Theoretical calculations of the Landé g-factors, electric quadrupole moments, and quadratic Zeeman shift coefficients of the clock states in the Lu+ optical clock

Min Feng1,2,3, Ting Liang1,2,3, Jin Cao1,2,3, Yiming Wang1,2, Tingxian Zhang4, Benquan Lu1,2,*, and Hong Chang1,2,3,†

  • *Contact author: lubenquan@ntsc.ac.cn
  • †Contact author: changhong@ntsc.ac.cn
PDF

Phys. Rev. A 113, 032821 – Published 27 March, 2026

DOI: https://doi.org/10.1103/98z8-wv5d

Abstract

In this study, the multiconfiguration Dirac-Hartree-Fock method was employed to calculate the Landé g-factors and electric-quadrupole moments of the 5d6s3D1,2,3 and 1D2 states, as well as the quadratic Zeeman shift coefficients of the 3D1,2 clock states in Lu+. The electron correlation, particularly higher-order electron correlation effects, along with the Breit interaction and quantum electrodynamics corrections, are systematically taken into account. Our calculated Landé g-factors, electric-quadrupole moments, and quadratic Zeeman shift coefficients for the 5d6s3D1,2 clock states are in agreement with experimental measurements within 1%. The influence of hyperfine interactions and perturbing states on these parameters was also analyzed. Our results demonstrate that both the magnetic-dipole and the electric-quadrupole hyperfine interactions contribute significantly to the hyperfine-induced Landé g-factors and electric-quadrupole moments of the 3D1,2 states. In particular, for Lu+176, the electric-quadrupole hyperfine interaction accounts for approximately 15% of the total hyperfine-induced electric-quadrupole moment of the 3D1,2 states. This study provides valuable theoretical support for evaluating frequency shifts in the Lu+ optical clock.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (51)

  1. T. Bothwell, D. Kedar, E. Oelker, J. M. Robinson, S. L. Bromley, W. L. Tew, J. Ye, and C. J. Kennedy, JILA SrI optical lattice clock with uncertainty of 2.0×10−18, Metrologia 56, 065004 (2019).
  2. A. Tofful, C. F. A. Baynham, E. A. Curtis, A. O. Parsons, B. I. Robertson, M. Schioppo, J. Tunesi, H. S. Margolis, R. J. Hendricks, J. Whale, R. C. Thompson, and R. M. Godun, Yb+171 optical clock with 2.2×10−18 systematic uncertainty and absolute frequency measurements, Metrologia 61, 045001 (2024).
  3. C. Wang, Y. Yao, H. Shi, H. Yu, L. Ma, and Y. Jiang, A Yb optical clock with a lattice power enhancement cavity, Chin. Phys. B 33, 030601 (2024).
  4. Y. Hao, R. Hu, B. Zhang, M. Zeng, H. Zhang, Z. Ma, Y. Huang, Q. Chen, K. Gao, and H. Guan, Stability improvement of Ca+40 optical clock by using a transportable ultra-stable cavity, Opt. Express 32, 4081 (2024).
  5. X. Lu, F. Guo, Y. Liu, J. Cao, J. Li, J. Xia, Q. Xu, B. Lu, Y. Wang, and H. Chang, NTSC SrII optical lattice clock with uncertainty of 2×10−18, Metrologia 62, 035007 (2025).
  6. H. N. Hausser, J. Keller, T. Nordmann, N. M. Bhatt, J. Kiethe, H. Liu, I. M. Richter, M. von Boehn, J. Rahm, S. Weyers, E. Benkler, B. Lipphardt, S. Dörscher, K. Stahl, J. Klose, C. Lisdat, M. Filzinger, N. Huntemann, E. Peik, and T. E. Mehlstäubler, In+115−Yb+172 Coulomb crystal clock with 2.5×10−18 systematic uncertainty, Phys. Rev. Lett. 134, 023201 (2025).
  7. Z. Zhang, K. J. Arnold, R. Kaewuam, and M. D. Barrett, Lu+176 clock comparison at the 10−18 level via correlation spectroscopy, Sci. Adv. 9, eadg1971 (2023).
  8. K. J. Arnold, S. Bustabad, Z. Qi, Q. Qichen, Z. Zhang, Z. Zhao, and M. D. Barrett, Validating a lutetium frequency reference, J. Phys.: Conf. Ser. 2889, 012040 (2024).
  9. A. Aeppli, K. Kim, W. Warfield, M. S. Safronova, and J. Ye, Clock with 8×10−19 systematic uncertainty, Phys. Rev. Lett. 133, 023401 (2024).
  10. M. C. Marshall, D. A. R. Castillo, W. J. Arthur-Dworschack, A. Aeppli, K. Kim, D. Lee, W. Warfield, J. Hinrichs, N. V. Nardelli, T. M. Fortier, J. Ye, D. R. Leibrandt, and D. B. Hume, High-stability single-ion clock with 5.5×10−19 systematic uncertainty, Phys. Rev. Lett. 135, 033201 (2025).
  11. M. Barrett, Developing a field independent frequency reference, New J. Phys. 17, 053024 (2015).
  12. R. Kaewuam, T. R. Tan, K. J. Arnold, S. R. Chanu, Z. Zhang, and M. D. Barrett, Hyperfine averaging by dynamic decoupling in a multi-ion lutetium clock, Phys. Rev. Lett. 124, 083202 (2020)a).
  13. K. J. Arnold, R. Kaewuam, A. Roy, T. R. Tan, and M. D. Barrett, Blackbody radiation shift assessment for a lutetium ion clock, Nat. Commun. 9, 1650 (2018).
  14. K. Arnold, E. Hajiyev, E. Paez, C. H. Lee, M. D. Barrett, and J. Bollinger, Prospects for atomic clocks based on large ion crystals, Phys. Rev. A 92, 032108 (2015).
  15. T. R. Tan, R. Kaewuam, K. J. Arnold, S. R. Chanu, Z. Zhang, M. S. Safronova, and M. D. Barrett, Suppressing inhomogeneous broadening in a lutetium multi-ion optical clock, Phys. Rev. Lett. 123, 063201 (2019).
  16. Z. Zhiqiang, K. J. Arnold, R. Kaewuam, M. S. Safronova, and M. D. Barrett, Hyperfine-mediated effects in a Lu+ optical clock, Phys. Rev. A 102, 052834 (2020).
  17. V. Dzuba and A. Derevianko, Dynamic polarizabilities and related properties of clock states of the ytterbium atom, J. Phys. B: At. Mol. Opt. Phys. 43, 074011 (2010).
  18. S. G. Porsev, U. I. Safronova, and M. S. Safronova, Theoretical study of the g factor and lifetime of the 6s6p3P0 state of mercury, Phys. Rev. A 96, 012509 (2017).
  19. K. Beloy, D. R. Leibrandt, and W. M. Itano, Hyperfine-mediated electric quadrupole shifts in Al+ and In+ ion clocks, Phys. Rev. A 95, 043405 (2017).
  20. E. V. Kahl, J. C. Berengut, M. Laatiaoui, E. Eliav, and A. Borschevsky, High-precision ab initio calculations of the spectrum of Lr+, Phys. Rev. A 100, 062505 (2019).
  21. Q. Zhao, M. D. Lee, Q. Qichen, Z. Zhang, N. Jayjong, K. J. Arnold, and M. D. Barrett, Landé g-factor measurements for the 5d6s3D2 hyperfine levels of 176Lu+, Phys. Rev. A 112, 032808 (2025); 112, 069901(E) (2025).
  22. S. G. Porsev, U. I. Safronova, and M. S. Safronova, Clock-related properties of Lu+, Phys. Rev. A 98, 022509 (2018).
  23. R. Kaewuam, T. R. Tan, Z. Zhang, K. J. Arnold, M. S. Safronova, and M. D. Barrett, Precision measurement of the 3D1 and 3D2 quadrupole moments in Lu+, Phys. Rev. A 102, 042819 (2020).
  24. R. Kaewuam, Development of an optical atomic clock based on trapped lutetium ions, Ph.D. thesis, National University of Singapore, 2020.
  25. T. X. Zhang, C. B. Li, and T. Y. Shi, Hyperfine-induced frequency shifts for the candidate clock transitions in the Ni12+61 ion, Phys. Rev. A 110, 032801 (2024).
  26. I. Lindgren, Effective operators in the atomic hyperfine interaction, Rep. Prog. Phys. 47, 345 (1984).
  27. M. Andersson and P. Jönssonn, HFSZEEMAN—A program for computing weak and intermediate field fine and hyperfine structure Zeeman splittings from MCDHF wave functions, Comput. Phys. Commun. 178, 156 (2008).
  28. P. Jönsson, X. He, C. Froese Fischer, and I. Grant, The grasp2K relativistic atomic structure package, Comput. Phys. Commun. 177, 597 (2007).
  29. G. Marx, G. Tommaseo, and G. Werth, Precise - and -factor measurements of Ba+ isotopes, Eur. Phys. J. D 4, 279 (1998).
  30. B. Lu and H. Chang, Theoretical calculations on Landé g-factors and quadratic Zeeman shift coefficients of nsnp 3P0o clock states in Mg and Cd optical lattice clocks, Chin. Phys. B 32, 013101 (2023).
  31. A. N. Petrov, Hyperfine and Zeeman interactions of the a(1)[3Σ1+] state of PbO, Phys. Rev. A 83, 024502 (2011).
  32. B. Lu, X. Lu, J. Li, and H. Chang, Theoretical calculation of the quadratic Zeeman shift coefficient of the 3P0o clock state for strontium optical lattice clock, Chin. Phys. B 31, 043101 (2022).
  33. W. M. Itano, External-field shifts of the Hg+199 optical frequency standard, J. Res. Natl. Inst. Stand. Technol. 105, 829 (2000).
  34. T. Zhang, Y. Zhang, C. Li, and T. Shi, Theoretical study of the hyperfine interaction constants, Landé g-factors, and electric quadrupole moments for the low-lying states of the Niq+61(q=11,12,14, and 15) ions, Chin. Phys. B 30, 013101 (2021).
  35. A. Aboussaıd, M. R. Godefroid, P. Jönsson, and C. Froese Fischer, Multiconfigurational Hartree-Fock calculations of hyperfine-induced transitions in heliumlike ions, Phys. Rev. A 51, 2031 (1995).
  36. J. Bieron, C. F. Fischer, and P. Jönsson, Recent advances in multiconfigurational atomic structure calculations, Atoms 11, 123 (2023).
  37. C. Froese-Fischer, T. Brage, and P. Jönsson, Computational Atomic Structure: An MCHF Approach (Routledge, Boca Raton, FL, 2022), p. 90.
  38. K. Dyall, I. Grant, C. Johnson, F. Parpia, and E. Plummer, GRASP: A general-purpose relativistic atomic structure program, Comput. Phys. Commun. 55, 425 (1989).
  39. B. Lu and H. Chang, Re-evaluation of the nuclear electric quadrupole moment and mean-square charge radii of Lu+175,176 isotopes, Phys. Rev. A 110, 042820 (2024).
  40. J. Li, P. Jönsson, M. Godefroid, C. Dong, and G. Gaigalas, Effects of the electron correlation and Breit and hyperfine interactions on the lifetime of the 2p53s states in neutral neon, Phys. Rev. A 86, 052523 (2012).
  41. J. Han, B. Lu, Y. Yu, J. Li, Z. Huang, J. Wen, L. Qian, and L. Wang, Determination of the Landé gJ factor and Zeeman coefficients in ground-state Yb+171 and their applications to quantum frequency standards, Phys. Rev. A 111, 012814 (2025).
  42. T. Zhang, B. Lu, J. Li, C. Li, H. Chang, T. Shi, and Z. Lu, Role of hyperfine interaction in Landé g-factors of 3P0o clock states, J. Quant. Spectrosc. Radiat. Transfer 266, 107562 (2021).
  43. C. F. Fischer, G. Gaigalas, P. Jönsson, J. Bieroń, GRASP2018—a Fortran 95 version of the general relativistic atomic structure package, Comput. Phys. Commun. 237, 184 (2019).
  44. W. Li, J. Grumer, T. Brage, and P. Jönsson, Hfszeeman95—A program for computing weak and intermediate magnetic-field- and hyperfine-induced transition rates, Comput. Phys. Commun. 253, 107211 (2020).
  45. V. A. Dzuba, Combination of the single-double–coupled-cluster and the configuration-interaction methods: Application to barium, lutetium, and their ions, Phys. Rev. A 90, 012517 (2014).
  46. A. Kramida, Yu. Ralchenko, J. Reader and the NIST ASD team, NIST Atomic Spectra Database, ver. 5.10 (National Institute of Standards and Technology, Gaithersburg, MD, 2022).
  47. W. C. Martin, R. Zalubas, and L. Hagan, Atomic Energy Levels-the Rare Earth Elements, NSRDS-NBS 60 (National Bureau of Standards, Washington, D.C., 1978).
  48. C. F. Fischer, M. Godefroid, T. Brage, P. Jönsson, and G. Gaigalas, Advanced multiconfiguration methods for complex atoms: I. Energies and wave functions, J. Phys. B: At. Mol. Opt. Phys. 49, 182004 (2016).
  49. T. Brenner, S. Büttgenbach, W. Rupprecht, and F. Träber, Nuclear moments of the low abundant natural isotope Lu176 and hyperfine anomalies in the lutetium isotopes, Nucl. Phys. A 440, 92 (1985).
  50. E. Paez, K. J. Arnold, E. Hajiyev, S. G. Porsev, V. A. Dzuba, U. I. Safronova, M. S. Safronova, and M. D. Barrett, Atomic properties of Lu+, Phys. Rev. A 93, 042112 (2016).
  51. M. Feng, Dataset of Landé g-factors, electricquadrupole moments, and quadratic Zeeman shift coefficients of clock states in Lu+ optical clock, Dataset, figshare (2026), https://doi.org/10.6084/m9.figshare.31476229.v1.
