Controlling knot topology in magnetic hopfions via spin-orbit torque

Shoya Kasai1,*, Shun Okumura1,2,3,4, and Yukitoshi Motome1,†

  • *Contact author: kasai@aion.t.u-tokyo.ac.jp
  • †Contact author: motome@ap.t.u-tokyo.ac.jp
PDF

APS Open Sci. 1, L000007 – Published 29 April, 2026

DOI: https://doi.org/10.1103/ngvg-h27j

Abstract

Knots formed by the intertwining of strings have attracted broad interest across various scientific disciplines owing to their rich topology. This concept has recently gained increasing importance in condensed matter physics, as exemplified by a magnetic hopfion labeled by a topological invariant called the Hopf number H. Here, we show that spin-orbit torque (SOT) enables dynamic manipulation of the Hopf number of magnetic hopfions. We investigate the SOT-driven evolution of hopfions, revealing the splitting of a high-H hopfion into multiple lower-H ones, a process that can be quantified by an effective tension picture. Comparative analysis across different H uncovers a hierarchy of instabilities that dictates these dynamical topological transitions. These findings not only indicate potential applications of hopfions in SOT-driven multilevel memory devices, but also provide a paradigm for the dynamical control of knot topology.

View figure in article

Physics Subject Headings (PhySH)

synopsis

Hopfions at the Breaking Point

Published 29 April, 2026

Simulations show that knot-like magnetic structures called hopfions can be pulled apart—a capability that could be harnessed for spintronic memory devices.

See more in Physics

See Also

Nonequilibrium dynamics of magnetic hopfions driven by spin-orbit torque

Shoya Kasai, Shun Okumura, and Yukitoshi Motome
Phys. Rev. B 113, 134445 (2026)

Article Text

References (44)

  1. W. Thomson, On vortex atoms, Proc. R. Soc. Edinburgh 6, 94 (1869).
  2. C. Adams, The Knot Book: An Elementary Introduction to the Mathematical Theory of Knots (American Mathematical Society, Providence, 2004), p. 306.
  3. B. Zwiebach, A First Course in String Theory (Cambridge University Press, Cambridge, 2009), p. 673.
  4. E. Witten, Quantum field theory and the Jones polynomial, Commun. Math. Phys. 121, 351 (1989).
  5. C. O. Dietrich‐Buchecker and J. Sauvage, A synthetic molecular trefoil knot, Angew. Chem. Int. Ed. Engl. 28, 189 (1989).
  6. A. D. Bates and A. Maxwell, DNA Topology (Oxford University Press, New York, 2005), p. 198.
  7. A. Kitaev, Fault-tolerant quantum computation by anyons, Ann. Phys. 303, 2 (2003).
  8. H. Hopf, Über die Abbildungen der dreidimensionalen Sphäre auf die Kugelfläche, Math. Ann. 104, 637 (1931).
  9. L. Faddeev and A. J. Niemi, Stable knot-like structures in classical field theory, Nature (London) 387, 58 (1997).
  10. D. Sugic, R. Droop, E. Otte, D. Ehrmanntraut, F. Nori, J. Ruostekoski, C. Denz, and M. R. Dennis, Particle-like topologies in light, Nat. Commun. 12, 6785 (2021).
  11. Y. Shen, B. Yu, H. Wu, C. Li, Z. Zhu, and A. V. Zayats, Topological transformation and free-space transport of photonic hopfions, Adv. Photonics 5, 015001 (2023).
  12. G. Volovik and V. Mineev, Particle-like solitons in superfluid He3 phases, Zh. Eksp. Teor. Fiz. 73, 767 (1977) [Sov. Phys. JETP 46, 401 (1977)].
  13. E. Babaev, Dual neutral variables and knot solitons in triplet superconductors, Phys. Rev. Lett. 88, 177002 (2002).
  14. Y. Kawaguchi, M. Nitta, and M. Ueda, Knots in a spinor Bose-Einstein condensate, Phys. Rev. Lett. 100, 180403 (2008).
  15. D. S. Hall, M. W. Ray, K. Tiurev, E. Ruokokoski, A. H. Gheorghe, and M. Möttönen, Tying quantum knots, Nat. Phys. 12, 478 (2016).
  16. I. Luk’yanchuk, Y. Tikhonov, A. Razumnaya, and V. M. Vinokur, Hopfions emerge in ferroelectrics, Nat. Commun. 11, 2433 (2020).
  17. P. J. Ackerman and I. I. Smalyukh, Static three-dimensional topological solitons in fluid chiral ferromagnets and colloids, Nat. Mater. 16, 426 (2017).
  18. P. J. Ackerman and I. I. Smalyukh, Diversity of knot solitons in liquid crystals manifested by linking of preimages in torons and hopfions, Phys. Rev. X 7, 011006 (2017).
  19. J.-S. B. Tai and I. I. Smalyukh, Three-dimensional crystals of adaptive knots, Science 365, 1449 (2019).
  20. N. Kent, N. Reynolds, D. Raftrey, I. T. G. Campbell, S. Virasawmy, S. Dhuey, R. V. Chopdekar, A. Hierro-Rodriguez, A. Sorrentino, E. Pereiro, S. Ferrer, F. Hellman, P. Sutcliffe, and P. Fischer, Creation and observation of Hopfions in magnetic multilayer systems, Nat. Commun. 12, 1562 (2021).
  21. X. Yu, Y. Liu, K. V. Iakoubovskii, K. Nakajima, N. Kanazawa, N. Nagaosa, and Y. Tokura, Realization and current‐driven dynamics of fractional hopfions and their ensembles in a helimagnet FeGe, Adv. Mater. 35, 2210646 (2023).
  22. F. Zheng, N. S. Kiselev, F. N. Rybakov, L. Yang, W. Shi, S. Blügel, and R. E. Dunin-Borkowski, Hopfion rings in a cubic chiral magnet, Nature (London) 623, 718 (2023).
  23. P. Sutcliffe, Hopfions in chiral magnets, J. Phys. A: Math. Theor. 51, 375401 (2018).
  24. Y. Liu, R. K. Lake, and J. Zang, Binding a hopfion in a chiral magnet nanodisk, Phys. Rev. B 98, 174437 (2018).
  25. J.-S. B. Tai and I. I. Smalyukh, Static Hopf solitons and knotted emergent fields in solid-state noncentrosymmetric magnetic nanostructures, Phys. Rev. Lett. 121, 187201 (2018).
  26. S. Li, J. Xia, L. Shen, X. Zhang, M. Ezawa, and Y. Zhou, Mutual conversion between a magnetic Néel hopfion and a Néel toron, Phys. Rev. B 105, 174407 (2022).
  27. I. L. Bogolubsky, Three-dimensional topological solitons in the lattice model of a magnet with competing interactions, Phys. Lett. A 126, 511 (1988).
  28. P. Sutcliffe, Skyrmion knots in frustrated magnets, Phys. Rev. Lett. 118, 247203 (2017).
  29. F. N. Rybakov, N. S. Kiselev, A. B. Borisov, L. Döring, C. Melcher, and S. Blügel, Magnetic hopfions in solids, APL Mater. 10, 111113 (2022).
  30. M. Sallermann, H. Jónsson, and S. Blügel, Stability of hopfions in bulk magnets with competing exchange interactions, Phys. Rev. B 107, 104404 (2023).
  31. I. S. Lobanov and V. M. Uzdin, Lifetime, collapse, and escape paths for hopfions in bulk magnets with competing exchange interactions, Phys. Rev. B 107, 104405 (2023).
  32. Y. Liu, W. Hou, X. Han, and J. Zang, Three-dimensional dynamics of a magnetic hopfion driven by spin transfer torque, Phys. Rev. Lett. 124, 127204 (2020).
  33. Y. Liu, H. Watanabe, and N. Nagaosa, Emergent magnetomultipoles and nonlinear responses of a magnetic hopfion, Phys. Rev. Lett. 129, 267201 (2022).
  34. A. F. Vakulenko and L. V. Kapitanski, Stability of solitons in S2 in the nonlinear σ-model, Dokl. Akad. Nauk. SSSR 246, 840 (1979).
  35. R. S. Ward, The interaction of two Hopf solitons, Phys. Lett. B 473, 291 (2000).
  36. J. Hietarinta, J. Palmu, J. Jäykkä, and P. Pakkanen, Scattering of knotted vortices (Hopfions) in the Faddeev–Skyrme model, New J. Phys. 14, 013013 (2012).
  37. S. Kasai, K. Shimizu, S. Okumura, Y. Kato, and Y. Motome, Three-dimensional topological superstructure of magnetic hopfions threaded by meron strings in easy-plane magnets, Phys. Rev. B 112, 184424 (2025).
  38. D. Hall, J.-S. B. Tai, L. H. Kauffman, and I. I. Smalyukh, Fusion and fission of particle-like chiral nematic vortex knots, Nat. Phys. 22, 103 (2026).
  39. S. Kasai, S. Okumura, and Y. Motome, companion paper, Nonequilibrium dynamics of magnetic hopfions driven by spin-orbit torque, Phys. Rev. B 113, 134445 (2026).
  40. I. M. Miron, K. Garello, G. Gaudin, P.-J. Zermatten, M. V. Costache, S. Auffret, S. Bandiera, B. Rodmacq, A. Schuhl, and P. Gambardella, Perpendicular switching of a single ferromagnetic layer induced by in-plane current injection, Nature (London) 476, 189 (2011).
  41. L. Liu, C.-F. Pai, Y. Li, H. W. Tseng, D. C. Ralph, and R. A. Buhrman, Spin-torque switching with the giant spin Hall effect of Tantalum, Science 336, 555 (2012).
  42. J. Hietarinta and P. Salo, Faddeev-Hopf knots: dynamics of linked un-knots, Phys. Lett. B 451, 60 (1999).
  43. X. S. Wang, A. Qaiumzadeh, and A. Brataas, Current-driven dynamics of magnetic hopfions, Phys. Rev. Lett. 123, 147203 (2019).
  44. X. Zhang, J. Xia, Y. Zhou, X. Liu, H. Zhang, and M. Ezawa, Skyrmion dynamics in a frustrated ferromagnetic film and current-induced helicity locking-unlocking transition, Nat. Commun. 8, 1717 (2017).
