Predictive Theory of Electrochemical Ostwald Ripening for Electrodeposited Lithium Metal

Hanning Zhang, Oleg V. Yazyev, and Ruslan Yamaletdinov*

  • *Contact author: ruslan.yamaletdinov@epfl.ch
PDF

PRX Energy 5, 033010 – Published 12 August, 2026

DOI: https://doi.org/10.1103/xqcq-f8q1

Abstract

Electrode morphology critically determines the stability and efficiency of lithium metal anodes, yet no predictive framework has explained how measurable parameters control deposition. Here we introduce the first theoretical model of electrochemical Ostwald ripening, capturing the competition between electroplating and surface-energy-driven redistribution and identifying it as the governing process behind morphology evolution in the nondendritic regime. The framework explicitly incorporates solid electrolyte interphase (SEI) resistance, electrolyte conductivity, electrode wettability, and current density, revealing the transition from a 2D SEI-limited to a 3D electrolyte-limited growth. The model yields analytical expressions for nucleus size, density, and distribution that quantitatively reproduce independent experimental results and establishes a direct link between plating conditions, morphology, and Coulombic efficiency. By providing experimentally accessible relationships between key parameters and deposition outcomes, the framework enables a predictive understanding of lithium plating and provides a broadly applicable basis for controlling electrodeposition morphology across diverse electrochemical systems.

View figure in article

Physics Subject Headings (PhySH)

Popular Summary

One often-overlooked aspect of lithium electrodeposition is the redistribution of material between growing nuclei. While lithium is continuously supplied during plating, it is also transferred from smaller nuclei to larger ones through electrochemical Ostwald ripening, reducing the total interfacial energy of the deposit. Here, the authors show that the competition between deposition and this energy-driven redistribution governs how the number and size of the nuclei evolve, and thereby how ion transport and interfacial properties shape the final morphology. By expressing the competition quantitatively, the authors provide a predictive framework for lithium growth and, more broadly, for electrochemical growth at interfaces. These insights into plating morphology will support further advances in lithium-metal battery research, including improvements in performance, reliability, and safety.

Article Text

Supplemental Material

References (49)

  1. J. Zheng, M. S. Kim, Z. Tu, S. Choudhury, T. Tang, and L. A. Archer, Regulating electrodeposition morphology of lithium: Towards commercially relevant secondary Li metal batteries, Chem. Soc. Rev. 49, 2701 (2020).
  2. A. Jetybayeva, D. S. Aaron, I. Belharouak, and M. M. Mench, Critical review on recently developed lithium and non-lithium anode-based solid-state lithium-ion batteries, J. Power Sources 566, 232914 (2023).
  3. C. Monroe and J. Newman, Dendrite growth in lithium/polymer systems : A propagation model for liquid electrolytes under galvanostatic conditions, J. Electrochem. Soc. 150, A1377 (2003).
  4. N. M. Schneider, J. H. Park, J. M. Grogan, D. A. Steingart, H. H. Bau, and F. M. Ross, Nanoscale evolution of interface morphology during electrodeposition, Nat. Commun. 8, 2174 (2017).
  5. J. Barton and J. Bockris, The electrolytic growth of dendrites from ionic solutions, Proc. R. Soc. London, Ser. A 268, 485 (1962).
  6. P. Bai, J. Li, F. R. Brushett, and M. Z. Bazant, Transition of lithium growth mechanisms in liquid electrolytes, Energy Environ. Sci. 9, 3221 (2016).
  7. J. K. Stark, Y. Ding, and P. A. Kohl, Nucleation of electrodeposited lithium metal: Dendritic growth and the effect of co-deposited sodium, J. Electrochem. Soc. 160, D337 (2013).
  8. G. Feng, Y. Shi, H. Jia, S. Risal, X. Yang, P. Ruchhoeft, W.-C. Shih, Z. Fan, W. Xu, and X. Shan, Progressive and instantaneous nature of lithium nucleation discovered by dynamic and operando imaging, Sci. Adv. 9, eadg6813 (2023).
  9. K. C. Russell, Grain boundary nucleation kinetics, Acta Metall. 17, 1123 (1969).
  10. D. R. Ely and R. E. García, Heterogeneous nucleation and growth of lithium electrodeposits on negative electrodes, J. Electrochem. Soc. 160, A662 (2013).
  11. I. M. Lifshitz and V. V. Slyozov, The kinetics of precipitation from supersaturated solid solutions, J. Phys. Chem. Solids 19, 35 (1961).
  12. C. Wagner, Theorie der alterung von niederschlägen durch umlösen (ostwald-reifung), Z. Elektrochem. Berichte Bunsengesellschaft Phys. Chem. 65, 581 (1961).
  13. A. Pei, G. Zheng, F. Shi, Y. Li, and Y. Cui, Nanoscale nucleation and growth of electrodeposited lithium metal, Nano Lett. 17, 1132 (2017).
  14. K. Yan, J. Wang, S. Zhao, D. Zhou, B. Sun, Y. Cui, and G. Wang, Temperature-dependent nucleation and growth of dendrite-free lithium metal anodes, Angew. Chem. 131, 11486 (2019).
  15. P. L. Redmond, A. J. Hallock, and L. E. Brus, Electrochemical Ostwald ripening of colloidal Ag particles on conductive substrates, Nano Lett. 5, 131 (2005).
  16. L. Geng, Q. Liu, J. Chen, P. Jia, H. Ye, J. Yan, L. Zhang, Y. Tang, and J. Huang, In situ observation of electrochemical Ostwald ripening during sodium deposition, Nano Res. 15, 2650 (2022).
  17. H. Hwang, H. Oh, and H. Song, Shaping copper oxide layers on gold nanoparticle ensembles by controlled electrodeposition with single particle scatterometry, Small 19, 2301241 (2023).
  18. L. Ye, C. Zhang, Y. Zhou, B. Ülgüt, Y. Zhao, and J. Qian, Guided lithium nucleation and growth on lithiophilic tin-decorated copper substrate, J. Energy. Chem. 74, 412 (2022).
  19. R. Zhang, X.-R. Chen, X. Chen, X.-B. Cheng, X.-Q. Zhang, C. Yan, and Q. Zhang, Lithiophilic sites in doped graphene guide uniform lithium nucleation for dendrite-free lithium metal anodes, Angew. Chem., Int. Ed. 56, 7764 (2017). 10.1002/anie.201702099
  20. K. V. Kravchyk, H. Zhang, and M. V. Kovalenko, On the interfacial phenomena at the Li7La3Zr2O12(LLZO)/Li interface, Commun. Chem. 7, 257 (2024).
  21. J. Wang, W. Huang, A. Pei, Y. Li, F. Shi, X. Yu, and Y. Cui, Improving cyclability of Li metal batteries at elevated temperatures and its origin revealed by cryo-electron microscopy, Nat. Energy 4, 664 (2019).
  22. L. Que and W. Chen, Analysis of the lithium electrodeposition behavior in the charge process of lithium metal battery associated with overpotential, J. Power Sources 557, 232536 (2023).
  23. G. M. Hobold, J. Lopez, R. Guo, N. Minafra, A. Banerjee, Y. S. Meng, Y. Shao-Horn, and B. M. Gallant, Moving beyond 99.9% coulombic efficiency for lithium anodes in liquid electrolytes, Nat. Energy 6, 951 (2021).
  24. R. M. Kasse, N. R. Geise, J. S. Ko, J. Nelson Weker, H.-G. Steinrück, and M. F. Toney, Understanding additive controlled lithium morphology in lithium metal batteries, J. Mater. Chem. A 8, 16960 (2020).
  25. N. Boaretto, I. Garbayo, S. Valiyaveettil-SobhanRaj, A. Quintela, C. Li, M. Casas-Cabanas, and F. Aguesse, Lithium solid-state batteries: State-of-the-art and challenges for materials, interfaces and processing, J. Power Sources 502, 229919 (2021).
  26. A. Schröder, J. Fleig, D. Gryaznov, J. Maier, and W. Sitte, Quantitative model of electrochemical Ostwald ripening and its application to the time-dependent electrode potential of nanocrystalline metals, J. Phys. Chem. B 110, 12274 (2006).
  27. M. Hess, Non-linearity of the solid-electrolyte-interphase overpotential, Electrochim. Acta 244, 69 (2017).
  28. G. M. Hobold, K.-H. Kim, and B. M. Gallant, Beneficial vs inhibiting passivation by the native lithium solid electrolyte interphase revealed by electrochemical Li+ exchange, Energy Environ. Sci. 16, 2247 (2023).
  29. S. Solchenbach, X. Huang, D. Pritzl, J. Landesfeind, and H. A. Gasteiger, Monitoring SEI formation on graphite electrodes in lithium-ion cells by impedance spectroscopy, J. Electrochem. Soc. 168, 110503 (2021).
  30. R. Amin and I. Belharouak, Part I: Electronic and ionic transport properties of the ordered and disordered LiNi0.5Mn1.5O4 spinel cathode, J. Power Sources 348, 311 (2017).
  31. See Supplemental Material at http://link.aps.org/supplemental/10.1103/xqcq-f8q1 for Notes 1–3, which includes Refs. [3, 11, 12, 21, 32].
  32. K. Kroenlein, C. Muzny, A. Kazakov, V. Diky, R. Chirico, J. Magee, I. Abdulagatov, and M. Frenkel, NIST/TRC web thermo tables (WTT) NIST standard reference subscription database 3 - professional edition version 2 (2011).
  33. J. Bartels, U. Lembke, R. Pascova, J. Schmelzer, and I. Gutzow, Evolution of cluster size distribution in nucleation and growth processes, J. Non-Cryst. Solids 136, 181 (1991).
  34. B. Scharifker and G. Hills, Theoretical and experimental studies of multiple nucleation, Electrochim. Acta 28, 879 (1983).
  35. J. L. Fransaer and R. M. Penner, Brownian dynamics simulation of the growth of metal nanocrystal ensembles on electrode surfaces from solution. i. instantaneous nucleation and diffusion-controlled growth, J. Phys. Chem. B 103, 7643 (1999).
  36. Y.-H. Xu, W.-Z. Fang, K.-B. An, Z.-H. Xuan, D.-K. Hu, Y. Zhu, and W.-Q. Tao, Rapid predictions of platinum degradation in cathode catalyst layers based on Ostwald ripening theory and numerical insights, Chem. Eng. J. 529, 172952 (2026).
  37. J. Wang, H. Wang, J. Xie, A. Yang, A. Pei, C.-L. Wu, F. Shi, Y. Liu, D. Lin, Y. Gong, and Y. Cui, Fundamental study on the wetting property of liquid lithium, Energy Storage Mater. 14, 345 (2018).
  38. L. Shi et al., Monolayer amorphous carbon: Unlocking disorder-induced lithiophilicity, Adv. Sci. 13, e16490 (2026).
  39. C. Park, M. Kanduč, R. Chudoba, A. Ronneburg, S. Risse, M. Ballauff, and J. Dzubiella, Molecular simulations of electrolyte structure and dynamics in lithium–sulfur battery solvents, J. Power Sources 373, 70 (2018).
  40. S. Zhang, Y. Li, L. J. Bannenberg, M. Liu, S. Ganapathy, and M. Wagemaker, The lasting impact of formation cycling on the Li-ion kinetics between SEI and the Li-metal anode and its correlation with efficiency, Sci. Adv. 10, 8889 (2024).
  41. L. Liu and M. Zhu, Modeling of SEI layer growth and electrochemical impedance spectroscopy response using a thermal-electrochemical model of Li-ion batteries, ECS Trans. 61, 43 (2014).

  42. This value likely underestimates ohmic RSEI due to the omission of small nuclei in the original size histograms. While this discrepancy has a negligible effect on the ⟨r⟩, it can lead to an overestimation of ⟨r3⟩, and thus an underestimation of N by up to a factor of five.

  43. A. V. Teran, A. Bill, and R. B. Bergmann, Time-evolution of grain size distributions in random nucleation and growth crystallization processes, Phys. Rev. B 81, 075319 (2010).
  44. A. R. Despic, J. Diggle, and J. O.’M. Bockris, Mechanism of the formation of zinc dendrites, J. Electrochem. Soc. 115, 507 (1968).
  45. C.-J. Ko, C.-H. Chen, and K.-C. Chen, Influence of inhomogeneity of lithium-ion transport within the anode/electrolyte interface on mossy lithium formation, J. Power Sources 563, 232779 (2023).
  46. P. Du, J. Wan, J. Qu, H. Xie, D. Wang, and H. Yin, Passivation and corrosion of Al current collectors in lithium-ion batteries, npj Mater. Degrad. 8, 43 (2024).
  47. Q. Fu, Y. Xue, and Z. Cui, Size- and shape-dependent surface thermodynamic properties of nanocrystals, J. Phys. Chem. Solids 116, 79 (2018).
  48. Z. Wu, C. Wang, Z. Hui, H. Liu, S. Wang, S. Yu, X. Xing, J. Holoubek, Q. Miao, H. L. Xin, and P. Liu, Growing single-crystalline seeds on lithiophobic substrates to enable fast-charging lithium-metal batteries, Nat. Energy 8, 340 (2023).
  49. K. Xu, Electrolytes, Interfaces and Interphases (The Royal Society of Chemistry, 2023), 10.1039/9781837671311.
