Robotectonics: Emergent Phototactic Aggregation-Disaggregation in Swarms

Fabio Giardina1,*, S. Ganga Prasath1,2,*, and L. Mahadevan1,3,4,†

  • 1School of Engineering and Applied Sciences, Harvard University, Cambridge, Massachusetts 02138, USA
  • 2Department of Applied Mechanics & Biomedical Engineering, IIT Madras, Chennai 600036, Tamil Nadu, India
  • 3Department of Physics, Harvard University, Cambridge, Massachusetts 02138, USA
  • 4Department of Organismic and Evolutionary Biology, Harvard University, Cambridge, Massachusetts 02138, USA

  • *These authors contributed equally to this work.
  • †Contact author: lmahadev@g.harvard.edu
PDF

PRX Life 4, 023005 – Published 10 April, 2026

DOI: https://doi.org/10.1103/cx3h-bwhc

Abstract

The collective construction of complex architectures by social insects involves the use of decentralized spatiotemporal signals in a dynamical environment that changes the behavior of the insects and is changed by them. Inspired by this original example of “stigmergy,” we show that a robot collective can nucleate, construct, and deconstruct aggregates via a trapping instability by simply altering their local transport behavior. We quantify these observations in terms of a two-dimensional phase space that encompasses agent-agent interaction and the agent-environment interaction (collection and deposition). Our results show how coordinated function can emerge spontaneously through simple local rules for sensing and action without the need for global representation, planning, or optimization/control algorithms, in sharp contrast with the traditional views of complex task execution. More broadly, our study shows that embodied collectives can leverage the environment as both a communication channel and a spatiotemporal memory, coupling organismal behavior to environmental remodeling leading to “exbodied intelligence.”

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (40)

  1. B. Hölldobler and E. O Wilson, The Ants (Harvard University Press, Cambridge, MA, 1990).
  2. D. M. Gordon, Ants at Work: How An Insect Society is Organized (Simon and Schuster, 1999).
  3. S. Camazine, J.-L. Deneubourg, N. R Franks, J. Sneyd, G. Theraulaz, and E. Bonabeau, Self-Organization in Biological Systems (Princeton University Press, Princeton, NJ, 2020).
  4. A. Perna and G. Theraulaz, When social is moulded in clay: On growth and form of social insect nests, J. Exp. Biol. 220, 83 (2017).
  5. S. G. Prasath, S. Mandal, F. Giardina, J. Kennedy, V. N. Murthy, and L. Mahadevan, Dynamics of cooperative excavation in ant and robot collectives, eLife 11, e79638 (2022).
  6. R. Pfeifer, M. Lungarella, and F. Iida, Self-organization, embodiment, and biologically inspired robotics, Science 318, 1088 (2007).
  7. G. Wang, T. V. Phan, S. Li, J. Wang, Y. Peng, G. Chen, J. Qu, D. I. Goldman, S. A. Levin, K. Pienta, et al., Robots as models of evolving systems, Proc. Natl. Acad. Sci. USA 119, e2120019119 (2022).
  8. A. Miriyev and M. Kovač, Skills for physical artificial intelligence, Nat. Mach. Intell. 2, 658 (2020).
  9. K. H. Petersen, N. Napp, R. Stuart-Smith, D. Rus, and M. Kovac, A review of collective robotic construction, Sci. Rob. 4, 28 (2019).
  10. J. P. Desai, J. Ostrowski, and V. Kumar, Controlling formations of multiple mobile robots, in Proceedings of the 1998 IEEE International Conference on Robotics and Automation (Cat. No. 98CH36146) (IEEE, Piscataway, NJ, 1998), Vol. 4, pp. 2864–2869.
  11. M. Rubenstein, A. Cornejo, and R. Nagpal, Programmable self-assembly in a thousand-robot swarm, Science 345, 795 (2014).
  12. S. Li, B. Dutta, S. Cannon, J. J. Daymude, R. Avinery, E. Aydin, A. W. Richa, D. I. Goldman, and D. Randall, Programming active cohesive granular matter with mechanically induced phase changes, Sci. Adv. 7, eabe8494 (2021).
  13. P.-P. Grassé, La reconstruction du nid et les coordinations interindividuelles chez bellicositermes natalensis et cubitermes sp. la théorie de la stigmergie: Essai d'interprétation du comportement des termites constructeurs, Insectes Soc. 6, 41 (1959).
  14. A. Heyde, L. Guo, C. Jost, G. Theraulaz, and L. Mahadevan, Self-organized biotectonics of termite nests, Proc. Natl. Acad. Sci. USA 118, e2006985118 (2021).
  15. M. Dorigo, G. Theraulaz, and V. Trianni, Swarm robotics: Past, present, and future [point of view], Proc. IEEE 109, 1152 (2021).
  16. M. Gauci, J. Chen, W. Li, T. J. Dodd, and R. Gross, Clustering objects with robots that do not compute, in Proceedings of the 2014 International Conference on Autonomous Agents and Multi-Agent Systems (International Foundation for Autonomous Agents and Multiagent Systems, Paris, 2014), pp. 421–428.
  17. C. A. C. Parker, H. Zhang, and C. R. Kube, Blind bulldozing: Multiple robot nest construction, in Proceedings of the 2003 IEEE/RSJ International Conference on Intelligent Robots and Systems (IROS 2003) (Cat. No. 03CH37453) (IEEE, Piscataway, NJ, 2003), Vol. 2, pp. 2010–2015.
  18. Y. Song, J.-H. Kim, and D. A Shell, Self-organized clustering of square objects by multiple robots, in Swarm Intelligence: 8th International Conference, ANTS 2012, Lecture Notes in Computer Science (LNTCS), Vol. 7461 (Springer, Berlin, Heidelberg, 2012), pp. 308–315.
  19. O. Holland and C. Melhuish, Stigmergy, self-organization, and sorting in collective robotics, Artif. Life 5, 173 (1999).
  20. F. Iida and F. Giardina, On the timescales of embodied intelligence for autonomous adaptive systems, Annu. Rev. Control Rob. Auton. Syst. 6, 95 (2023).
  21. I. Rahwan, M. Cebrian, N. Obradovich, J. Bongard, J.-F. Bonnefon, C. Breazeal, J. W. Crandall, N. A. Christakis, I. D. Couzin, M. O. Jackson, et al., Machine behaviour, Nature (London) 568, 477 (2019).
  22. R. Fujisawa, S. Dobata, D. Kubota, H. Imamura, and F. Matsuno, Dependency by concentration of pheromone trail for multiple robots, in International Conference on Ant Colony Optimization and Swarm Intelligence, ANTS 2008, edited by M. Dorigo, M. Birattari, C. Blum, M. Clerc, T. Stützle, and A. F. T. Winfield, Lecture Notes in Computer Science (LNTCS), Vol. 5217 (Springer, Berlin, Heidelberg, 2008), pp. 283–290.
  23. R. Mayet, J. Roberz, T. Schmickl, and K. Crailsheim, Antbots: A feasible visual emulation of pheromone trails for swarm robots, in International Conference on Swarm Intelligence, ANTS 2010, edited by M. Dorigo, et al., Lecture Notes in Computer Science (LNTCS), Vol. 6234 (Springer, Berlin, Heidelberg, 2010), pp. 84–94.
  24. A. A. Khaliq, M. D. Rocco, and A. Saffiotti, Stigmergic algorithms for multiple minimalistic robots on an RFID floor, Swarm Intell. 8, 199 (2014).
  25. A. Reina, M. Salvaro, G. Francesca, L. Garattoni, C. Pinciroli, M. Dorigo, and M. Birattari, Augmented reality for robots: Virtual sensing technology applied to a swarm of e-pucks, in 2015 NASA/ESA Conference on Adaptive Hardware and Systems (AHS) (IEEE, Piscataway, NJ, 2015), pp. 1–6.
  26. K. Sugawara, T. Kazama, and T. Watanabe, Foraging behavior of interacting robots with virtual pheromone, in 2004 IEEE/RSJ International Conference on Intelligent Robots and Systems (IROS) (IEEE Cat. No. 04CH37566) (IEEE, Piscataway, NJ, 2004), Vol. 3, pp. 3074–3079.
  27. S. Garnier, F. Tache, M. Combe, A. Grimal, and G. Theraulaz, Alice in pheromone land: An experimental setup for the study of ant-like robots, in 2007 IEEE Swarm Intelligence Symposium (IEEE, Piscataway, NJ, 2007), pp. 37–44.
  28. F. Arvin, T. Krajník, A. E. Turgut, and S. Yue, Coso: Artificial pheromone system for robotic swarms research, in 2015 IEEE/RSJ International Conference on Intelligent Robots and Systems (IROS) (IEEE, Piscataway, NJ, 2015), pp. 407–412.
  29. G. Wang, T. V. Phan, S. Li, M. Wombacher, J. Qu, Y. Peng, G. Chen, D. I. Goldman, S. A. Levin, R. H. Austin, et al., Emergent field-driven robot swarm states, Phys. Rev. Lett. 126, 108002 (2021).
  30. L. Giomi, N. Hawley-Weld, and L. Mahadevan, Swarming, swirling and stasis in sequestered bristle-bots, Proc. R. Soc. A 469, 20120637 (2013).
  31. J. Aguilar, D. Monaenkova, V. Linevich, W. Savoie, B. Dutta, H.-S. Kuan, M. D. Betterton, M. A. D. Goodisman, and D. I. Goldman, Collective clog control: Optimizing traffic flow in confined biological and robophysical excavation, Science 361, 672 (2018).
  32. S. Na, M. Raoufi, A. E. Turgut, T. Krajník, and F. Arvin, Extended artificial pheromone system for swarm robotic applications, in Artificial Life Conference Proceedings (MIT Press, Cambridge, MA, 2019), pp. 608–615.
  33. See Supplemental Material at http://link.aps.org/supplemental/10.1103/cx3h-bwhc for SI Videos, calculation and simulation details as well as the extended experimental results.
  34. T. C. Schneirla, A unique case of circular milling in ants, considered in relation to trail following and the general problem of orientation, Am Museum Novitates 1253, 1 (1944).
  35. Y. Tsori and P.-G. De Gennes, Self-trapping of a single bacterium in its own chemoattractant, Europhys. Lett. 66, 599 (2004).
  36. J. Taktikos, V. Zaburdaev, and H. Stark, Modeling a self-propelled autochemotactic walker, Phys. Rev. E 84, 041924 (2011).
  37. W. T. Kranz, A. Gelimson, K. Zhao, G. C. L. Wong, and R. Golestanian, Effective dynamics of microorganisms that interact with their own trail, Phys. Rev. Lett. 117, 038101 (2016).
  38. T. Hillen and K. J. Painter, A user's guide to PDE models for chemotaxis, J. Math. Biol. 58, 183 (2009).
  39. https://datadryad.org/stash/share/k3zM3bg_Owr1QvgjX7NjaHJY15GRDbByHH1XAK9e0sE
  40. M. L. Goc, L. H. Kim, A. Parsaei, J.-D. Fekete, P. Dragicevic, and S. Follmer, Zooids: Building blocks for swarm user interfaces, in Proceedings of the 29th Annual Symposium on User Interface Software and Technology (Association for Computing Machinery, New York, 2016), pp. 97–109.
