3D Agent-Based Modeling without Chemical Signaling Recreates Collective Behaviors seen in Myxococcus xanthus Colonies

Katherine Copenhagen1, Matthew Black1, and Joshua W. Shaevitz1,2,*

  • *Contact author: shaevitz@princeton.edu
PDF

PRX Life 3, 043015 – Published 1 December, 2025

DOI: https://doi.org/10.1103/jfqj-2n4q

Abstract

Myxococcus xanthus is a soil-dwelling bacterium that lives in dense populations of millions of cells and displays an array of collective behaviors and macroscopic patterns in response to environmental conditions. The transitions between macroscopic patterns formed by this species are driven by changes in cell motility such as increasing Péclet number via increasing cell speed and reversal period. While cells are capable of passing contact-mediated signals that can trigger reversal events, we set out to study which aspects of M. xanthus collective behavior may be driven by simple individual cell behavior changes in the absence of direct chemical cell signaling. We do this through three-dimensional agent-based simulations with a bead-spring chain model. We find that when tuned to match single-cell properties, this model captures multicellular structures observed at both intermediate and global scales in M. xanthus experiments. Increasing cell speed and reversal period together (as cells do when they starve) maintains a constant overall nematic structure in the population, while significantly increasing the net flow into and out of topological defects, which drives an increased aggregation that leads to fruiting-body formation during starvation.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (37)

  1. M. Bär, R. Großmann, S. Heidenreich, and F. Peruani, Self-propelled rods: Insights and perspectives for active matter, Annu. Rev. Condens. Matter Phys. 11, 441 (2020).
  2. A. Sciortino and A. R. Bausch, Pattern formation and polarity sorting of driven actin filaments on lipid membranes, Proc. Natl. Acad. Sci. USA 118, e2017047118 (2021).
  3. A. Sokolov and I. S. Aranson, Physical properties of collective motion in suspensions of bacteria, Phys. Rev. Lett. 109, 248109 (2012).
  4. L. Huber, T. Krüger, and E. Frey, Microphase separation in active filament systems maintained by cyclic dynamics of cluster size and order, Phys. Rev. Res. 3, 013280 (2021).
  5. E. Han, C. Fei, R. Alert, K. Copenhagen, M. D. Koch, N. S. Wingreen, and J. W. Shaevitz, Local polar order controls mechanical stress and triggers layer formation in myxococcus xanthus colonies, Nat. Commun. 16, 952 (2025).
  6. R. Großmann, F. Peruani, and M. Bär, Diffusion properties of active particles with directional reversal, New J. Phys. 18, 043009 (2016).
  7. J. Taktikos, H. Stark, and V. Zaburdaev, How the motility pattern of bacteria affects their dispersal and chemotaxis, PLoS One 8, e81936 (2013).
  8. I. Santra, U. Basu, and S. Sabhapandit, Active brownian motion with directional reversals, Phys. Rev. E 104, L012601 (2021).
  9. K. Kawaguchi, R. Kageyama, and M. Sano, Topological defects control collective dynamics in neural progenitor cell cultures, Nature (London) 545, 327 (2017).
  10. J. E. Johansen, J. Pinhassi, N. Blackburn, U. L. Zweifel, and Å. Hagström, Variability in motility characteristics among marine bacteria, Aquat. Microb. Ecol. 28, 229 (2002).
  11. G. M. Barbara and J. G. Mitchell, Bacterial tracking of motile algae, FEMS microbiol. ecol. 44, 79 (2003).
  12. C. Tamulonis, M. Postma, and J. Kaandorp, Modeling filamentous cyanobacteria reveals the advantages of long and fast trichomes for optimizing light exposure, PLoS One 6, e22084 (2011).
  13. A. Be'er, S. K. Strain, R. A. Hernández, E. Ben-Jacob, and E.-L. Florin, Periodic reversals in paenibacillus dendritiformis swarming, J. Bacteriol. 195, 2709 (2013).
  14. M. J. Kühn, L. Talà, Y. F. Inclan, R. Patino, X. Pierrat, I. Vos, Z. Al-Mayyah, H. Macmillan, J. Negrete, Jr., J. N. Engel et al., Mechanotaxis directs pseudomonas aeruginosa twitching motility, Proc. Natl. Acad. Sci. USA 118, e2101759118 (2021).
  15. U. Pfreundt, J. Słomka, G. Schneider, A. Sengupta, F. Carrara, V. Fernandez, M. Ackermann, and R. Stocker, Controlled motility in the cyanobacterium trichodesmium regulates aggregate architecture, Science 380, 830 (2023).
  16. D. Kaiser and R. Welch, Dynamics of fruiting body morphogenesis, J. Bacteriol. 186, 919 (2004).
  17. J. Muñoz-Dorado, F. J. Marcos-Torres, E. García-Bravo, A. Moraleda-Muñoz, and J. Pérez, Myxobacteria: Moving, killing, feeding, and surviving together, Front. microbiol. 7, 781 (2016).
  18. G. Liu, A. Patch, F. Bahar, D. Yllanes, R. D. Welch, M. C. Marchetti, S. Thutupalli, and J. W. Shaevitz, Self-driven phase transitions drive myxococcus xanthus fruiting body formation, Phys. Rev. Lett. 122, 248102 (2019).
  19. L. Jelsbak and L. Søgaard-Andersen, Pattern formation by a cell surface-associated morphogen in myxococcus xanthus, Proc. Natl. Acad. Sci. USA 99, 2032 (2002).
  20. R. Mercier and T. Mignot, Regulations governing the multicellular lifestyle of myxococcus xanthus, Curr. Opin. Microbiol. 34, 104 (2016).
  21. T. Sanchez, D. T. Chen, S. J. DeCamp, M. Heymann, and Z. Dogic, Spontaneous motion in hierarchically assembled active matter, Nature (London) 491, 431 (2012).
  22. K. Copenhagen, R. Alert, N. S. Wingreen, and J. W. Shaevitz, Topological defects promote layer formation in myxococcus xanthus colonies, Nat. Phys. 17, 211 (2021).
  23. M. Dedenon, C. Blanch-Mercader, K. Kruse, and J. Elgeti, The importance of being discrete—an agent-based model for active nematics and more, arXiv:2501.04559.
  24. A. P. Thompson, H. M. Aktulga, R. Berger, D. S. Bolintineanu, W. M. Brown, P. S. Crozier, P. J. In't Veld, A. Kohlmeyer, S. G. Moore, T. D. Nguyen et al., lammps—a flexible simulation tool for particle-based materials modeling at the atomic, meso, and continuum scales, Comput. Phys. Commun. 271, 108171 (2022).
  25. R. G. Winkler, A. Wysocki, and G. Gompper, Virial pressure in systems of spherical active brownian particles, Soft Matter 11, 6680 (2015).
  26. See Supplemental Material at http://link.aps.org/supplemental/10.1103/jfqj-2n4q for supplemental figures and methods.
  27. M. E. Black, C. Fei, R. Alert, N. S. Wingreen, and J. W. Shaevitz, Capillary interactions drive the self-organization of bacterial colonies, Nat. Phys. 21, 1444 (2025).
  28. A. Baskaran and M. C. Marchetti, Self-regulation in self-propelled nematic fluids, Eur. Phys. J. E 35, 95 (2012).
  29. G. A. Vliegenthart, A. Ravichandran, M. Ripoll, T. Auth, and G. Gompper, Filamentous active matter: Band formation, bending, buckling, and defects, Sci. Adv. 6, eaaw9975 (2020).
  30. H. Chaté, F. Ginelli, and R. Montagne, Simple model for active nematics: Quasi-long-range order and giant fluctuations, Phys. Rev. Lett. 96, 180602 (2006).
  31. M. C. Marchetti, J.-F. Joanny, S. Ramaswamy, T. B. Liverpool, J. Prost, M. Rao, and R. A. Simha, Hydrodynamics of soft active matter, Rev. Mod. Phys. 85, 1143 (2013).
  32. L. Giomi, M. J. Bowick, P. Mishra, R. Sknepnek, and M. Cristina Marchetti, Defect dynamics in active nematics, Philos. Trans. R. Soc. A 372, 20130365 (2014).
  33. A. J. Tan, E. Roberts, S. A. Smith, U. A. Olvera, J. Arteaga, S. Fortini, K. A. Mitchell, and L. S. Hirst, Topological chaos in active nematics, Nat. Phys. 15, 1033 (2019).
  34. L. Giomi, Geometry and topology of turbulence in active nematics, Phys. Rev. X 5, 031003 (2015).
  35. B. Nan, J. Chen, J. C. Neu, R. M. Berry, G. Oster, and D. R. Zusman, Myxobacteria gliding motility requires cytoskeleton rotation powered by proton motive force, Proc. Natl. Acad. Sci. USA 108, 2498 (2011).
  36. R. Balagam, D. B. Litwin, F. Czerwinski, M. Sun, H. B. Kaplan, J. W. Shaevitz, and O. A. Igoshin, Myxococcus xanthus gliding motors are elastically coupled to the substrate as predicted by the focal adhesion model of gliding motility, PLoS Comput. Biol. 10, e1003619 (2014).
  37. K. Copenhagen, Myxo symulations, https://github.com/kcopenhagen/lammps-myxosim
