All-optical magnetometric characterization of the exchange-coupled antiferromagnet/ferromagnet system Mn2Au|Ni80Fe20 by terahertz spin-orbit torques

Y. Behovits1, A. L. Chekhov1, B. Rosinus Serrano1, A. Ruge1, S. Reimers2, Y. Lytvynenko2,3, M. Kläui2, M. Jourdan2, and T. Kampfrath1

PDF

Phys. Rev. B 113, 214408 – Published 1 June, 2026

DOI: https://doi.org/10.1103/86ds-j6vv

Abstract

Antiferromagnetic materials have great potential for spintronic applications at terahertz (THz) frequencies. However, in contrast to ferromagnets, experimental investigations of antiferromagnets are often challenging due to a lack of straightforward external control of the Néel vector L and suitable probes. Here, we study an AFM|FM stack consisting of an antiferromagnetic metal layer (AFM) of the novel material Mn2Au and a ferromagnetic metal layer (FM) of Ni80Fe20. To characterize the AFM|FM stack as a function of the quasistatic Bext, we perform quasistatic as well as THz-pump magneto-optic probe experiments. Our results demonstrate that AFM and FM are exchange-coupled, and that L of the AFM can be set by the simple application of an external in-plane magnetic field Bext. We identify ultrafast signal components that can consistently be explained by the in-plane antiferromagnetic magnon mode excited by fieldlike Néel spin-orbit torque (NSOT). Remarkably, we find that the Bext- and THz-pump-induced changes in the optical response of the sample are dominated exclusively by the spin degrees of freedom of AFM. Nonmagnetic signal contributions are minor. We fully calibrate the magnetic circular and magnetic linear optical birefringence of AFM and extract the efficiency of the NSOT. Finally, by selective excitation of domains with different orientations of L, we are able to determine the relative volume fraction of 0∘, 90∘, 180∘ and 270∘ domains during the quasistatic reversal of L by Bext. Our insights are an important prerequisite for future studies of ultrafast coherent switching of spins by THz NSOT and show that THz-pump magneto-optic-probe experiments are a powerful tool to characterize magnetic properties of antiferromagnets.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (55)

  1. T. Jungwirth, X. Marti, P. Wadley, and J. Wunderlich, Antiferromagnetic spintronics, Nat. Nanotechnol. 11, 231 (2016).
  2. S. Schlauderer, C. Lange, S. Baierl, T. Ebnet, C. P. Schmid, D. C. Valovcin, A. K. Zvezdin, A. V. Kimel, R. V. Mikhaylovskiy, and R. Huber, Temporal and spectral fingerprints of ultrafast all-coherent spin switching, Nature (London) 569, 383 (2019).
  3. C. Tzschaschel, T. Satoh, and M. Fiebig, Tracking the ultrafast motion of an antiferromagnetic order parameter, Nat. Commun. 10, 3995 (2019).
  4. A. S. Disa, M. Fechner, T. F. Nova, B. Liu, M. Först, D. Prabhakaran, P. G. Radaelli, and A. Cavalleri, Polarizing an antiferromagnet by optical engineering of the crystal field, Nat. Phys. 16, 937 (2020).
  5. E. A. Mashkovich, K. A. Grishunin, R. M. Dubrovin, A. K. Zvezdin, R. V. Pisarev, and A. V. Kimel, Terahertz light-driven coupling of antiferromagnetic spins to lattice, Science 374, 1608 (2021).
  6. Z. Zhang, M. Kanega, K. Maruyama, T. Kurihara, M. Nakajima, T. Tachizaki, M. Sato, Y. Kanemitsu, and H. Hirori, Spin switching in Sm0.7Er0.3FeO3 triggered by terahertz magnetic-field pulses, Nat. Mater. 24, 219 (2024).
  7. R. A. Leenders, D. Afanasiev, A. V. Kimel, and R. V. Mikhaylovskiy, Canted spin order as a platform for ultrafast conversion of magnons, Nature (London) 630, 335 (2024).
  8. J. Železný, H. Gao, K. Výborný, J. Zemen, J. Mašek, A. Manchon, J. Wunderlich, J. Sinova, and T. Jungwirth, Relativistic Néel-order fields induced by electrical current in antiferromagnets, Phys. Rev. Lett. 113, 157201 (2014).
  9. P. Wadley, B. Howells, J. Železný, C. Andrews, V. Hills, R. P. Campion, V. Novák, K. Olejník, F. Maccherozzi, S. S. Dhesi, et al., Electrical switching of an antiferromagnet, Science 351, 587 (2016).
  10. S. Y. Bodnar, L. Šmejkal, I. Turek, T. Jungwirth, O. Gomonay, J. Sinova, A. A. Sapozhnik, H. J. Elmers, M. Kläui, and M. Jourdan, Writing and reading antiferromagnetic Mn2Au by Néel spin-orbit torques and large anisotropic magnetoresistance, Nat. Commun. 9, 348 (2018).
  11. K. Olejník, T. Seifert, Z. Kašpar, V. Novák, P. Wadley, R. P. Campion, M. Baumgartner, P. Gambardella, P. Němec, J. Wunderlich, et al., Terahertz electrical writing speed in an antiferromagnetic memory, Sci. Adv. 4, eaar3566 (2018).
  12. X. Chen, X. Zhou, R. Cheng, C. Song, J. Zhang, Y. Wu, Y. Ba, H. Li, Y. Sun, Y. You, et al., Electric field control of Néel spin–orbit torque in an antiferromagnet, Nat. Mater. 18, 931 (2019).
  13. S. Reimers, Y. Lytvynenko, Y. R. Niu, E. Golias, B. Sarpi, L. S. I. Veiga, T. Denneulin, A. Kovács, R. E. Dunin-Borkowski, J. Bläßer, et al., Current-driven writing process in antiferromagnetic Mn2Au for memory applications, Nat. Commun. 14, 1861 (2023).
  14. Y. Behovits, A. L. Chekhov, S. Y. Bodnar, O. Gueckstock, S. Reimers, Y. Lytvynenko, Y. Skourski, M. Wolf, T. S. Seifert, O. Gomonay, et al., Terahertz Néel spin-orbit torques drive nonlinear magnon dynamics in antiferromagnetic Mn2Au, Nat. Commun. 14, 6038 (2023).
  15. H. Al-Hamdo, T. Wagner, Y. Lytvynenko, G. Kendzo, S. Reimers, M. Ruhwedel, M. Yaqoob, V. I. Vasyuchka, P. Pirro, J. Sinova, et al., Coupling of ferromagnetic and antiferromagnetic spin dynamics in Mn2Au|NiFe thin film bilayers, Phys. Rev. Lett. 131, 046701 (2023).
  16. S. P. Bommanaboyena, D. Backes, L. S. I. Veiga, S. S. Dhesi, Y. R. Niu, B. Sarpi, T. Denneulin, A. Kovács, T. Mashoff, O. Gomonay, et al., Readout of an antiferromagnetic spintronics system by strong exchange coupling of Mn2Au and Permalloy, Nat. Commun. 12, 6539 (2021).
  17. See Supplemental Material at http://link.aps.org/supplemental/10.1103/86ds-j6vv for electric field characterization, raw data of the waveforms, fitting parameters, alternative fitting method, and balanced detection schematic.
  18. R. Rouzegar, A. L. Chekhov, Y. Behovits, B. R. Serrano, M. A. Syskaki, C. H. Lambert, D. Engel, U. Martens, M. Münzenberg, M. Wolf, et al., Broadband spintronic terahertz source with peak electric fields exceeding 1.5 MV/cm, Phys. Rev. Appl. 19, 034018 (2023).
  19. A. L. Chekhov, Y. Behovits, U. Martens, B. R. Serrano, M. Wolf, T. S. Seifert, M. Münzenberg, and T. Kampfrath, Broadband spintronic detection of the absolute field strength of terahertz electromagnetic pulses, Phys. Rev. Appl. 20, 034037 (2023).
  20. S. F. Maehrlein, I. Radu, P. Maldonado, A. Paarmann, M. Gensch, A. M. Kalashnikova, R. V. Pisarev, M. Wolf, P. M. Oppeneer, J. Barker, et al., Dissecting spin-phonon equilibration in ferrimagnetic insulators by ultrafast lattice excitation, Sci. Adv. 4, eaar5164 (2018).
  21. V. M. T. S. Barthem, C. V. Colin, H. Mayaffre, M. H. Julien, and D. Givord, Revealing the properties of Mn2Au for antiferromagnetic spintronics, Nat. Commun. 4, 2892 (2013).
  22. V. Grigorev, M. Filianina, S. Y. Bodnar, S. Sobolev, N. Bhattacharjee, S. Bommanaboyena, Y. Lytvynenko, Y. Skourski, D. Fuchs, M. Kläui, et al., Optical readout of the Néel vector in the metallic antiferromagnet Mn2Au, Phys. Rev. Appl. 16, 014037 (2021).
  23. X. Fan, A. R. Mellnik, W. Wang, N. Reynolds, T. Wang, H. Celik, V. O. Lorenz, D. C. Ralph, and J. Q. Xiao, All-optical vector measurement of spin-orbit-induced torques using both polar and quadratic magneto-optic Kerr effects, Appl. Phys. Lett. 109, 122406 (2016).
  24. R. Silber, O. Stejskal, L. Beran, P. Cejpek, R. Antoš, T. Matalla-Wagner, J. Thien, O. Kuschel, J. Wollschläger, M. Veis, et al., Quadratic magneto-optic Kerr effect spectroscopy of Fe epitaxial films on MgO(001) substrates, Phys. Rev. B 100, 064403 (2019).
  25. R. Lopusnik, J. P. Nibarger, T. J. Silva, and Z. Celinski, Different dynamic and static magnetic anisotropy in thin Permalloy films, Appl. Phys. Lett. 83, 96 (2003).
  26. J. Hamrle, S. Blomeier, O. Gaier, B. Hillebrands, H. Schneider, G. Jakob, K. Postava, and C. Felser, Huge quadratic magneto-optical Kerr effect and magnetization reversal in the Co2FeSi Heusler compound, J. Phys. D Appl. Phys. 40, 1563 (2007).
  27. C. Vicario, C. Ruchert, F. Ardana-Lamas, P. M. Derlet, B. Tudu, J. Luning, and C. P. Hauri, Off-resonant magnetization dynamics phase-locked to an intense phase-stable terahertz transient, Nat. Photon. 7, 720 (2013).
  28. K. Neeraj, N. Awari, S. Kovalev, D. Polley, N. Zhou Hagström, S. S. P. K. Arekapudi, A. Semisalova, K. Lenz, B. Green, J.-C. Deinert, et al., Inertial spin dynamics in ferromagnets, Nat. Phys. 17, 245 (2021).
  29. T. Kampfrath, A. Sell, G. Klatt, A. Pashkin, S. Mährlein, T. Dekorsy, M. Wolf, M. Fiebig, A. Leitenstorfer, and R. Huber, Coherent terahertz control of antiferromagnetic spin waves, Nat. Photon. 5, 31 (2011).
  30. M. Arana, F. Estrada, D. S. Maior, J. B. S. Mendes, L. E. Fernandez-Outon, W. A. A. Macedo, V. M. T. S. Barthem, D. Givord, A. Azevedo, and S. M. Rezende, Observation of magnons in Mn2Au films by inelastic Brillouin and Raman light scattering, Appl. Phys. Lett. 111, 192409 (2017).
  31. M. Weißenhofer, F. Foggetti, U. Nowak, and P. M. Oppeneer, Néel vector switching and terahertz spin-wave excitation in Mn2Au due to femtosecond spin-transfer torques, Phys. Rev. B 107, 174424 (2023).
  32. I. V. Bar'yakhtar and B. A. Ivanov, Nonlinear waves in antiferromagnets, Solid State Commun. 34, 545 (1980).
  33. B. A. Ivanov, Spin dynamics for antiferromagnets and ultrafast spintronics, J. Exp. Theor. Phys. 131, 95 (2020).
  34. O. Gomonay, V. Baltz, A. Brataas, and Y. Tserkovnyak, Antiferromagnetic spin textures and dynamics, Nat. Phys. 14, 213 (2018).
  35. A. L. Chekhov, Y. Behovits, J. J. F. Heitz, C. Denker, D. A. Reiss, M. Wolf, M. Weinelt, P. W. Brouwer, M. Münzenberg, and T. Kampfrath, Ultrafast demagnetization of iron induced by optical versus terahertz pulses, Phys. Rev. X 11, 041055 (2021).
  36. B. Koopmans, M. van Kampen, J. T. Kohlhepp, and W. J. M. de Jonge, Ultrafast magneto-optics in nickel: Magnetism or optics? Phys. Rev. Lett. 85, 844 (2000).
  37. T. Kampfrath, R. G. Ulbrich, F. Leuenberger, M. Münzenberg, B. Sass, and W. Felsch, Ultrafast magneto-optical response of iron thin films, Phys. Rev. B 65, 104429 (2002).
  38. M. C. Hoffmann, N. C. Brandt, H. Y. Hwang, K.-L. Yeh, and K. A. Nelson, Terahertz Kerr effect, Appl. Phys. Lett. 95, 231105 (2009).
  39. M. Sajadi, M. Wolf, and T. Kampfrath, Terahertz-field-induced optical birefringence in common window and substrate materials, Opt. Express 23, 28985 (2015).
  40. S. Baierl, J. H. Mentink, M. Hohenleutner, L. Braun, T.-M. Do, C. Lange, A. Sell, M. Fiebig, G. Woltersdorf, T. Kampfrath, et al., Terahertz-driven nonlinear spin response of antiferromagnetic nickel oxide, Phys. Rev. Lett. 117, 197201 (2016).
  41. L. Nádvorník, M. Borchert, L. Brandt, R. Schlitz, K. A. De Mare, K. Výborný, I. Mertig, G. Jakob, M. Kläui, S. T. B. Goennenwein, et al., Broadband terahertz probes of anisotropic magnetoresistance disentangle extrinsic and intrinsic contributions, Phys. Rev. X 11, 021030 (2021).
  42. O. Gomonay, T. Jungwirth, and J. Sinova, Narrow-band tunable terahertz detector in antiferromagnets via staggered-field and antidamping torques, Phys. Rev. B 98, 104430 (2018).
  43. T. Kuschel, H. Bardenhagen, H. Wilkens, R. Schubert, J. Hamrle, J. Pištora, and J. Wollschläger, Vectorial magnetometry using magnetooptic Kerr effect including first- and second-order contributions for thin ferromagnetic films, J. Phys. D Appl. Phys. 44, 265003 (2011).
  44. O. Gomonay and D. Bossini, Linear and nonlinear spin dynamics in multi-domain magnetoelastic antiferromagnets, J. Phys. D Appl. Phys. 54, 374004 (2021).
  45. H. Meer, O. Gomonay, C. Schmitt, R. Ramos, L. Schnitzspan, F. Kronast, M.-A. Mawass, S. Valencia, E. Saitoh, J. Sinova, et al., Strain-induced shape anisotropy in antiferromagnetic structures, Phys. Rev. B 106, 094430 (2022).
  46. L. Šmejkal, J. Sinova, and T. Jungwirth, Emerging research landscape of altermagnetism, Phys. Rev. X 12, 040501 (2022).
  47. S. F. Weber, A. Urru, S. Bhowal, C. Ederer, and N. A. Spaldin, Surface magnetization in antiferromagnets: Classification, example materials, and relation to magnetoelectric responses, Phys. Rev. X 14, 021033 (2024).
  48. M. Fiebig, D. Fröhlich, G. Sluyterman v. L., and R. V. Pisarev, Domain topography of antiferromagnetic Cr2O3 by second-harmonic generation, Appl. Phys. Lett. 66, 2906 (1995).
  49. B. Zhang, Z. Ma, J. Ma, X. Wu, C. Ouyang, D. Kong, T. Hong, X. Wang, P. Yang, L. Chen, et al., 1.4-mJ high energy terahertz radiation from lithium niobates, Laser and Photonics Reviews 15, 2000295 (2021).
  50. L. Tesi, D. Bloos, M. Hrtoň, A. Beneš, M. Hentschel, M. Kern, A. Leavesley, R. Hillenbrand, V. Křápek, T. Šikola, et al., Plasmonic metasurface resonators to enhance terahertz magnetic fields for high-frequency electron paramagnetic resonance, Small Methods 5, 2100376 (2021).
  51. Y. Behovits, A. L. Chekhov, B. Rosinus Serrano, A. Ruge, S. Reimers, Y. Lytvynenko, M. Kläui, M. Jourdan, and T. Kampfrath, Data for Behovits et al. “All-optical magnetometric characterization of the exchange-coupled antiferromagnet|ferromagnet system Mn2Au|Ni80Fe20 by terahertz spin-orbit torques”, [Data set] Zenodo, https://doi.org/10.5281/zenodo.19651386 (2026).
  52. D. L. Mills, Nonlinear Optics (Springer, Berlin, Heidelberg, 1998).
  53. L. Novotny and B. Hecht, Principles of Nano-Optics, 2nd ed. (Cambridge University Press, Cambridge, 2012).
  54. A. Hubert and G. Traeger, Magneto-optical sensitivity functions of thin-film systems, J. Magn. Magn. Mater. 124, 185 (1993).
  55. L. Braun, G. Mussler, A. Hruban, M. Konczykowski, T. Schumann, M. Wolf, M. Münzenberg, L. Perfetti, and T. Kampfrath, Ultrafast photocurrents at the surface of the three-dimensional topological insulator Bi2Se3, Nat. Commun. 7, 13259 (2016).

Outline

Information

Phys. Rev. B 113, 214408– Published 1 June, 2026
  • Received 18 November 2024
  • Revised 19 March 2026
  • Accepted 31 March 2026
Crossmark - Check for updates button
Creative Commons Logo

Published by the American Physical Society under the terms of the Creative Commons Attribution 4.0 International license. Further distribution of this work must maintain attribution to the author(s) and the published article's title, journal citation, and DOI.
