Generalized Hall conductivities in local commuting projector models: Generalized symmetries and protected surface modes

Po-Shen Hsin1 and Ryohei Kobayashi2

PDF

Phys. Rev. B 113, 075106 – Published 3 February, 2026

DOI: https://doi.org/10.1103/94bv-37h1

Abstract

Hall conductivities are important characterizations of phases of matter. It is known that nonzero Hall conductivities are difficult to realize in local commuting projector lattice models due to no-go theorems in (2+1)D. In this work we construct local commuting projector models in (2+1)D and (3+1)D with nonzero generalized Hall conductivities for ordinary and higher-form continuous symmetries on tensor product Hilbert space of finite local dimension. The model is given by a standard ZN toric code, but the symmetries do not admit expression in terms of on-site charge operators. The symmetry do not have local charges or currents on the lattice in the absence of boundaries, but there is still a notion of Hall conductivities that coincide with the continuum field theories. We construct protected gapless boundaries of the lattice models using modified Villain formalism. The generalized Hall conductivities are computed by surface currents as well as bulk flux insertion and many-body Chern number.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (61)

  1. H. Park, J. Cai, E. Anderson, Y. Zhang, J. Zhu, X. Liu, C. Wang, W. Holtzmann, C. Hu, Z. Liu, T. Taniguchi, K. Watanabe, J.-H. Chu, T. Cao, L. Fu, W. Yao, C.-Z. Chang, D. Cobden, D. Xiao, and X. Xu, Observation of fractionally quantized anomalous Hall effect, Nature (London) 622, 74 (2023).
  2. Z. Lu, T. Han, Y. Yao, A. P. Reddy, J. Yang, J. Seo, K. Watanabe, T. Taniguchi, L. Fu, and L. Ju, Fractional quantum anomalous Hall effect in multilayer graphene, Nature (London) 626, 759 (2024).
  3. A. Kapustin and L. Fidkowski, Local commuting projector Hamiltonians and the quantum Hall effect, Commun. Math. Phys. 373, 763 (2020).
  4. C. Zhang, M. Levin, and S. Bachmann, Vanishing Hall conductance for commuting Hamiltonians, Phys. Rev. B 105, L081103 (2022).
  5. A. Kitaev, Anyons in an exactly solved model and beyond, Ann. Phys. 321, 2 (2006).
  6. A. Kapustin and L. Spodyneiko, Thermal Hall conductance and a relative topological invariant of gapped two-dimensional systems, Phys. Rev. B 101, 045137 (2020).
  7. M. A. Levin and X.-G. Wen, String-net condensation: A physical mechanism for topological phases, Phys. Rev. B 71, 045110 (2005).
  8. K. Walker and Z. Wang, (3+1)-TQFTs and topological insulators, Front. Phys. 7, 150 (2012).
  9. X. Chen, Z.-C. Gu, Z.-X. Liu, and X.-G. Wen, Symmetry protected topological orders and the group cohomology of their symmetry group, Phys. Rev. B 87, 155114 (2013).
  10. J. Haah, Local stabilizer codes in three dimensions without string logical operators, Phys. Rev. A 83, 042330 (2011).
  11. M. DeMarco and X.-G. Wen, A commuting projector model with a non-zero quantized Hall conductance, arXiv:2102.13057.
  12. S. Sengoku, H. C. Po, and H. Watanabe, Quasilocal frustration-free free fermions, Phys. Rev. B 112, 115104 (2025).
  13. Z. Han and J.-Y. Chen, Solvable lattice Hamiltonians with fractional Hall conductivity, Phys. Rev. B 105, 155130 (2022).
  14. P.-S. Hsin and Z. Wang, On topology of the moduli space of gapped Hamiltonians for topological phases, J. Math. Phys. 64, 041901 (2023).
  15. R. Kobayashi and M. Barkeshli, (3+1)-dimensional path integral state sums on curved U(1) bundles and U(1) anomalies of (2+1)-dimensional topological phases, Phys. Rev. B 110, 155140 (2024).
  16. Q.-R. Wang and M. Cheng, Exactly solvable models for U(1) symmetry-enriched topological phases, Phys. Rev. B 106, 115104 (2022).
  17. A. Y. Kitaev, Fault-tolerant quantum computation by anyons, Ann. Phys. 303, 2 (2003).
  18. B. Blok and X. G. Wen, Effective theories of the fractional quantum Hall effect at generic filling fractions, Phys. Rev. B 42, 8133 (1990).
  19. D. Gaiotto, A. Kapustin, N. Seiberg, and B. Willett, Generalized global symmetries, J. High Energy Phys. 02 (2015) 172.
  20. M. Barkeshli, P. Bonderson, M. Cheng, and Z. Wang, Symmetry fractionalization, defects, and gauging of topological phases, Phys. Rev. B 100, 115147 (2019).
  21. J. C. Teo, T. L. Hughes, and E. Fradkin, Theory of twist liquids: Gauging an anyonic symmetry, Ann. Phys. 360, 349 (2015).
  22. N. Tarantino, N. H. Lindner, and L. Fidkowski, Symmetry fractionalization and twist defects, New J. Phys. 18, 035006 (2016).
  23. F. Benini, C. Córdova, and P.-S. Hsin, On 2-group global symmetries and their anomalies, J. High Energy Phys. 03 (2019) 118.
  24. A. Das, A. Florio, N. Iqbal, and N. Poovuttikul, Higher-form symmetry and chiral transport in real-time Abelian lattice gauge theory, SciPost Phys. 17, 085 (2024).
  25. A. Polyakov, Quark confinement and topology of gauge theories, Nucl. Phys. B 120, 429 (1977).
  26. J. Villain, Theory of one-dimensional and two-dimensional magnets with an easy magnetization plane. II. The planar, classical, two-dimensional magnet, J. Phys. France 36, 581 (1975).
  27. J. V. José, L. P. Kadanoff, S. Kirkpatrick, and D. R. Nelson, Renormalization, vortices, and symmetry-breaking perturbations in the two-dimensional planar model, Phys. Rev. B 16, 1217 (1977).
  28. D. J. Gross and I. R. Klebanov, One-dimensional string theory on a circle, Nucl. Phys. B 344, 475 (1990).
  29. T. Sulejmanpasic and C. Gattringer, Abelian gauge theories on the lattice: θ-Terms and compact gauge theory with(out) monopoles, Nucl. Phys. B 943, 114616 (2019).
  30. P. Gorantla, H. T. Lam, N. Seiberg, and S.-H. Shao, A modified Villain formulation of fractons and other exotic theories, J. Math. Phys. 62, 102301 (2021).
  31. M. Cheng and N. Seiberg, Lieb-Schultz-Mattis, Luttinger, and 't Hooft–anomaly matching in lattice systems, SciPost Phys. 15, 051 (2023).
  32. S. Seifnashri and W. Shirley, Disentangling anomaly-free symmetries of quantum spin chains, arXiv:2503.09717.
  33. A. Kapustin, Higher symmetries and anomalies in quantum lattice systems, arXiv:2505.04719.
  34. Q. Niu and D. J. Thouless, Quantised adiabatic charge transport in the presence of substrate disorder and many-body interaction, J. Phys. A: Math. Gen. 17, 2453 (1984).
  35. Q. Niu, D. J. Thouless, and Y.-S. Wu, Quantized Hall conductance as a topological invariant, Phys. Rev. B 31, 3372 (1985).
  36. J. E. Avron and R. Seiler, Quantization of the Hall conductance for general, multiparticle Schrödinger Hamiltonians, Phys. Rev. Lett. 54, 259 (1985).
  37. M. B. Hastings and S. Michalakis, Quantization of Hall conductance for interacting electrons on a torus, Commun. Math. Phys. 334, 433 (2015).
  38. S. Bachmann, A. Bols, W. De Roeck, and M. Fraas, Quantization of conductance in gapped interacting systems, Ann. Henri Poincaré 19, 695 (2018).
  39. G. T. Horowitz, Exactly soluble diffeomorphism invariant theories, Commun. Math. Phys. 125, 417 (1989).
  40. A. Kapustin and N. Seiberg, Coupling a QFT to a TQFT and duality, J. High Energy Phys. 04 (2014) 001.
  41. P.-S. Hsin and A. Turzillo, Symmetry-enriched quantum spin liquids in (3+1)d, J. High Energy Phys. 09 (2020) 022.
  42. X. Chen, A. Dua, P.-S. Hsin, C.-M. Jian, W. Shirley, and C. Xu, Loops in 4+1d topological phases, SciPost Phys. 15, 001 (2023).
  43. M. Oshikawa, Commensurability, excitation gap, and topology in quantum many-particle systems on a periodic lattice, Phys. Rev. Lett. 84, 1535 (2000).
  44. A. Kapustin and N. Sopenko, Hall conductance and the statistics of flux insertions in gapped interacting lattice systems, J. Math. Phys. 61, 101901 (2020).
  45. A. Kitaev and L. Kong, Models for gapped boundaries and domain walls, Commun. Math. Phys. 313, 351 (2012).
  46. M. Barkeshli, Y.-A. Chen, S.-J. Huang, R. Kobayashi, N. Tantivasadakarn, and G. Zhu, Codimension-2 defects and higher symmetries in (3+1)D topological phases, SciPost Phys. 14, 065 (2023).
  47. R. Kobayashi and G. Zhu, Cross-cap defects and fault-tolerant logical gates in the surface code and the honeycomb Floquet code, PRX Quantum 5, 020360 (2024).
  48. W. Shirley, C. Zhang, W. Ji, and M. Levin, Anomaly-free symmetries with obstructions to gauging and onsiteability, arXiv:2507.21267.
  49. R. Kobayashi and M. Barkeshli, Soft symmetries of topological orders, arXiv:2501.03314.
  50. M. Barkeshli, Y.-A. Chen, P.-S. Hsin, and R. Kobayashi, Higher-group symmetry in finite gauge theory and stabilizer codes, SciPost Phys. 16, 089 (2024).
  51. M. Barkeshli, P.-S. Hsin, and R. Kobayashi, Higher-group symmetry of (3+1)D fermionic Z2 gauge theory: Logical CCZ, CS, and T gates from higher symmetry, SciPost Phys. 16, 122 (2024).
  52. R. Thorngren, T. Rakovszky, R. Verresen, and A. Vishwanath, Higgs condensates are symmetry-protected topological phases: II U(1) gauge theory and superconductors, arXiv:2303.08136.
  53. M. DeMarco and X.-G. Wen, Compact Uk(1) Chern-Simons theory as a local bosonic lattice model with exact discrete 1-symmetries, Phys. Rev. Lett. 126, 021603 (2021).
  54. T. Jacobson and T. Sulejmanpasic, Canonical quantization of lattice Chern-Simons theory, J. High Energy Phys. 11 (2024) 087.
  55. D. V. Else and C. Nayak, Classifying symmetry-protected topological phases through the anomalous action of the symmetry on the edge, Phys. Rev. B 90, 235137 (2014).
  56. D. Gross, V. Nesme, H. Vogts, and R. F. Werner, Index theory of one dimensional quantum walks and cellular automata, Commun. Math. Phys. 310, 419 (2012).
  57. K. Kawagoe and M. Levin, Microscopic definitions of anyon data, Phys. Rev. B 101, 115113 (2020).
  58. R. Kobayashi, Y. Li, H. Xue, P.-S. Hsin, and Y.-A. Chen, Generalized statistics on lattices, Phys. Rev. X 16, 011010 (2026).
  59. P.-S. Hsin, R. Kobayashi, and A. Prem, Higher-form anomalies imply intrinsic long-range entanglement, arXiv:2504.10569.
  60. P.-S. Hsin, R. Kobayashi, and C. Zhang, Fractionalization of coset non-invertible symmetry and exotic Hall conductance, SciPost Phys. 17, 095 (2024).
  61. P.-S. Hsin, R. Kobayashi, and C. Zhang, Anomalies of coset non-invertible symmetries, SciPost Phys. 20, 006 (2026).
