Doping dependence of the low-temperature planar carrier density in overdoped YBa2Cu3O7−δ

R. Nicholls1,*,†, R. D. H. Hinlopen1,*,‡, J. Ayres1, T. Kotte2, T. Förster2, J. Park2, J. Sourd2, A. Carrington1, and N. E. Hussey1,3,§

  • *These authors contributed equally to this work.
  • †Contact author: beckie.nicholls@bristol.ac.uk
  • ‡Contact author: roemer.hinlopen@mpsd.mpg.de
  • §Contact author: n.e.hussey@bristol.ac.uk
PDF

Phys. Rev. B 112, 064511 – Published 7 August, 2025

DOI: https://doi.org/10.1103/6kk9-xq3z

Abstract

Whether a quantum critical point (QCP) demarcates the end of the pseudogap (PG) regime in hole-doped cuprates at a singular doping level p*≈0.19 is still an open question. A crucial component of the puzzle is the manner in which the carrier density predicted by electronic structure calculations is recovered for p>p*. Here, we use magnetic fields up to 67 T to suppress superconductivity down to 50 K, allowing us to simultaneously measure the low-temperature Hall number nH and the in-plane resistivity anisotropy ρa/ρb in overdoped Y1−xCaxBa2Cu3O7−δ single crystals. We confirm a previous finding [S. Badoux et al., Nature (London) 531, 210 (2016)] that nH(50 K) exhibits a sharp increase below p* and use the measured resistivity anisotropy to obtain the planar carrier density npl=nH(ρa/ρb)−1. The doping dependence of npl(50 K) reveals two key findings: (i) At optimal doping, npl≈p, and (ii) the sharp rise in nH(p) is softened to such an extent that the full Fermi volume (npl=1+p) is only partially recovered at p*. The latter result disfavors a conventional QCP scenario in which the PG end point leads to a reconstructed Fermi surface.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (67)

  1. B. Keimer, S. A. Kivelson, M. R. Norman, S. Uchida, and J. Zaanen, From quantum matter to high-temperature superconductivity in copper oxides, Nature (London) 518, 179 (2015).
  2. C. Proust, E. Boaknin, R. Hill, L. Taillefer, and A. P. Mackenzie, Heat transport in a strongly overdoped cuprate: Fermi liquid and a pure d-wave BCS superconductor, Phys. Rev. Lett. 89, 147003 (2002).
  3. S. Nakamae, K. Behnia, N. Mangkorntong, M. Nohara, H. Takagi, S. J. C. Yates, and N. E. Hussey, Electronic ground state of heavily overdoped nonsuperconducting La2−xSrxCuO4, Phys. Rev. B 68, 100502(R) (2003).
  4. P. M. C. Rourke, A. F. Bangura, T. M. Benseman, M. Matusiak, J. R. Cooper, A. Carrington, and N. E. Hussey, A detailed de Haas–van Alphen effect study of the overdoped cuprate Tl2Ba2CuO6+δ, New J. Phys. 12, 105009 (2010).
  5. A. Carrington, A. P. Mackenzie, C. T. Lin, and J. R. Cooper, Temperature dependence of the Hall angle in single crystal YBa2(Cu1−xCox)3O7−δ, Phys. Rev. Lett. 69, 2855 (1992).
  6. A. Narduzzo, G. Albert, M. French, N. Mangkorntong, M. Nohara, H. Takagi, and N. E. Hussey, Violation of the isotropic mean free path approximation for overdoped La2−xSrxCuO4, Phys. Rev. B 77, 220502(R) (2008).
  7. F. F. Balakirev, J. B. Betts, A. Migliori, S. Ono, Y. Ando, and G. S. Boebinger, Signature of optimal doping in Hall-effect measurements on a high-temperature superconductor, Nature (London) 424, 912 (2003).
  8. D. LeBoeuf, N. Doiron-Leyraud, J. Levallois, R. Daou, J.-B. Bonnemaison, N. E. Hussey, L. Balicas, B. J. Ramshaw, R. Liang, D. A. Bonn, W. N. Hardy, S. Adachi, C. Proust, and L. Taillefer, Electron pockets in the Fermi surface of hole-doped high-Tc superconductors, Nature (London) 450, 533 (2007).
  9. C. Putzke, S. Benhabib, W. Tabis, J. Ayres, Z. Wang, L. Malone, S. Licciardello, J. Lu, T. Kondo, T. Takeuchi, N. E. Hussey, J. R. Cooper, and A. Carrington, Reduced Hall carrier density in the overdoped strange metal regime of cuprate superconductors, Nat. Phys. 17, 826 (2021).
  10. S. Badoux, W. Tabis, F. Laliberté, G. Grissonnanche, B. Vignolle, D. Vignolles, J. Béard, D. A. Bonn, W. N. Hardy, R. Liang, N. Doiron-Leyraud, L. Taillefer, and C. Proust, Change of carrier density at the pseudogap critical point of a cuprate superconductor, Nature (London) 531, 210 (2016).
  11. J. Storey, Hall effect and Fermi surface reconstruction via electron pockets in the high-Tc cuprates, Europhys. Lett. 113, 27003 (2016).
  12. Y. Su, H. Li, H. Huang, and D. Li, Effects of the pseudogap and the Fermi surface on the rapid Hall-coefficient changes in cuprates, Phys. Rev. B 111, 064518 (2025).
  13. C. Collignon, S. Badoux, S. A. A. Afshar, B. Michon, F. Laliberté, O. Cyr-Choinière, J. S. Zhou, S. Licciardello, S. Wiedmann, N. Doiron-Leyraud, and L. Taillefer, Fermi-surface transformation across the pseudogap critical point of the cuprate superconductor La1.6−xNd0.4SrxCuO4, Phys. Rev. B 95, 224517 (2017).
  14. B. Michon, C. Girod, S. Badoux, J. Kačmarčík, Q. Ma, M. Dragomir, H. A. Dabkowska, B. D. Gaulin, J. S. Zhou, S. Pyon, T. Takayama, H. Takagi, S. Verret, N. Doiron-Leyraud, C. Marcenat, L. Taillefer, and T. Klein, Thermodynamic signatures of quantum criticality in cuprate superconductors, Nature (London) 567, 218 (2019).
  15. A. Legros, K. W. Post, P. Chuahan, D. G. Rickel, X. He, X. Xu, X. Shi, I. Božović, S. A. Crooker, and N. P. Armitage, Evolution of the cyclotron mass with doping in La2−xSrxCuO4, Phys. Rev. B 106, 195110 (2022).
  16. R. A. Cooper, Y. Wang, B. Vignolle, O. J. Lipscombe, S. M. Hayden, Y. Tanabe, T. Adachi, Y. Koike, M. Nohara, H. Takagi, C. Proust, and N. E. Hussey, Anomalous criticality in the electrical resistivity of La2−xSrxCuO4, Science 323, 603 (2009).
  17. N. E. Hussey, H. Gordon-Moys, J. Kokalj, and R. H. McKenzie, Generic strange-metal behaviour of overdoped cuprates, J. Phys.: Conf. Ser. 449, 012004 (2013).
  18. N. E. Hussey, J. Buhot, and S. Licciardello, A tale of two metals: Contrasting criticalities in the pnictides and hole-doped cuprates, Rep. Prog. Phys. 81, 052501 (2018).
  19. P. Giraldo-Gallo, J. A. Galvis, Z. Stegen, K. A. Modic, F. F. Balakirev, J. B. Betts, X. Lian, C. Moir, S. C. Riggs, J. Wu, A. T. Bollinger, X. He, I. Božović, B. J. Ramshaw, R. D. McDonald, G. S. Boebinger, and A. Shekhter, Scale-invariant magnetoresistance in a cuprate superconductor, Science 361, 479 (2018).
  20. J. Ayres, M. Berben, M. Čulo, Y. T. Hsu, E. van Heumen, Y. Huang, J. Zaanen, T. Kondo, T. Takeuchi, J. R. Cooper, C. Putzke, S. Friedemann, A. Carrington, and N. E. Hussey, Incoherent transport across the strange-metal regime of overdoped cuprates, Nature (London) 595, 661 (2021).
  21. J. Ayres, M. Berben, C. Duffy, R. Hinlopen, Y.-T. Hsu, A. Cuoghi, M. Leroux, I. Gilmutdinov, M. Massoudzadegan, D. Vignolles, Y. Huang, T. Kondo, T. Takeuchi, S. Friedemann, A. Carrington, C. Proust, and N. E. Hussey, Universal correlation between H-linear magnetoresistance and T-linear resistivity in high-temperature superconductors, Nat. Commun. 15, 8406 (2024).
  22. See Supplemental Material at http://link.aps.org/supplemental/10.1103/6kk9-xq3z for Boltzmann transport calculations, derivations and additional experimental data to support Figs. 2, 3, 4, 5.
  23. K. Segawa and Y. Ando, Intrinsic Hall response of the CuO2 planes in a chain-plane composite system of YBa2Cu3Oy, Phys. Rev. B 69, 104521 (2004).
  24. N. P. Ong, Geometric interpretation of the weak-field Hall conductivity in two-dimensional metals with arbitrary Fermi surface, Phys. Rev. B 43, 193 (1991).
  25. Y. Ando, K. Segawa, S. Komiya, and A. N. Lavrov, Electrical resistivity anisotropy from self-organized one dimensionality in high-temperature superconductors, Phys. Rev. Lett. 88, 137005 (2002).
  26. M. Čulo, C. Duffy, J. Ayres, M. Berben, Y. T. Hsu, R. D. H. Hinlopen, B. Bernáth, and N. E. Hussey, Possible superconductivity from incoherent carriers in overdoped cuprates, SciPost Phys. 11, 012 (2021).
  27. R. Liang, D. A. Bonn, and W. N. Hardy, Evaluation of CuO2 plane hole doping in YBa2Cu3O6+x single crystals, Phys. Rev. B 73, 180505(R) (2006).
  28. R. Liang, D. A. Bonn, and W. N. Hardy, Growth of YBCO single crystals by the self-flux technique, Philos. Mag. 92, 2563 (2012).
  29. H. C. Montgomery, Method for measuring electrical resistivity of anisotropic materials, J. Appl. Phys. 42, 2971 (1971).
  30. C. A. Dos Santos, A. De Campos, M. S. Da Luz, B. D. White, J. J. Neumeier, B. S. De Lima, and C. Y. Shigue, Procedure for measuring electrical resistivity of anisotropic materials: A revision of the Montgomery method, J. Appl. Phys. 110, 083703 (2011).
  31. T. Ito, K. Takenaka, and S. Uchida, Systematic deviation from T-linear behavior in the in-plane resistivity of YBa2Cu3O7−δ: Evidence for dominant spin scattering, Phys. Rev. Lett. 70, 3995 (1993).
  32. K. Yoshida, A. I. Rykov, S. Tajima, and I. Terasaki, Pressure effects on anisotropic resistivity in detwinned YBa2Cu3O7−δ: Unconventional carrier doping, Phys. Rev. B 60, R15035 (1999).
  33. F. Rullier-Albenque, H. Alloul, C. Proust, P. Lejay, A. Forget, and D. Colson, Total suppression of superconductivity by high magnetic fields in YBa2Cu3O6.6, Phys. Rev. Lett. 99, 027003 (2007).
  34. M. K. Chan, M. J. Veit, C. J. Dorow, Y. Ge, Y. Li, W. Tabis, Y. Tang, X. Zhao, N. Barišić, and M. Greven, In-plane magnetoresistance obeys Kohler's rule in the pseudogap phase of cuprate superconductors, Phys. Rev. Lett. 113, 177005 (2014).
  35. C. Proust, B. Vignolle, J. Levallois, S. Adachi, and N. E. Hussey, Fermi-liquid behavior of the in-plane resistivity in the pseudogap state of YBa2Cu4O8, Proc. Natl. Acad. Sci. USA 113, 13654 (2016).
  36. M. Berben, S. Smit, C. Duffy, Y.-T. Hsu, L. Bawden, F. Heringa, F. Gerritsen, S. Cassanelli, X. Feng, S. Bron, E. van Heumen, Y. Huang, F. Bertran, T. K. Kim, C. Cacho, A. Carrington, M. S. Golden, and N. E. Hussey, Superconducting dome and pseudogap endpoint in Bi2201, Phys. Rev. Mater. 6, 044804 (2022).
  37. M. R. Chandrachood, I. S. Mulla, S. M. Gorwadkar, and A. P. Sinha, Calcium substitution at yttrium site in YBa2Cu3O7−y, Appl. Phys. Lett. 56, 183 (1990).
  38. S. G. Titova, A. V. Lukoyanov, S. V. Pryanichnikov, L. A. Cherepanova, and A. N. Titov, Crystal and electronic structure of high temperature superconducting compound Y1−xCaxBa2Cu3Oy in the temperature interval 80–300 K, J. Alloys Compd. 658, 891 (2016).
  39. H. Yakabe, M. Kosuge, J. Tsujino, Y. Shiohara, and N. K. N. Koshizuka, Correlation between Hall numbers and Tc in Y1−xCaxBa2Cu3O7−δ (0≤x<0.5) thin films prepared by RF thermal plasma deposition method, Jpn. J. Appl. Phys. 34, 4754 (1995).
  40. B. Fisher, J. Genossar, C. G. Kuper, L. Patlagan, G. M. Reisner, and A. Knizhnik, Effects of substituting calcium for yttrium on the properties of Y1−xCaxBa2Cu3O7−δ, Phys. Rev. B 47, 6054 (1993).
  41. Z. Jirák, E. Pollert, A. Tříska, and S. Vratislav, Structure and the orthorhombic-tetragonal transition in YBa2Cu3O7, Phys. Status Solidi A 102, K61 (1987).
  42. B. J. Ramshaw, S. E. Sebastian, R. D. McDonald, J. Day, B. S. Tan, Z. Zhu, J. B. Betts, R. Liang, D. A. Bonn, W. N. Hardy, and N. Harrison, Quasiparticle mass enhancement approaching optimal doping in a high-Tc superconductor, Science 348, 317 (2015).
  43. M. D. Hossain, J. C. Baglo, B. M. Wojek, O. Ofer, S. R. Dunsiger, G. D. Morris, T. Prokscha, H. Saadaoui, Z. Salman, D. A. Bonn, R. Liang, W. N. Hardy, A. Suter, E. Morenzoni, and R. F. K. Kiefl, Absolute value and anisotropy of the magnetic penetration depth in YBa2Cu3O6.92, Phys. Procedia 30, 235 (2012).
  44. A. J. Leggett, Theory of a superfluid Fermi liquid. I. General formalism and static properties, Phys. Rev. 140, A1869 (1965).
  45. C. M. Varma, K. Miyake, and S. Schmitt-Rink, London penetration depth of heavy-fermion superconductors, Phys. Rev. Lett. 57, 626 (1986).
  46. T. Nomoto and H. Ikeda, Effect of magnetic criticality and Fermi-surface topology on the magnetic penetration depth, Phys. Rev. Lett. 111, 167001 (2013).
  47. P. Walmsley, C. Putzke, L. Malone, I. Guillamón, D. Vignolles, C. Proust, S. Badoux, A. I. Coldea, M. D. Watson, S. Kasahara, Y. Mizukami, T. Shibauchi, Y. Matsuda, and A. Carrington, Quasiparticle mass enhancement close to the quantum critical point in BaFe2(As1−xPx)2, Phys. Rev. Lett. 110, 257002 (2013).
  48. A. P. Mackenzie, S. R. Julian, A. J. Diver, G. G. Lonzarich, N. E. Hussey, Y. Maeno, S. Nishizaki, and T. Fujita, Calculation of thermodynamic and transport properties of Sr2RuO4 at low temperatures using known Fermi surface parameters, Phys. C (Amsterdam, Neth.) 263, 510 (1996).
  49. J. W. Loram, K. A. Mirza, J. R. Cooper, and W. Y. Liang, Electronic specific heat of YBa2(Cu1−xCox)3O6+x from 1.8 to 300 K, Phys. Rev. Lett. 71, 1740 (1993).
  50. O. K. Andersen, A. I. Liechtenstein, O. Jepsen, and F. Paulsen, LDA energy bands, low-energy Hamiltonians, t′, t′′, t⊥ (k), and J⊥, J. Phys. Chem. Solids 56, 1573 (1995).
  51. A. Carrington and E. A. Yelland, Band-structure calculations of Fermi-surface pockets in ortho–II YBa2Cu3O6.5, Phys. Rev. B 76, 140508(R) (2007).
  52. N. Momono, M. Ido, T. Nakano, Y. Okajima and K. Yamaya Low-temperature electronic specific heat of La2−xSrxCuO4 and La2−xSrxCu1−yZnyO4: Evidence for a d-wave superconductor, Phys. C (Amsterdam, Neth.) 233, 395 (1994).
  53. J. Baglo, A detailed doping survey of the low-energy electrodynamics of YBa2Cu3O6+x, Ph.D. thesis, University of British Columbia, 2014.
  54. K. Hashimoto, K. Cho, T. Shibauchi, S. Kasahara, Y. Mizukami, R. Katsumata, Y. Tsuruhara, T. Terashima, H. Ikeda, M. A. Tanatar, H. Kitano, N. Salovich, R. W. Giannetta, P. P. Walmsley, A. Carrington, R. Prozorov, and Y. Matsuda, A sharp peak of the zero-temperature penetration depth at optimal composition in BaFe2(As1−xPx)2, Science 336, 1554 (2012).
  55. C. C. Tam, M. Zhu, J. Ayres, K. Kummer, F. Yakhou-Harris, J. R. Cooper, A. Carrington, and S. M. Hayden, Charge density waves and Fermi surface reconstruction in the clean overdoped cuprate Tl2Ba2CuO6+δ, Nat. Commun. 13, 570 (2022).
  56. F. F. Balakirev, J. B. Betts, A. Migliori, I. Tsukada, Y. Ando, and G. S. Boebinger, Quantum phase transition in the magnetic-field-induced normal state of optimum-doped high-Tc cuprate superconductors at low temperatures, Phys. Rev. Lett. 102, 017004 (2009).
  57. C. Liu, T. Kondo, R. M. Fernandes, A. D. Palczewski, E. D. Mun, N. Ni, A. N. Thaler, A. Bostwick, E. Rotenberg, J. Schmalian, S. L. Bud'ko, P. C. Canfield, and A. Kaminski, Evidence for a Lifshitz transition in electron-doped iron arsenic superconductors at the onset of superconductivity, Nat. Phys. 6, 419 (2010).
  58. N. Hayes, I. M. Maksimovic, G. N. Lopez, M. K. Chan, B. J. Ramshaw, R. D. McDonald, and J. G. Analytis, Superconductivity and quantum criticality linked by the Hall effect in a strange metal, Nat. Phys. 17, 58 (2021).
  59. M. Čulo, M. Berben, Y.-T. Hsu, J. Ayres, R. D. H. Hinlopen, S. Kasahara, Y. Matsuda, T. Shibauchi, and N. E. Hussey, Putative Hall response of the strange metal component in FeSe1−xSx, Phys. Rev. Res. 3, 023069 (2021).
  60. S. Friedemann, N. Oeschler, S. Wirth, C. Krellner, C. Geibel, F. Steglich, S. Paschen, S. Kirchner, and Q. Si, Fermi-surface collapse and dynamical scaling near a quantum-critical point, Proc. Natl. Acad. Sci. USA 107, 14547 (2010).
  61. Y.-T. Hsu, A. Rydh, M. Berben, C. Duffy, A. de la Torre, R. S. Perry, and N. E. Hussey, Carrier density crossover and quasiparticle mass enhancement in a doped 5d Mott insulator, Nat. Phys. 20, 1596 (2024).
  62. W. Shockley, Effect of magnetic fields on conduction—“tube integrals”, Phys. Rev. 79, 191 (1950).
  63. R. G. Chambers, The kinetic formulation of conduction problems, Proc. Phys. Soc. A 65, 458 (1952).
  64. A. Carrington, N. Hussey, R. Nicholls, and R. Hinlopen, Hall effect in YBa2Cu3O7 (2025), https://doi.org/10.5523/bris.1645z6yvvvb9d2gznuchw70nnc
  65. N. Barišić and D. K. Sunko, High-Tc cuprates: A story of two electronic subsystems, J. Supercond. Novel Magn. 35, 1781 (2022).
  66. W. O. Tromp, T. Benschop, J. F. Ge, I. Battisti, K. M. Bastiaans, D. Chatzopoulos, A. H. Vervloet, S. Smit, E. van Heumen, M. S. Golden, Y. Huang, T. Kondo, T. Takeuchi, Y. Yin, J. E. Hoffman, M. A. Sulangi, J. Zaanen, and M. P. Allan, Puddle formation and persistent gaps across the non-mean-field breakdown of superconductivity in overdoped (Pb,Bi)2Sr2CuO6+δ, Nat. Mater. 22, 703 (2023).
  67. S. Ye, M. Xu, H. Yan, Z. X. Li, C. Zou, X. Li, Z. Hao, C. Yin, Y. Chen, X. Zhou, D. H. Lee, and Y. Wang, Emergent normal fluid in the superconducting ground state of overdoped cuprates, Nat. Commun. 15, 4939 (2024).
