Single Molecule Investigations of Impacts from Mycobacterial Topoisomerase I C-terminal Deletions on Supercoil Relaxation

Dillon Balthrop1, Deepesh Sigdel1, Chunfeng Mao1, Yuk-Ching Tse-Dinh2,3, and Maria Mills1,*

  • *Contact author: k.maria.mills@missouri.edu
PDF

PRX Life 4, 033002 – Published 6 July, 2026

DOI: https://doi.org/10.1103/9tkx-w3zj

Abstract

Type IA topoisomerases relieve torsional stress in DNA by a strand-passage mechanism, using the strain in the DNA to drive relaxation. The topoisomerase IAs of the Mycobacterium genus have distinct C-terminal domains which are crucial for successful strand passage. We used single molecule magnetic tweezers to observe supercoil relaxation by wild type Mycobacterium smegmatis topoisomerase IA and two C-terminal truncation mutants. We recorded distinct behaviors from each truncation mutant. We calculated the free energy stored in the DNA as it is twisted under force to examine the differences between the proteins. Based on our results, we propose a modified model of the strand-passage cycle.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (41)

  1. R. N. Irobalieva, J. M. Fogg, D. J. Catanese, T. Sutthibutpong, M. Chen, A. K. Barker, S. J. Ludtke, S. A. Harris, M. F. Schmid, W. Chiu, and L. Zechiedrich, Structural diversity of supercoiled DNA, Nat. Commun. 6, 8440 (2015).
  2. J. F. Marko, Torque and dynamics of linking number relaxation in stretched supercoiled DNA, Phys. Rev. E 76, 021926 (2007).
  3. J. C. Wang, L. J. Peck, and K. Becherer, DNA supercoiling and its effects on DNA structure and function, Cold Spring Harbor Symp. Quant. Biol. 47, 85 (1983).
  4. P. Bettotti, V. Visone, L. Lunelli, G. Perugino, M. Ciaramella, and A. Valenti, Structure and properties of DNA molecules over the full range of biologically relevant supercoiling states, Sci. Rep. 8, 6163 (2018).
  5. A. S. Krasilnikov, A. Podtelezhnikov, A. Vologodskii, and S. M. Mirkin, Large-scale effects of transcriptional DNA supercoiling in vivo, J. Mol. Biol. 292, 1149 (1999).
  6. A. L. Mikheikin, A. Y. Lushnikov, and Y. L. Lyubchenko, Effect of DNA supercoiling on the geometry of Holliday junctions, Biochemistry 45, 12998 (2006).
  7. L. A. Freeman and W. T. Garrard, DNA supercoiling in chromatin structure and gene expression, Crit. Rev. Eukaryotic Gene Expression 2, 165 (1992).
  8. J. J. Champoux, DNA topoisomerases: Structure, function, and mechanism, Annu. Rev. Biochem. 70, 369 (2001).
  9. A. J. Schoeffler and J. M. Berger, DNA topoisomerases: Harnessing and constraining energy to govern chromosome topology, Q. Rev. Biophys. 41, 41 (2008).
  10. P. Forterre, S. Gribaldo, D. Gadelle, and M.-C. Serre, Origin and evolution of DNA topoisomerases, Biochimie 89, 427 (2007).
  11. M. Mills, Y.-C. Tse-Dinh, and K. C. Neuman, Direct observation of topoisomerase IA gate dynamics, Nat. Struct. Mol. Biol. 25, 1111 (2018).
  12. Z. Li, A. Mondragón, and R. J. DiGate, The mechanism of type IA topoisomerase-mediated DNA topological transformations, Mol. Cell 7, 301 (2001).
  13. N. H. Dekker, V. V. Rybenkov, M. Duguet, N. J. Crisona, N. R. Cozzarelli, D. Bensimon, and V. Croquette, The mechanism of type IA topoisomerases, Proc. Natl. Acad. Sci. USA 99, 12126 (2002).
  14. J. F. Marko, DNA under high tension: Overstretching, undertwisting, and relaxation dynamics, Phys. Rev. E 57, 2134 (1998).
  15. J. C. Wang, DNA topoisomerases, Annu. Rev. Biochem. 65, 635 (1996).
  16. T. Viard and C. B. de la Tour, Type IA topoisomerases: A simple puzzle? Biochimie 89, 456 (2007).
  17. K. D. Corbett and J. M. Berger, Structure, molecular mechanisms, and evolutionary relationships in DNA topoisomerases, Annu. Rev. Biophys. 33, 95 (2004).
  18. W. Ahmed, A. G. Bhat, M. N. Leelaram, S. Menon, and V. Nagaraja, Carboxyl terminal domain basic amino acids of mycobacterial topoisomerase I bind DNA to promote strand passage, Nucl. Acids Res. 41, 7462 (2013).
  19. N. Cao, K. Tan, X. Zuo, T. Annamalai, and Y.-C. Tse-Dinh, Mechanistic insights from structure of Mycobacterium smegmatis topoisomerase I with ssDNA bound to both N- and C-terminal domains, Nucl. Acids Res. 48, 4448 (2020).
  20. S. Ferdous, T. Dasgupta, T. Annamalai, K. Tan, and Y.-C. Tse-Dinh, The interaction between transport-segment DNA and topoisomerase IA—crystal structure of MtbTOP1 in complex with both G- and T-segments, Nuc. Acids Res. 51, 349 (2023).
  21. A. Seddek, T. Annamalai, and Y.-C. Tse-Dinh, Type IA topoisomerases as targets for infectious disease treatments, Microorganisms 9, 86 (2021).
  22. K. Buzun, A. Bielawska, K. Bielawski, and A. Gornowicz, DNA topoisomerases as molecular targets for anticancer drugs, J. Enzyme Inhib. Med. Chem. 35, 1781 (2020).
  23. P. Jain and V. Nagaraja, Indispensable, functionally complementing N and C-terminal domains constitute site-specific topoisomerase I, J. Mol. Biol. 357, 1409 (2006).
  24. I. De Vlaminck and C. Dekker, Recent advances in magnetic tweezers, Annu. Rev. Biophys. 41, 453 (2012).
  25. K. Kim and O. A. Saleh, A high-resolution magnetic tweezer for single-molecule measurements, Nucl. Acids Res. 37, e136 (2009).
  26. S. Gaire, R. Fabian, Jr., I. Pegg, and A. Sarkar, Magnetic tweezers: Development and use in single-molecule research, BioTechniques 72, 65 (2022).
  27. K. C. Neuman and A. Nagy, Single-molecule force spectroscopy: Optical tweezers, magnetic tweezers and atomic force microscopy, Nat. Methods 5, 491 (2008).
  28. Y. Seol and K. C. Neuman, Magnetic tweezers for single-molecule manipulation, in Single Molecule Analysis: Methods and Protocols, Methods in Molecular Biology, edited by E. J. G. Peterman and G. J. L. Wuite (Humana Press, Totowa, NJ, 2011), pp. 265–293.
  29. D. Spakman, J. A. M. Bakx, A. S. Biebricher, E. J. G. Peterman, G. J. L. Wuite, and G. A. King, Unravelling the mechanisms of type 1A topoisomerases using single-molecule approaches, Nucl. Acids Res. 49, 5470 (2021).
  30. F. Mosconi, J. F. Allemand, D. Bensimon, and V. Croquette, Measurement of the torque on a single stretched and twisted DNA using magnetic tweezers, Phys. Rev. Lett. 102, 078301 (2009).
  31. A. Celedon, I. M. Nodelman, B. Wildt, R. Dewan, P. Searson, D. Wirtz, G. D. Bowman, and S. X. Sun, Magnetic tweezers measurement of single molecule torque, Nano Lett. 9, 1720 (2009).
  32. M. J. Szafran, T. Strick, A. Strzałka, J. Zakrzewska-Czerwińska, and D. Jakimowicz, A highly processive topoisomerase I: Studies at the single-molecule level, Nucl. Acids Res. 42, 7935 (2014).
  33. See Supplemental Material at http://link.aps.org/supplemental/10.1103/9tkx-w3zj for additional figures.
  34. C. Mao and M. Mills, Characterization of human XPD helicase activity with single-molecule magnetic tweezers, Biophys. J. 123, 260 (2024).
  35. X. Gao, Y. Hong, F. Ye, J. T. Inman, and M. D. Wang, Torsional stiffness of extended and plectonemic DNA, Phys. Rev. Lett. 127, 028101 (2021).
  36. K. Terekhova, K. H. Gunn, J. F. Marko, and A. Mondragón, Bacterial topoisomerase I and topoisomerase III relax supercoiled DNA via distinct pathways, Nucl. Acids Res. 40, 10432 (2012).
  37. D. A. Koster, V. Croquette, C. Dekker, S. Shuman, and N. H. Dekker, Friction and torque govern the relaxation of DNA supercoils by eukaryotic topoisomerase IB, Nature (London) 434, 671 (2005).
  38. J. J. Champoux, Type IA DNA topoisomerases: Strictly one step at a time, Proc. Natl. Acad. Sci. USA 99, 11998 (2002).
  39. K. H. Gunn, J. F. Marko, and A. Mondragón, An orthogonal single-molecule experiment reveals multiple-attempt dynamics of type IA topoisomerases, Nat. Struct. Mol. Biol. 24, 484 (2017).
  40. D. Balthrop, D. Sigdel, C. Mao, Y. C. Tse-Dinh, and M. Mills, Data traces for supercoil relaxation of mycobacterial type IA topoisomerase and deletion variants [Data set], Zenodo, 2026, https://doi.org/10.5281/zenodo.20671367.
  41. D. Balthrop, D. Sigdel, and M. Mills, Step analysis program for time series data (v1.0), Zenodo, 2026, https://doi.org/10.5281/zenodo.20706183.
