Security of the BB84 protocol with passive biased basis choice by the receiver

Shun Kawakami1,2,*, Atsushi Taniguchi1, Yoshihide Tonomura1, Koichi Takasugi1, and Koji Azuma3,2

  • 1Network Innovation Laboratories, NTT Inc., 1-1 Hikari-no-oka, Yokosuka, Kanagawa 239-0847, Japan
  • 2NTT Research Center for Theoretical Quantum Information, NTT Inc., 3-1 Morinosato Wakamiya, Atsugi, Kanagawa 243-0198, Japan
  • 3Basic Research Laboratories, NTT Inc., 3-1 Morinosato Wakamiya, Atsugi, Kanagawa 243-0198, Japan

  • *Contact author: shun.kawakami@ntt.com
PDF

Phys. Rev. Applied 24, 054070 – Published 24 November, 2025

DOI: https://doi.org/10.1103/2pzb-ssrs

Abstract

The Bennett-Brassard 1984 (BB84) protocol is one of the simplest protocols for implementing quantum key distribution (QKD). In the protocol, the sender and the receiver iteratively choose one of two complementary measurement bases. Regarding the basis choice by the receiver, a passive setup has been adopted in a number of its implementations, including satellite QKD and time-bin encoding. However, conventional theoretical techniques to prove the security of the BB84 protocol are not applicable if the receiver chooses their measurement basis passively, rather than actively, with a biased probability, followed by measurement with threshold detectors. Here we present a fully analytical security proof against coherent attacks for such a decoy-state BB84 protocol with the receiver’s passive basis choice and measurement with threshold detectors. Numerical simulations under practical situations show that the difference in secure key rate between the active and passive implementations of the protocol is negligible except for long communication distances.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (35)

  1. C. H. Bennett and G. Brassard, in Proceedings of IEEE International Conference on Computers, Systems and Signal Processing, Bangalore, India (IEEE Press, New York, 1984), Vol. 175.
  2. W.-Y. Hwang, Quantum key distribution with high loss: Toward global secure communication, Phys. Rev. Lett. 91, 057901 (2003).
  3. X.-B. Wang, Beating the photon-number-splitting attack in practical quantum cryptography, Phys. Rev. Lett. 94, 230503 (2005).
  4. H.-K. Lo, X. Ma, and K. Chen, Decoy state quantum key distribution, Phys. Rev. Lett. 94, 230504 (2005).
  5. X.-B. Wang, Decoy-state protocol for quantum cryptography with four different intensities of coherent light, Phys. Rev. A 72, 012322 (2005).
  6. N. J. Beaudry, T. Moroder, and N. Lütkenhaus, Squashing models for optical measurements in quantum communication, Phys. Rev. Lett. 101, 093601 (2008).
  7. T. Tsurumaru and K. Tamaki, Security proof for quantum-key-distribution systems with threshold detectors, Phys. Rev. A 78, 032302 (2008).
  8. M. Koashi, Efficient quantum key distribution with practical sources and detectors, ArXiv:quant-ph/0609180.
  9. M. Koashi, Simple security proof of quantum key distribution based on complementarity, New J. Phys. 11, 045018 (2009).
  10. M. Tomamichel and R. Renner, Uncertainty relation for smooth entropies, Phys. Rev. Lett. 106, 110506 (2011).
  11. H.-K. Lo, H. Chau, and M. Ardehali, Efficient quantum key distribution scheme and a proof of its unconditional security, J. Cryptol. 18, 133 (2004).
  12. S.-K. Liao, et al., Satellite-to-ground quantum key distribution, Nature 549, 43 (2017).
  13. S. Sivasankaran, C. Liu, M. Mihm, and A. Ling, in 2022 IEEE International Conference on Space Optical Systems and Applications (ICSOS) (IEEE, Kyoto, Japan, 2022), p. 51.
  14. T. Roger, R. Singh, C. Perumangatt, D. G. Marangon, M. Sanzaro, P. R. Smith, R. I. Woodward, and A. J. Shields, Real-time gigahertz free-space quantum key distribution within an emulated satellite overpass, Sci. Adv. 9, eadj5873 (2023).
  15. Y. Li, et al., Microsatellite-based real-time quantum key distribution, Nature 640, 47 (2025).
  16. H.-L. Yin, P. Liu, W.-W. Dai, Z.-H. Ci, J. Gu, T. Gao, Q.-W. Wang, and Z.-Y. Shen, Experimental composable security decoy-state quantum key distribution using time-phase encoding, Opt. Express 28, 29479 (2020).
  17. D. Scalcon, C. Agnesi, M. Avesani, L. Calderaro, G. Foletto, A. Stanco, G. Vallone, and P. Villoresi, Cross-encoded quantum key distribution exploiting time-bin and polarization states with qubit-based synchronization, Adv. Quantum Technol. 5, 2200051 (2022).
  18. Y.-L. Tang, et al., Time-bin phase-encoding quantum key distribution using Sagnac-based optics and compatible electronics, Opt. Express 31, 26335 (2023).
  19. F. Grünenfelder, A. Boaron, G. V. Resta, M. Perrenoud, D. Rusca, C. Barreiro, R. Houlmann, R. Sax, L. Stasi, S. El-Khoury, E. Hänggi, N. Bosshard, F. Bussières, and H. Zbinden, Fast single-photon detectors and real-time key distillation enable high secret-key-rate quantum key distribution systems, Nat. Photonics 17, 422 (2023).
  20. S. Francesconi, C. De Lazzari, D. Ribezzo, I. Vagniluca, N. Biagi, T. Occhipinti, A. Zavatta, and D. Bacco, Scalable implementation of temporal and phase encoding QKD with phase-randomized states, Adv. Quantum Technol. 7, 2300224 (2024).
  21. L. Kamin and N. Lütkenhaus, Improved decoy-state and flag-state squashing methods, Phys. Rev. Res. 6, 043223 (2024).
  22. D. Tupkary, E. Y. Z. Tan, S. Nahar, L. Kamin, and N. Lütkenhaus, QKD security proofs for decoy-state BB84: Protocol variations, proof techniques, gaps and limitations, ArXiv:2502.10340.
  23. Y. Zhang, P. J. Coles, A. Winick, J. Lin, and N. Lütkenhaus, Security proof of practical quantum key distribution with detection-efficiency mismatch, Phys. Rev. Res. 3, 013076 (2021).
  24. L. Kamin, D. Tupkary, and N. Lütkenhaus, Improved finite-size effects in QKD protocols with applications to decoy-state QKD, ArXiv:2502.05382.
  25. L. Kamin, J. Burniston, and E. Y. Z. Tan, Rényi security framework against coherent attacks applied to decoy-state QKD, ArXiv:2504.12248.
  26. G. Brassard, N. Lütkenhaus, T. Mor, and B. C. Sanders, Limitations on practical quantum cryptography, Phy. Rev. Lett. 85, 1330 (2000).
  27. X. Ma, B. Qi, Y. Zhao, and H.-K. Lo, Practical decoy state for quantum key distribution, Phys. Rev. A 72, 012326 (2005).
  28. Y. Sanari, A. Taniguchi, M. Miura, H. Takahashi, K. Takasugi, H.-P. Lo, T. Ikuta, T. Honjo, and H. Takesue, in 2024 Conference on Lasers and Electro-Optics Pacific Rim (CLEO-PR) (Optica Publishing Group, Incheon, Korea, 2024).
  29. Y. Luo, X. Cheng, H.-K. Mao, and Q. Li, An overview of postprocessing in quantum key distribution, Mathematics 12, 2243 (2024).
  30. B. Li, Y. Niu, Y. Feng, and X. Chen, Ultra-low dark count InGaAs/InP single photon avalanche diode, Optoelectron. Lett. 18, 647 (2022).
  31. G. Kato, Concentration inequality using unconfirmed knowledge, ArXiv:2002.04357.
  32. W. Wang, R. Wang, C. Hu, V. Zapatero, L. Qian, B. Qi, M. Curty, and H.-K. Lo, Fully passive quantum key distribution, Phys. Rev. Lett. 130, 220801 (2023).
  33. V. Zapatero, W. Wang, and M. Curty, A fully passive transmitter for decoy-state quantum key distribution, Quantum Sci. Technol. 8, 025014 (2023).
  34. V. Zapatero and M. Curty, Finite-key security of passive quantum key distribution, Phys. Rev. Appl. 21, 014018 (2024).
  35. Z. Wang, D. Tupkary, and S. Nahar, Phase error estimation for passive detection setups with imperfections and memory effects, ArXiv:2508.21486.
