Four-Dimensional Quasielastic Neutron Scattering (4D-QENS) Analysis of Correlated Ionic Conduction in SrCl2

Jared Coles1,2, Omar Chmaissem1,2, Matthew Krogstad3, Daniel M. Pajerowski4, Feng Ye4, Duck Young Chung1, Mercouri G. Kanatzidis1,5, Stephan Rosenkranz1, and Raymond Osborn1,*

  • *Contact author: rosborn@anl.gov
PDF

PRX Energy 5, 023002 – Published 14 April, 2026

DOI: https://doi.org/10.1103/b93d-755s

Abstract

Methods of elucidating the mechanisms of fast-ion conduction in solid-state materials are pivotal for advancements in energy technologies such as batteries, fuel cells, sensors, and supercapacitors. In this study, we examine the ionic conduction pathways in single crystal SrCl2, which is a fast-ion conductor above 900 K, using four-dimensional quasielastic neutron scattering (4D-QENS). We explore both coherent and incoherent neutron scattering at temperatures above the transition temperature into the superionic phase to explore the correlated motion of hopping anions. Refinements of the incoherent QENS yield residence times and jump probabilities between lattice sites in good agreement with previous studies, confirming that ionic hopping along nearest-neighbor directions is the most probable conduction pathway. However, the coherent QENS reveals evidence of de Gennes narrowing, indicating the importance of ionic correlations in the conduction mechanism. This highlights the need for improvements both in the theory of ionic transport in fluorite compounds and the modeling of coherent 4D-QENS in single crystals.

View figure in article

Physics Subject Headings (PhySH)

Popular Summary

State-of-the-art experimental techniques can enable a deeper understanding of energy materials’ structure and properties. Advances in time-of-flight neutron scattering from single crystals now allow the energy broadening of ionic conductors to be measured over large volumes of momentum transfer, a technique known as four-dimensional quasielastic neutron scattering (4D-QENS). Experiments in the superionic phase of SrCl2 reveal the enhanced lifetime of ionic correlations from trapped interstitials during the conduction process. The results show that 4D-QENS can be a powerful probe of the mechanism of ionic diffusion in energy storage and transport materials.

Article Text

Supplemental Material

References (40)

  1. Y. Wang, W. D. Richards, S. P. Ong, L. J. Miara, J. C. Kim, Y. Mo, and G. Ceder, Design principles for solid-state lithium superionic conductors, Nat. Mater. 14, 1026 (2015).
  2. K. Jun, Y. Chen, G. Wei, X. Yang, and G. Ceder, Diffusion mechanisms of fast lithium-ion conductors, Nat. Rev. Mater. 9, 887 (2024).
  3. J. Boyce and B. Huberman, Superionic conductors: Transitions, structures, dynamics, Phys. Rep. 51, 189 (1979).
  4. K. Funke, Jump relaxation in solid electrolytes, Prog. Solid State Chem. 22, 111 (1993).
  5. C. Wang and X. Sun, The promise of solid-state batteries for safe and reliable energy storage, Engineering 21, 32 (2023).
  6. S. Hull, Superionics: Crystal structures and conduction processes, Rep. Prog. Phys. 67, 1233 (2004).
  7. M. Hutchings, K. Clausen, M. Dickens, W. Hayes, J. Kjems, P. Schnabel, and C. Smith, Investigation of thermally induced anion disorder in fluorites using neutron scattering techniques, J. Phys. C 17, 3903 (1984).
  8. C. R. A. Catlow and W. Hayes, The nature of disorder in the superionic state of fluorites, J. Phys. C 15, L9 (1982).
  9. M. K. Tufail, P. Zhai, M. Jia, N. Zhao, and X. Guo, Design of solid electrolytes with fast ion transport: Computation-driven and practical approaches, Energy Mater. Adv. 4, 0015 (2023).
  10. X. He, Y. Zhu, and Y. Mo, Origin of fast ion diffusion in super-ionic conductors, Nat. Commun. 8, 15893 (2017).
  11. M. J. Gillan and M. Dixon, Molecular dynamics simulation of fast-ion conduction in SrCl2. I. Self-diffusion, J. Phys. C 13, 1901 (1980).
  12. M. J. Gillan and M. Dixon, Quasi-elastic scattering in fast-ion conducting SrCl2: A molecular dynamics study, J. Phys. C 13, L835 (1980).
  13. Y. Ishii, S. Kiko, and N. Ohtori, Analysis of the transport properties of alkaline-earth halides MX2 (M=Ca,Sr,Ba, and X=F,Cl,Br) by simulation with a polarizable ion model, Electrochemistry 92, 043024 (2024).
  14. M. Dixon, Molecular dynamics simulation of fast-ion conduction in SrCl2. II. Distribution of ions and specific heat anomaly, J. Phys. C 13, 1919 (1980).
  15. K. Funke, Ion transport and relaxation studied by high-frequency conductivity and quasi-elastic neutron scattering, Philos. Mag. A 64, 1025 (1991).
  16. T. Springer and R. E. Lechner, Diffusion studies of solids by quasielastic neutron scattering. In Diffusion in Condensed Matter, edited by P. Heitjans and J. Kärger (Springer, Berlin, Heidelberg, 2005).
  17. B. Schwaighofer, M. A. Gonzalez, M. R. Johnson, J. S. O. Evans, and I. R. Evans, Ionic mobility in energy materials: Through the lens of quasielastic neutron scattering, Chem. Mater. 37, 3575 (2025).
  18. C. T. Chudley and R. J. Elliott, Neutron scattering from a liquid on a jump diffusion model, Proc. Phys. Soc. 77, 353 (1961).
  19. J.-C. Boivin, Structural and electrochemical features of fast oxide ion conductors, Inorg. Mater. 3, 1261 (2001).
  20. F. Abraham, J. Boivin, G. Mairesse, and G. Nowogrocki, The BIMEVOX series: A new family of high performances oxide ion conductors, Solid State Ion. 40–41, 934 (1990).
  21. R. A. Ewings, A. Buts, M. D. Le, J. v. Duijn, I. Bustinduy, and T. G. Perring, Horace: Software for the analysis of data from single crystal spectroscopy experiments at time-of-flight neutron instruments, Nucl. Instrum. Methods A 834, 132 (2016).
  22. T. Lanigan-Atkins, X. He, M. J. Krogstad, D. M. Pajerowski, D. L. Abernathy, G. N. M. N. Xu, Z. Xu, D.-Y. Chung, M. G. Kanatzidis, S. Rosenkranz, R. Osborn, and O. Delaire, Two-dimensional overdamped fluctuations of the soft perovskite lattice in CsPbBr3, Nat. Mater. 20, 977 (2021).
  23. E. A. Goremychkin, H. Park, R. Osborn, S. Rosenkranz, J.-P. Castellan, V. R. Fanelli, A. D. Christianson, M. B. Stone, E. D. Bauer, K. J. McClellan, D. D. Byler, and J. M. Lawrence, Coherent band excitations in CePd3: A comparison of neutron scattering and ab initio theory, Science 359, 186 (2018).
  24. M. J. Gillan and D. Wolf, Point-defect diffusion from coherent quasielastic neutron scattering, Phys. Rev. Lett. 55, 1299 (1985).
  25. P. G. D. Gennes, Liquid dynamics and inelastic scattering of neutrons, Physica 25, 825 (1959).
  26. S. Sinha and D. Ross, Self-consistent density response function method for dynamics of light interstitials in crystals, Phys. B+C 149, 51 (1988).
  27. M. J. Gillan, Collective dynamics in superionic CaF2 I. Simulation compared with neutron-scattering experiment, J. Phys. C 19, 3391 (1986).
  28. See Supplemental Material at http://link.aps.org/supplemental/10.1103/b93d-755s for additional details of the sample synthesis and data analysis methods.
  29. F. Ye, Y. Liu, R. Whitfield, R. Osborn, and S. Rosenkranz, Implementation of cross correlation for energy discrimination on the time-of-flight spectrometer CORELLI, J. Appl. Cryst. 51, 315 (2018).
  30. G. Ehlers, A. Podlesnyak, and A. I. Kolesnikov, The cold neutron chopper spectrometer at the spallation neutron source—a review of the first 8 years of operation, Rev. Sci. Instrum. 87, 093902 (2016).
  31. A. T. Savici, M. A. Gigg, O. Arnold, R. Tolchenov, R. E. Whitfield, S. E. Hahn, W. Zhou, and I. A. Zaliznyak, Efficient data reduction for time-of-flight neutron scattering experiments on single crystals, J. Appl. Cryst. 55, 1514 (2022).
  32. O. Arnold et al., Mantid—data analysis and visualization package for neutron scattering and μ SR experiments, Nucl. Instrum. Methods Phys. Res. A 764, 156 (2014).
  33. A. T. Boothroyd, Principles of Neutron Scattering from Condensed Matter (Oxford University Press, Oxford, 2020), 1st ed.
  34. M. Newville, R. Otten, A. Nelson, T. Stensitzki, A. Ingargiola, D. Allan, A. Fox, F. Carter, and M. Rawlik, LMFIT: Non-linear least-squares minimization and curve-fitting for python, Zenodo. https://doi.org/10.5281/zenodo.598352 (2025).
  35. M. H. Dickens, W. Hayes, P. G. Schnabel, M. T. Hutchings, R. E. Lechner, and B. Renker, Incoherent quasielastic neutron scattering investigation of chlorine ion hopping in the fast-ion phase of strontium chloride, J. Phys. C 16, L1 (1983).
  36. J. Rowe, K. Sköld, H. Flotow, and J. Rush, Quasielastic neutron scattering by hydrogen in the α and β phases of vanadium hydride, J. Phys. Chem. Solids 32, 41 (1971).
  37. F. M. A. Margaca, R. L. McGreevy, and E. W. J. Mitchell, Collective modes in molten alkaline-earth chlorides. II. inelastic neutron scattering from molten SrCl2, J. Phys. C 17, 4725 (1984).
  38. M. Russina, F. Mezei, R. Lechner, S. Longeville, and B. Urban, Experimental evidence for fast heterogeneous collective structural relaxation in a supercooled liquid near the glass transition, Phys. Rev. Lett. 84, 3630 (2000).
  39. M. J. Gillan, Collective dynamics in super-ionic CaF2 II. Defect interpretation, J. Phys. C 19, 3517 (1986).
  40. M. Gillan, The simulation of superionic materials, Phys. B+C 131, 157 (1985).
