Spectral-crystal efficiency mapping: An analytical tool for visualizing the parametric conversion potential of broadband sources

Sebastian C. Robarts*, Derryck T. Reid, and Richard A. McCracken

  • *Contact author: scr2@hw.ac.uk
PDF

Phys. Rev. Applied 25, 034036 – Published 11 March, 2026

DOI: https://doi.org/10.1103/bpxv-v274

Abstract

Quasi-phase-matching in χ(2) media underpins many nonlinear conversion techniques, yet conventional sinc-squared gain models assume monochromatic pumps and wavelength-independent efficiency, limiting their accuracy for broadband sources. We introduce spectral-crystal efficiency mapping (SCEM), an analytical framework that combines input spectra with the nonlinear properties of a crystal to evaluate conversion potential. SCEM incorporates pump spectral profiles, higher-order interactions, and cascaded processes, providing an upper bound on efficiency that complements more computationally demanding numerical models. The resulting maps agree with experiment and simulation, while offering experimentalists an intuitive tool for assessing nonlinear gain media and guiding optimization of broadband frequency-conversion systems.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (27)

  1. R. W. Boyd, Nonlinear Optics (Academic Press, London, 2020).
  2. E. Allan, D. Bajek, and R. A. McCracken, Compact low-repetition-rate femtosecond optical parametric oscillators enabled by Herriott cells, Opt. Express 32, 24679 (2024).
  3. M. M. Coto and R. A. McCracken, Pellin-Broca prism chirped-pulse optical parametric oscillator, Opt. Contin. 3, 2165 (2024).
  4. J. Fan, C. Gu, C. Wang, and M. Hu, Extended femtosecond laser wavelength range to 330 nm in a high power LBO based optical parametric oscillator, Opt. Express 24, 13250 (2016).
  5. S. C. Kumar and M. Ebrahim-Zadeh, Yb-fiber-based, high-average-power, high-repetition-rate, picosecond source at 2.1 μm, Laser Photonics Rev. 10, 970 (2016).
  6. C. F. O’Donnell, S. C. Kumar, K. T. Zawilski, P. G. Schunemann, and M. Ebrahim-Zadeh, Critically phase-matched Ti:sapphire-laser-pumped deep-infrared femtosecond optical parametric oscillator based on CdSiP2, Opt. Lett. 43, 1507 (2018).
  7. H. Wu, Z. Zhang, S. Chen, K. Sun, J. Sun, D. Reid, Z. Lu, and J. Zhang, Development of a deep-ultraviolet pulse laser source operating at 234 nm for direct cooling of Al+ ion clocks, Opt. Express 29, 11468 (2021).
  8. G. Genty, P. Kinsler, B. Kibler, and J. M. Dudley, Nonlinear envelope equation modeling of sub-cycle dynamics and harmonic generation in nonlinear waveguides, Opt. Express 15, 5382 (2007).
  9. M. Conforti, F. Baronio, and C. De Angelis, Nonlinear envelope equation for broadband optical pulses in quadratic media, Phys. Rev. A 81, 053841 (2010).
  10. S. Robarts, D. Hunter, D. Reid, and R. McCracken, GPU-accelerated full-field modelling of highly dispersive ultrafast optical parametric oscillators, Opt. Express 31, 42624 (2023).
  11. T. Voumard, M. Ludwig, T. Wildi, F. Ayhan, V. Brasch, L. G. Villanueva, and T. Herr, Simulating supercontinua from mixed and cascaded nonlinearities, APL Photonics 8, 036114 (2023).
  12. O. Melchert and A. Demircan, py-fmas: A Python package for ultrashort optical pulse propagation in terms of forward models for the analytic signal, Comput. Phys. Commun. 273, 108257 (2022).
  13. N. Karpowicz, Open source, heterogeneous, nonlinear optics simulation, Opt. Contin. 2, 2244 (2023).
  14. R. Schiek and T. Pertsch, Absolute measurement of the quadratic nonlinear susceptibility of lithium niobate in waveguides, Opt. Mater. Express 2, 126 (2012).
  15. OptiFax - a GPU accelerated, full-field nonlinear optical facsimile, Github, https://github.com/McCrackenLab/OptiFax.
  16. 1040 nm femtosecond laser: Chromacity ultrafast lasers, https://web.archive.org/web/20250615181312/https://chromacitylasers.com/ultrafast-lasers/chromacity-1040/.
  17. R. A. McCracken and D. T. Reid, Few-cycle near-infrared pulses from a degenerate 1 GHz optical parametric oscillator, Opt. Lett. 40, 4102 (2015).
  18. G. K. Samanta, S. C. Kumar, M. Mathew, C. Canalias, V. Pasiskevicius, F. Laurell, and M. Ebrahim-Zadeh, High-power, continuous-wave, second-harmonic generation at 532 nm in periodically poled KTiOPO4, Opt. Lett. 33, 2955 (2008).
  19. K. Fradkin, A. Arie, A. Skliar, and G. Rosenman, Tunable midinfrared source by difference frequency generation in bulk periodically poled KTiOPO4, Appl. Phys. Lett. 74, 914 (1999).
  20. D. E. Hunter and R. A. McCracken, Ultrashort-pulsed optical parametric oscillator employing Brewster angle prism retroreflectors, Opt. Express 29, 37013 (2021).
  21. K. Balskus, Z. Zhang, R. A. McCracken, and D. T. Reid, Mid-infrared 333 MHz frequency comb continuously tunable from 1.95 to 4.0 μm, Opt. Lett. 40, 4178 (2015).
  22. K. A. Tillman, D. T. Reid, D. Artigas, and T. Y. Jiang, Idler-resonant femtosecond tandem optical parametric oscillator tuning from 2.1 μm to 4.2 μm, J. Opt. Soc. Am. B 21, 1551 (2004).
  23. X. Wu, L. Zhang, Z. Hao, R. Zhang, R. Ma, F. Bo, G. Zhang, and J. Xu, Broadband second-harmonic generation in step-chirped periodically poled lithium niobate waveguides, Opt. Lett. 47, 1574 (2022).
  24. J. Wang, X. Xue, J. Qiu, Y. Tang, R. Ye, Y. Zhang, Y. Huang, H. Li, S. Liu, Y. Zheng, and X. Chen, Chirped periodically poled lithium-niobate-on-insulator micro-waveguides for broadband second-harmonic generation, Opt. Lett. 49, 5348 (2024).
  25. L. Serino, W. Ridder, A. Bhattacharjee, J. Gil-Lopez, B. Brecht, and C. Silberhorn, Orchestrating time and color: A programmable source of high-dimensional entanglement, Opt. Quantum 2, 339 (2024).
  26. A. Dosseva, L. Cincio, and A. M. Brańczyk, Shaping the joint spectrum of down-converted photons through optimized custom poling, Phys. Rev. A 93, 013801 (2016).
  27. A. M. Brańczyk, A. Fedrizzi, T. M. Stace, T. C. Ralph, and A. G. White, Engineered optical nonlinearity for quantum light sources, Opt. Express 19, 55 (2011).
