Emergence of spin-orbit coupling among spin, atomic orbital, and Bloch dynamics in Janus double-transition-metal MXenes

Tetsuro Habe

PDF

Phys. Rev. B 114, 165427 – Published 30 September, 2026

DOI: https://doi.org/10.1103/5fwf-wws8

Abstract

We found a spin-orbit coupling to cause a simultaneous correlation among 3 degrees of freedom, the electronic spin, orbital, and Bloch dynamics in an investigation into the electronic structure of Janus double-transition-metal MXenes, Mo2HfC2OS and W2HfC2OS. In this paper, it is also revealed that the spin-orbit coupling causes a staggered spin configuration with a trigonal pattern around the Γ point near the insulating gap. We developed a reduced Hamiltonian describing the electronic states and show that the spin-orbit coupling cannot be equated with conventional forms for a single electron in solids, LS, Rashba, and Dresselhaus couplings, even in the approximation under the low-energy and small wave-number condition. Because of the intrinsic shape of the conduction band, a trigonally alternating spin-momentum locking emerges with the spin axis perpendicular to the layer plane. The theoretical analysis shows that these Janus materials can provide a platform for exploring the spin-related phenomena due to the trigonal spin-momentum locking other than Rashba and Dresselhaus types.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (34)

  1. V. Galitski and I. B. Spielman, Spin–orbit coupling in quantum gases, Nature (London) 494, 49 (2013).
  2. A. Soumyanarayanan, N. Reyren, A. Fert, and C. Panagopoulos, Emergent phenomena induced by spin–orbit coupling at surfaces and interfaces, Nature (London) 539, 509 (2016).
  3. G. Dresselhaus, Spin-orbit coupling effects in zinc blende structures, Phys. Rev. 100, 580 (1955).
  4. Y. A. Bychkov and E. I. Rashba, Properties of a 2D electron gas with lifted spectral degeneracy, Pis'ma Zh. Eksp. Teor. Fiz. 39, 66 (1984) [JETP Lett. 39, 78 (1984)].
  5. S. Murakami, N. Nagaosa, and S.-C. Zhang, Dissipationless quantum spin current at room temperature, Science 301, 1348 (2003).
  6. M. König, S. Wiedmann, C. Brüne, A. Roth, H. Buhmann, L. W. Molenkamp, X.-L. Qi, and S.-C. Zhang, Quantum spin Hall insulator state in HgTe quantum wells, Science 318, 766 (2007).
  7. P. Tang, Q. Zhou, and S.-C. Zhang, Multiple types of topological fermions in transition metal silicides, Phys. Rev. Lett. 119, 206402 (2017).
  8. D. Xiao, G.-B. Liu, W. Feng, X. Xu, and W. Yao, Coupled spin and valley physics in monolayers of MoS2 and other group-VI dichalcogenides, Phys. Rev. Lett. 108, 196802 (2012).
  9. A. Kormányos, V. Zólyomi, N. D. Drummond, P. Rakyta, G. Burkard, and V. I. Fal'ko, Monolayer MoS2: Trigonal warping, the Γ valley, and spin-orbit coupling effects, Phys. Rev. B 88, 045416 (2013).
  10. H. N. Russell and F. A. Saunders, New regularities in the spectra of the alkaline earths, Astrophys. J. 61, 38 (1925).
  11. A.-Y. Lu, H. Zhu, J. Xiao, C.-P. Chuu, Y. Han, M.-H. Chiu, C.-C. Cheng, C.-W. Yang, K.-H. Wei, Y. Yang, Y. Wang, D. Sokaras, D. Nordlund, P. Yang, D. A. Muller, M.-Y. Chou, X. Zhang, and L.-J. Li, Janus monolayers of transition metal dichalcogenides, Nat. Nanotechnol. 12, 744 (2017).
  12. J. Zhang, S. Jia, I. Kholmanov, L. Dong, D. Er, W. Chen, H. Guo, Z. Jin, V. B. Shenoy, L. Shi, and J. Lou, Janus monolayer transition-metal dichalcogenides, ACS Nano 11, 8192 (2017).
  13. M. Khazaei, A. Ranjbar, M. Arai, and S. Yunoki, Topological insulators in the ordered double transition metals M2′M″C2 MXenes (M′=Mo, W; M″=Ti, Zr, Hf), Phys. Rev. B 94, 125152 (2016).
  14. C. Si, K.-H. Jin, J. Zhou, Z. Sun, and F. Liu, Large-gap quantum spin Hall state in MXenes: D-band topological order in a triangular lattice, Nano Lett. 16, 6584 (2016).
  15. Y. Liang, M. Khazaei, A. Ranjbar, M. Arai, S. Yunoki, Y. Kawazoe, H. Weng, and Z. Fang, Theoretical prediction of two-dimensional functionalized MXene nitrides as topological insulators, Phys. Rev. B 96, 195414 (2017).
  16. M. Naguib, V. N. Mochalin, M. W. Barsoum, and Y. Gogotsi, 25th anniversary article: MXenes: A new family of two-dimensional materials, Adv. Mater. 26, 992 (2014).
  17. Y. Gogotsi and B. Anasori, The rise of MXenes, ACS Nano 13, 8491 (2019).
  18. K. R. G. Lim, M. Shekhirev, B. C. Wyatt, B. Anasori, Y. Gogotsi, and Z. W. Seh, Fundamentals of MXene synthesis, Nat. Synth. 1, 601 (2022).
  19. H. H. S. Thangavelu, C. Huang, F. Chabanais, J. Palisaitis, and P. O. A. Persson, A review on MXene terminations, Adv. Funct. Mater. 36, e15604 (2026).
  20. Z.-Q. Huang, M.-L. Xu, G. Macam, C.-H. Hsu, and F.-C. Chuang, Large-gap topological insulators in functionalized ordered double transition metal carbide MXenes, Phys. Rev. B 102, 075306 (2020).
  21. D. Parajuli and K. Samatha, Topological signatures of Mo2TiC2O2, AIP Adv. 14, 035011 (2024).
  22. P. Giannozzi et al., Quantum ESPRESSO: A modular and open-source software project for quantum simulations of materials, J. Phys.: Condens. Matter 21, 395502 (2009).
  23. J. P. Perdew, K. Burke, and M. Ernzerhof, Generalized gradient approximation made simple, Phys. Rev. Lett. 77, 3865 (1996).
  24. A. Dal Corso, Pseudopotentials periodic table: From H to Pu, Comput. Mater. Sci. 95, 337 (2014).
  25. T. Habe, Optical conductivity of the topologically nontrivial MXenes Mo2HfC2O2 and W2HfC2O2: First-principles calculation and effective model analysis, Phys. Rev. B 111, 035422 (2025).
  26. T. Habe, Enhancement of the anomalous Hall effect by tilt of the Zeeman field in the topologically nontrivial MXenes M2M′C2O2, Phys. Rev. B 111, 035303 (2025).
  27. A. Manchon, H. C. Koo, J. Nitta, S. M. Frolov, and R. A. Duine, New perspectives for Rashba spin–orbit coupling, Nat. Mater. 14, 871 (2015).
  28. K. V. Shanavas, Z. S. Popović, and S. Satpathy, Theoretical model for Rashba spin-orbit interaction in d electrons, Phys. Rev. B 90, 165108 (2014).
  29. H. Yang, Q. Wang, and J. Fu, Interface involved Dresselhaus spin-orbit coupling in GaInAs/AlInAs heterostructures, Phys. Rev. B 104, 125426 (2021).
  30. A. A. Mostofi, J. R. Yates, Y.-S. Lee, I. Souza, D. Vanderbilt, and N. Marzari, wannier90: A tool for obtaining maximally-localised Wannier functions, Comput. Phys. Commun. 178, 685 (2008).
  31. See Supplemental Material at http://link.aps.org/supplemental/10.1103/5fwf-wws8 for a description of the reproducibility of the first-principles band structures of Mo2HfC2OS and W2HfC2OS by using the tight-binding model in Sec. 4.
  32. Y. M. Koroteev, G. Bihlmayer, J. E. Gayone, E. V. Chulkov, S. Blügel, P. M. Echenique, and P. Hofmann, Strong spin-orbit splitting on Bi surfaces, Phys. Rev. Lett. 93, 046403 (2004).
  33. H. Yi, L.-H. Hu, Y. Wang, R. Xiao, J. Cai, D. R. Hickey, C. Dong, Y.-F. Zhao, L.-J. Zhou, R. Zhang, A. R. Richardella, N. Alem, J. A. Robinson, M. H. W. Chan, X. Xu, N. Samarth, C.-X. Liu, and C.-Z. Chang, Crossover from Ising-to Rashba-type superconductivity in epitaxial Bi2Se3/monolayer NbSe2 heterostructures, Nat. Mater. 21, 1366 (2022).
  34. J. Heyd, G. E. Scuseria, and M. Ernzerhof, Hybrid functionals based on a screened Coulomb potential, J. Chem. Phys. 118, 8207 (2003).
