Resource-efficient universal photonic processors based on time-multiplexed hybrid architectures

Jonas Lammers1,*, Laura Ares2, Federico Pegoraro1, Philip Held1, Benjamin Brecht1, Jan Sperling2, and Christine Silberhorn1

  • 1Paderborn University, Integrated Quantum Optics, Institute for Photonic Quantum Systems (PhoQS), Warburger Str. 100, 33098 Paderborn, Germany
  • 2Paderborn University, Theoretical Quantum Science, Institute for Photonic Quantum Systems (PhoQS), Warburger Str. 100, 33098 Paderborn, Germany

  • *Contact author: jonas.lammers@uni-paderborn.de
PDF

Phys. Rev. Applied 25, 054011 – Published 5 May, 2026

DOI: https://doi.org/10.1103/x99y-2sms

Abstract

For the ever-growing field of quantum information processing, large-scale, efficient multiport interferometers serving as photonic processors are required. In this context, the suitability of quantum walks as the interferometric base for universal computation has been theoretically proven. In this work, we bridge the gap between theoretical proposals and state-of-the-art experimental capabilities by providing the recipe for the implementation of a universal photonic processor in discrete-time quantum walks. Specifically, we present the protocol for translating arbitrary linear transformations into the coin and step operator of a quantum walk and map these to the experimental parameters of the established time-multiplexed platform [A. Schreiber et al., Phys. Rev. Lett. 104, 050502 (2010)]. We show that our interface is highly scalable and resource efficient due to the hybrid encoding consisting of multiple degrees of freedom. Finally, we prove that our system is highly resilient against experimental imperfections and show that it compares favorably against existing architectures.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (44)

  1. H. J. Briegel, D. E. Browne, W. Dür, R. Raussendorf, and M. Van den Nest, Measurement-based quantum computation, Nat. Phys. 5, 19 (2009).
  2. M. V. Larsen, C. Chamberland, K. Noh, J. S. Neergaard-Nielsen, and U. L. Andersen, Fault-tolerant continuous-variable measurement-based quantum computation architecture, PRX Quantum 2, 030325 (2021).
  3. J. Carolan, C. Harrold, C. Sparrow, E. Martín-López, N. J. Russell, J. W. Silverstone, P. J. Shadbolt, N. Matsuda, M. Oguma, M. Itoh, G. D. Marshall, M. G. Thompson, J. C. F. Matthews, T. Hashimoto, J. L. O’Brien, and A. Laing, Universal linear optics, Science 349, 711 (2015).
  4. L. Chen, E. Hall, L. Theogarajan, and J. Bowers, Photonic switching for data center applications, IEEE Photonics J. 3, 834 (2011).
  5. K. Jacobs, R. Wu, X. Wang, S. Ashhab, Q.-M. Chen, and H. Rabitz, Fast quantum communication in linear networks, Europhys. Lett. 114, 40007 (2016).
  6. F. Ewert, M. Bergmann, and P. van Loock, Ultrafast long-distance quantum communication with static linear optics, Phys. Rev. Lett. 117, 210501 (2016).
  7. X.-B. Xu, W.-T. Wang, L.-Y. Sun, and C.-L. Zou, Hybrid superconducting photonic-phononic chip for quantum information processing, Chip 1, 100016 (2022).
  8. H.-S. Zhong et al., Quantum computational advantage using photons, Science 370, 1460 (2020).
  9. H.-S. Zhong et al., Quantum computational advantage using photons, Science 370, 1460 (2020).
  10. L. S. Madsen, F. Laudenbach, M. F. Askarani, F. Rortais, T. Vincent, J. F. F. Bulmer, F. M. Miatto, L. Neuhaus, L. G. Helt, M. J. Collins, A. E. Lita, T. Gerrits, S. W. Nam, V. D. Vaidya, M. Menotti, I. Dhand, Z. Vernon, N. Quesada, and J. Lavoie, Quantum computational advantage with a programmable photonic processor, Nature 606, 75 (2022).
  11. S. Yu et al., A universal programmable Gaussian boson sampler for drug discovery, Nat. Comput. Sci. 3, 839 (2023).
  12. J. Gao, X.-W. Wang, W.-H. Zhou, Z.-Q. Jiao, R.-J. Ren, Y.-X. Fu, L.-F. Qiao, X.-Y. Xu, C.-N. Zhang, X.-L. Pang, H. Li, Y. Wang, X.-M. Jin et al., Quantum advantage with membosonsampling, Chip 1, 100007 (2022).
  13. M. Reck, A. Zeilinger, H. J. Bernstein, and P. Bertani, Experimental realization of any discrete unitary operator, Phys. Rev. Lett. 73, 58 (1994).
  14. W. R. Clements, P. C. Humphreys, B. J. Metcalf, W. S. Kolthammer, and I. A. Walmsley, Optimal design for universal multiport interferometers, Optica 3, 1460 (2016).
  15. F. Hoch, T. Giordani, L. Castello, G. Carvacho, N. Spagnolo, F. Ceccarelli, C. Pentangelo, S. Piacentini, A. Crespi, R. Osellame, E. F. Galvão, and F. Sciarrino, Modular quantum-to-quantum Bernoulli factory in an integrated photonic processor, Nat. Photonics 19, 12 (2025).
  16. A. Barzaghi, M. Bénéfice, F. Ceccarelli, G. Corrielli, V. Galli, M. Gardina, V. Grimaldi, J. Kaczorowski, F. Malaspina, R. Osellame, C. Pentangelo, A. Rocchetto, and A. Rudi, in Proc. SPIE 13391, Quantum Computing, Communication, and Simulation V, 1339112 (2025).
  17. J. M. Arrazola, N. Quesada, D. J. Broome, A. A. Gaggero, M. J. Pugh, S. Slussarenko, M. E. Simmons, M. J. B. Prystawko, A. Acín, J. L. O’Brien et al., Quantum circuits with many photons on a programmable nanophotonic chip, Nature 591, 54 (2021).
  18. S. De, V. Ansari, J. Sperling, S. Barkhofen, B. Brecht, and C. Silberhorn, Realization of high-fidelity unitary operations on up to 64 frequency bins, Phys. Rev. Res. 6, L022040 (2024).
  19. L. Serino, C. Eigner, B. Brecht, and C. Silberhorn, Programmable time-frequency mode-sorting of single photons with a multi-output quantum pulse gate, Opt. Express 33, 5577 (2025).
  20. P. Folge, M. Stefszky, B. Brecht, and C. Silberhorn, A framework for fully programmable frequency-encoded quantum networks harnessing multioutput quantum pulse gates, PRX Quantum 5, 040329 (2024).
  21. L. Serino, J. Gil-Lopez, M. Stefszky, R. Ricken, C. Eigner, B. Brecht, and C. Silberhorn, Realization of a multi-output quantum pulse gate for decoding high-dimensional temporal modes of single-photon states, PRX Quantum 4, 020306 (2023).
  22. A. Schreiber, K. N. Cassemiro, V. Potoček, A. Gábris, P. J. Mosley, E. Andersson, I. Jex, and Ch. Silberhorn, Photons walking the line: A quantum walk with adjustable coin operations, Phys. Rev. Lett. 104, 050502 (2010).
  23. K. R. Motes, A. Gilchrist, J. P. Dowling, and P. P. Rohde, Scalable boson sampling with time-bin encoding using a loop-based architecture, Phys. Rev. Lett. 113, 120501 (2014).
  24. P. P. Rohde, Simple scheme for universal linear-optics quantum computing with constant experimental complexity using fiber loops, Phys. Rev. A 91, 012306 (2015).
  25. D. Su, I. Dhand, L. G. Helt, Z. Vernon, and K. Brádler, Hybrid spatiotemporal architectures for universal linear optics, Phys. Rev. A 99, 062301 (2019).
  26. M. Borghi, E. Brusaschi, M. Liscidini, M. Galli, and D. Bajoni, Bipartite Gaussian boson sampling in the time-frequency-bin domain with squeezed light generated by a silicon nitride microresonator, Quantum Inf. 11, 135 (2025).
  27. Y. Aharonov, L. Davidovich, and N. Zagury, Quantum random walks, Phys. Rev. A 48, 1687 (1993).
  28. A. M. Childs, Universal computation by quantum walk, Phys. Rev. Lett. 102, 180501 (2009).
  29. N. B. Lovett, S. Cooper, M. Everitt, M. Trevers, and V. Kendon, Universal quantum computation using the discrete-time quantum walk, Phys. Rev. A 81, 042330 (2010).
  30. F. Pegoraro, P. Held, J. Lammers, B. Brecht, and C. Silberhorn, Demonstration of a photonic time-multiplexed C-NOT gate, arXiv:2412.02478 [quant-ph].
  31. T. G. de Brugière, R. Mezher, S. Currie, and S. Mansfield, Designs of linear optical interferometers with minimal depth and component count, Phys. Rev. A 113, 033512 (2026).
  32. M. Araújo, F. Costa, and C. Brukner, Computational advantage from quantum-controlled ordering of gates, Phys. Rev. Lett. 113, 250402 (2014).
  33. N. Habermann, Parallel neighbor-sort (or the glory of the induction principle), CMU Computer Science Report, Tech. Rep. AD-759 248 (1972).
  34. C. S. Hamilton, S. Barkhofen, L. Sansoni, I. Jex, and C. Silberhorn, Driven discrete time quantum walks, New J. Phys. 18, 073008 (2016).
  35. T. Nitsche, S. Barkhofen, R. Kruse, L. Sansoni, M. Štefaňák, A. Gábris, V. Potoček, T. Kiss, I. Jex, and C. Silberhorn, Probing measurement-induced effects in quantum walks via recurrence, Sci. Adv. 4, eaar6444 (2018).
  36. F. Pegoraro, P. Held, S. Barkhofen, B. Brecht, and C. Silberhorn, Dynamic conditioning of two particle discrete-time quantum walks, Phys. Scr. 98, 034005 (2023).
  37. L. Carosini, V. Oddi, F. Giorgino, L. M. Hansen, B. Seron, S. Piacentini, T. Guggemos, I. Agresti, J. C. Loredo, and P. Walther, Programmable multiphoton quantum interference in a single spatial mode, Sci. Adv. 10, eadj0993 (2024).
  38. B.-C. Pan, H.-X. Liu, H.-C. Xu, Y.-S. Huang, H. Li, Z.-J. Yu, L. Liu, Y.-C. Shi, and D.-X. Dai, Ultra-compact lithium niobate microcavity electro-optic modulator beyond 110 GHz, Chip 1, 100029 (2022).
  39. G. Lindblad, On the generators of quantum dynamical semigroups, Commun. Math. Phys. 48, 119 (1976).
  40. V. Gorini, A. Kossakowski, and E. C. G. Sudarshan, Completely positive dynamical semigroups of N-level systems, J. Math. Phys. 17, 821 (1976).
  41. C.-Y. Ju, A. Miranowicz, G.-Y. Chen, and F. Nori, Non-Hermitian Hamiltonians and no-go theorems in quantum information, Phys. Rev. A 100, 062118 (2019).
  42. C. S. Hamilton, R. Kruse, L. Sansoni, S. Barkhofen, C. Silberhorn, and I. Jex, Gaussian boson sampling, Phys. Rev. Lett. 119, 170501 (2017).
  43. A. P. Lund, A. Laing, S. Rahimi-Keshari, T. Rudolph, J. L. O’Brien, and T. C. Ralph, Boson sampling from a Gaussian state, Phys. Rev. Lett. 113, 100502 (2014).
  44. R. J. Marshman, D. Singh, T. C. Ralph, and A. P. Lund, Unitary averaging with fault and loss tolerance, Phys. Rev. A 109, 062436 (2024).
