Optical control of electron-spin texture based on modulation of spin-orbit interaction in a modulation-doped GaAs/(Al,Ga)As quantum well

Jun Ishihara1,*, Ryo Tokimitsu2, Takuya Suzuki2, Takachika Mori2, Makoto Kohda1, Yuzo Ohno3, and Kensuke Miyajima2

  • *Contact author: j.ishihara@tohoku.ac.jp
PDF

Phys. Rev. Applied 25, 034025 – Published 6 March, 2026

DOI: https://doi.org/10.1103/9n82-79tj

Abstract

We demonstrate the optical control of the spatial spin texture in a modulation-doped GaAs/AlGaAs quantum well based on the modulation of the spin-orbit interaction. Spatiotemporal evolution of electron spins with irradiation by a continuous-wave laser that does not induce interband transitions of electrons reveals an increase in the Rashba coefficient and the spin diffusion coefficient, in contrast to the decrease in these coefficients due to optical doping by increasing the electron-spin excitation density. From the difference between the absorption energy and the emission energy, the carrier density in the quantum well increases. This indicates that the continuous-wave laser irradiation causes photoactivation of naturally deactivated electrons in the doping layer of AlGaAs, and therefore the Rashba spin-orbit interaction increases due to the increased asymmetry of the quantum well profile.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (34)

  1. J. Schliemann and D. Loss, Anisotropic transport in a two-dimensional electron gas in the presence of spin-orbit coupling, Phys. Rev. B 68, 165311 (2003).
  2. B. A. Bernevig, J. Orenstein, and S.-C. Zhang, Exact SU(2) symmetry and persistent spin helix in a spin-orbit coupled system, Phys. Rev. Lett. 97, 236601 (2006).
  3. M. Dyakonov and V. I. Perel, Spin orientation of electrons associated with the interband absorption of light in semiconductors, Sov. J. Exp. Theor. Phys. 33, 1053 (1971).
  4. E. Rashba, Properties of semiconductors with an extremum loop. I. Cyclotron and combinational resonance in a magnetic field perpendicular to the plane of the loop, Sov. Phys.-Solid State 2, 1109 (1960).
  5. G. Dresselhaus, Spin-orbit coupling effects in zinc blende structures, Phys. Rev. 100, 580 (1955).
  6. M. P. Walser, C. Reichl, W. Wegscheider, and G. Salis, Direct mapping of the formation of a persistent spin helix, Nat. Phys. 8, 757 (2012).
  7. J. Ishihara, Y. Ohno, and H. Ohno, Direct imaging of gate-controlled persistent spin helix state in a modulation-doped GaAs/AlGaAs quantum well, Appl. Phys. Express 7, 013001 (2013).
  8. J. Ishihara, Y. Ohno, and H. Ohno, Direct mapping of photoexcited local spins in a modulation-doped GaAs/AlGaAs wires, Jpn. J. Appl. Phys. 53, 04EM04 (2014).
  9. Y. Kunihashi, H. Sanada, H. Gotoh, K. Onomitsu, M. Kohda, J. Nitta, and T. Sogawa, Drift transport of helical spin coherence with tailored spin-orbit interactions, Nat. Commun. 7, 10722 (2016).
  10. F. Passmann, S. Anghel, T. Tischler, A. V. Poshakinskiy, S. A. Tarasenko, G. Karczewski, T. Wojtowicz, A. D. Bristow, and M. Betz, Persistent spin helix manipulation by optical doping of a CdTe quantum well, Phys. Rev. B 97, 201413 (2018).
  11. M. Kohda and G. Salis, Physics and application of persistent spin helix state in semiconductor heterostructures, Semicond. Sci. Technol. 32, 073002 (2017).
  12. M. Kohda, T. Seki, Y. Yuminaka, T. Uemura, K. Kikuchi, and G. Salis, Perspective on spin-based wave-parallel computing, Appl. Phys. Lett. 123, 190502 (2023).
  13. J. D. Koralek, C. P. Weber, J. Orenstein, B. A. Bernevig, S.-C. Zhang, S. Mack, and D. D. Awschalom, Emergence of the persistent spin helix in semiconductor quantum wells, Nature 458, 610 (2009).
  14. C. P. Weber, J. Orenstein, B. A. Bernevig, S.-C. Zhang, J. Stephens, and D. D. Awschalom, Nondiffusive spin dynamics in a two-dimensional electron gas, Phys. Rev. Lett. 98, 076604 (2007).
  15. J. Ishihara, T. Mori, T. Suzuki, S. Sato, K. Morita, M. Kohda, Y. Ohno, and K. Miyajima, Imprinting spatial helicity structure of vector vortex beam on spin texture in semiconductors, Phys. Rev. Lett. 130, 126701 (2023).
  16. K. Kikuchi, J. Ishihara, M. Hiyama, S. Yamamoto, Y. Ohno, T. Mori, K. Miyajima, and M. Kohda, Direct imprinting of arbitrary spin helices using programmable structured light in a semiconductor two-dimensional electron gas, Phys. Rev. Appl. 23, 044017 (2025).
  17. J. Nitta, T. Akazaki, H. Takayanagi, and T. Enoki, Gate control of spin-orbit interaction in an inverted In0.53Ga0.47As/In0.52Al0.48As heterostructure, Phys. Rev. Lett. 78, 1335 (1997).
  18. M. Kohda, V. Lechner, Y. Kunihashi, T. Dollinger, P. Olbrich, C. Schönhuber, I. Caspers, V. V. Bel'kov, L. E. Golub, D. Weiss, K. Richter, J. Nitta, and S. D. Ganichev, Gate-controlled persistent spin helix state in (In,Ga)As quantum wells, Phys. Rev. B 86, 081306(R) (2012).
  19. S. Anghel, A. V. Poshakinskiy, K. Schiller, G. Yusa, T. Mano, T. Noda, and M. Betz, Spin helices in GaAs quantum wells: Interplay of electron density, spin diffusion, and spin lifetime, J. Appl. Phys. 132, 054301 (2022).
  20. R. Tokimitsu, T. Mori, J. Ishihara, M. Kohda, Y. Ohno, and K. Miyajima, Effect of photoexcited carrier density on spin diffusion coefficient and helical spin lifetime, Phys. Rev. Res. 7, 023072 (2025).
  21. L. M. Weegels, J. E. Haverkort, M. R. Leys, and J. H. Wolter, Band-structure modifications due to photogenerated carriers in a GaAs/AlxGa1−xAs heterostructure, Phys. Rev. B 46, 3886 (1992).
  22. S. R. Andrews, A. S. Plaut, R. T. Harley, and T. M. Kerr, Optical studies of electron and hole Fermi seas in a single GaAs/AlxGa1−xAs quantum well, Phys. Rev. B 41, 5040 (1990).
  23. K. Flensberg, T. Stibius Jensen, and N. Asger Mortensen, Diffusion equation and spin drag in spin-polarized transport, Phys. Rev. B 64, 245308 (2001).
  24. I. D’Amico and G. Vignale, Spin Coulomb drag in the two-dimensional electron liquid, Phys. Rev. B 68, 045307 (2003).
  25. I. D’Amico and G. Vignale, Theory of spin Coulomb drag in spin-polarized transport, Phys. Rev. B 62, 4853 (2000).
  26. C. P. Weber, N. Gedik, J. E. Moore, J. Orenstein, J. Stephens, and D. D. Awschalom, Observation of spin Coulomb drag in a two-dimensional electron gas, Nature 437, 1330 (2005).
  27. L. Yang, J. D. Koralek, J. Orenstein, D. R. Tibbetts, J. L. Reno, and M. P. Lilly, Doppler velocimetry of spin propagation in a two-dimensional electron gas, Nat. Phys. 8, 153 (2011).
  28. W. J. H. Leyland, R. T. Harley, M. Henini, A. J. Shields, I. Farrer, and D. A. Ritchie, Energy-dependent electron-electron scattering and spin dynamics in a two-dimensional electron gas, Phys. Rev. B 77, 205321 (2008).
  29. J. Ishihara, T. Suzuki, G. Kitazawa, T. Mori, Y. Ohno, and K. Miyajima, Spatiotemporal spin dynamics of two-dimensional electron gas with ballistic motion in persistent spin helix state, Phys. Rev. B 105, 144412 (2022).
  30. Y.-W. Tan, J. Zhu, H. L. Stormer, L. N. Pfeiffer, K. W. Baldwin, and K. W. West, Spin susceptibility of a two-dimensional electron system in GaAs towards the weak interaction region, Phys. Rev. B 73, 045334 (2006).
  31. W. J. H. Leyland, G. H. John, R. T. Harley, M. M. Glazov, E. L. Ivchenko, D. A. Ritchie, I. Farrer, A. J. Shields, and M. Henini, Enhanced spin-relaxation time due to electron-electron scattering in semiconductor quantum wells, Phys. Rev. B 75, 165309 (2007).
  32. K. Hirakawa and H. Sakaki, Mobility of the two-dimensional electron gas at selectively doped n-type AlxGa1−xAs/GaAs heterojunctions with controlled electron concentrations, Phys. Rev. B Condens. Matter 33, 8291 (1986).
  33. E. H. Hwang and S. Das Sarma, Limit to two-dimensional mobility in modulation-doped GaAs quantum structures: How to achieve a mobility of 100 million, Phys. Rev. B 77, 235437 (2008).
  34. M. P. Walser, U. Siegenthaler, V. Lechner, D. Schuh, S. D. Ganichev, W. Wegscheider, and G. Salis, Dependence of the Dresselhaus spin-orbit interaction on the quantum well width, Phys. Rev. B 86, 195309 (2012).
