Block encoding of the three-dimensional heterogeneous Poisson equation with application to fracture flow

Austin Pechan1,*, John Golden2,†, and Daniel O’Malley3

  • *Contact author: agp@berkeley.edu
  • †Contact author: golden@lanl.gov
PDF

Phys. Rev. Applied 25, 044038 – Published 15 April, 2026

DOI: https://doi.org/10.1103/mx5c-8vqk

Abstract

Quantum linear system (QLS) algorithms offer the potential to solve large-scale linear systems exponentially faster than classical methods. However, applying QLS algorithms to real-world problems remains challenging due to issues such as state preparation, data loading, and efficient information extraction. In this work, we study the feasibility of applying QLS algorithms to solve discretized three-dimensional (3D) heterogeneous Poisson equations, with specific examples relating to groundwater flow through geologic fracture networks. We explicitly construct a block encoding for the 3D heterogeneous Poisson matrix by leveraging the sparse local structure of the discretized operator. While classical solvers benefit from preconditioning, we show that block encoding the system matrix and preconditioner separately does not improve the effective condition number that dominates the QLS run-time. This differs from classical approaches where the preconditioner and the system matrix can often be implemented independently. Nevertheless, due to the structure of the problem in three dimensions, the quantum algorithm achieves a run-time of O(N2/3polylog N⋅log(1/ϵ)), outperforming the best classical methods (with run times of O(NlogN⋅log(1/ϵ))) and offering exponential memory savings. These results highlight both the promise and limitations of QLS algorithms for practical scientific computing, and point to effective condition-number reduction as a key barrier in achieving quantum advantages.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (25)

  1. Pedro C. S. Costa, Dong An, Yuval R. Sanders, Yuan Su, Ryan Babbush, and Dominic W. Berry, Optimal scaling quantum linear-systems solver via discrete adiabatic theorem, PRX Quantum 3, 040303 (2022).
  2. Alex Dalzell, A shortcut to an optimal quantum linear system solver, arXiv:2406.12086.
  3. Yu Tong, Dong An, Nathan Wiebe, and Lin Lin, Fast inversion, preconditioned quantum linear system solvers, fast Green’s-function computation, and fast evaluation of matrix functions, Phys. Rev. A 104, 032422 (2021).
  4. Pedro C. S. Costa, Dong An, Ryan Babbush, and Dominic Berry, The discrete adiabatic quantum linear system solver has lower constant factors than the randomized adiabatic solver, Quantum 9, 1887 (2025).
  5. Guang Hao Low and Yuan Su, Quantum linear system algorithm with optimal queries to initial state preparation, Quantum 10, 2041 (2026).
  6. Matthias Deiml and Dirk Peterseim, Quantum realization of the finite element method, Am. Math. Soc. 95 (2024).
  7. Davide Orsucci and Vedran Dunjko, On solving classes of positive-definite quantum linear systems with quadratically improved runtime in the condition number, Quantum 5, 573 (2021).
  8. Leigh Lapworth and Christoph Süunderhauf, Preconditioned block encodings for quantum linear systems, Quantum Sci. Technol. 10, 045064 (2025).
  9. Gilbert Strang, Computational Science and Engineering (Wellesley-Cambridge Press, Wellesley, MA, 2007).
  10. Jeffrey D. Hyman, Satish Karra, Nataliia Makedonska, Carl W. Gable, Scott L. Painter, and Hari S. Viswanathan, dfnWorks: A discrete fracture network framework for modeling subsurface flow and transport, Comput. Geosci. 84, 10 (2015).
  11. John Golden, Daniel O’Malley, and Hari Viswanathan, Quantum computing and preconditioners for hydrological linear systems, Sci. Rep. 12, 22285 (2022).
  12. Aram W. Harrow, Avinatan Hassidim, and Seth Lloyd, Quantum algorithm for linear systems of equations, Phys. Rev. Lett. 103, 150502 (2009).
  13. Jessie M. Henderson, John Kath, John K. Golden, Allon G. Percus, and Daniel O’Malley, Addressing quantum’s “fine print”: State preparation and information extraction for quantum algorithms and geologic fracture networks, Sci. Rep. 14, 3592 (2024).
  14. Christoph Sünderhauf, Earl Campbell, and Joan Camps, Block-encoding structured matrices for data input in quantum computing, Quantum 8, 1226 (2024).
  15. J. D. Hyman, G Aldrich, H Viswanathan, Nataliia Makedonska, and Satish Karra, Fracture size and transmissivity correlations: Implications for transport simulations in sparse three-dimensional discrete fracture networks following a truncated power law distribution of fracture size, Water Resour. Res. 52, 6472 (2016).
  16. Thomas Lubinski, Sonika Johri, Paul Varosy, Jeremiah Coleman, Luning Zhao, Jason Necaise, Charles Baldwin, Karl Mayer, and Timothy Proctor, Application-oriented performance benchmarks for quantum computing, IEEE Trans. Quantum Eng. 4, 1 (2023).
  17. Maxime Remaud, in Proceedings of Recent Advances in Quantum Computing and Technology, ReAQCT ’24 (Association for Computing Machinery, New York, NY, USA, 2024), pp. 56–61.
  18. Jefferson D. S. Silva and Adenilton J. da Silva, Logarithmic depth decomposition of approximate multi-controlled single-qubit gates without ancilla qubits, arXiv:2507.00400 [quant-ph].
  19. Sarah Greer, Jeffrey Hyman, and Daniel O’Malley, A comparison of linear solvers for resolving flow in three-dimensional discrete fracture networks, Water Resour. Res. 58, e2021WR031188 (2022).
  20. Frank Arute, Kunal Arya, Ryan Babbush, Dave Bacon, Joseph C. Bardin, Rami Barends, Rupak Biswas, Sergio Boixo, Fernando G. S. L. Brandao, David A. Buell et al., Quantum supremacy using a programmable superconducting processor, Nature 574, 505 (2019).
  21. Google Quantum AI and Collaborators, Quantum error correction below the surface code threshold, Nature 638, 920 (2025).
  22. L. Riesebos, X. Fu, S. Varsamopoulos, C. G. Almudever, and K. Bertels, in Proceedings of the 54th Annual Design Automation Conference 2017, DAC ’17 (Association for Computing Machinery, New York, NY, USA, 2017).
  23. Philippe Davy, Olivier Bour, J.-R. De Dreuzy, and Caroline Darcel, Flow in multiscale fractal fracture networks, Geological Society, London, Special Publications 261, 31 (2006).
  24. Alireza Jafari and Tayfun Babadagli, Estimation of equivalent fracture network permeability using fractal and statistical network properties, J. Petrol. Sci. Eng. 92, 110 (2012).
  25. Austin Pechan, Code for: Block encoding the 3D heterogeneous Poisson equation with application to fracture flow, https://github.com/Austin-Pechan/Block-encoding-the-3D-heterogeneous-Poisson-equation-with-application-to-fracture-flow, 2024.
