Spin-wave resonance in yttrium iron garnet stripe domains

Daniel Prestwood1,2,3,*, Christopher E. A. Barker4, Kilian D. Stenning3, Charlie W. F. Freeman1,2,4, Tianyi Wei1,2, Takashi Kikkawa5,6, Troy Dion7,8,9, Daniel Stoeffler10, Yves Henry10 et al.

Matthieu Bailleul10, Noora Naushad11, William Griggs11, Thomas Thomson11, Murat Cubukcu1,4, Jack C. Gartside3,12, Eiji Saitoh6,13,14,15, Will R. Branford3,12, and Hidekazu Kurebayashi1,2,8,9,15

  • *Contact author: daniel.prestwood.22@ucl.ac.uk
PDF

Phys. Rev. B 113, 134410 – Published 7 April, 2026

DOI: https://doi.org/10.1103/c721-178b

Abstract

We study a thin-film yttrium iron garnet sample that exhibits magnetic stripe domains due to a small perpendicular magnetic anisotropy. Using wide-field magneto-optic Kerr effect measurements we reveal the domain pattern evolution as a function of applied field and discuss the role of cubic anisotropy in the domain formation. Rich magnon spectra are observed in the stripe domain states, with a range of excitation conditions providing distinct spectra. The measurements are interpreted using micromagnetic simulations to provide the spatial profiles of each resonance mode. We further simulate domain patterns and resonance spectra accounting for the cubic anisotropy, with good correlation to experiment. This study highlights how noncollinear magnetic domain structures can host complex resonant behavior in a low-damping magnetic material, with potential use in future magnonic applications.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (73)

  1. A. V. Chumak, V. I. Vasyuchka, A. A. Serga, and B. Hillebrands, Magnon spintronics, Nat. Phys. 11, 453 (2015).
  2. A. A. Serga, A. V. Chumak, and B. Hillebrands, YIG magnonics, J. Phys. D: Appl. Phys. 43, 264002 (2010).
  3. D. D. Awschalom, C. R. Du, R. He, F. J. Heremans, A. Hoffmann, J. Hou, H. Kurebayashi, Y. Li, L. Liu, V. Novosad, J. Sklenar, S. E. Sullivan, D. Sun, H. Tang, V. Tyberkevych, C. Trevillian, A. W. Tsen, L. R. Weiss, W. Zhang, X. Zhang, et al., Quantum engineering with hybrid magnonic systems and materials (invited paper), IEEE Trans. Quantum Eng. 2, 1 (2021).
  4. B. Flebus, D. Grundler, B. Rana, Y. Otani, I. Barsukov, A. Barman, G. Gubbiotti, P. Landeros, J. Akerman, U. Ebels, P. Pirro, V. E. Demidov, K. Schultheiss, G. Csaba, Q. Wang, F. Ciubotaru, D. E. Nikonov, P. Che, R. Hertel, T. Ono, et al., The 2024 magnonics roadmap, J. Phys.: Condens. Matter 36, 363501 (2024).
  5. Y.-H. Rao, H.-W. Zhang, Q.-H. Yang, D.-N. Zhang, L.-C. Jin, B. Ma, and Y.-J. Wu, Liquid phase epitaxy magnetic garnet films and their applications*, Chin. Phys. B 27, 086701 (2018).
  6. R. W. Damon and H. van de Vaart, Dispersion of spin waves and magnetoelastic waves in YIG, Proc. IEEE 53, 348 (1965).
  7. Y. Zhou, H. Jiao, Y.-t. Chen, G. E. W. Bauer, and J. Xiao, Current-induced spin-wave excitation in Pt/YIG bilayer, Phys. Rev. B 88, 184403 (2013).
  8. B. Bhoi, T. Cliff, I. S. Maksymov, M. Kostylev, R. Aiyar, N. Venkataramani, S. Prasad, and R. L. Stamps, Study of photon–magnon coupling in a YIG-film split-ring resonant system, J. Appl. Phys. 116, 243906 (2014).
  9. L. J. Cornelissen, K. Oyanagi, T. Kikkawa, Z. Qiu, T. Kuschel, G. E. W. Bauer, B. J. van Wees, and E. Saitoh, Nonlocal magnon-polaron transport in yttrium iron garnet, Phys. Rev. B 96, 104441 (2017).
  10. B. Satywali, V. P. Kravchuk, L. Pan, M. Raju, S. He, F. Ma, A. P. Petrović, M. Garst, and C. Panagopoulos, Microwave resonances of magnetic skyrmions in thin film multilayers, Nat. Commun. 12, 1909 (2021).
  11. H. Kurebayashi, O. Dzyapko, V. E. Demidov, D. Fang, A. J. Ferguson, and S. O. Demokritov, Controlled enhancement of spin-current emission by three-magnon splitting, Nat. Mater. 10, 660 (2011).
  12. T. Makiuchi, T. Hioki, H. Shimizu, K. Hoshi, M. Elyasi, K. Yamamoto, N. Yokoi, A. A. Serga, B. Hillebrands, G. E. W. Bauer, and E. Saitoh, Persistent magnetic coherence in magnets, Nat. Mater. 23, 627 (2024).
  13. X. D. Zhu, Magnetic domains and unusual hysteresis loops of yttrium iron garnet crystals revealed by magneto-optic effects, AIP Adv. 11, 085214 (2021).
  14. A. V. Vashkovskii, E. G. Lokk, and V. I. Shcheglov, Influence of induced uniaxial anisotropy on the domain structure and phase transitions of yttrium-iron garnet films, Phys. Solid State 41, 1868 (1999).
  15. R. Wang, Y.-X. Shang, R. Wu, J.-B. Yang, and Y. Ji, Evolution of magnetic domain structure in a YIG thin film, Chin. Physics Lett. 33, 047502 (2016).
  16. M. Gidding, C. S. Davies, and A. Kirilyuk, Reorientation of magnetic stripe domains by mid-infrared pulses, Phys. Rev. B 109, L060408 (2024).
  17. K. Schultheiss, R. Verba, F. Wehrmann, K. Wagner, L. Körber, T. Hula, T. Hache, A. Kákay, A. A. Awad, V. Tiberkevich, A. N. Slavin, J. Fassbender, and H. Schultheiss, Excitation of whispering gallery magnons in a magnetic vortex, Phys. Rev. Lett. 122, 097202 (2019).
  18. K. Vogt, O. Sukhostavets, H. Schultheiss, B. Obry, P. Pirro, A. A. Serga, T. Sebastian, J. Gonzalez, K. Y. Guslienko, and B. Hillebrands, Optical detection of vortex spin-wave eigenmodes in microstructured ferromagnetic disks, Phys. Rev. B 84, 174401 (2011).
  19. J. C. Gartside, K. D. Stenning, A. Vanstone, H. H. Holder, D. M. Arroo, T. Dion, F. Caravelli, H. Kurebayashi, and W. R. Branford, Reconfigurable training and reservoir computing in an artificial spin-vortex ice via spin-wave fingerprinting, Nat. Nanotechnol. 17, 460 (2022).
  20. O. Lee, J. Sahliger, A. Aqeel, S. Khan, S. Seki, H. Kurebayashi, and C. H. Back, Tunable gigahertz dynamics of low-temperature skyrmion lattice in a chiral magnet, J. Phys.: Condens. Matter 34, 095801 (2022).
  21. T. E. Hasty, Ferromagnetic resonance in multidomain thin films, J. Appl. Phys. 35, 1434 (1964).
  22. R. Nakane, A. Hirose, and G. Tanaka, Spin waves propagating through a stripe magnetic domain structure and their applications to reservoir computing, Phys. Rev. Res. 3, 033243 (2021).
  23. O. Lee, T. Wei, K. D. Stenning, J. C. Gartside, D. Prestwood, S. Seki, A. Aqeel, K. Karube, N. Kanazawa, Y. Taguchi, C. Back, Y. Tokura, W. R. Branford, and H. Kurebayashi, Task-adaptive physical reservoir computing, Nat. Mater. 23, 79 (2024).
  24. A. Papp, W. Porod, and G. Csaba, Nanoscale neural network using non-linear spin-wave interference, Nat. Commun. 12, 6422 (2021).
  25. R. Nakane, G. Tanaka, and A. Hirose, Reservoir computing with spin waves excited in a garnet film, IEEE Access 6, 4462 (2018).
  26. B. Heinz, T. Brächer, M. Schneider, Q. Wang, B. Lägel, A. M. Friedel, D. Breitbach, S. Steinert, T. Meyer, M. Kewenig, C. Dubs, P. Pirro, and A. V. Chumak, Propagation of spin-wave packets in individual nanosized yttrium iron garnet magnonic conduits, Nano Lett. 20, 4220 (2020).
  27. A. D. Giacco, F. Maspero, V. Levati, M. Vitali, E. Albisetti, D. Petti, L. Brambilla, V. Polewczyk, G. Vinai, G. Panaccione, R. Silvani, M. Madami, S. Tacchi, R. Dreyer, S. R. Lake, G. Woltersdorf, G. Schmidt, and R. Bertacco, Patterning magnonic structures via laser induced crystallization of yittrium iron garnet, Adv. Funct. Mater. 34, 2401129 (2024).
  28. M. Kiechle, A. Papp, S. Mendisch, V. Ahrens, M. Golibrzuch, G. H. Bernstein, W. Porod, G. Csaba, and M. Becherer, Spin-wave optics in YIG realized by ion-beam irradiation, Small 19, 2207293 (2023).
  29. D. Petti, S. Tacchi, and E. Albisetti, Review on magnonics with engineered spin textures, J. Phys. D: Appl. Phys. 55, 293003 (2022).
  30. K. Szulc, S. Tacchi, A. Hierro-Rodríguez, J. Díaz, P. Gruszecki, P. Graczyk, C. Quirós, D. Markó, J. I. Martín, M. Vélez, D. S. Schmool, G. Carlotti, M. Krawczyk, and L. M. Prado, Reconfigurable magnonic crystals based on imprinted magnetization textures in hard and soft dipolar-coupled bilayers, ACS Nano 16, 14168 (2022).
  31. K. Wagner, A. Kákay, K. Schultheiss, A. Henschke, T. Sebastian, and H. Schultheiss, Magnetic domain walls as reconfigurable spin-wave nanochannels, Nat. Nanotechnol. 11, 432 (2016).
  32. F. Garcia-Sanchez, P. Borys, R. Soucaille, J.-P. Adam, R. L. Stamps, and J.-V. Kim, Narrow magnonic waveguides based on domain walls, Phys. Rev. Lett. 114, 247206 (2015).
  33. Y. Henry, D. Stoeffler, J.-V. Kim, and M. Bailleul, Unidirectional spin-wave channeling along magnetic domain walls of Bloch type, Phys. Rev. B 100, 024416 (2019).
  34. R. B. Holländer, C. Müller, J. Schmalz, M. Gerken, and J. McCord, Magnetic domain walls as broadband spin wave and elastic wave emitters, Sci. Rep. 8, 13871 (2018).
  35. X. S. Wang and X. R. Wang, Spin wave emission in field-driven domain wall motion, Phys. Rev. B 90, 184415 (2014).
  36. B. Van de Wiele, S. J. Hämäläinen, P. Baláž, F. Montoncello, and S. van Dijken, Tunable short-wavelength spin wave excitation from pinned magnetic domain walls, Sci. Rep. 6, 21330 (2016).
  37. R. Salikhov, F. Samad, S. S. P. K. Arekapudi, R. Ehrler, J. Lindner, N. S. Kiselev, and O. Hellwig, Control and tunability of magnetic bubble states in multilayers with strong perpendicular magnetic anisotropy at ambient conditions, Phys. Rev. B 106, 054404 (2022).
  38. A. Hubert and R. Schäfer, Domain theory, in Magnetic Domains: The Analysis of Magnetic Microstructures, edited by A. Hubert and R. Schäfer (Springer, Berlin, Heidelberg, 1998), pp. 99–335.
  39. S. Fin, R. Tomasello, D. Bisero, M. Marangolo, M. Sacchi, H. Popescu, M. Eddrief, C. Hepburn, G. Finocchio, M. Carpentieri, A. Rettori, M. G. Pini, and S. Tacchi, In-plane rotation of magnetic stripe domains in Fe1−xGax thin films, Phys. Rev. B 92, 224411 (2015).
  40. W. T. Soh, N. N. Phuoc, C. Y. Tan, and C. K. Ong, Magnetization dynamics in permalloy films with stripe domains, J. Appl. Phys. 114, 053908 (2013).
  41. I. S. Camara, S. Tacchi, L.-C. Garnier, M. Eddrief, F. Fortuna, G. Carlotti, and M. Marangolo, Magnetization dynamics of weak stripe domains in Fe–N thin films: a multi-technique complementary approach, J. Phys.: Condens. Matter 29, 465803 (2017).
  42. K. A. Oukaci, D. Stoeffler, M. Hehn, M. Grassi, B. Sarpi, M. Bailleul, Y. Henry, S. Petit, F. Montaigne, R. Belkhou, and D. Lacour, Oscillatory buckling reversal of a weak stripe magnetic texture, Mater. Res. Lett. 11, 789 (2023).
  43. N. Vukadinovic and J. B. Youssef, Nonlinear domain-mode ferromagnetic resonances in garnet films with perpendicular anisotropy, Phys. Rev. B 100, 224423 (2019).
  44. B. Lührmann, H. Dötsch, and S. Sure, High-frequency excitations of stripe-domain lattices in magnetic garnet films, Appl. Phys. A 57, 553 (1993).
  45. M. Ramesh and P. E. Wigen, Ferromagnetodynamics of parallel stripe domains - domain walls system, J. Magn. Magn. Mater. 74, 123 (1988).
  46. U. Ebels, L. Buda, K. Ounadjela, and P. E. Wigen, Ferromagnetic resonance excitation of two-dimensional wall structures in magnetic stripe domains, Phys. Rev. B 63, 174437 (2001).
  47. N. Vukadinovic, M. Labrune, J. B. Youssef, A. Marty, J. C. Toussaint, and H. L. Gall, Ferromagnetic resonance spectra in a weak stripe domain structure, Phys. Rev. B 65, 054403 (2001).
  48. J. Wei, Z. Zhu, H. Feng, J. Du, Q. Liu, and J. Wang, Top-down control of dynamic anisotropy in permalloy thin films with stripe domains, J. Phys. D: Appl. Phys. 48, 465001 (2015).
  49. C. Banerjee, P. Gruszecki, J. W. Klos, O. Hellwig, M. Krawczyk, and A. Barman, Magnonic band structure in a Co/Pd stripe domain system investigated by Brillouin light scattering and micromagnetic simulations, Phys. Rev. B 96, 024421 (2017).
  50. M. Grassi, M. Geilen, K. A. Oukaci, Y. Henry, D. Lacour, D. Stoeffler, M. Hehn, P. Pirro, and M. Bailleul, Higgs and Goldstone spin-wave modes in striped magnetic texture, Phys. Rev. B 105, 094444 (2022).
  51. A. V. Vashkovskii, É. G. Lokk, and V. I. Shcheglov, Propagation of zero-exchange spin waves in ferrite films with domain structure, J. Exp. Theor. Phys. Lett. 63, 572 (1996).
  52. A. V. Vashkovskii, E. G. Lokk, and V. I. Shcheglov, Propagation of magnetostatic waves in unsaturated ferrite films with a strip domain structure, J. Exp. Theor. Phys. 84, 560 (1997).
  53. A. V. Vashkovskii, É. G. Lokk, and V. I. Shcheglov, Hysteresis of the characteristics of magnetostatic waves in ferrite films with stripe domains whose magnetization vectors are oriented close to the plane of the film, J. Exp. Theor. Phys. 87, 776 (1998).
  54. T. Kikkawa, K. Oyanagi, T. Hioki, M. Ishida, Z. Qiu, R. Ramos, Y. Hashimoto, and E. Saitoh, Composition-tunable magnon-polaron anomalies in spin Seebeck effects in epitaxial BixY3−xFe5O12 films, Phys. Rev. Mater. 6, 104402 (2022).
  55. O. Lee, K. Yamamoto, M. Umeda, C. W. Zollitsch, M. Elyasi, T. Kikkawa, E. Saitoh, G. E. W. Bauer, and H. Kurebayashi, Nonlinear magnon polaritons, Phys. Rev. Lett. 130, 046703 (2023).
  56. Ming-Yau Chern and Juin-Sen Liaw, Study of BixY3−xFe5O12 thin films grown by pulsed laser deposition, Jpn. J. Appl. Phys. 36, 1049 (1997).
  57. G. G. Siu, C. M. Lee, and Y. Liu, Magnons and acoustic phonons in Y3−xBixFe5O12, Phys. Rev. B 64, 094421 (2001).
  58. W. T. Stacy and W. Tolksdorf, Growth-induced magnetic anistropy in yttrium iron garnet, AIP Conf. Proc. 5, 185 (1972).
  59. W. Ya-Qi and Z. Xun-Yi, Growth-induced magnetic anisotropy in YIG, Hyperfine Interact. 28, 447 (1986).
  60. E. Duda, B. Desormiere, and G. Volluet, Domain structure in YIG films subjected to magnetic fields and stresses, IEEE Trans. Magn. 10, 634 (1974).
  61. A. Vansteenkiste, J. Leliaert, M. Dvornik, M. Helsen, F. Garcia-Sanchez, and B. Van Waeyenberge, The design and verification of MuMax3, AIP Adv. 4, 107133 (2014).
  62. C. Kittel, Theory of the structure of ferromagnetic domains in films and small particles, Phys. Rev. 70, 965 (1946).
  63. J. M. D. Coey, Ferromagnetism and exchange, in Magnetism and Magnetic Materials, (Cambridge University, Cambridge, 2010), pp. 128–194.
  64. H. Wang, C. Du, P. C. Hammel, and F. Yang, Strain-tunable magnetocrystalline anisotropy in epitaxial Y3Fe5O12 thin films, Phys. Rev. B 89, 134404 (2014).
  65. M. J. Gross, W. A. Misba, K. Hayashi, D. Bhattacharya, D. B. Gopman, J. Atulasimha, and C. A. Ross, Voltage modulated magnetic anisotropy of rare earth iron garnet thin films on a piezoelectric substrate, Appl. Phys. Lett. 121, 252401 (2022).
  66. L. Chen, Y. Sun, S. Mankovsky, T. N. G. Meier, M. Kronseder, C. Sun, A. Orekhov, H. Ebert, D. Weiss, and C. H. Back, Signatures of magnetism control by flow of angular momentum, Nature (London) 633, 548 (2024).
  67. H. Yu, J. Xiao, and H. Schultheiss, Magnetic texture based magnonics, Phys. Rep. 905, 1 (2021).
  68. Y. Zhang, L. Qiu, J. Chen, S. Wu, H. Wang, I. A. Malik, M. Cai, M. Wu, P. Gao, C. Hua, W. Yu, J. Xiao, Y. Jiang, H. Yu, K. Shen, and J. Zhang, Switchable long-distance propagation of chiral magnonic edge states, Nat. Mater. 24, 69 (2025).
  69. S. Lee, S. Grudichak, J. Sklenar, C. C. Tsai, M. Jang, Q. Yang, H. Zhang, and J. B. Ketterson, Ferromagnetic resonance of a YIG film in the low frequency regime, J. Appl. Phys. 120, 033905 (2016).
  70. P. Hansen, Anisotropy and magnetostriction of gallium-substituted yttrium iron garnet, J. Appl. Phys. 45, 3638 (1974).
  71. S. Klingler, A. V. Chumak, T. Mewes, B. Khodadadi, C. Mewes, C. Dubs, O. Surzhenko, B. Hillebrands, and A. Conca, Measurements of the exchange stiffness of YIG films using broadband ferromagnetic resonance techniques, J. Phys. D: Appl. Phys. 48, 015001 (2015).
  72. J. C. Slonczewski, A. P. Malozemoff, and E. A. Giess, Temperature dependence of exchange stiffness in garnet bubble films, Appl. Phys. Lett. 24, 396 (1974).
  73. K. Matsumoto, T. Brächer, P. Pirro, T. Fischer, D. Bozhko, M. Geilen, F. Heussner, T. Meyer, B. Hillebrands, and T. Satoh, Optical determination of the exchange stiffness constant in an iron garnet, Jpn. J. Appl. Phys. 57, 070308 (2018).

Outline

Information

Phys. Rev. B 113, 134410– Published 7 April, 2026
  • Received 4 July 2025
  • Revised 18 November 2025
  • Accepted 4 February 2026
Crossmark - Check for updates button
Creative Commons Logo

Published by the American Physical Society under the terms of the Creative Commons Attribution 4.0 International license. Further distribution of this work must maintain attribution to the author(s) and the published article's title, journal citation, and DOI.
