Design and nonlinear optimization of a one-fold lattice for the Super Tau-Charm Facility collider rings

Tao Liu1, Anton Bogomyagkov2, Demin Zhou3,4,*, Penghui Yang5, Sangya Li5, Linhao Zhang1, Ye Zou1, Jingyu Tang1, and Qing Luo1,5,†

  • *Contact author: dmzhou@post.kek.jp
  • †Contact author: luoqing@ustc.edu.cn
PDF

Phys. Rev. Accel. Beams 29, 083703 – Published 28 August, 2026

DOI: https://doi.org/10.1103/44m8-gk5x

Abstract

The Super Tau-Charm Facility (STCF) is a proposed high-luminosity electron-positron collider operating at beam energies of 1–3.5 GeV, with a nominal peak-luminosity target exceeding 0.5×1035  cm−2 s−1 at 2 GeV. At such low energies, the combined effects of beam-beam interactions in the crab-waist collision scheme, collective effects, and Touschek scattering impose stringent requirements on the dynamic aperture, momentum acceptance, and beam lifetime. This paper presents the design and nonlinear optimization of a one-fold lattice for the STCF collider rings. The design procedure consists of three main steps: lattice-independent optimization of the global machine parameters under luminosity, beam-beam, collective effects, and lifetime constraints; design of a compact interaction region (IR) with local chromatic correction and dedicated crab-waist sextupoles; and full-ring nonlinear optimization. The last step employs a two-stage strategy combining analysis-driven preoptimization with tracking-based refinement. Particular emphasis is placed on controlling momentum- and amplitude-dependent nonlinearities in the IR and preserving the nonlinear transparency of the crab-waist sextupole pair. At 2 GeV, the optimized lattice achieves a theoretical peak luminosity of 1.1×1035  cm−2 s−1 while maintaining sufficient dynamic aperture, momentum acceptance, and a Touschek lifetime of approximately 600 s. These results demonstrate the effectiveness of the proposed staged optimization strategy and provide a systematic framework for the design of high-luminosity, low-energy electron-positron colliders.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (41)

  1. P. Raimondi, Status on SuperB Effort, 2nd SuperB Workshop (INFN-LNF, Frascati, 2006).
  2. P. Raimondi, D. N. Shatilov, and M. Zobov, Beam-beam issues for colliding schemes with large Piwinski angle and crabbed waist, arXiv:physics/0702033.
  3. P. Raimondi, D. Shatilov, and M. Zobov, Suppression of beam-beam resonances in crab waist collisions, in Proceedings of the 11th European Particle Accelerator Conference (EPAC 2008) (2008), pp. 2620–2622.
  4. M. Zobov, D. Alesini, M. E. Biagini et al., Test of crab-waist collisions at the DAΦNE Φ factory, Phys. Rev. Lett. 104, 174801 (2010).
  5. Y. Ohnishi, T. Abe, K. Akai, Y. Arimoto, K. Egawa, S. Enomoto, H. Fukuma, Y. Funakoshi, K. Furukawa, N. Iida et al., SuperKEKB operation using crab waist collision scheme, Eur. Phys. J. Plus 136, 1023 (2021).
  6. A. Abada, M. Abbrescia, S. S. AbdusSalam, I. Abdyukhanov, J. Abelleira Fernandez, A. Abramov, M. Aburaia, A. O. Acar, P. R. Adzic, P. Agrawal et al., FCC-ee: The Lepton collider: Future circular collider conceptual design report volume 2, Eur. Phys. J. ST 228, 261 (2019).
  7. CEPC Study Group, CEPC conceptual design report: Volume 1-accelerator, arXiv:1809.00285.
  8. H. Peng, Y.-H. Zheng, and X.-R. Zhou, Super Tau-Charm Facility of China, Physics 49, 513 (2020).
  9. X.-C. Ai, L.-P. An, S.-Z. An, Y. Bai, Z.-H. Bai, O. Bakina, J.-C. Bao, V. Batozskaya, A. Belias, M. E. Biagini et al., Conceptual design report of the Super Tau-Charm Facility: The accelerator, Nucl. Sci. Tech. 36, 242 (2025).
  10. M. Biagini, R. Boni, M. Boscolo, A. Chiarucci, R. Cimino, A. Clozza, A. Drago, S. Guiducci, C. Ligi, G. Mazzitelli et al., Tau/Charm factory accelerator report, arXiv:1310.6944.
  11. V. Anashin et al., Super Charm-Tau Factory: Conceptual design report, Tech. Rep. (Budker Institute of Nuclear Physics, Novosibirsk Russia, 2018).
  12. A. Y. Barnyakov et al., The project of the Super Charm-Tau Factory in Novosibirsk, J. Phys. Conf. Ser. 1561, 012004 (2020).
  13. SuperB Collaboration, SuperB progress reports—accelerator, arXiv:1009.6178.
  14. SuperKEKB design report.
  15. Q. Luo, W. Gao, J. Lan, W. Li, D. Xu et al., Progress of conceptual study for the accelerators of a 2–7 GeV Super Tau Charm Facility at China, in Proceedings of the 10th Int. Particle Accelerator Conf. (IPAC’19), Melbourne, Australia, 19–24 May 2019 (JACOW Publishing, Geneva, Switzerland, 2019), pp. 643–645.
  16. J. Q. Lan, Q. Luo, C. Zhang, W. W. Gao, Y. Xu, and Y. Bai, Design of beam optics for a Super Tau-Charm Factory, J. Instrum. 16, T07001 (2021).
  17. T. Liu, C. Zhang, L. Wang, and Q. Luo, Design of a hybrid seven-bend-achromat-based lattice for a Super Tau Charm Facility, in Proceedings of Ipac2023, Venice, Italy, 07–12 May 2023 (JACoW Publishing, Venice, Italy, 2023), Vol. 14, pp. 768–771.
  18. T. Liu, L. Zhang, S. Li, L. Wang, and Q. Luo, Recent progress and future plan for STCF collider ring lattice design, Mod. Phys. Lett. A 39, 2440005 (2024).
  19. T. Liu, L. Wang, and Q. Luo, Study of chromaticity correction methods for a hybrid Multi-bend-achromat lattice, J. Phys. Conf. Ser. 2709, 012001 (2024).
  20. Y. Zou, L. Zhang, T. Liu, P. Yang, W. Li, T. He, D. Zhou, K. Ohmi, S. Li, Z. Yu et al., Optics design of the Super Tau-Charm Facility collider rings, Nucl. Instrum.Methods Phys. Res., Sect. A 1084, 171191 (2025).
  21. N. S. Dikansky and D. V. Pestrikov, Effect of the crab waist and of the micro-beta on the beam–beam instability, Nucl. Instrum. Methods Phys. Res., Sect. A 600, 538 (2009).
  22. D. Zhou, Formulae of luminosity and beam-beam tune shifts for flat-beam asymmetric colliders, arXiv:2212.12706.
  23. P. Raimondi and M. Zobov, Tune shift in beam-beam collisions with a crossing angle, Technical note G-58 (DAΦNE, 2003).
  24. K. Ohmi, N. Kuroo, K. Oide, D. Zhou, and F. Zimmermann, Coherent beam-beam instability in collisions with a large crossing angle, Phys. Rev. Lett. 119, 134801 (2017).
  25. T. Liu et al., Nonlinear optimization for the Super Tau-Charm Facility, in The 7th International Workshop on Future Tau Charm Facilities (FTCF2025), Huangshan, China (2025).
  26. P. Raimondi, S. M. Liuzzo, L. Farvacque, S. White, and M. Hofer, Local chromatic correction optics for future circular collider e+e−, Phys. Rev. Accel. Beams 28, 021002 (2025).
  27. K. Oide, M. Aiba, S. Aumon, M. Benedikt, A. Blondel, A. Bogomyagkov, M. Boscolo, H. Burkhardt, Y. Cai, A. Doblhammer et al., Design of beam optics for the future circular collider e+e− collider rings, Phys. Rev. Accel. Beams 19, 111005 (2016).
  28. T. Liu, PAMKIT-Particle Accelerator Modeling Kit, https://pypi.org/project/PAMKIT (2025).
  29. SAD Home Page, https://acc-physics.kek.jp/SAD.
  30. L. Zhang, T. Liu, Y. Zou, P. Yang, D. Zhou, J. Bao, Z. Yu, Y. Jin, Y. Mo, S. Li, T. He, Q. Luo, and J. Tang, Crab-waist interaction region design and integration for the Super Tau-Charm Facility, arXiv:2510.09198.
  31. A. Bogomyagkov, E. Levichev, and P. Piminov, Final focus designs for crab waist colliders, Phys. Rev. Accel. Beams 19, 121005 (2016).
  32. K. L. Brown and R. V. Servranckx, First- and second-order charged particle optics, in AIP Conference Proceedings (AIP, 1985), Vol. 127, pp. 62–138.
  33. J. Bengtsson, The sextupole scheme for the Swiss Light Source (SLS): An analytic approach, SLS-Note 9, 97 (1997). 10.55402/psi:86776.
  34. A. Bogomyagkov, Chromaticity correction of the interaction region, in The First IHEP-BINP CEPC Accelerator Collaboration Workshop, Beijing (2016).
  35. B. W. Montague, Linear optics for improved chromaticity correction, Tech. Rep. (SCAN-0009131, 1979).
  36. Y. Cai, Y. Nosochkov, J. S. Berg, J. Kewisch, Y. Li, D. Marx, C. Montag, S. Tepikian, F. Willeke, G. Hoffstaetter, and J. Unger, Optimization of chromatic optics in the electron storage ring of the electron-ion collider, Phys. Rev. Accel. Beams 25, 71001 (2022).
  37. A. Bogomyagkov, Single-particle effects limiting the parameters of modern synchrotron radiation sources and electron-positron colliders, Dr.Sc. thesis (Doktor Nauk) [Budker Institute of Nuclear Physics, Siberian Branch, Russian Academy of Sciences, Siberian, 2024 (in Russian)], https://www.inp.nsk.su/images/Bogomyagkov_disser.pdf.
  38. A. Bogomyagkov, E. Levichev, and S. Sinyatkin, Touschek lifetime and luminosity optimization for Russian Super Charm Tau Factory, J. Instrum. 19, P02018 (2024).
  39. B. Wei, Z. Bai, J. Tan, L. Wang, and G. Feng, Minimizing the fluctuation of resonance driving terms in dynamic aperture optimization, Phys. Rev. Accel. Beams 26, 84001 (2023).
  40. K. Deb, A. Pratap, S. Agarwal, and T. Meyarivan, A fast and elitist multiobjective genetic algorithm: NSGA-II, IEEE Trans. Evol. Comput. 6, 182 (2002).
  41. B. Riemann, M. Aiba, J. Kallestrup, and A. Streun, Efficient algorithms for dynamic aperture and momentum acceptance calculation in synchrotron light sources, Phys. Rev. Accel. Beams 27, 94002 (2024).
