NMR evidence of pairing fluctuations above Tc and absence of spin magnetism in the time-reversal symmetry-breaking state of Ba1−xKxFe2As2

Florian Bärtl1,2,*, Nadia Stegani3,4, Federico Caglieris4, Ilya Shipulin2, Yongwei Li5, Ruidan Zhong5, Quanxin Hu5, Yu Zheng5, Chi-Ming Yim5 et al.

Sven Luther1, Jochen Wosnitza1,2, Rajib Sarkar2, Hans-Henning Klauss2, Julien Garaud6, Albert Samoilenka7,8, Anton Talkachov7, Egor Babaev7,9,†, Hannes Kühne1, and Vadim Grinenko5,‡

  • *Contact author: f.baertl@hzdr.de
  • †Contact author: babaev@kth.se
  • ‡Contact author: vadim.grinenko@sjtu.edu.cn
PDF

Phys. Rev. B 114, 134504 – Published 4 September, 2026

DOI: https://doi.org/10.1103/928z-jgcx

Abstract

Zero-field muon-spin-rotation (μSR) experiments and the observation of a spontaneous Nernst effect indicate broken time-reversal symmetry (BTRS) at TcZ2, slightly above the superconducting transition temperature Tc in Ba1−xKxFe2As2, with x∼0.8. This was interpreted as evidence of a distinct state of matter where BTRS above Tc arises from noncondensed Cooper pairs, which maintain long-range interband correlations. However, an inhomogeneous superconducting state competing with magnetism as the origin of the observed behavior cannot be completely ruled out to date. Here, we present detailed As75 nuclear magnetic resonance (NMR) measurements of Ba1−xKxFe2As2, with x=0.766, yielding TcZ2>Tc. The NMR data demonstrate that the superconductivity is homogeneous throughout the entire sample volume despite the occurrence of nanoclustering of Ba/K atoms. We observe a suppression of the spin-lattice relaxation rate 1/T1T below the characteristic temperature T*, well above Tc. The specific heat yields somewhat lower values of T*, consistent with the microscopic theory of electron quadrupling. The observed monotonous suppression of T* and TcZ2 in applied magnetic field, the overall temperature dependence of 1/T1T, the NMR spectral characteristics, and the μSR Knight shift rule out spin magnetism and the proximity to a magnetic instability. We conclude that our data indicate the appearance of pairing fluctuations below T* and that the breaking of time-reversal symmetry represents an unconventional state which is unrelated to spin magnetism.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (36)

  1. V. Grinenko, P. Materne, R. Sarkar, H. Luetkens, K. Kihou, C. H. Lee, S. Akhmadaliev, D. V. Efremov, S.-L. Drechsler, and H.-H. Klauss, Superconductivity with broken time-reversal symmetry in ion-irradiated Ba0.27K0.73Fe2A2 single crystals, Phys. Rev. B 95, 214511 (2017).
  2. V. Grinenko, R. Sarkar, K. Kihou, C. H. Lee, I. Morozov, S. Aswartham, B. Büchner, P. Chekhonin, W. Skrotzki, K. Nenkov, R. Hühne, K. Nielsch, S. L. Drechsler, V. L. Vadimov, M. A. Silaev, P. Volkov, I. Eremin, H. Luetkens, and H. H. Klauss, Superconductivity with broken time-reversal symmetry inside a superconducting s-wave state, Nat. Phys. 16, 789 (2020).
  3. Y. Iguchi, R. Shi, K. Kihou, C. Lee, M. Barkman, A. Benfenati, V. Grinenko, E. Babaev, and K. Moler, Superconducting vortices carrying a temperature-dependent fraction of the flux quantum, Science 380, 1244 (2023).
  4. Q. Z. Zhou, B. R. Chen, B. K. Xiang, I. Timoshuk, J. Garaud, Y. Li, K. Y. Liang, Q. S. He, Z. J. Li, P. H. Zhang, K. Z. Yao, H. X. Yao, E. Babaev, V. Grinenko, and Y. H. Wang, Observation of single-quantum vortex splitting in the Ba1−xKxFe2As2 superconductor, arXiv:2408.05902.
  5. Y. Zheng, Q. Hu, X. Yu, H. Ji, I. Timoshuk, J. Garaud, H. Xu, Y. Li, Y. Gao, X. Lu, V. Grinenko, E. Babaev, N. F. Q. Yuan, R. Wu, B. Lv, C.-M. Yim, and H. Ding, Observation of quantum vortex core fractionalization and skyrmion formation in a superconductor, Science 393, 80 (2026).
  6. V. Grinenko et al., State with spontaneously broken time-reversal symmetry above the superconducting phase transition, Nat. Phys. 17, 1254 (2021).
  7. I. Shipulin, N. Stegani, I. Maccari, K. Kihou, C.-H. Lee, Q. Hu, Y. Zheng, F. Yang, Y. Li, C.-M. Yim, R. Hühne, H.-H. Klauss, M. Putti, F. Caglieris, E. Babaev, and V. Grinenko, Calorimetric evidence for two phase transitions in Ba1−xKxFe2As2 with fermion pairing and quadrupling states, Nat. Commun. 14, 6734 (2023).
  8. C. Halcrow, I. Shipulin, F. Caglieris, Y. Li, J. Wosnitza, H.-H. Klauss, S. Zherlitsyn, V. Grinenko, and E. Babaev, Probing electron quadrupling order through ultrasound, npj Quantum Mater. 10, 107 (2025).
  9. J. Garaud and E. Babaev, Effective model and magnetic properties of the resistive electron quadrupling state, Phys. Rev. Lett. 129, 087602 (2022).
  10. See Supplemental Material at http://link.aps.org/supplemental/10.1103/928z-jgcx for information about sample characterization and additional NMR and μSR data, which includes Refs. [5, 34, 35, 36].
  11. K. Kihou, T. Saito, K. Fujita, S. Ishida, M. Nakajima, K. Horigane, H. Fukazawa, Y. Kohori, S.-I. Uchida, J. Akimitsu, A. Iyo, C.-H. Lee, and H. Eisaki, Single-crystal growth of Ba1−xKxFe2As2 by KAs self-flux method, J. Phys. Soc. Jpn. 85, 034718 (2016).
  12. A. Suter and B. M. Wojek, Musrfit: A free platform-independent framework for μSR data analysis, Phys. Procedia 30, 69 (2012).
  13. H. Fukazawa, K. Hirayama, K. Kondo, T. Yamazaki, Y. Kohori, N. Takeshita, K. Miyazawa, H. Kito, H. Eisaki, and A. Iyo, As75 NMR study of the ternary iron arsenide BaFe2As2, J. Phys. Soc. Jpn. 77, 093706 (2008).
  14. K. Kitagawa, N. Katayama, K. Ohgushi, M. Yoshida, and M. Takigawa, Commensurate itinerant antiferromagnetism in BaFe2As2: As75-NMR studies on a self-flux grown single crystal, J. Phys. Soc. Jpn. 77, 114709 (2008).
  15. M.-H. Julien, H. Mayaffre, M. Horvatić, C. Berthier, X. D. Zhang, W. Wu, G. F. Chen, N. L. Wang, and J. L. Luo, Homogeneous vs. inhomogeneous coexistence of magnetic order and superconductivity probed by NMR in Co- and K-doped iron pnictides, Europhys. Lett. 87, 37001 (2009).
  16. J. Korringa, Nuclear magnetic relaxation and resonance line shift in metals, Physica 16, 601 (1950).
  17. H.-J. Grafe, D. Paar, G. Lang, N. J. Curro, G. Behr, J. Werner, J. Hamann-Borrero, C. Hess, N. Leps, R. Klingeler, and B. Büchner, As75 NMR studies of superconducting LaFeAsO0.9F0.1, Phys. Rev. Lett. 101, 047003 (2008).
  18. Y. Nakai, K. Ishida, Y. Kamihara, M. Hirano, and H. Hosono, Evolution from itinerant antiferromagnet to unconventional superconductor with fluorine doping in LaFeAs(O1−xFx) revealed by As75 and La139 nuclear magnetic resonance, J. Phys. Soc. Jpn. 77, 073701 (2008).
  19. F. Ning, K. Ahilan, T. Imai, A. S. Sefat, R. Jin, M. A. McGuire, B. C. Sales, and D. Mandrus, Co59 and As75 NMR investigation of electron-doped high Tc superconductor BaFe1.8Co0.2As2 (Tc=22K), J. Phys. Soc. Jpn. 77, 103705 (2008).
  20. S. W. Zhang, L. Ma, Y. D. Hou, J. Zhang, T.-L. Xia, G. F. Chen, J. P. Hu, G. M. Luke, and W. Yu, As75 NMR study of single crystals of the heavily overdoped pnictide superconductors Ba1−xKxFe2As2 (x=0.7 and 1), Phys. Rev. B 81, 012503 (2010).
  21. G. Zhang, F. Martelli, and S. Torquato, The structure factor of primes, J. Phys. A 51, 115001 (2018).
  22. P. Carretta and G. Prando, Iron-based superconductors: Tales from the nuclei, Riv. Nuovo Cimento 43, 1 (2020).
  23. H. Matsuki, R. Khasanov, J. A. Krieger, T. J. Hicken, K. Yuchi, J. S. Bobowski, G. Mattoni, A. Ikeda, R. Okuma, H. Luetkens, and Y. Maeno, Muon Knight shift as a precise probe of the superconducting symmetry of Sr2RuO4, Phys. Rev. Lett. 136, 066001 (2026).
  24. V. Grinenko, R. Sarkar, P. Materne, S. Kamusella, A. Yamamshita, Y. Takano, Y. Sun, T. Tamegai, D. V. Efremov, S.-L. Drechsler, J.-C. Orain, T. Goko, R. Scheuermann, H. Luetkens, and H.-H. Klauss, Low-temperature breakdown of antiferromagnetic quantum critical behavior in FeSe, Phys. Rev. B 97, 201102(R) (2018).
  25. D. Parker, O. V. Dolgov, M. M. Korshunov, A. A. Golubov, and I. I. Mazin, Extended s± scenario for the nuclear spin-lattice relaxation rate in superconducting pnictides, Phys. Rev. B 78, 134524 (2008).
  26. A. Samoilenka and E. Babaev, Microscopic theory of electron quadrupling condensates, Phys. Rev. Res. 8, 013139 (2026).
  27. L. Aslamasov and A. Larkin, The influence of fluctuation pairing of electrons on the conductivity of normal metal, Phys. Lett. A 26, 238 (1968).
  28. A. Larkin and A. Varlamov, Theory of Fluctuations in Superconductors, International Series of Monographs on Physics (Oxford University Press, Oxford, 2005), Vol. 127.
  29. M. Hirano, Y. Yamada, T. Saito, R. Nagashima, T. Konishi, T. Toriyama, Y. Ohta, H. Fukazawa, Y. Kohori, Y. Furukawa, K. Kihou, C.-H. Lee, A. Iyo, and H. Eisaki, Potential antiferromagnetic fluctuations in hole-doped iron-pnictide superconductor Ba1−xKxFe2As2 studied by As75 nuclear magnetic resonance measurement, J. Phys. Soc. Jpn. 81, 054704 (2012).
  30. A. Shi, T. Arai, S. Kitagawa, T. Yamanaka, K. Ishida, A. E. Böhmer, C. Meingast, T. Wolf, M. Hirata, and T. Sasaki, Pseudogap behavior of the nuclear spin–lattice relaxation rate in FeSe probed by Se77-NMR, J. Phys. Soc. Jpn. 87, 013704 (2018).
  31. B. L. Kang, M. Z. Shi, D. Zhao, S. J. Li, J. Li, L. X. Zheng, D. W. Song, L. P. Nie, T. Wu, and X. H. Chen, NMR evidence for universal pseudogap behavior in quasi-two-dimensional FeSe-based superconductors, Chin. Phys. Lett. 39, 127401 (2022).
  32. K. Matsuura et al., Two superconducting states with broken time-reversal symmetry in FeSe1−xSx, Proc. Natl. Acad. Sci. USA 120, e2208276120 (2023).
  33. B. D. Faeth, S.-L. Yang, J. K. Kawasaki, J. N. Nelson, P. Mishra, C. T. Parzyck, C. Li, D. G. Schlom, and K. M. Shen, Incoherent Cooper pairing and pseudogap behavior in single-layer FeSe/SrTiO3, Phys. Rev. X 11, 021054 (2021).
  34. K. Ahilan, F. L. Ning, T. Imai, A. S. Sefat, R. Jin, M. A. McGuire, B. C. Sales, and D. Mandrus, F19 NMR investigation of the iron pnictide superconductor LaFeAs0.89F0.11, Phys. Rev. B 78, 100501(R) (2008).
  35. H. Choi, I. Vinograd, C. Chaffey, and N. J. Curro, Inverse Laplace transformation analysis of stretched exponential relaxation, J. Magn. Reson. 331, 107050 (2021).
  36. K. Ishida, Y. Nakai, S. Kitagawa, and T. Iye, NMR studies on iron-pnictide superconductors: LaFeAs(O1−xFx) and BaFe2(As1−xPx)2, C. R. Phys. 12, 515 (2011).
