvarez-Alonso, and A. Fernández, Formation of Néel-type skyrmions in an antidot lattice with perpendicular magnetic anisotropy, Nanotechnology 31, 485708 (2020).
  38. T. Feggeler, R. Meckenstock, D. Spoddig, C. Schöppner, B. Zingsem, T. Schaffers, H. Ohldag, H. Wende, M. Farle, A. Ney, and K. Ollefs, Element-specific visualization of dynamic magnetic coupling in a Co/Py bilayer microstructure, Sci. Rep. 12, 18724 (2022).
  39. R. Wilks, R. J. Hicken, M. Ali, B. J. Hickey, J. D. R. Buchanan, A. T. G. Pym, and B. K. Tanner, Investigation of ultrafast demagnetization and cubic optical nonlinearity of Ni in the polar geometry, J. Appl. Phys. 95, 7441 (2004).
  40. See Supplemental Material at http://link.aps.org/supplemental/10.1103/d7vt-jlkg for S1. Time-resolved MOKE experiments, S2. μT model for bilayers, and S3. Transient temperature rise using μT model, which includes Refs. [8, 39, 41, 42, 62, 63, 64, 65].
  41. C. Seibel, M. Weber, M. Stiehl, S. T. Weber, M. Aeschlimann, H. C. Schneider, B. Stadtmüller, and B. Rethfeld, Control of transport phenomena in magnetic heterostructures by wavelength modulation, Phys. Rev. B 106, L140405 (2022).
  42. B. Y. Mueller and B. Rethfeld, Thermodynamic μ T model of ultrafast magnetization dynamics, Phys. Rev. B 90, 144420 (2014).
  43. D. Zusin, P. M. Tengdin, M. Gopalakrishnan, C. Gentry, A. Blonsky, M. Gerrity, D. Legut, J. M. Shaw, H. T. Nembach, T. J. Silva, P. M. Oppeneer, H. C. Kapteyn, and M. M. Murnane, Direct measurement of the static and transient magneto-optical permittivity of cobalt across the entire M-edge in reflection geometry by use of polarization scanning, Phys. Rev. B 97, 024433 (2018).
  44. A. De, A. Lentfert, L. Scheuer, B. Stadtmüller, G. von Freymann, M. Aeschlimann, and P. Pirro, Coherent and incoherent magnons induced by strong ultrafast demagnetization in thin permalloy films, Phys. Rev. B 109, 024422 (2024).
  45. F. Batallan, I. Rosenman, and C. Sommers, Band structure and Fermi surface of hcp ferromagnetic cobalt, Phys. Rev. B 11, 545 (1975).
  46. M. He, C. Wu, M. V. Shugaev, G. D. Samolyuk, and L. V. Zhigilei, Computational study of short-pulse laser-induced generation of crystal defects in Ni-based single-phase binary solid–solution alloys, J. Phys. Chem. C 123, 2202 (2019).
  47. V. Unikandanunni, R. Medapalli, E. E. Fullerton, K. Carva, P. M. Oppeneer, and S. Bonetti, Anisotropic ultrafast spin dynamics in epitaxial cobalt, Appl. Phys. Lett. 118, 232404 (2021).
  48. T. Roth, A. J. Schellekens, S. Alebrand, O. Schmitt, D. Steil, B. Koopmans, M. Cinchetti, and M. Aeschlimann, Temperature dependence of laser-induced demagnetization in Ni: A key for identifying the underlying mechanism, Phys. Rev. X 2, 021006 (2012).
  49. F. Dalla Longa, J. T. Kohlhepp, W. J. M. De Jonge, and B. Koopmans, Influence of photon angular momentum on ultrafast demagnetization in nickel, Phys. Rev. B 75, 224431 (2007).
  50. T. Gilbert, A phenomenological theory of damping in ferromagnetic materials, IEEE Trans. Magn. 40, 3443 (2004).
  51. G. B. G. Stenning, L. R. Shelford, S. A. Cavill, F. Hoffmann, M. Haertinger, T. Hesjedal, G. Woltersdorf, G. J. Bowden, S. A. Gregory, and C. H. Back, Magnetization dynamics in an exchange-coupled NiFe/CoFe bilayer studied by x-ray detected ferromagnetic resonance, New J. Phys. 17, 013019 (2015).
  52. S. Mondal and A. Barman, Laser controlled spin dynamics of ferromagnetic thin film from femtosecond to nanosecond timescale, Phys. Rev. Appl. 10, 054037 (2018).
  53. C. Kittel, On the theory of ferromagnetic resonance absorption, Phys. Rev. 73, 155 (1948).
  54. A. Lentfert, A. De, L. Scheuer, B. Stadtmüller, G. von Freymann, M. Aeschlimann, and P. Pirro, Phase shift of coherent magnetization dynamics after ultrafast demagnetization in strongly quenched nickel thin films, J. Phys.: Condens. Matter 36, 455801 (2024).
  55. K. Gilmore, Y. U. Idzerda, and M. D. Stiles, Identification of the dominant precession-damping mechanism in Fe, Co, and Ni by first-principles calculations, Phys. Rev. Lett. 99, 027204 (2007).
  56. B. Liu, X. Ruan, Z. Wu, H. Tu, J. Du, J. Wu, X. Lu, L. He, R. Zhang, and Y. Xu, Transient enhancement of magnetization damping in CoFeB film via pulsed laser excitation, Appl. Phys. Lett. 109, 042401 (2016).
  57. Y. Zhao, Q. Song, S.-H. Yang, T. Su, W. Yuan, S. S. P. Parkin, J. Shi, and W. Han, Experimental investigation of temperature-dependent Gilbert damping in permalloy thin films, Sci. Rep. 6, 22890 (2016).
  58. P. Nieves, D. Serantes, U. Atxitia, and O. Chubykalo-Fesenko, Quantum Landau-Lifshitz-Bloch equation and its comparison with the classical case, Phys. Rev. B 90, 104428 (2014).
  59. M. Cinchetti, M. Sánchez Albaneda, D. Hoffmann, T. Roth, J.-P. Wüstenberg, M. Krauß, O. Andreyev, H. C. Schneider, M. Bauer, and M. Aeschlimann, Spin-flip processes and ultrafast magnetization dynamics in Co: Unifying the microscopic and macroscopic view of femtosecond magnetism, Phys. Rev. Lett. 97, 177201 (2006).
  60. U. Atxitia, O. Chubykalo-Fesenko, J. Walowski, A. Mann, and M. Münzenberg, Evidence for thermal mechanisms in laser-induced femtosecond spin dynamics, Phys. Rev. B 81, 174401 (2010).
  61. K. C. Kuiper, T. Roth, A. J. Schellekens, O. Schmitt, B. Koopmans, M. Cinchetti, and M. Aeschlimann, Spin-orbit enhanced demagnetization rate in Co/Pt-multilayers, Appl. Phys. Lett. 105, 202402 (2014).
  62. B. Y. Mueller, T. Roth, M. Cinchetti, M. Aeschlimann, and B. Rethfeld, Driving force of ultrafast magnetization dynamics, New J. Phys. 13, 123010 (2011).
  63. M. O. A. Ellis, T. A. Ostler, and R. W. Chantrell, Classical spin model of the relaxation dynamics of rare-earth doped permalloy, Phys. Rev. B 86, 174418 (2012).
  64. P. B. Johnson and R. W. Christy, Optical constants of transition metals: Ti, V, Cr, Mn, Fe, Co, Ni, and Pd, Phys. Rev. B 9, 5056 (1974).
  65. K. K. Tikuišis, L. Beran, P. Cejpek, K. Uhlířová, J. Hamrle, M. Vaňatka, M. Urbánek, and M. Veis, Optical and magneto-optical properties of permalloy thin films in 0.7–6.4 eV photon energy range, Mater. Des. 114, 31 (2017).

Outline

Information

Phys. Rev. B 112, 144407– Published 2 October, 2025
  • Received 28 April 2025
  • Revised 11 August 2025
  • Accepted 5 September 2025
