Fracture toughness and auxeticity in disordered metamaterials

Hannes Holey1, Andrea Lorenzo Henri Sergio Detry1, Silvia Bonfanti1,2, Roberto Guerra1, Anshul D.S. Parmar2, Jacopo Fiocchi3, Ausonio Tuissi3, Michael Zaiser4, and Stefano Zapperi1,5,*

  • *Contact author: stefano.zapperi@unimi.it
PDF

Phys. Rev. Applied 25, 024075 – Published 24 February, 2026

DOI: https://doi.org/10.1103/r66g-hyxx

Abstract

Auxetic metamaterials are commonly thought to exhibit favorable mechanical properties, notably high-energy absorption. Here we investigate disordered metamaterials obtained from random beam networks by optimizing simultaneously auxeticity and the energy absorbed before fracture. By giving different weights to these optimization targets, we demonstrate that the optimal configurations are connected along a Pareto front where high auxeticity implies comparatively low-energy absorption and vice versa. We study the mechanical properties of the resulting metamaterials and characterize the different deformation modes obtained for distinct optimization targets. The simulation and optimization results are validated by comparison with the deformation behavior of additively manufactured samples. Our work provides an illustration of the potentials and limitations of multiobjective optimization in the design of disordered mechanical metamaterials.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (34)

  1. M. Mir, M. N. Ali, J. Sami, and U. Ansari, Review of mechanics and applications of auxetic structures, Adv. Mater. Sci. Eng. 2014, 753496 (2014).
  2. V. H. Carneiro, J. Meireles, and H. Puga, Auxetic materials—A review, Mater. Sci.-Pol. 31, 561 (2013).
  3. K. E. Evans, Auxetic polymers: A new range of materials, Endeavour 15, 170 (1991).
  4. K. E. Evans and A. Alderson, Auxetic materials: Functional materials and structures from lateral thinking!, Adv. Mater. 12, 617 (2000).
  5. F. Scarpa, Auxetic materials for bioprostheses [In the Spotlight], IEEE Signal. Process. Mag. 25, 128 (2008).
  6. A. Alderson and K. L. Alderson, Auxetic materials, Proc. Inst. Mech. Eng. G: J. Aerosp. Eng. 221, 565 (2007).
  7. K. Bertoldi, V. Vitelli, J. Christensen, and M. Van Hecke, Flexible mechanical metamaterials, Nat. Rev. Mater. 2, 1 (2017).
  8. K. E. Evans, A. Alderson, and F. R. Christian, Auxetic two-dimensional polymer networks. An example of tailoring geometry for specific mechanical properties, J. Chem. Soc. Faraday Trans. 91, 2671 (1995).
  9. J. Schwerdtfeger, F. Wein, G. Leugering, R. F.. Singer, C. Körner, M. Stingl, and F. Schury, Design of auxetic structures via mathematical optimization, Adv. Mater. 23, 2650 (2011).
  10. M. Zaiser and S. Zapperi, Disordered mechanical metamaterials, Nat. Rev. Phys. 5, 679 (2023).
  11. M. Hanifpour, C. F. Petersen, M. J. Alava, and S. Zapperi, Mechanics of disordered auxetic metamaterials, Eur. Phys. J. B 91, 271 (2018).
  12. S. Bonfanti, S. Hiemer, R. Zulkarnain, R. Guerra, M. Zaiser, and S. Zapperi, Computational design of mechanical metamaterials, Nat. Comput. Sci. 4, 574 (2024).
  13. D. R. Reid, N. Pashine, J. M. Wozniak, H. M. Jaeger, A. J. Liu, S. R. Nagel, and J. J. de Pablo, Auxetic metamaterials from disordered networks, Proc. Natl. Acad. Sci. 115, E1384 (2018).
  14. M. Shen, M. A. Reyes-Martinez, L. A. Powell, M. A. Iadicola, A. Sharma, F. Byléhn, N. Pashine, E. P. Chan, C. L. Soles, H. M. Jaeger, and J. J. de Pablo, An autonomous design algorithm to experimentally realize three-dimensionally isotropic auxetic network structures without compromising density, npj Comput. Mater. 10, 1 (2024).
  15. M. A. Reyes-Martinez, E. P. Chan, C. L. Soles, E. Han, K. A. Murphy, H. M. Jaeger, D. R. Reid, and J. J. de Pablo, Tuning the mechanical impedance of disordered networks for impact mitigation, Soft Matter 18, 2039 (2022).
  16. S. Bonfanti, R. Guerra, F. Font-Clos, D. Rayneau-Kirkhope, and S. Zapperi, Automatic design of mechanical metamaterial actuators, Nat. Commun. 11, 4162 (2020).
  17. L. Beretta, S. Bonfanti, J. Fiocchi, F. Font-Clos, R. Guerra, A. Tuissi, and S. Zapperi, Automatic design of chiral mechanical metamaterials, APL Mater. 9, 101112 (2021).
  18. H. J. Herrmann, A. Hansen, and S. Roux, Fracture of disordered, elastic lattices in two dimensions, Phys. Rev. B 39, 637 (1989).
  19. M. J. Alava, P. K. V. V. Nukala, and S. Zapperi, Statistical models of fracture, Adv. Phys. 55, 349 (2006).
  20. P. K. V. V. Nukala, S. Zapperi, M. J. Alava, and S. Šimunović, Crack roughness in the two-dimensional random threshold beam model, Phys. Rev. E 78, 046105 (2008).
  21. L. Berthier, D. Coslovich, A. Ninarello, and M. Ozawa, Equilibrium sampling of hard spheres up to the jamming density and beyond, Phys. Rev. Lett. 116, 238002 (2016).
  22. Anshul D. S. Parmar, M. Ozawa, and L. Berthier, Ultrastable metallic glasses in silico, Phys. Rev. Lett. 125, 085505 (2020).
  23. S. Liebenstein, S. Sandfeld, and M. Zaiser, Size and disorder effects in elasticity of cellular structures: From discrete models to continuum representations, Int. J. Solids Struct. 146, 97 (2018).
  24. P. Chaudhuri, L. Berthier, and S. Sastry, Jamming transitions in amorphous packings of frictionless spheres occur over a continuous range of volume fractions, Phys. Rev. Lett. 104, 165701 (2010).
  25. I. Giagkiozis and P. J. Fleming, Methods for multi-objective optimization: An analysis, Inf. Sci. 293, 338 (2015).
  26. See Supplemental Material at http://link.aps.org/supplemental/10.1103/r66g-hyxx for details on specimen preparation, detection of the first damaged cells and image-based evaluation of Poisson’s ratio. Supplementary figures illustrating the comparison of fracture surfaces in non-optimized and optimized structures, large in-plane displacements during loading and force displacement curves for disordered networks with material heterogeneity.
  27. A. Detry, PoissonCalc, GitHub repository (2025), https://github.com/andrea199/PoissonCalc.
  28. D. Rayneau-Kirkhope, S. Bonfanti, and S. Zapperi, Density scaling in the mechanics of a disordered mechanical meta-material, Appl. Phys. Lett. 114, 111902 (2019).
  29. E. Berthier, M. A. Porter, and K. E. Daniels, Forecasting failure locations in 2-dimensional disordered lattices, Proc. Natl. Acad. Sci. 116, 16742 (2019).
  30. P. Moretti and M. Zaiser, Network analysis predicts failure of materials and structures, Proc. Natl. Acad. Sci. 116, 16666 (2019).
  31. M. Pournajar, M. Zaiser, and P. Moretti, Edge betweenness centrality as a failure predictor in network models of structurally disordered materials, Sci. Rep. 12, 11814 (2022).
  32. M. Treinish, I. Carvalho, G. Tsilimigkounakis, and N. Sá, Rustworkx: A high-performance graph library for python, J. Open Source Softw. 7, 3968 (2022).
  33. A. Detry, Replication data for: Fracture toughness and auxeticity in disordered metamaterials, UNIMI Dataverse. https://doi.org/doi:10.13130/RD_UNIMI/N9ENQ4 (2025).
  34. H. Holey, BeamNetworks, GitHub repository (2025), https://github.com/hannes-holey/BeamNetworks.
