Energy offset between femtosecond and thermal electrons in nanometer field-emitter tips

Daniel Kazenwadel, Jacob Holder, Joel Kuttruff, and Peter Baum*

  • *Contact author: peter.baum@uni-konstanz.de
PDF

Phys. Rev. Applied 24, 024021 – Published 8 August, 2025

DOI: https://doi.org/10.1103/y8mq-nhx2

Abstract

We investigate the ultrafast photoelectric effect at sharp tungsten needles and find a considerable energy offset between thermally emitted and photoemitted electrons. Neither changes in temperature nor tuning the work function by the Schottky effect strongly affect the free-space energy of the photoelectrons. We explain these discoveries by a direct optical excitation within the band structure of tungsten, followed by scatter-free transport to the surface and emission into free space. Experiments at different photon energies support that the material and not the photon energy determines the primary properties of the electron beam.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (44)

  1. A. Einstein, Über einen die Erzeugung und Verwandlung des Lichtes betreffenden heuristischen Gesichtspunkt, Ann. Phys. 322, 132 (1905).
  2. Armin Feist, Nora Bach, Nara Rubiano da Silva, Thomas Danz, Marcel Möller, Katharina E. Priebe, Till Domröse, J. Gregor Gatzmann, Stefan Rost, Jakob Schauss, Stefanie Strauch, Reiner Bormann, Murat Sivis, Sascha Schäfer, and Claus Ropers, Ultrafast transmission electron microscopy using a laser-driven field emitter: Femtosecond resolution with a high coherence electron beam, Ultramicroscopy 176, 63 (2017).
  3. F. Houdellier, G. M. Caruso, S. Weber, M. Kociak, and A. Arbouet, Development of a high brightness ultrafast Transmission Electron Microscope based on a laser-driven cold field emission source, Ultramicroscopy 186, 128 (2018).
  4. J. Kuttruff, D. Nabben, A.-C. Zimmermann, A. Ryabov, and P. Baum, Terahertz control and timing correlations in a transmission electron microscope, Sci. Adv. 10, eadl6543 (2024).
  5. F. Boschini, M. Zonno, and A. Damascelli, Time-resolved ARPES studies of quantum materials, Rev. Mod. Phys. 96, 015003 (2024).
  6. L. Kasmi, D. Kreier, M. Bradler, E. Riedle, and P. Baum, Femtosecond single-electron pulses generated by two-photon photoemission close to the work function, New J. Phys. 17, 033008 (2015).
  7. R. J. D. Miller, Femtosecond crystallography with ultrabright electrons and x-rays: Capturing chemistry in action, Science 343, 1108 (2014).
  8. M. Aidelsburger, F. O. Kirchner, F. Krausz, and P. Baum, Single-electron pulses for ultrafast diffraction, Proc. Natl. Acad. Sci. 107, 19714 (2010).
  9. D. H. Dowell and J. F. Schmerge, Quantum efficiency and thermal emittance of metal photocathodes, Phys. Rev. Spec. Top. - Accel. Beams 12, 074201 (2009).
  10. K. L. Jensen, N. A. Moody, D. W. Feldman, E. J. Montgomery, and P. G. O’Shea, Photoemission from metals and cesiated surfaces, J. Appl. Phys. 102, 074902 (2007).
  11. L. Wu and L. K. Ang, Nonequilibrium model of ultrafast laser-induced electron photofield emission from a dc-biased metallic surface, Phys. Rev. B 78, 224112 (2008).
  12. P. Hommelhoff, Y. Sortais, A. Aghajani-Talesh, and M. A. Kasevich, Field emission tip as a nanometer source of free electron femtosecond pulses, Phys. Rev. Lett. 96, 077401 (2006).
  13. P. Hommelhoff, C. Kealhofer, and M. A. Kasevich, Ultrafast electron pulses from a tungsten tip triggered by low-power femtosecond laser pulses, Phys. Rev. Lett. 97, 247402 (2006).
  14. R. Haindl, K. Köster, J. H. Gaida, M. Franz, A. Feist, and C. Ropers, Femtosecond tunable-wavelength photoassisted cold field emission, Appl. Phys. B 129, 40 (2023).
  15. H. Y. Kim, M. Garg, S. Mandal, L. Seiffert, T. Fennel, and E. Goulielmakis, Attosecond field emission, Nature 613, 662 (2023).
  16. M. Tsarev, A. Ryabov, and P. Baum, Measurement of temporal coherence of free electrons by time-domain electron interferometry, Phys. Rev. Lett. 127, 165501 (2021).
  17. B. Barwick, C. Corder, J. Strohaber, N. Chandler-Smith, C. Uiterwaal, and H. Batelaan, Laser-induced ultrafast electron emission from a field emission tip, New J. Phys. 9, 142 (2007).
  18. D. Nabben, J. Kuttruff, L. Stolz, A. Ryabov, and P. Baum, Attosecond electron microscopy of sub-cycle optical dynamics, Nature 619, 63 (2023).
  19. J. H. Gaida, H. Lourenço-Martins, M. Sivis, T. Rittmann, A. Feist, F. J. García De Abajo, and C. Ropers, Attosecond electron microscopy by free-electron homodyne detection, Nat. Photonics 18, 509 (2024).
  20. M. Tsarev, J. W. Thurner, and P. Baum, Nonlinear-optical quantum control of free-electron matter waves, Nat. Phys. 19, 1350 (2023).
  21. M. V. Tsarev, A. Ryabov, and P. Baum, Free-electron qubits and maximum-contrast attosecond pulses via temporal Talbot revivals, Phys. Rev. Res. 3, 043033 (2021).
  22. A. Feist, K. E. Echternkamp, J. Schauss, S. V. Yalunin, S. Schäfer, and C. Ropers, Quantum coherent optical phase modulation in an ultrafast transmission electron microscope, Nature 521, 200 (2015).
  23. O. Reinhardt, C. Mechel, M. Lynch, and I. Kaminer, Free-electron qubits, Ann. Phys. 533, 2000254 (2021).
  24. C. Davisson and L. H. Germer, The thermionic work function of tungsten, Phys. Rev. 20, 300 (1922).
  25. JEOL, Schottky-Type Electron Gun, https://www.jeol.com/words/emterms/20121023.045159.php.
  26. Handbook of Charged Particle Optics, 2nd ed., edited by J. Orloff (CRC Press, Boca Raton, London, New York, 2009).
  27. L. R. Danielson and L. W. Swanson, High temperature coadsorption study of zirconium and oxygen on the W(100) crystal face, Surf. Sci. 88, 14 (1979).
  28. N. Bach, T. Domröse, A. Feist, T. Rittmann, S. Strauch, C. Ropers, and S. Schäfer, Coulomb interactions in high-coherence femtosecond electron pulses from tip emitters, Struct. Dyn. 6, 014301 (2019).
  29. M. J. Fransen, Th. L. Van Rooy, P. C. Tiemeijer, M. H. F. Overwijk, J. S. Faber, and P. Kruit, in Advances in Imaging and Electron Physics, edited by Peter W. Hawkes (Elsevier, San Diego, California, USA, 1999), Vol. 111, pp. 91–166.
  30. R. Bormann, S. Strauch, S. Schäfer, and C. Ropers, An ultrafast electron microscope gun driven by two-photon photoemission from a nanotip cathode, J. Appl. Phys. 118, 173105 (2015).
  31. J. Kuttruff, J. Holder, Y. Meng, and P. Baum, Real-time electron clustering in an event-driven hybrid pixel detector, Ultramicroscopy 255, 113864 (2024).
  32. Z. Lin, L. V. Zhigilei, and V. Celli, Electron-phonon coupling and electron heat capacity of metals under conditions of strong electron-phonon nonequilibrium, Phys. Rev. B 77, 075133 (2008).
  33. T. Genieys, M. Sentis, and O. Utéza, Investigation of ultrashort laser excitation of aluminum and tungsten by reflectivity measurements, Appl. Phys. A 126, 263 (2020).
  34. J. H. Weaver, C. G. Olson, and D. W. Lynch, Optical properties of crystalline tungsten, Phys. Rev. B 12, 1293 (1975).
  35. A. L. Cavalieri, N. Müller, Th. Uphues, V. S. Yakovlev, A. Baltuška, B. Horvath, B. Schmidt, L. Blümel, R. Holzwarth, S. Hendel, M. Drescher, U. Kleineberg, P. M. Echenique, R. Kienberger, F. Krausz, and U. Heinzmann, Attosecond spectroscopy in condensed matter, Nature 449, 1029 (2007).
  36. S. Meier, J. Heimerl, and P. Hommelhoff, Few-electron correlations after ultrafast photoemission from nanometric needle tips, Nat. Phys. 19, 1402 (2023).
  37. R. Haindl, A. Feist, T. Domröse, M. Möller, J. H. Gaida, S. V. Yalunin, and C. Ropers, Coulomb-correlated electron number states in a transmission electron microscope beam, Nat. Phys. 19, 1410 (2023).
  38. G. M. Caruso, F. Houdellier, S. Weber, M. Kociak, and A. Arbouet, High brightness ultrafast transmission electron microscope based on a laser-driven cold-field emission source: principle and applications, Adv. Phys. X 4, 1660214 (2019).
  39. P. Baum, On the physics of ultrashort single-electron pulses for time-resolved microscopy and diffraction, Chem. Phys. 423, 55 (2013).
  40. B. Barwick, D. J. Flannigan, and A. H. Zewail, Photon-induced near-field electron microscopy, Nature 462, 902 (2009).
  41. E. Pomarico, Y.-J. Kim, F. J. García De Abajo, O.-H. Kwon, F. Carbone, and R. M. Van Der Veen, Ultrafast electron energy-loss spectroscopy in transmission electron microscopy, MRS Bull. 43, 497 (2018).
  42. Y. Fang, J. Kuttruff, D. Nabben, and P. Baum, Structured electrons with chiral mass and charge, Science 385, 183 (2024).
  43. J. Heimerl, A. Mikhaylov, S. Meier, H. Höllerer, I. Kaminer, M. Chekhova, and P. Hommelhoff, Multiphoton electron emission with non-classical light, Nat. Phys. 20, 945 (2024).
  44. A. Schröder, A. Wendeln, J. T. Weber, M. Mukai, Y. Kohno, and S. Schäfer, Ultramicroscopy 275, 114158 (2025).
