Inherent Leakage of Hydrophobic Gating in BK Channels

Zhiguang Jia and Jianhan Chen*

  • *Contact author: jianhanc@umass.edu
PDF

PRX Life 4, 013019 – Published 10 February, 2026

DOI: https://doi.org/10.1103/m89c-6vv7

Abstract

The big potassium (BK) channels remain open with a small limiting probability of Po∼10−7 at minimal Ca2+ and negative voltages below −100mV. The molecular origin of such an “intrinsic opening” is not understood. Here, free-energy analysis of K+ permeation shows that the intrinsic opening of BK channels is likely an inherent property of the vapor barrier, generated by hydrophobic dewetting of the inner pore in the Ca2+-free state. The vapor barrier only gives rise to a finite free-energy barrier, of ∼8kcal/mol, and it cannot completely shut down K+ flow even when the voltage sensor domains are fully deactivated. The resulting “leaking” currents can be measured at negative voltages as intrinsic opening. The shallow limiting slope of Po at negative voltages arises primarily from the electric field effects on the permeating ion through the vapor barrier. We further demonstrate that the vapor barrier can be perturbed by truncation of the cytosolic domains, inner pore mutations, and ligand binding to the pore, leading to predicable changes in limiting slope measurements highly consistent with existing experimental data. Therefore, the intrinsic opening paves the way for direct experimental study of hydrophobic gating in BK and many other ion channels.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (83)

  1. A. Marty, Ca-dependent K channels with large unitary conductance in chromaffin cell membranes, Nature (London) 291, 497 (1981).
  2. U. S. Lee and J. Cui, BK channel activation: Structural and functional insights, Trends Neurosci. 33, 415 (2010).
  3. R. MacKinnon, Potassium channels, FEBS Lett. 555, 62 (2003).
  4. L. Salkoff, A. Butler, G. Ferreira, C. Santi, and A. Wei, High-conductance potassium channels of the SLO family, Nat. Rev. Neurosci. 7, 921 (2006).
  5. H. Yang, G. Zhang, and J. Cui, BK channels multiple sensors, one activation gate, Front Physiol. 6, 29 (2015).
  6. F. T. Horrigan and R. W. Aldrich, Coupling between voltage sensor activation, Ca2+ binding and channel opening in large conductance (BK) potassium channels, J. Gen. Physiol. 120, 267 (2002).
  7. J. Shi and J. Cui, Intracellular Mg2+ Enhances the Function of Bk-Type Ca2+-Activated K+ Channels, J. Gen. Physiol. 118, 589 (2001).
  8. K. L. Magleby, Gating mechanism of BK (Slo1) channels: So near, yet so far, J. Gen. Physiol. 121, 81 (2003).
  9. G. F. Contreras, K. Castillo, N. Enrique, W. Carrasquel-Ursulaez, J. P. Castillo, V. Milesi, A. Neely, O. Alvarez, G. Ferreira, C. González, and R. Latorre, A BK (Slo1) channel journey from molecule to physiology, Channels 7, 442 (2013).
  10. B. H. Bentzen, S.-P. Olesen, L. C. B. Rønn, and M. Grunnet, BK channel activators and their therapeutic perspectives, Front. Physiol. 5, 389 (2014).
  11. C. Contet, S. P. Goulding, D. A. Kuljis, and A. L. Barth, BK channels in the central nervous system, Int. Rev. Neurobiol. 128, 281 (2016).
  12. M. A. Zaydman, J. R. Silva, and J. Cui, Ion channel associated diseases: Overview of molecular mechanisms, Chem. Rev. 112, 6319 (2012).
  13. W. Du, J. F. Bautista, H. Yang, A. Diez-Sampedro, S.-A. You, L. Wang, P. Kotagal, H. O. Lüders, J. Shi, J. Cui, G. B. Richerson, and Q. K. Wang, Calcium-sensitive potassium channelopathy in human epilepsy and paroxysmal movement disorder, Nat. Genet. 37, 733 (2005).
  14. T. Lührs, C. Ritter, M. Adrian, D. Riek-Loher, B. Bohrmann, H. Döbeli, D. Schubert, and R. Riek, 3D structure of Alzheimer's amyloid-β(1–42) fibrils, Proc. Natl. Acad. Sci. USA 102, 17342 (2005).
  15. R. Brenner, Q. H. Chen, A. Vilaythong, G. M. Toney, J. L. Noebels, and R. W. Aldrich, BK channel β4 subunit reduces dentate gyrus excitability and protects against temporal lobe seizures, Nat. Neurosci. 8, 1752 (2005).
  16. M. Sausbier, C. Arntz, I. Bucurenciu, H. Zhao, X.-B. Zhou, U. Sausbier, S. Feil, S. Kamm, K. Essin, C. A. Sailer, U. Abdullah, P. Krippeit-Drews, R. Feil, F. Hofmann, H.-G. Knaus, C. Kenyon, M. J. Shipston, J. F. Storm, W. Neuhuber, M. Korth, R. Schubert, M. Gollasch, and P. Ruth, Elevated blood pressure linked to primary hyperaldosteronism and impaired vasodilation in BK channel–deficient mice, Circulation 112, 60 (2005).
  17. M. E. Rockman, A. G. Vouga, and B. S. Rothberg, Molecular mechanism of BK channel activation by the smooth muscle relaxant NS11021, J. Gen. Physiol. 152, e201912506 (2020).
  18. W. A. Catterall, Ion channel voltage sensors: Structure, function, and pathophysiology, Neuron 67, 915 (2010).
  19. J. Wu, Z. Yan, Z. Li, X. Qian, S. Lu, M. Dong, Q. Zhou, and N. Yan, Structure of the voltage-gated calcium channel Ca(v)1.1 at 3.6 A resolution, Nature (London) 537, 191 (2016).
  20. M. J. Lenaeus, T. M. Gamal El-Din, C. Ing, K. Ramanadane, R. Pomes, N. Zheng, and W. A. Catterall, Structures of closed and open states of a voltage-gated sodium channel, Proc. Natl. Acad. Sci. USA 114, E3051 (2017).
  21. K. J. Swartz, Towards a structural view of gating in potassium channels, Nat. Rev. Neurosci. 5, 905 (2004).
  22. R. K. Hite, X. Tao, and R. MacKinnon, Structural basis for gating the high-conductance Ca2+-activated K+ channel, Nature (London) 541, 52 (2017).
  23. X. Tao, R. K. Hite, and R. MacKinnon, Cryo-EM structure of the open high-conductance Ca2+-activated K+ channel, Nature (London) 541, 46 (2017).
  24. X. Tao and R. MacKinnon, Molecular structures of the human Slo1 K+ channel in complex with β4, eLife 8, e51409 (2019).
  25. T. Raisch, A. Brockmann, U. Ebbinghaus-Kintscher, J. Freigang, O. Gutbrod, J. Kubicek, B. Maertens, O. Hofnagel, and S. Raunser, Small molecule modulation of the Drosophila Slo channel elucidated by cryo-EM, Nat. Commun. 12, 7164 (2021).
  26. X. Tao, C. Zhao, and R. MacKinnon, Membrane protein isolation and structure determination in cell-derived membrane vesicles, Proc. Natl. Acad. Sci. USA 120, e2302325120 (2023).
  27. G. F. Contreras, R. Shen, R. Latorre, and E. Perozo, Structural basis of voltage-dependent gating in BK channels, Nat. Commun. 16, 5846 (2025).
  28. J. Cui, BK channel gating mechanisms: Progresses toward a better understanding of variants linked neurological diseases, Front. Physiol. 12, 762175 (2021).
  29. G. Yellen, The voltage-gated potassium channels and their relatives, Nature (London) 419, 35 (2002).
  30. M. S. P. Sansom, I. H. Shrivastava, J. N. Bright, J. Tate, C. E. Capener, and P. C. Biggin, Potassium channels: Structures, models, simulations, Biochim. Biophys. Acta (BBA) 1565, 294 (2002).
  31. S. B. Long, E. B. Campbell, and R. Mackinnon, Crystal structure of a mammalian voltage-dependent Shaker family K+ channel, Science 309, 897 (2005).
  32. Z. Jia, M. Yazdani, G. Zhang, J. Cui, and J. Chen, Hydrophobic gating in BK channels, Nat. Commun. 9, 3408 (2018).
  33. R.-X. Gu and B. L. de Groot, Central cavity dehydration as a gating mechanism of potassium channels, Nat. Commun. 14, 2178 (2023).
  34. E. B. Nordquist, Z. Jia, and J. Chen, Inner pore hydration free-energy controls the activation of big potassium channels, Biophys. J. 122, 1158 (2023).
  35. W. Li and R. W. Aldrich, Unique inner pore properties of BK channels revealed by quaternary ammonium block, J. Gen. Physiol. 124, 43 (2004).
  36. C. M. Wilkens and R. W. Aldrich, State-independent block of BK channels by an intracellular quaternary ammonium, J. Gen. Physiol. 128, 347 (2006).
  37. Y. Zhou, X. M. Xia, and C. J. Lingle, Cysteine scanning and modification reveal major differences between BK channels and Kv channels in the inner pore region, Proc. Natl. Acad. Sci. USA 108, 12161 (2011).
  38. X. Chen, J. Yan, and R. W. Aldrich, BK channel opening involves side-chain reorientation of multiple deep-pore residues, Proc. Natl. Acad. Sci. USA 111, E79 (2014).
  39. M. Yazdani, Z. Jia, and J. Chen, Hydrophobic dewetting in gating and regulation of transmembrane protein ion channels, J. Chem. Phys. 153, 110901 (2020).
  40. P. Aryal, M. S. Sansom, and S. J. Tucker, Hydrophobic gating in ion channels, J. Mol. Biol. 427, 121 (2015).
  41. J. Huang and J. Chen, Hydrophobic gating in bundle-crossing ion channels: A case study of TRPV4, Commun. Biol. 6, 1094 (2023).
  42. G. Zhang, H. Yang, H. Liang, J. Yang, J. Shi, K. McFarland, Y. Chen, and J. Cui, A charged residue in S4 regulates coupling among the activation gate, voltage, and Ca2+ sensors in BK channels, J. Neurosci. 34, 12280 (2014).
  43. D. H. Cox, J. Cui, and R. W. Aldrich, Allosteric gating of a large conductance Ca-activated K+ channel, J. Gen. Physiol. 110, 257 (1997).
  44. J. Cui, D. H. Cox, and R. W. Aldrich, Intrinsic voltage dependence and Ca2+ regulation of mslo large conductance Ca-activated K+ channels, J. Gen. Physiol. 109, 647 (1997).
  45. W. N. Zagotta, T. Hoshi, and R. W. Aldrich, Shaker potassium channel gating. III: Evaluation of kinetic models for activation, J. Gen. Physiol. 103, 321 (1994).
  46. G. J. Soler-Llavina, M. Holmgren, and K. J. Swartz, Defining the conductance of the closed state in a voltage-gated K+ channel, Neuron 38, 61 (2003).
  47. See Supplemental Material at http://link.aps.org/supplemental/10.1103/m89c-6vv7 for tables summarizing all simulations and supporting figures reporting additional structural and dynamic properties derived from simulations.
  48. T. I. Brelidze, X. Niu, and K. L. Magleby, A ring of eight conserved negatively charged amino acids doubles the conductance of BK channels and prevents inward rectification, Proc. Natl. Acad. Sci. USA 100, 9017 (2003).
  49. L. Coronel, G. Di Muccio, B. S. Rothberg, A. Giacomello, and V. Carnevale, Lipid-mediated hydrophobic gating in the BK potassium channel, Nat. Commun. 16, 7354 (2025).
  50. J. Deng and Q. Cui, Electronic polarization leads to a drier Dewetted State for hydrophobic gating in the big potassium channel, J. Phys. Chem. Lett. 15, 7436 (2024).
  51. F. T. Horrigan, J. Cui, and R. W. Aldrich, Allosteric voltage gating of potassium channels I. Mslo ionic currents in the absence of Ca(2+), J. Gen. Physiol. 114, 277 (1999).
  52. G. Zhang, Y. Geng, Y. Jin, J. Shi, K. McFarland, K. L. Magleby, L. Salkoff, and J. Cui, Deletion of cytosolic gating ring decreases gate and voltage sensor coupling in BK channels, J. Gen. Physiol. 149, 373 (2017).
  53. F. T. Horrigan and R. W. Aldrich, Allosteric voltage gating of potassium channels II. Mslo channel gating charge movement in the absence of Ca(2+), J. Gen. Physiol. 114, 305 (1999).
  54. J. C. Rasaiah, S. Garde, and G. Hummer, Water in nonpolar confinement: From nanotubes to proteins and beyond, Annu. Rev. Phys. Chem. 59, 713 (2008).
  55. G. Klesse, S. J. Tucker, and M. S. P. Sansom, Electric field induced wetting of a hydrophobic gate in a model nanopore based on the 5-HT3 receptor channel, ACS Nano 14, 10480 (2020).
  56. E. B. Nordquist, S. A. Schultz, and J. Chen, Using metadynamics to explore the free-energy of dewetting in biologically relevant nanopores, J. Phys. Chem. B 126, 6428 (2022).
  57. J. Aqvist and V. Luzhkov, Ion permeation mechanism of the potassium channel, Nature (London) 404, 881 (2000).
  58. S. Bernèche and B. Roux, Energetics of ion conduction through the K+ channel, Nature (London) 414, 73 (2001).
  59. L. Sun and F. T. Horrigan, A gating lever and molecular logic gate that couple voltage and calcium sensor activation to opening in BK potassium channels, Sci. Adv. 8, eabq5772 (2022).
  60. G. Budelli, Y. Y. Geng, A. Butler, K. L. Magleby, and L. Salkoff, Properties of Slo1 K+ channels with and without the gating ring, Proc. Natl. Acad. Sci. USA 110, 16657 (2013).
  61. M. Schewe, H. Sun, U. Mert, A. Mackenzie, A. C. W. Pike, F. Schulz, C. Constantin, K. S. Vowinkel, L. J. Conrad, A. K. Kiper, W. Gonzalez, M. Musinszki, M. Tegtmeier, D. C. Pryde, H. Belabed, M. Nazare, B. L. de Groot, N. Decher, B. Fakler, E. P. Carpenter, S. J. Tucker, and T. Baukrowitz, A pharmacological master key mechanism that unlocks the selectivity filter gate in K+ channels, Science 363, 875 (2019).
  62. E. B. Nordquist, Z. Jia, and J. Chen, Small molecule NS11021 promotes BK channel activation by increasing inner pore hydration, J. Chem. Inf. Model. 64, 7616 (2024).
  63. J. Yang, G. Krishnamoorthy, A. Saxena, G. Zhang, J. Shi, H. Yang, K. Delaloye, D. Sept, and J. Cui, An epilepsy/dyskinesia-associated mutation enhances BK channel activation by potentiating Ca2+ sensing, Neuron 66, 871 (2010).
  64. G. F. Contreras, R. Sheng, R. Latorre, and E. Perozo, Structural basis of voltage-dependent gating in BK channels and its coupling to the calcium sensor, BiorXiv:2023.12.29.573674 (2023).
  65. J. Lee, X. Cheng, J. M. Swails, M. S. Yeom, P. K. Eastman, J. A. Lemkul, S. Wei, J. Buckner, J. C. Jeong, Y. Qi, S. Jo, V. S. Pande, D. A. Case, C. L. Brooks, A. D. MacKerell, J. B. Klauda, and W. Im, CHARMM-GUI input generator for NAMD, GROMACS, AMBER, OpenMM, and CHARMM/OpenMM simulations using the CHARMM36 additive force field, J. Chem. Theor. Comput. 12, 405 (2016).
  66. J. Huang, S. Rauscher, G. Nawrocki, T. Ran, M. Feig, B. L. de Groot, H. Grubmüller, and A. D. MacKerell Jr., CHARMM36m: An improved force field for folded and intrinsically disordered proteins, Nat. Methods 14, 71 (2016).
  67. J. B. Klauda, R. M. Venable, J. A. Freites, J. W. O'Connor, D. J. Tobias, C. Mondragon-Ramirez, I. Vorobyov, A. D. MacKerell, and R. W. Pastor, Update of the CHARMM all-atom additive force field for lipids: Validation on six lipid types, J. Phys. Chem. B 114, 7830 (2010).
  68. B. Hess, C. Kutzner, D. van der Spoel, and E. Lindahl, GROMACS 4: Algorithms for highly efficient, load-balanced, and scalable molecular simulation, J. Chem. Theor. Comput. 4, 435 (2008).
  69. M. J. Abraham, T. Murtola, R. Schulz, S. Páll, J. C. Smith, B. Hess, and E. Lindahl, GROMACS: High performance molecular simulations through multi-level parallelism from laptops to supercomputers, SoftwareX 1–2, 19 (2015).
  70. T. Darden, D. York, and L. Pedersen, Particle mesh Ewald: An N-log (N) method for Ewald sums in large systems, J. Chem. Phys. 98, 10089 (1993).
  71. J.-P. Ryckaert, G. Ciccotti, and H. J. C. Berendsen, Numerical integration of the cartesian equations of motion of a system with constraints: Molecular dynamics of n-alkanes, J. Comput. Phys. 23, 327 (1977).
  72. S. Nosé, A unified formulation of the constant temperature molecular dynamics methods, J. Chem. Phys. 81, 511 (1984).
  73. W. G. Hoover, Canonical dynamics: Equilibrium phase-space distributions, Phys. Rev. A 31, 1695 (1985).
  74. M. Parrinello and A. Rahman, Polymorphic transitions in single crystals: A new molecular dynamics method, J. Appl. Phys. 52, 7182 (1981).
  75. S. Jo, T. Kim, and W. Im, Automated builder and database of protein/membrane complexes for molecular dynamics simulations, PLoS ONE 2, e880 (2007).
  76. J. Gumbart, F. Khalili-Araghi, M. Sotomayor, and B. Roux, Constant electric field simulations of the membrane potential illustrated with simple systems, Biochim. Biophys. Acta (BBA) 1818, 294 (2012).
  77. G. M. Torrie and J. P. Valleau, Non-physical sampling distributions in Monte-Carlo free-energy estimation–umbrella sampling, J. Comput. Phys. 23, 187 (1977).
  78. S. Kumar, J. M. Rosenberg, D. Bouzida, R. H. Swendsen, and P. A. Kollman, The weighted histogram analysis method for free-energy calculations on biomolecules. I. The method, J. Comput. Chem. 13, 1011 (1992).
  79. W. Humphrey, A. Dalke, and K. Schulten, VMD: Visual molecular dynamics, J. Mol. Graph. 14, 33 (1996).
  80. N. Michaud-Agrawal, E. J. Denning, T. B. Woolf, and O. Beckstein, MDAnalysis: A toolkit for the analysis of molecular dynamics simulations, J. Comput. Chem. 32, 2319 (2011).
  81. O. S. Smart, J. G. Neduvelil, X. Wang, B. A. Wallace, and M. S. P. Sansom, HOLE: A program for the analysis of the pore dimensions of ion channel structural models, J. Mol. Graphics Model. 14, 354 (1996).
  82. A. Aksimentiev and K. Schulten, Imaging alpha-hemolysin with molecular dynamics: Ionic conductance, osmotic permeability, and the electrostatic potential map, Biophys. J. 88, 3745 (2005).
  83. https://github.com/zhiguangjia/BK_vapor_barrier.
