Localization versus hybridization of f states in actinide and lanthanide dioxides probed in core-level photoemission spectra

Sergei M. Butorin*

  • Condensed Matter Physics of Energy Materials, X-ray Photon Science, Department of Physics and Astronomy, Uppsala University, P.O. Box 516, SE-751 20 Uppsala, Sweden

  • *Contact author: sergei.butorin@physics.uu.se
PDF

Phys. Rev. B 112, 125118 – Published 9 September, 2025

DOI: https://doi.org/10.1103/8x4b-6651

Abstract

The degrees of the localization and hybridization of the valence f states/covalency of the chemical bonding in actinide and lanthanide dioxides were investigated using the atomic, crystal-field multiplet and Anderson impurity model (AIM) approaches to calculate actinide 5d and lanthanide 3d x-ray photoemission spectra (XPS). The actinide 5d XPS can be largely described within atomic, crystal-field multiplet theory due to an extended multiplet structure as a result of the strong interaction of 5f electrons with a 5d core hole. The multiplet structure was found to be quite sensitive to the oxidation state of actinides. In turn, the lanthanide 3d XPS description requires the AIM type of calculations due to significant 4f–O 2p hybridization effects. As a result derived from the analysis of the XPS spectra, an increase in the f-shell occupancy in the ground state due to the f–O 2p hybridization and covalency of the chemical bonding appears to be higher in lanthanide dioxides as compared to actinide dioxides.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (46)

  1. E. S. Ilton and P. S. Bagus, XPS determination of uranium oxidation states, Surf. Interface Anal. 43, 1549 (2011).
  2. R. Caciuffo, G. H. Lander, and G. van der Laan, Synchrotron radiation techniques and their application to actinide materials, Rev. Mod. Phys. 95, 015001 (2023).
  3. S. M. Butorin, S. Bauters, L. Amidani, A. Beck, S. Weiss, T. Vitova, and O. Tougait, X-ray spectroscopic study of chemical state in uranium carbides, J. Synchrotron Radiat. 29, 295 (2022).
  4. S. M. Butorin and D. K. Shuh, Chemical bonding in americium oxides probed by X-ray spectroscopy, Sci. Rep. 13, 11607 (2023).
  5. N. Beatham, A. Orchard, and G. Thornton, On the photoelectron spectra of UO2, J. Electron Spectrosc. Relat. Phenom. 19, 205 (1980).
  6. E. S. Ilton, Y. Du, J. E. Stubbs, P. J. Eng, A. M. Chaka, J. R. Bargar, C. J. Nelin, and P. S. Bagus, Quantifying small changes in uranium oxidation states using XPS of a shallow core level, Phys. Chem. Chem. Phys. 19, 30473 (2017).
  7. B. W. Veal, D. J. Lam, H. Diamond, and H. R. Hoekstra, X-ray photoelectron-spectroscopy study of oxides of the transuranium elements Np, Pu, Am, Cm, Bk, and Cf, Phys. Rev. B 15, 2929 (1977).
  8. G. C. Allen, I. R. Trickle, and P. M. Tucker, Surface characterization of uranium metal and uranium dioxide using x-ray photoelectron spectroscopy, Philos. Mag. B 43, 689 (1981).
  9. Y. A. Teterin, K. I. Maslakov, A. Y. Teterin, K. E. Ivanov, M. V. Ryzhkov, V. G. Petrov, D. A. Enina, and S. N. Kalmykov, Electronic structure and chemical bonding in PuO2, Phys. Rev. B 87, 245108 (2013).
  10. Y. A. Teterin, A. Y. Teterin, K. E. Ivanov, M. V. Ryzhkov, K. I. Maslakov, S. N. Kalmykov, V. G. Petrov, and D. A. Enina, X-ray photoelectron spectra structure and chemical bond nature in NpO2, Phys. Rev. B 89, 035102 (2014).
  11. Y. A. Teterin, K. Maslakov, M. Ryzhkov, A. Teterin, K. Ivanov, S. Kalmykov, and V. Petrov, X-ray photoelectron spectra structure and chemical bonding in AmO2, Nucl. Technol. Radiat. Prot. 30, 83 (2015).
  12. A. E. Putkov, K. I. Maslakov, A. Y. Teterin, Y. A. Teterin, M. V. Ryzhkov, K. E. Ivanov, S. N. Kalmykov, and V. G. Petrov, Structure of the XPS spectra of a ThO2 crystal film, Radiochemistry 64, 133 (2022).
  13. P. W. Anderson, Localized magnetic states in metals, Phys. Rev. 124, 41 (1961).
  14. A. Kotani and H. Ogasawara, Theory of core-level spectroscopy of rare-earth oxides, J. Electron Spectrosc. Relat. Phenom. 60, 257 (1992).
  15. M. Nakazawa, S. Tanaka, T. Uozumi, and A. Kotani, Theory of resonant x-ray emission spectra in Ce compounds, J. Phys. Soc. Jpn. 65, 2303 (1996).
  16. S. M. Butorin, D. C. Mancini, J.-H. Guo, N. Wassdahl, J. Nordgren, M. Nakazawa, S. Tanaka, T. Uozumi, A. Kotani, Y. Ma, K. E. Myano, B. A. Karlin, and D. K. Shuh, Resonant x-ray fluorescence spectroscopy of correlated systems: A probe of charge-transfer excitations, Phys. Rev. Lett. 77, 574 (1996).
  17. J. Kolorenč, Metal-oxygen hybridization and core-level spectra in actinide and rare-earth oxides, MRS Adv. 1, 3007 (2016).
  18. T. Ikeda, K. Okada, H. Ogasawara, and A. Kotani, Theory of 3d core photoemission spectra in rare earth oxides series, J. Phys. Soc. Jpn. 59, 622 (1990).
  19. S. M. Butorin, A. Modin, J. R. Vegelius, K. O. Kvashnina, and D. K. Shuh, Probing chemical bonding in uranium dioxide by means of high-resolution X-ray absorption spectroscopy, J. Phys. Chem. C 120, 29397 (2016).
  20. S. M. Butorin, 3d-4f resonant inelastic X-ray scattering of actinide dioxides: Crystal-field multiplet description, Inorg. Chem. 59, 16251 (2020).
  21. B. G. Wybourne, Spectroscopic Properties of Rare Earths (Wiley, New York, 1965).
  22. H. Ogasawara, A. Kotani, and B. T. Thole, Lifetime effect on the multiplet structure of 4d x-ray-photoemission spectra in heavy rare-earth elements, Phys. Rev. B 50, 12332 (1994).
  23. The TT-MULTIPLETS package is available at https://bitbucket.org/cjtitus/ttmult/src/master/.
  24. R. D. Cowan, The Theory of Atomic Structure and Spectra, Los Alamos Series in Basic and Applied Sciences (University of California Press, Berkeley, 1981).
  25. P. H. Butler, Point Group Symmetry Applications: Methods and Tables. (Springer US, Boston, 1981).
  26. B. Thole, G. van der Laan, and P. Butler, Spin-mixed ground state of Fe phthalocyanine and the temperature-dependent branching ratio in x-ray absorption spectroscopy, Chem. Phys. Lett. 149, 295 (1988).
  27. A. Kotani, H. Ogasawara, K. Okada, B. T. Thole, and G. A. Sawatzky, Theory of multiplet structure in 4d core photoabsorption spectra of CeO2, Phys. Rev. B 40, 65 (1989).
  28. H. Ogasawara, A. Kotani, and B. T. Thole, Calculation of magnetic x-ray dichroism in 4d and 5d absorption spectra of actinides, Phys. Rev. B 44, 2169 (1991).
  29. K. T. Moore and G. van der Laan, Nature of the 5f states in actinide metals, Rev. Mod. Phys. 81, 235 (2009).
  30. S. M. Butorin, Resonant inelastic x-ray scattering as a probe of optical scale excitations in strongly electron-correlated systems: Quasi-localized view, J. Electron Spectrosc. Relat. Phenom. 110-111, 213 (2000).
  31. S. M. Butorin, Resonant inelastic soft x-ray scattering spectroscopy of light-actinide materials, in Actinide Nanoparticle Research, edited by S. N. Kalmykov and M. A. Denecke (Springer, Berlin, 2011), pp. 63–103.
  32. S. M. Butorin, D. K. Shuh, K. O. Kvashnina, J. Guo, L. Werme, and J. Nordgren, Chemical reduction of actinides probed by resonant inelastic X-ray scattering, Anal. Chem. 85, 11196 (2013).
  33. S. M. Butorin and D. K. Shuh, Electronic structure of americium sesquioxide probed by resonant inelastic x-ray scattering, Phys. Rev. B 108, 195152 (2023).
  34. K. O. Kvashnina, S. M. Butorin, D. K. Shuh, J.-H. Guo, L. Werme, and J. Nordgren, Resonant inelastic x-ray scattering of curium oxide, Phys. Rev. B 75, 115107 (2007).
  35. T. Gouder, G. van der Laan, A. B. Shick, R. G. Haire, and R. Caciuffo, Electronic structure of elemental curium studied by photoemission, Phys. Rev. B 83, 125111 (2011).
  36. T. Yamazaki and A. Kotani, Systematic analysis of 4f core photoemission spectra in actinide oxides, J. Phys. Soc. Jpn. 60, 49 (1991).
  37. S. M. Butorin, Advanced x-ray spectroscopy of actinide trichlorides, J. Chem. Phys. 155, 164103 (2021).
  38. H. Ogasawara and A. Kotani, Calculation of rare-earth 4d giant-absorption spectra with multiplet effects and decay processes, J. Synchrotron Rad. 8, 220 (2001).
  39. S. M. Butorin, K. O. Kvashnina, J. R. Vegelius, D. Meyer, and D. K. Shuh, High-resolution x-ray absorption spectroscopy as a probe of crystal-field and covalency effects in actinide compounds, Proc. Natl. Acad. Sci. USA 113, 8093 (2016).
  40. O. Gunnarsson and O. Jepsen, Configuration dependence of hopping matrix elements in the Anderson model, Phys. Rev. B 38, 3568 (1988).
  41. M.-T. Suzuki, N. Magnani, and P. M. Oppeneer, First-principles theory of multipolar order in neptunium dioxide, Phys. Rev. B 82, 241103(R) (2010).
  42. S. M. Butorin, L.-C. Duda, J.-H. Guo, N. Wassdahl, J. Nordgren, M. Nakazawa, and A. Kotani, Resonant valence-to-core x-ray fluorescence spectroscopy on PrO2, J. Phys.: Condens. Matter 9, 8155 (1997).
  43. A. Schaefer, S. Gevers, V. Zielasek, T. Schroeder, J. Falta, J. Wollschläger, and M. Bäumer, Photoemission study of praseodymia in its highest oxidation state: The necessity of in situ plasma treatment, J. Chem. Phys. 134, 054701 (2011).
  44. G. Blanco, J. Pintado, S. Bernal, M. Cauqui, M. Corchado, A. Galtayries, J. Ghijsen, R. Sporken, T. Eickhoff, and W. Drube, Influence of the nature of the noble metal (Rh,Pt) on the low-temperature reducibility of a Ce/Tb mixed oxide with application as TWC component, Surf. Interface Anal. 34, 120 (2002).
  45. Z. Hu, G. Kaindl, H. Ogasawara, A. Kotani, and I. Felner, Ln-4f/ligand-2p covalence in BaLnO3 and Cs3LnF7 (Ln=Ce, Pr, Tb), Chem. Phys. Lett. 325, 241 (2000).
  46. E. F. Bazarkina, S. Bauters, Y. Watier, S. Weiss, S. M. Butorin, and K. O. Kvashnina, Exploring cluster formation in uranium oxidation using high resolution X-ray spectroscopy at elevated temperatures, Commun. Mater. 6, 75 (2025).
