Reconstruction of the Bacterial Flagellar Motor's Energy Landscape, Viscous Load, and Torque Generation Across Diffusion Regimes

N. J. López-Alamilla1,*, A. L. Nord2, F. Pedaci2, J. Palmeri1, and N.-O. Walliser1,†

  • *Contact author: n.jared.lopezalamilla@gmail.com
  • †Contact author: nils-ole.walliser@umontpellier.fr
PDF

PRX Life 4, 043003 – Published 23 October, 2026

DOI: https://doi.org/10.1103/55kj-nm3g

Abstract

The bacterial flagellar motor (BFM) converts transmembrane ion flux into directed mechanical rotation, driving bacterial motility. Despite extensive study, the frictional forces and energetics governing its torque generation remain poorly understood. Here we combine single-molecule rotation measurements with stochastic thermodynamics to quantitatively estimate its effective torque, viscous drag, and activation energy barriers. We present three complementary methods based on solutions to the Smoluchowski equation for overdamped diffusion in a tilted periodic potential, which use as input the steady-state angular velocity and rotational diffusion data from individual Escherichia coli motors spanning different dynamical regimes. Crucially, these three methods require neither active external torque control, nor prior knowledge of the system's viscous drag or the motor's torque output. The first method assumes as input a model-dependent sinusoidal effective potential (single Fourier mode), albeit with unknown periodicity, yielding closed-form results in the low- and high-tilt limits, whereas the last two methods use a full Fourier-based reconstruction to output the now model-independent effective potential landscape. These approaches yield consistent estimates of the potential periodicity (≈26-fold symmetry), energy barrier height (≈2–4 kBT), and internal friction coefficient (≈0.1 pNnms/rad2). These findings suggest that the reconstructed effective energy landscape is dominated by interactions associated with the LP-ring bearing. Our results reveal that the BFM's torque-velocity relationship deviates significantly from the linear approximation near the critical tilt, where angular diffusion is maximized. More broadly, our framework provides a coherent strategy for reconstructing nanoscale energy landscapes from single-molecule data and is generalizable to other stepping molecular motors operating in cyclic conditions.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (52)

  1. B. Alberts, A. Johnson, J. Lewis, D. Morgan, M. Raff, K. Roberts, and P. Walter, Molecular Biology of the Cell, 6th ed. (Garland Science, New York, 2014).
  2. J. Howard, Mechanics of Motor Proteins and the Cytoskeleton (Sinauer Associates, Sunderland, MA, 2001).
  3. P. Reimann, Brownian motors: Noisy transport far from equilibrium, Phys. Rep. 361, 57 (2002).
  4. R. D. Astumian, Thermodynamics and kinetics of a Brownian motor, Science 276, 917 (1997).
  5. H. C. Berg and R. A. Anderson, Bacteria swim by rotating their flagellar filaments, Nature (London) 245, 380 (1973).
  6. T. Minamino and K. Imada, The bacterial flagellar motor and its structural diversity, Trends Microbiol. 23, 267 (2015).
  7. S. Johnson, J. C. Deme, E. J. Furlong, J. J. E. Caesar, F. F. V. Chevance, K. T. Hughes, and S. M. Lea, Structural basis of directional switching by the bacterial flagellum, Nat. Microbiol. 9, 1282 (2024).
  8. T. Yamaguchi, F. Makino, T. Miyata, T. Minamino, T. Kato, and K. Namba, Structure of the molecular bushing of the bacterial flagellar motor, Nat. Commun. 12, 4469 (2021).
  9. S. Kojima and D. F. Blair, The bacterial flagellar motor: Structure and function of a complex molecular machine, Int. Rev. Cytol. 233, 93 (2004).
  10. Y. Sowa, A. D. Rowe, M. C. Leake, T. Yakushi, M. Homma, A. Ishijima, and R. M. Berry, Direct observation of steps in rotation of the bacterial flagellar motor, Nature (London) 437, 916 (2005).
  11. S. Nakamura, N. Kami-ike, J.-I. P. Yokota, T. Minamino, and K. Namba, Evidence for symmetry in the elementary process of bidirectional torque generation by the bacterial flagellar motor, Proc. Natl. Acad. Sci. USA 107, 17616 (2010).
  12. S. Johnson, E. J. Furlong, J. C. Deme, A. L. Nord, J. J. E. Caesar, F. F. V. Chevance, R. M. Berry, K. T. Hughes, and S. M. Lea, Molecular structure of the intact bacterial flagellar basal body, Nat. Microbiol. 6, 712 (2021).
  13. T. Drobnič, E. Cohen, T. Calcraft, M. Alzheimer, K. Froschauer, S. Svensson, W. Hoffmann, N. Singh, S. Garg, L. Henderson, T. Umrekar, A. Nans, D. Ribardo, F. Pedaci, A. Nord, G. Hochberg, D. Hendrixson, C. Sharma, P. Rosenthal, and M. Beeby, In situ structure of a bacterial flagellar motor at subnanometre resolution reveals adaptations for increased torque, Nat. Microbiol. 10, 1723 (2025).
  14. J. Tan, L. Zhang, X. Zhou, S. Han, Y. Zhou, Y. Zhu, et al., Structural basis of the bacterial flagellar motor rotational switching, Cell Res. 34, 788 (2024).
  15. A. L. Nord, E. Gachon, R. Perez-Carrasco, J. A. Nirody, A. Barducci, R. M. Berry, and F. Pedaci, Catch bond drives stator mechanosensitivity in the bacterial flagellar motor, Proc. Natl. Acad. Sci. USA 114, 12952 (2017).
  16. S. Nakamura and T. Minamino, Structure and dynamics of the bacterial flagellar motor complex, Biomolecules 14, 1488 (2024).
  17. J. Xing, F. Bai, R. Berry, and G. Oster, Torque–speed relationship of the bacterial flagellar motor, Proc. Natl. Acad. Sci. USA 103, 1260 (2006).
  18. T. Mora, H. Yu, Y. Sowa, and N. S. Wingreen, Steps in the bacterial flagellar motor, PLoS Comput. Biol. 5, e1000540 (2009).
  19. M. Rieu, A. L. Nord, A. Courbet, H. El Sayyed, and R. M. Berry, Single-molecule observation of multi-scale dynamic heterogeneity in the molecular bearing of the bacterial flagellum, bioRxiv (2025).
  20. R. Hayashi, K. Sasaki, S. Nakamura, S. Kudo, Y. Inoue, H. Noji, and K. Hayashi, Giant acceleration of diffusion observed in a single-molecule experiment on F1-ATPase, Phys. Rev. Lett. 114, 248101 (2015).
  21. R. M. Berry and H. C. Berg, Absence of a barrier to backwards rotation of the bacterial flagellar motor demonstrated with optical tweezers, Proc. Natl. Acad. Sci. USA 94, 14433 (1997).
  22. B. Wang, G. Yue, R. Zhang, and J. Yuan, Direct measurement of the stall torque of the flagellar motor in Escherichia coli with magnetic tweezers, mBio 13, e00782-22 (2022).
  23. R. M. Berry, L. Turner, and H. C. Berg, Mechanical limits of bacterial flagellar motors probed by electrorotation, Biophys. J. 69, 280 (1995).
  24. W. H. Hoffmann, A. Biquet-Bisquert, F. Pedaci, and A. L. Nord, Measuring bacterial flagellar motor dynamics via a bead assay, in Molecular Motors: Methods and Protocols, edited by C. Lavelle and A. Le Gall (Humana Press, New York, 2025), Vol. 2881, pp. 43–64.
  25. Z. Wu and N. E. Huang, Ensemble empirical mode decomposition: A noise-assisted data analysis method, Adv. Adapt. Data Analysis 1, 1 (2009).
  26. D. Goodsell, Flagellar motor, RCSB Protein Data Bank 2024, 12 (2024).
  27. H. Risken, The Fokker-Planck Equation Methods of Solution and Applications (Springer, Berlin, 1996).
  28. C. W. Gardiner, Stochastic Methods: A Handbook for the Natural and Social Sciences, 4th ed. (Springer, Berlin, 2009).
  29. P. Reimann, C. Van den Broeck, H. Linke, P. Hänggi, J. M. Rubi, and A. Pérez-Madrid, Giant acceleration of free diffusion by use of tilted periodic potentials, Phys. Rev. Lett. 87, 010602 (2001).
  30. A. C. Barato and U. Seifert, Thermodynamic uncertainty relation for biomolecular processes, Phys. Rev. Lett. 114, 158101 (2015).
  31. A. L. Nord and F. Pedaci, Mechanisms and dynamics of the bacterial flagellar motor, in Physical Microbiology, edited by G. Duménil and S. van Teeffelen (Springer International Publishing, Cham, 2020), pp. 81–100.
  32. R. Wang, Q. Chen, R. Zhang, and J. Yuan, Measurement of the internal frictional drag of the bacterial flagellar motor by fluctuation analysis, Biophys. J. 118, 2718 (2020).
  33. K. J. Challis and M. W. Jack, Energy transfer in a molecular motor in the Kramers regime, Phys. Rev. E 88, 042114 (2013).
  34. K. J. Challis, Numerical study of the tight-binding approach to overdamped Brownian motion on a tilted periodic potential, Phys. Rev. E 94, 062123 (2016).
  35. N. J. López-Alamilla, M. W. Jack, and K. J. Challis, Reconstructing free-energy landscapes for nonequilibrium periodic potentials, Phys. Rev. E 97, 032419 (2018).
  36. N. J. López-Alamilla, M. W. Jack, and K. J. Challis, Enhanced diffusion and the eigenvalue band structure of Brownian motion in tilted periodic potentials, Phys. Rev. E 102, 042405 (2020).
  37. M. W. Jack, N. J. López-Alamilla, and K. J. Challis, Thermodynamic uncertainty relations and molecular-scale energy conversion, Phys. Rev. E 101, 062123 (2020).
  38. C. Kittel, Introduction to Solid State Physics (Wiley, Hoboken, NJ, 2004).
  39. R. Festa and E. d'Agliano, Diffusion coefficient for a Brownian particle in a periodic field of force: I. Large friction limit, Physica A 90, 229 (1978).
  40. See Supplemental Material at http://link.aps.org/supplemental/10.1103/55kj-nm3g for additional theoretical derivations, numerical methods, and supplemental figures.
  41. N. J. López-Alamilla and R. Cachi, Virial-like thermodynamic uncertainty relation in the tight-binding regime, AIP Chaos 32, 103109 (2022).
  42. A. L. Nord, A. Biquet-Bisquert, M. Abkarian, T. Pigaglio, F. Seduk, A. Magalon, and F. Pedaci, Dynamic stiffening of the flagellar hook, Nat. Commun. 13, 2925 (2022).
  43. N. J. López-Alamilla, M. W. Jack, and K. J. Challis, Analysing single-molecule trajectories to reconstruct free-energy landscapes of cyclic motor proteins, J. Theor. Biol. 462, 321 (2019).
  44. N. J. López-Alamilla, M. W. Jack, and K. J. Challis, Reconstructing free-energy landscapes for cyclic molecular motors using full multidimensional or partial one dimensional dynamic information, Phys. Rev. E 100, 012404 (2019).
  45. M. C. Leake, J. H. Chandler, G. H. Wadhams, F. Bai, R. M. Berry, and J. P. Armitage, Stoichiometry and turnover in single, functioning membrane protein complexes, Nature (London) 443, 355 (2006).
  46. P. P. Lele, B. G. Hosu, and H. C. Berg, Dynamics of mechanosensing in the bacterial flagellar motor, Proc. Natl. Acad. Sci. USA 110, 11839 (2013).
  47. M. J. Tipping, N. J. Delalez, R. Lim, R. M. Berry, and J. P. Armitage, Load-dependent assembly of the bacterial flagellar motor, mBio 4, e00551-13 (2013).
  48. M. Beeby, D. A. Ribardo, C. A. Brennan, E. G. Ruby, G. J. Jensen, and D. R. Hendrixson, Diverse high-torque bacterial flagellar motors assemble wider stator rings using a conserved protein scaffold, Proc. Natl. Acad. Sci. USA 113, E1917 (2016).
  49. E. J. Cohen, T. Drobnič, D. A. Ribardo, A. Yoshioka, T. Umrekar, X. Guo, J.-J. Fernandez, E. E. Brock, L. Wilson, D. Nakane, D. R. Hendrixson, and M. Beeby, Evolution of a large periplasmic disk in Campylobacterota flagella enables both efficient motility and autoagglutination, Dev. Cell 59, 3306 (2024).
  50. A. L. Nord, F. Pedaci, and R. M. Berry, Transient pauses of the bacterial flagellar motor at low load, New J. Phys. 18, 115002 (2016).
  51. A. L. Nord, Stepping dynamics of the bacterial flagellar motor and F1−ATPase, Ph.D. thesis, University of Oxford, 2014.
  52. Y. Lanoiselée, G. Pagnini, and A. Wyłomańska, Super-resolved anomalous diffusion: Deciphering the joint distribution of anomalous exponent and diffusion coefficient, Phys. Rev. Lett. 135, 137101 (2025).
