Spatial superposition for a two-dimensional matter-wave interferometer in an inverted harmonic potential with gyroscopic rotational stability

Ryan Rizaldy1,*, Tian Zhou1, Run Zhou2, and Anupam Mazumdar1

  • 1Van Swinderen Institute for Particle Physics and Gravity, University of Groningen, 9747AG Groningen, The Netherlands
  • 2Key Laboratory of Low-Dimensional Quantum Structures and Quantum Control of Ministry of Education, Key Laboratory for Matter Microstructure and Function of Hunan Province, Department of Physics and Synergetic Innovation Center for Quantum Effects and Applications, Hunan Normal University, Changsha 410081, China

  • *Contact author: r.rizaldy@rug.nl
PDF

APS Open Sci. 1, 000130 – Published 11 September, 2026

DOI: https://doi.org/10.1103/cwm2-6vgp

Abstract

This study presents a mathematical model of the spatial and rotational motion of a nanodiamond in an inverted harmonic potential to create a macroscopic quantum spatial superposition. The model is based on the Stern-Gerlach interferometer scheme, which utilizes linear and quadratic magnetic fields to generate a harmonic potential (linear magnetic field) and a nonlinear potential (nonlinear/quadratic magnetic field). By incorporating two-dimensional dynamics into the model, we provide a more realistic and accurate depiction of nanoparticle dynamics in linear and inverted harmonic potentials and explore the interaction between motion in a two-dimensional plane. Importantly, we derive the equations of motion for the rotational degrees of freedom, i.e., libration, precession, and rotation. The results show that adding a magnetic-field bias term to the magnetic-field profile in the linear stage affects the classical equations of motion but does not affect the width of the wave packet. Moreover, the libration mode always forms a harmonic potential at each stage because the applied initial angular velocity is dominated by the nanoparticle's defect axis, making it more stable in the presence of the trap frequency in the orthogonal direction along the axis that enables the creation of a macroscopic quantum superposition.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (85)

  1. S. L. Adler and A. Bassi, Is quantum theory exact? Science 325, 275 (2009).
  2. A. Bassi, K. Lochan, S. Satin, T. P. Singh, and H. Ulbricht, Models of wave-function collapse, underlying theories, and experimental tests, Rev. Mod. Phys. 85, 471 (2013).
  3. C. Pfister, J. Kaniewski, M. Tomamichel, A. Mantri, R. Schmucker, N. McMahon, G. Milburn, and S. Wehner, A universal test for gravitational decoherence, Nat. Commun. 7, 13022 (2016).
  4. A. Bassi, A. Großardt, and H. Ulbricht, Gravitational decoherence, Class. Quantum Gravity 34, 193002 (2017).
  5. C. Anastopoulos and B.-L. Hu, Gravitational decoherence: A thematic overview, AVS Quantum Sci. 4, 015602 (2022).
  6. Q. Xu and M. P. Blencowe, Zero-dimensional models for gravitational and scalar QED decoherence, New J. Phys. 24, 113048 (2022).
  7. M. Toroš, A. Mazumdar, and S. Bose, Loss of coherence and coherence protection from a graviton bath, Phys. Rev. D 109, 084050 (2024).
  8. L. Petruzziello and F. Illuminati, Quantum gravitational decoherence from fluctuating minimal length and deformation parameter at the Planck scale, Nat. Commun. 12, 4449 (2021).
  9. A. Tonomura, J. Endo, T. Matsuda, T. Kawasaki, and H. Ezawa, Demonstration of single-electron buildup of an interference pattern, Am. J. Phys. 57, 117 (1989).
  10. M. A. Kasevich, E. Riis, S. Chu, and R. G. DeVoe, rf spectroscopy in an atomic fountain, Phys. Rev. Lett. 63, 612 (1989).
  11. T. Kovachy, Quantum superposition at the half-metre scale, Nature (London) 528, 530 (2015).
  12. P. Asenbaum, C. Overstreet, T. Kovachy, D. D. Brown, J. M. Hogan, and M. A. Kasevich, Phase shift in an atom interferometer due to spacetime curvature across its wave function, Phys. Rev. Lett. 118, 183602 (2017).
  13. O. Amit, Y. Margalit, O. Dobkowski, Z. Zhou, Y. Japha, M. Zimmermann, M. A. Efremov, F. A. Narducci, E. M. Rasel, W. P. Schleich, and R. Folman, T3 Stern-Gerlach matter-wave interferometer, Phys. Rev. Lett. 123, 083601 (2019).
  14. Y. Margalit, O. Dobkowski, Z. Zhou, O. Amit, Y. Japha, S. Moukouri, D. Rohrlich, A. Mazumdar, S. Bose, C. Henkel, and R. Folman, Realization of a complete Stern-Gerlach interferometer: Toward a test of quantum gravity, Sci. Adv. 7, eabg2879 (2021).
  15. M. Arndt, O. Nairz, J. Vos-Andreae, G. Keller, G. van der Zouw, and A. Zeilinger, Wave–particle duality of C60 molecules, Nature (London) 401, 680 (1999).
  16. Y. Y. Fein et al., Quantum superposition of molecules beyond 25 kDa, Nat. Phys. 15, 1242 (2019).
  17. M. Arndt and K. Hornberger, Testing the limits of quantum mechanical superpositions, Nat. Phys. 10, 271 (2014).
  18. O. Romero-Isart, Large quantum superpositions and interference of massive nanometer-sized objects, Phys. Rev. Lett. 107, 020405 (2011).
  19. O. Romero-Isart, Quantum superposition of massive objects and collapse models, Phys. Rev. A 84, 052121 (2011).
  20. M. Scala, M. Kim, G. Morley, P. Barker, and S. Bose, Matter-wave interferometry of a levitated thermal nano-oscillator induced and probed by a spin, Phys. Rev. Lett. 111, 180403 (2013).
  21. J. S. Pedernales, G. W. Morley, and M. B. Plenio, Motional dynamical decoupling for interferometry with macroscopic particles, Phys. Rev. Lett. 125, 023602 (2020).
  22. C. Wan, M. Scala, G. Morley, A. Rahman, H. Ulbricht, J. Bateman, P. Barker, S. Bose, and M. Kim, Free nano-object Ramsey interferometry for large quantum superpositions, Phys. Rev. Lett. 117, 143003 (2016).
  23. M. O. Steiner, J. S. Pedernales, and M. B. Plenio, Optically hyperpolarized materials for levitated optomechanics, Quantum 9, 1928 (2025).
  24. R. J. Marshman, A. Mazumdar, R. Folman, and S. Bose, Constructing nano-object quantum superpositions with a Stern-Gerlach interferometer, Phys. Rev. Res. 4, 023087 (2022).
  25. R. Zhou, R. J. Marshman, S. Bose, and A. Mazumdar, Gravito-diamagnetic forces for mass independent large spatial superpositions, Phys. Scr. 99, 055114 (2024).
  26. R. Zhou, R. J. Marshman, S. Bose, and A. Mazumdar, Catapulting towards massive and large spatial quantum superposition, Phys. Rev. Res. 4, 043157 (2022).
  27. R. Zhou, Q. Xiang, and A. Mazumdar, Spin-dependent force and inverted harmonic potential for rapid creation of macroscopic quantum superpositions, Phys. Rev. A 111, 052207 (2025).
  28. R. Zhou, R. J. Marshman, S. Bose, and A. Mazumdar, Mass-independent scheme for enhancing spatial quantum superpositions, Phys. Rev. A 107, 032212 (2023).
  29. F. Kialka, Y. Y. Fein, S. Pedalino, S. Gerlich, and M. Arndt, A roadmap for universal high-mass matter-wave interferometry, AVS Quantum Sci. 4, 020502 (2022).
  30. S. Bose, Matter wave Ramsey interferometry and the quantum nature of gravity, ICTS Bangalore, 2016, https://www.youtube.com/watch?v=0Fv-0k13s_k.
  31. S. Bose, A. Mazumdar, G. W. Morley, H. Ulbricht, M. Toroš, M. Paternostro, A. Geraci, P. Barker, M. S. Kim, and G. Milburn, Spin entanglement witness for quantum gravity, Phys. Rev. Lett. 119, 240401 (2017).
  32. C. Marletto and V. Vedral, Gravitationally induced entanglement between two massive particles is sufficient evidence of quantum effects in gravity, Phys. Rev. Lett. 119, 240402 (2017).
  33. R. J. Marshman, A. Mazumdar, and S. Bose, Locality and entanglement in table-top testing of the quantum nature of linearized gravity, Phys. Rev. A 101, 052110 (2020).
  34. S. Bose, A. Mazumdar, M. Schut, and M. Toroš, Mechanism for the quantum natured gravitons to entangle masses, Phys. Rev. D 105, 106028 (2022).
  35. U. K. Beckering Vinckers, Á. De La Cruz-Dombriz, and A. Mazumdar, Quantum entanglement of masses with nonlocal gravitational interaction, Phys. Rev. D 107, 124036 (2023).
  36. D. Biswas, S. Bose, A. Mazumdar, and M. Toroš, Gravitational optomechanics: Photon-matter entanglement via graviton exchange, Phys. Rev. D 108, 064023 (2023).
  37. S. G. Elahi, M. Schut, A. Dana, A. Grinin, S. Bose, A. Mazumdar, and A. Geraci, Diamagnetic microchip traps for levitated nanoparticle entanglement experiments, Phys. Rev. A 112, 063508 (2025).
  38. S. Bose, A. Mazumdar, M. Schut, and M. Toroš, Entanglement witness for the weak equivalence principle, Entropy 25, 448 (2023).
  39. M. Schut, A. Geraci, S. Bose, and A. Mazumdar, Micrometer-size spatial superpositions for the QGEM protocol via screening and trapping, Phys. Rev. Res. 6, 013199 (2024).
  40. M. Schut and A. Mazumdar, Parameter scanning in a quantum-gravity-induced entanglement of masses (QGEM) experiment with electromagnetic screening, arXiv:2502.12474.
  41. O. Romero-Isart, Coherent inflation for large quantum superpositions of levitated microspheres, New J. Phys. 19, 123029 (2017).
  42. M. Roda-Llordes, A. Riera-Campeny, D. Candoli, P. T. Grochowski, and O. Romero-Isart, Macroscopic quantum superpositions via dynamics in a wide double-well potential, Phys. Rev. Lett. 132, 023601 (2024).
  43. H. Pino, J. Prat-Camps, K. Sinha, B. P. Venkatesh, and O. Romero-Isart, On-chip quantum interference of a superconducting microsphere, Quantum Sci. Technol. 3, 025001 (2018).
  44. S. N. Moorthy and A. Mazumdar, Magnetic noise in macroscopic quantum spatial superposition induced by an inverted harmonic oscillator potential, Phys. Rev. A 113, 012419 (2026).
  45. J.-F. Hsu, P. Ji, C. W. Lewandowski, and B. D’Urso, Cooling the motion of diamond nanocrystals in a magneto-gravitational trap in high vacuum, Sci. Rep. 6, 30125 (2016).
  46. B. A. Stickler, K. Hornberger, and M. Kim, Quantum rotations of nanoparticles, Nat. Rev. Phys. 3, 589 (2021).
  47. Y. Japha and R. Folman, Quantum uncertainty limit for Stern-Gerlach interferometry with massive objects, Phys. Rev. Lett. 130, 113602 (2023).
  48. Y. Japha, Unified model of matter-wave-packet evolution and application to spatial coherence of atom interferometers, Phys. Rev. A 104, 053310 (2021).
  49. X.-Y. Chen, T. Li, and Z.-Q. Yin, Nonadiabatic dynamics and geometric phase of an ultrafast rotating electron spin, Sci. Bull. 64, 380 (2019).
  50. B. A. Stickler et al., Probing macroscopic quantum superpositions with nanorotors, New J. Phys. 20, 122001 (2018).
  51. C. C. Rusconi, M. Perdriat, G. Hétet, O. Romero-Isart, and B. A. Stickler, Spin-controlled quantum interference of levitated nanorotors, Phys. Rev. Lett. 129, 093605 (2022).
  52. Y. Ma, M. Kim, and B. A. Stickler, Torque-free manipulation of nanoparticle rotations via embedded spins, Phys. Rev. B 104, 134310 (2021).
  53. Y. Jin, K. Shen, P. Ju, X. Gao, C. Zu, A. J. Grine, and T. Li, Quantum control and Berry phase of electron spins in rotating levitated diamonds in high vacuum, Nat. Commun. 15, 5063 (2024).
  54. S. Kuhn, A. Kosloff, B. A. Stickler, F. Patolsky, K. Hornberger, M. Arndt, and J. Millen, Full rotational control of levitated silicon nanorods, Optica 4, 356 (2017).
  55. V. Wachter, S. V. Kusminskiy, G. Hétet, and B. A. Stickler, Gyroscopically stabilized quantum spin rotors, Phys. Rev. Lett. 136, 073604 (2026).
  56. M. Rademacher, A. Pontin, J. M. H. Gosling, P. F. Barker, and M. Toroš, Roto-translational levitated optomechanics, Phys. Rep. 1187, 1 (2026).
  57. B. Englert, J. Schwinger, and M. O. Scully, Is spin coherence like Humpty-Dumpty? I. Simplified treatment, Found. Phys. 18, 1045 (1988).
  58. J. Schwinger, M. O. Scully, and B. G. Englert, Is spin coherence like Humpty-Dumpty? Z. Phys. D 10, 135 (1988).
  59. M. O. Scully, B.-G. Englert, and J. Schwinger, Spin coherence and Humpty-Dumpty. III. The effects of observation, Phys. Rev. A 40, 1775 (1989).
  60. T. Zhou, S. Bose, and A. Mazumdar, Gyroscopic stability for nanoparticles in Stern-Gerlach interferometry and spin contrast, Phys. Rev. A 112, 013315 (2025).
  61. R. Rizaldy, T. Zhou, S. Bose, and A. Mazumdar, Rotational stability in nanorotor and spin contrast in one-loop interferometry in the Stern-Gerlach setup, Phys. Rev. Res. 7, 043095 (2025).
  62. M. W. Doherty, N. B. Manson, P. Delaney, F. Jelezko, J. Wrachtrup, and L. C. Hollenberg, The nitrogen-vacancy colour centre in diamond, Phys. Rep. 528, 1 (2013).
  63. M. M. Paraniak and B.-G. Englert, Quantum dynamical simulation of a transversal Stern–Gerlach interferometer, Symmetry 13, 1660 (2021).
  64. Y. Wang, H. Shen, Z. Liu, Y. Yu, S. Du, C. Zu, and C. Zhang, Simultaneous determination of local magnetic fields and sensor orientation with nitrogen-vacancy centers in nanodiamond, arXiv:2507.05366.
  65. J. Homrighausen, F. Hoffmann, J. Pogorzelski, P. Glösekötter, and M. Gregor, Microscale fiber-integrated vector magnetometer with on-tip field biasing using N−V ensembles in diamond microcrystals, Phys. Rev. Appl. 22, 034029 (2024).
  66. Q. Xiang, S. G. Elahi, A. Geraci, S. Bose, and A. Mazumdar, Magnetic levitation and spatial superposition of a nanodiamond with a current-carrying chip, arXiv:2601.06608.
  67. S. Machluf, Y. Japha, and R. Folman, Coherent Stern–Gerlach momentum splitting on an atom chip, Nat. Commun. 4, 2424 (2013).
  68. In principle, we can provide a switching function on-and-off by refined modeling (see Ref. [24]). First, it does not affect the trajectories or any aspects of the conclusion, and with superconducting wires, the switching can be done swiftly; therefore, for this paper we assume that the switching can be assumed as a step function.
  69. L. Braccini, A. Serafini, and S. Bose, Exponential expansion of massive Schrödinger cats for sensing and entanglement, arXiv:2408.11930.
  70. R. J. Marshman, S. Bose, A. Geraci, and A. Mazumdar, Entanglement of magnetically levitated massive Schrödinger cat states by induced dipole interaction, Phys. Rev. A 109, L030401 (2024).
  71. M. H. Abobeih, J. Cramer, M. A. Bakker, N. Kalb, M. Markham, D. J. Twitchen, and T. H. Taminiau, One-second coherence for a single electron spin coupled to a multi-qubit nuclear-spin environment, Nat. Commun. 9, 2552 (2018).
  72. The expectation value of an operator  satisfies the equation of motion as follows: d〈Â〉/dt=i〈[Ĥ,Â]〉/ℏ in the Heisenberg picture, and in this case  refers to the position operators x̂ and ŷ.
  73. If we refer to the trap frequencies generated in Ref. [37] from the current-carrying chip design, after coordinate adjustment in this case, ωx=2π×0.01Hz and ωy=2π×521Hz, compared to ωnl=31.412Hz and ωl=70.241Hz, so it will always be ωy>ωnl>ωl.
  74. We also constructed a similar two-spatial-dimensional SGI, but for a fixed-magnet setup (see Ref. [70]) based on the magnetic-field configuration of Ref. [45]. The advantage of our current setup is that we are able to create a significantly large spatial superposition in a shorter timescale, i.e., Δxmax∼4.4µm in t=0.5s for m∼10−15kg. This is mainly possible because we are using the trap frequencies of ωx,ωy arising from the magnetic-field profiles of a superconducting current-carrying chip design [37]. The magnetic-field gradients are typically large in a chip version as compared to the fixed-magnet configurations.
  75. See Ref. [61] for a complete derivation of the Hamiltonian.
  76. A. Rauh, Coherent states of harmonic and reversed harmonic oscillator, Symmetry 8, 46 (2016).
  77. G. Barton, Quantum mechanics of the inverted oscillator potential, Ann. Phys. 166, 322 (1986).
  78. C. Yuce, Quantum inverted harmonic potential, Phys. Scr. 96, 105006 (2021).
  79. K. Rajeev, S. Chakraborty, and T. Padmanabhan, Inverting a normal harmonic oscillator: Physical interpretation and applications, Gen. Relativ. Gravitation 50, 116 (2018).
  80. I. A. Pedrosa, A. L. de Lima, and A. M. de M. Carvalho, Gaussian wave packet states of a generalized inverted harmonic oscillator with time-dependent mass and frequency, Can. J. Phys. 93, 841 (2015).
  81. L. Braccini, M. Schut, A. Serafini, A. Mazumdar, and S. Bose, Large spin Stern-Gerlach interferometry for gravitational entanglement, arXiv:2312.05170.
  82. Macroscopic superpositions towards witnessing the quantum nature of gravity (MAST-QG), University of Warwick, Physics Department (2023), https://www.moore.org/grant-detail?grantId=GBMF12328.
  83. For nontrivial solution.
  84. Here, the canonical quantization procedure (see Ref.  [85]). We have the commutation relations of the angular momentum: [β̂,p̂β]=[α̂,p̂α]=[γ̂,p̂γ]=iℏand[p̂β,p̂α]=[p̂β,p̂γ]=[p̂α,p̂γ]=0.
  85. A. Barut, M. Božić, and Z. Marić, The magnetic top as a model of quantum spin, Ann. Phys. 214, 53 (1992).
