Time-resolved electron momentum spectroscopy with ultrashort electron pulses: Confined probing and effects of vacuum dispersion

Pieter Hessel Harkema and Lars Bojer Madsen*

  • Department of Physics and Astronomy, Aarhus University, Ny Munkegade 120, DK-8000 Aarhus C, Denmark

  • *Contact author: bojer@phys.au.dk
PDF

APS Open Sci. 1, 000089 – Published 7 August, 2026

DOI: https://doi.org/10.1103/gxwm-xbyp

Abstract

Previous theoretical studies have shown that attosecond electron dynamics can, in principle, be captured in electron momentum spectroscopy (EMS) using ultrashort electron pulses. By including further analytical considerations on the scattering probability, we here study the effect of the finite transversal extend of the projectile electron wave packet. We find that in wave packet scattering, the target momentum distribution is probed solely in a finite spatial region. This is evident from a spatially filtering Gabor transform appearing in the scattering probability, replacing the full momentum wave function appearing in the conventional plane wave treatment. In addition, by spatially shifting the target with regard to the wave packet focus, we illustrate the influence of vacuum dispersion, i.e., the spatial broadening of the wave packet as it propagates. Our findings are significant for the possibility to correctly interpret future attosecond-EMS results and the considered effects reflect fundamental aspects of wave packet scattering. The EMS setup may, therefore, constitute a useful framework for understanding scattering with finite wave packets.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (32)

  1. P. Baum and A. H. Zewail, Attosecond electron pulses for 4d diffraction and microscopy, Proc. Natl. Acad. Sci. USA 104, 18409 (2007).
  2. B. Barwick, D. J. Flannigan, and A. H. Zewail, Photon-induced near-field electron microscopy, Nature (London) 462, 902 (2009).
  3. S. T. Park, M. Lin, and A. H. Zewail, Photon-induced near-field electron microscopy (PINEM): Theoretical and experimental, New J. Phys. 12, 123028 (2010).
  4. A. Feist, K. E. Echternkamp, J. Schauss, S. V. Yalunin, S. Schäfer, and C. Ropers, Quantum coherent optical phase modulation in an ultrafast transmission electron microscope, Nature (London) 521, 200 (2015).
  5. G. M. Vanacore, I. Madan, G. Berruto, K. Wang, E. Pomarico, R. J. Lamb, D. McGrouther, I. Kaminer, B. Barwick, F. J. García de Abajo, and F. Carbone, Attosecond coherent control of free-electron wave functions using semi-infinite light fields, Nat. Commun. 9, 2694 (2018).
  6. M. Kozák, All-optical scheme for generation of isolated attosecond electron pulses, Phys. Rev. Lett. 123, 203202 (2019).
  7. K. E. Priebe, C. Rathje, S. V. Yalunin, T. Hohage, A. Feist, S. Schäfer, and C. Ropers, Attosecond electron pulse trains and quantum state reconstruction in ultrafast transmission electron microscopy, Nat. Photonics 11, 793 (2017).
  8. M. Kozák, N. Schönenberger, and P. Hommelhoff, Ponderomotive generation and detection of attosecond free-electron pulse trains, Phys. Rev. Lett. 120, 103203 (2018).
  9. Y. Morimoto and P. Baum, Diffraction and microscopy with attosecond electron pulse trains, Nat. Phys. 14, 252 (2018).
  10. Y. Morimoto and P. Baum, Attosecond control of electron beams at dielectric and absorbing membranes, Phys. Rev. A 97, 033815 (2018).
  11. N. Schönenberger, A. Mittelbach, P. Yousefi, J. McNeur, U. Niedermayer, and P. Hommelhoff, Generation and characterization of attosecond microbunched electron pulse trains via dielectric laser acceleration, Phys. Rev. Lett. 123, 264803 (2019).
  12. D. S. Black, U. Niedermayer, Y. Miao, Z. Zhao, O. Solgaard, R. L. Byer, and K. J. Leedle, Net acceleration and direct measurement of attosecond electron pulses in a silicon dielectric laser accelerator, Phys. Rev. Lett. 123, 264802 (2019).
  13. Y. Morimoto and P. Baum, Field-induced rocking-curve effects in attosecond electron diffraction, Phys. Rev. Lett. 132, 216902 (2024).
  14. D. Nabben, J. Kuttruff, L. Stolz, A. Ryabov, and P. Baum, Attosecond electron microscopy of sub-cycle optical dynamics, Nature (London) 619, 63 (2023).
  15. J. H. Gaida, H. Lourenço-Martins, M. Sivis, T. Rittmann, A. Feist, F. J. García de Abajo, and C. Ropers, Attosecond electron microscopy by free-electron homodyne detection, Nat. Photonics 18, 509 (2024).
  16. Y. Morimoto, P. Hommelhoff, and L. B. Madsen, Coherent scattering of an optically modulated electron beam by atoms, Phys. Rev. A 103, 043110 (2021).
  17. P. Baum, J. Manz, and A. Schild, Quantum model simulations of attosecond electron diffraction, Sci. China Phys., Mech. Astron. 53, 987 (2010).
  18. H.-C. Shao and A. F. Starace, Detecting electron motion in atoms and molecules, Phys. Rev. Lett. 105, 263201 (2010).
  19. P. Baum, On the physics of ultrashort single-electron pulses for time-resolved microscopy and diffraction, Chem. Phys. 423, 55 (2013).
  20. H.-C. Shao and A. F. Starace, Imaging coherent electronic motion in atoms by ultrafast electron diffraction, Phys. Rev. A 88, 062711 (2013).
  21. H.-C. Shao and A. F. Starace, Energy-resolved coherent diffraction from laser-driven electronic motion in atoms, Phys. Rev. A 96, 042706 (2017).
  22. Y. Morimoto, P. Hommelhoff, and L. B. Madsen, Scattering-asymmetry control with ultrafast electron wave packet shaping, New J. Phys. 27, 103201 (2025).
  23. I. E. McCarthy and E. Weigold, Electron momentum spectroscopy of atoms and molecules, Rep. Prog. Phys. 54, 789 (1991).
  24. M. A. Coplan, J. H. Moore, and J. P. Doering, (e,2e) spectroscopy, Rev. Mod. Phys. 66, 985 (1994).
  25. M. Yamazaki, K. Oishi, H. Nakazawa, C. Zhu, and M. Takahashi, Molecular orbital imaging of the acetone S2 excited state using time-resolved (e,2e) electron momentum spectroscopy, Phys. Rev. Lett. 114, 103005 (2015).
  26. Y. Tang, X. Shan, Z. Liu, S. Niu, E. Wang, and X. Chen, Development of an electron momentum spectrometer for time-resolved experiments employing nanosecond pulsed electron beam, Rev. Sci. Instrum. 89, 033101 (2018).
  27. H.-C. Shao and A. F. Starace, Time-resolved ultrafast electron (e,2e) momentum spectroscopy, Phys. Rev. A 87, 050701(R) (2013).
  28. H.-C. Shao and A. F. Starace, Time-resolved electron (e,2e) momentum spectroscopy: Application to laser-driven electron population transfer in atoms, Phys. Rev. A 97, 022702 (2018).
  29. Y. Morimoto and L. B. Madsen, Scattering of ultrashort electron wave packets: Optical theorem, differential phase contrast and angular asymmetries, New J. Phys. 26, 053012 (2024).
  30. J. R. Taylor, The Quantum Theory of Nonrelativistic Collisions (Dover Publications, Inc., Mineola, NY, 2006).
  31. M. Takahashi, Looking at molecular orbitals in three-dimensional form: From dream to reality, Bull. Chem. Soc. Jpn. 82, 751 (2009).
  32. F. Robicheaux, Scattering with longitudinally coherent matter beams, Phys. Rev. A 62, 062706 (2000).
