Imaging calculation of coherent transition radiation Michelson interferometry for adaptive bunch profile reconstruction

K. Huang1,2,*, G. Andonian1, A. Fukasawa1, O. Williams1, P. Manwani1, and J. Rosenzweig1

  • *Contact author: huang.kai@qst.go.jp
PDF

Phys. Rev. Accel. Beams 29, 074101 – Published 29 July, 2026

DOI: https://doi.org/10.1103/v5xw-2nz6

Abstract

We present a methodological study for measuring electron-bunch temporal profiles using coherent transition radiation Michelson interferometry. A numerical frequency-filter model is established through imaging calculations of the experimental setup, accounting for the electron-bunch transverse profile, finite angular acceptance, and detector size. An adaptive genetic-algorithm-based forward-fitting approach is implemented to retrieve arbitrary bunch temporal profiles, demonstrating advantages over the classical Kramers-Kronig minimum-phase method. The frequency-filter model, together with the adaptive fitting framework, provides a robust tool for electron-bunch temporal profile characterization in beam physics studies.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (55)

  1. P. Chen, J. M. Dawson, R. W. Huff, and T. Katsouleas, Phys. Rev. Lett. 54, 693 (1985).
  2. J. B. Rosenzweig, Phys. Rev. Lett. 58, 555 (1987).
  3. J. B. Rosenzweig, D. B. Cline, B. Cole, H. Figueroa, W. Gai, R. Konecny, J. Norem, P. Schoessow, and J. Simpson, Phys. Rev. Lett. 61, 98 (1988).
  4. I. Blumenfeld, C. E. Clayton, F.-J. Decker, M. J. Hogan, C. Huang, R. Ischebeck, R. Iverson, C. Joshi, T. Katsouleas, N. Kirby et al., Nature (London) 445, 741 (2007).
  5. E. Adli, A. Ahuja, O. Apsimon, R. Apsimon, A.-M. Bachmann, D. Barrientos, F. Batsch, J. Bauche, V. Berglyd Olsen, M. Bernardini et al., Nature (London) 561, 363 (2018).
  6. P. Emma, R. Akre, J. Arthur, R. Bionta, C. Bostedt, J. Bozek, A. Brachmann, P. Bucksbaum, R. Coffee, F.-J. Decker et al., Nat. Photonics 4, 641 (2010).
  7. T. Ishikawa, H. Aoyagi, T. Asaka, Y. Asano, N. Azumi, T. Bizen, H. Ego, K. Fukami, T. Fukui, Y. Furukawa et al., Nat. Photonics 6, 540 (2012).
  8. K. Yun, S. Kim, D. Kim, M. Chung, W. Jo, H. Hwang, D. Nam, S. Kim, J. Kim, S.-Y. Park et al., Sci. Rep. 9, 3300 (2019).
  9. W. Decking, S. Abeghyan, P. Abramian, A. Abramsky, A. Aguirre, C. Albrecht, P. Alou, M. Altarelli, P. Altmann, K. Amyan et al., Nat. Photonics 14, 391 (2020).
  10. V. Yakimenko, S. Meuren, F. Del Gaudio, C. Baumann, A. Fedotov, F. Fiuza, T. Grismayer, M. J. Hogan, A. Pukhov, L. O. Silva, and G. White, Phys. Rev. Lett. 122, 190404 (2019).
  11. W. Zhang, T. Grismayer, and L. O. Silva, Phys. Rev. Accel. Beams 28, 091001 (2025).
  12. K. Akai, K. Furukawa, H. Koiso, and S. accelerator team, Nucl. Instrum. Methods Phys. Res., Sect. A 907, 188 (2018).
  13. J. D. Jackson, Classical Electrodynamics, 3rd ed. (Wiley, New York, 1999).
  14. M. L. Ter-Mikaelian, High-Energy Electromagnetic Processes in Condensed Media (John Wiley & Sons, New York, 1972), Vol. 29.
  15. A. H. Lumpkin, B. X. Yang, W. J. Berg, Y. C. Chae, N. S. Sereno, R. J. Dejus, C. Benson, and E. Moog, Nucl. Instrum. Methods Phys. Res., Sect. A 475, 462 (2001).
  16. E. Chiadroni, A. Cianchi, M. Ferrario, A. Mostacci, R. Pompili, and V. Shpakov, Condens. Matter 5, 40 (2020).
  17. B. Schmidt, N. M. Lockmann, P. Schmüser, and S. Wesch, Phys. Rev. Accel. Beams 23, 062801 (2020).
  18. O. Zarini, J. C. Cabadağ, Y.-Y. Chang, A. Köhler, T. Kurz, S. Schöbel, W. Seidel, M. Bussmann, U. Schramm, A. Irman, and A. Debus, Phys. Rev. Accel. Beams 25, 012801 (2022).
  19. R. Lai, U. Happek, and A. J. Sievers, Phys. Rev. E 50, R4294 (1994).
  20. Q. Tian, Y. Du, H. Xu, Y. Liang, Y. Wang, Y. Tan, L. Yan, R. Li, C. Cheng, W. Huang, and C. Tang, Phys. Rev. Accel. Beams 23, 102802 (2020).
  21. W. Barry, in Proceedings of the workshop on advanced beam instrumentation, KEK-PROC–91-2 (v. 1) (High Energy Accelerator Research Organization (KEK), Tsukuba, Japan, 1991), pp. 224–235.
  22. H.-C. Lihn, P. Kung, C. Settakorn, H. Wiedemann, and D. Bocek, Phys. Rev. E 53, 6413 (1996).
  23. A. Murokh, J. B. Rosenzweig, M. Hogan, H. Suk, G. Travish, and U. Happek, Nucl. Instrum. Methods Phys. Res., Sect. A 410, 452 (1998).
  24. T. Watanabe, M. Uesaka, J. Sugahara, T. Ueda, K. Yoshii, Y. Shibata, F. Sakai, S. Kondo, M. Kando, H. Kotaki, and K. Nakajima, Nucl. Instrum. Methods Phys. Res., Sect. A 437, 1 (1999).
  25. I. Nozawa, K. Kan, J. Yang, A. Ogata, T. Kondoh, M. Gohdo, K. Norizawa, H. Kobayashi, H. Shibata, S. Gonda, and Y. Yoshida, Phys. Rev. ST Accel. Beams 17, 072803 (2014).
  26. X. J. Wang, X. Qiu, and I. Ben-Zvi, Phys. Rev. E 54, R3121 (1996).
  27. O. Williams, A. Fukasawa, Y. Sakai, G. Andonian, F. Bosco, M. Carillo, P. Manwani, S. O’Tool, J. Pan, M. Yadav et al., Instruments 7, 54 (2023).
  28. C. M. Scoby, P. Musumeci, J. T. Moody, and M. S. Gutierrez, Phys. Rev. ST Accel. Beams 13, 022801 (2010).
  29. T. Tajima and J. M. Dawson, Phys. Rev. Lett. 43, 267 (1979).
  30. J. Faure, Y. Glinec, A. Pukhov, S. Kiselev, S. Gordienko, E. Lefebvre, J.-P. Rousseau, F. Burgy, and V. Malka, Nature (London) 431, 541 (2004).
  31. C. G. R. Geddes, C. Toth, J. van Tilborg, E. Esarey, C. B. Schroeder, D. Bruhwiler, C. Nieter, J. Cary, and W. P. Leemans, Nature (London) 431, 538 (2004).
  32. S. P. Mangles, C. Murphy, Z. Najmudin, A. G. R. Thomas, J. Collier, A. E. Dangor, E. Divall, P. Foster, J. Gallacher, C. Hooker et al., Nature (London) 431, 535 (2004).
  33. A. D. Debus et al., Phys. Rev. Lett. 104, 084802 (2010).
  34. J. van Tilborg, C. B. Schroeder, C. V. Filip, C. Tóth, C. G. R. Geddes, G. Fubiani, R. Huber, R. A. Kaindl, E. Esarey, and W. P. Leemans, Phys. Rev. Lett. 96, 014801 (2006).
  35. K. Huang, Z. Jin, N. Nakanii, T. Hosokai, and M. Kando, Light Sci. Appl. 13, 84 (2024).
  36. S. Casalbuoni, B. Schmidt, and P. Schmusuer, TESLA FEL Reports, 2005-15, 2005.
  37. S. Casalbuoni, B. Schmidt, P. Schmüser, and B. Steffen, TESLA FEL Reports, 2006-4, 2006.
  38. D. Xiang and W.-H. Huang, Nucl. Instrum. Methods Phys. Res., Sect. A 570, 357 (2007).
  39. M. Castellano and V. A. Verzilov, Phys. Rev. ST Accel. Beams 1, 062801 (1998).
  40. A. Potylitsyn, L. Sukhikh, T. Gusvitskii, G. Kube, and A. Novokshonov, Phys. Rev. Accel. Beams 23, 042804 (2020).
  41. M. Mitchell, An Introduction to Genetic Algorithms (MIT Press, Cambridge, MA, 1998).
  42. R. Lai and A. J. Sievers, Phys. Rev. E 50, R3342 (1994).
  43. B. Schmidt, S. Wesch, C. Behrens, T. Koevener, E. Hass, S. Casalbuoni, and P. Schmüser, Deutsches Elektronen-Synchrotron (DESY), Technical Report, 2018.
  44. K. Huang, Z. Jin, N. Nakanii, T. Hosokai, and M. Kando, Phys. Rev. Accel. Beams 26, 112801 (2023).
  45. B. S.-Y. Ung, C. Fumeaux, H. Lin, B. M. Fischer, B. W.-H. Ng, and D. Abbott, Opt. Express 20, 4968 (2012).
  46. V. E. Rogalin, I. A. Kaplunov, and G. I. Kropotov, Opt. Spectrosc. 125, 1053 (2018).
  47. A. Fisher, Y. Park, M. Lenz, A. Ody, R. Agustsson, T. Hodgetts, A. Murokh, and P. Musumeci, Nat. Photonics 16, 441 (2022).
  48. G. Andonian, M. Dunning, E. Hemsing, J. Rosenzweig, A. Cook, A. Murokh, S. Reiche, M. Babzien, I. Ben-Zvi, K. Kusche et al., Int. J. Mod. Phys. A 22, 4101 (2007).
  49. H. Loos, R. Akre, A. Brachmann, F. Decker, Y. Ding, D. Dowell, P. Emma, J. Frisch, S. Gilevich, G. Hays et al., in Proceedings of the 2008 Free-Electron Laser Conference, Gyeongju, Korea (Joint Accelerator Conferences Website (JACoW), Geneva, Switzerland, 2008).
  50. RadiaBeam Technologies, https://radiabeam.com/.
  51. R. Lai and A. J. Sievers, Nucl. Instrum. Methods Phys. Res., Sect. A 397, 221 (1997).
  52. J. S. Toll, Phys. Rev. 104, 1760 (1956).
  53. R. Lai and A. J. Sievers, Phys. Rev. E 52, 4576 (1995).
  54. R. W. Gerchberg, Optik (Stuttgart) 35, 237 (1972).
  55. S. I. Bajlekov, M. Heigoldt, A. Popp, J. Wenz, K. Khrennikov, S. Karsch, and S. M. Hooker, Phys. Rev. ST Accel. Beams 16, 040701 (2013).

Outline

Information

Phys. Rev. Accel. Beams 29, 074101– Published 29 July, 2026
  • Received 30 January 2026
  • Accepted 9 July 2026
