Impact of coherent wiggler radiation impedance in Tau-Charm factories

Tianlong He1,*, Ye Zou2,†, Demin Zhou3,4,‡, Hao Zhou2, Hangzhou Li1, Linhao Zhang2, Tao Liu2, Weiwei Li1, and Jingyu Tang1,2

  • *Contact author: htlong@ustc.edu.cn
  • †Contact author: zouye@ustc.edu.cn
  • ‡Contact author: dmzhou@post.kek.jp
PDF

Phys. Rev. Accel. Beams 28, 101002 – Published 27 October, 2025

DOI: https://doi.org/10.1103/yqdj-r617

Abstract

Coherent synchrotron radiation (CSR) has long been recognized as a significant source of longitudinal impedance driving microwave instability in electron storage rings. In the pursuit of higher luminosity, next-generation circular e+e− colliders operating in the few-GeV energy range, such as B-factories and Tau-Charm factories, are being designed with low-emittance beams and high beam currents. Damping wigglers are commonly introduced to reduce damping times and control beam emittance. In this study, we systematically investigate the impact of coherent wiggler radiation (CWR), a specific form of CSR generated within wigglers, on beam stability in Tau-Charm factories. We revisit the threshold conditions for CWR-induced microwave instability and evaluate its effects under realistic lattice configurations of collider rings. Furthermore, we examine theoretical models of longitudinal CWR impedance and identify improved formulations that better capture its influence. As an illustrative example, the developed CWR impedance models are applied to simulate beam stability in the Super Tau-Charm Facility currently under design in China.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (30)

  1. Sara Dastan, Demin Zhou, Takuya Ishibashi, Emanuel Karantzoulis, Simone Di Mitri, and Ryan Lindberg, Coherent synchrotron radiation instability in low-emittance electron storage rings, Phys. Rev. Accel. Beams 27, 104401 (2024).
  2. Juhao Wu, Tor O. Raubenheimer, and Gennady V. Stupakov, Calculation of the coherent synchrotron radiation impedance from a wiggler, Phys. Rev. ST Accel. Beams 6, 040701 (2003).
  3. Juhao Wu, G. V.Stupakov, T. O. Raubenheimer, and Zhirong Huang, Impact of the wiggler coherent synchrotron radiation impedance on the beam instability and damping ring optimization, Phys. Rev. ST Accel. Beams 6, 104404 (2003).
  4. A. Blednykh, M. Blaskiewicz, R. Lindberg, and D. Zhou, Microwave instability threshold from coherent wiggler radiation impedance in storage rings, Phys. Rev. Accel. Beams 26, 051002 (2023).
  5. SuperB Collaboration et al., SuperB: A high-luminosity asymmetric e+e− super flavor factory. Conceptual design report, arXiv:0709.0451.
  6. SuperKEKB design report, https://kds.kek.jp/event/15914/.
  7. M. E. Biagini, R. Boni, M. Boscolo, A. Chiarucci, R. Cimino, A. Clozza, A. Drago, S. Guiducci, C. Ligi, G. Mazzitelli et al., Tau/Charm factory accelerator report, arXiv:1310.6944.
  8. V. V. Anashin et al., Super Charm-Tau factory: Conceptual design report, Technical Report, Budker Institute of Nuclear Physics, Novosibirsk, Russia, 2018.
  9. Qing Luo, Weiwei Gao, Jieqin Lan, Wei Li, Xu Derong et al., Progress of conceptual study for the accelerators of a 2–7 GeV super Tau Charm facility at China, in Proceedings of the 10th International Particle Accelerator Conference (IPAC-2019), Melbourne, Australia (JACoW, Geneva, Switzerland, 2019), pp. 643–645.
  10. CEPC Study Group et al., CEPC conceptual design report: Volume 1-accelerator, arXiv:1809.00285.
  11. FCC Collaboration et al., FCC-ee: The lepton collider: Future circular collider conceptual design report volume 2, Eur. Phys. J. Special Topics 228, 261 (2019).
  12. P.Raimondi, Status on SuperB effort, in 2nd SuperB Workshop (INFN-LNF, Frascati, 2006).
  13. M. Zobov, D. Alesini, M. E. Biagini, C. Biscari, A. Bocci, R. Boni, M. Boscolo, F. Bossi, B. Buonomo, A. Clozza et al., Test of “crab-waist” collisions at the DAϕNE ϕ factory, Phys. Rev. Lett. 104, 174801 (2010).
  14. Gennady Stupakov and Demin Zhou, Analytical theory of coherent synchrotron radiation wakefield of short bunches shielded by conducting parallel plates, Phys. Rev. Accel. Beams 19, 044402 (2016).
  15. D. Boussard, Observation of microwave longitudinal instability in the CPS, Technical Report No. CERN Lab II/RF/Int./75-2, CERN, Geneva, 1975.
  16. Andrzej Wolski, Dynamics in High Energy Particle Accelerators (World Scientific, Singapore, 2023), Vol. 6.
  17. G. Stupakov and S. Heifets, Beam instability and microbunching due to coherent synchrotron radiation, Phys. Rev. ST Accel. Beams 5, 054402 (2002).
  18. Y. Cai, Theory of microwave instability and coherent synchrotron radiation in electron storage rings, in Proceedings of the IPAC-2011, Number 2 in International Particle Accelerator Conference (JACoW, Geneva, Switzerland, 2011), Vol. 9, pp. 3774–3778.
  19. Demin Zhou, Coherent synchrotron radiation and microwave instability in electron storage rings, Ph.D. thesis, The Graduate University for Advanced Studies, 2011.
  20. T. Agoh and K. Yokoya, Calculation of coherent synchrotron radiation using mesh, Phys. Rev. ST Accel. Beams 7, 054403 (2004).
  21. Marco Venturini, Robert Warnock, Ronald Ruth, and James A. Ellison, Coherent synchrotron radiation and bunch stability in a compact storage ring, Phys. Rev. ST Accel. Beams 8, 014202 (2005).
  22. Andris Faltens and L. Jackson Laslett, Longitudinal coupling impedance of a stationary electron ring in a cylindrical geometry, Part. Accel. 4, 151 (1973), https://cds.cern.ch/record/1107915.
  23. Paul Emma and Tor Raubenhemier, Systematic approach to damping ring design, Phys. Rev. ST Accel. Beams 4, 021001 (2001).
  24. Andy Wolski, The accelerator physics of linear collider damping rings, in Notes for USPAS Course on Linear Colliders (U.S. Particle Accelerator School, Santa Barbara, CA, 2003).
  25. Y. Zou, Physics design of the STCF collider rings, in Proceedings of the 70th ICFA Advanced Beam Dynamics Workshop on High Luminosity Circular e+e− Colliders (eeFACT 2025), Tsukuba, Ibaraki, Japan (JACoW, Geneva, Switzerland, 2025), https://indico.jacow.org/event/75.
  26. L. Zhang, Optics design of the interaction region for the STCF, in Proceedings of the 70th ICFA Advanced Beam Dynamics Workshop on High Luminosity Circular e+e− Colliders (eeFACT 2025), Tsukuba, Ibaraki, Japan (JACoW, Geneva, Switzerland, 2025), https://indico.jacow.org/event/75.
  27. Ye Zou, Linhao Zhang, Tao Liu, Penghui Yang, Weiwei Li, Tianlong He, Demin Zhou, Kazuhito Ohmi, Sangya Li, Ze Yu, Yihao Mo, Hangzhou Li, Hao Zhou, Jiajun Gao, Zeyuan Meng, Qing Luo, Lei Wang, Youjin Yuan, and Jingyu Tang, Optics design of the super Tau-Charm facility collider rings, arXiv:2507.18924.
  28. Tianlong He and Zhenghe Bai, Graphics-processing-unit-accelerated simulation for longitudinal beam dynamics of arbitrary bunch trains in electron storage rings, Phys. Rev. Accel. Beams 24, 104401, 2021).
  29. Weiwei Li, Tianlong He, and Zhenghe Bai, Terahertz scale microbunching instability driven by high resistivity nonevaporable getter coating resistive-wall impedance, Phys. Rev. Accel. Beams 27, 034401 (2024).
  30. Miriam Brosi, Julian Gethmann, A. Bernhard, Benjamin Kehrer, A. Papash, P. Schönfeldt, Patrick Schreiber, J. L. Steinmann, and A. S. Müller, Studies of the micro-bunching instability in the presence of a damping wiggler, J. Phys. Conf. Ser. 1067, 062017 (2018).
