Enhancing Capacity and Rate Performance of Lamellar V2O5 Cathode Materials by Modulating Vanadium 3d Orbital Splitting

Xiu-Fen Ma1,*, Bai-Qing Zhao2,*, Qing Zhong1, Hongyu Liu1, Hong-Yi Li1,3,†, Xie Zhang4,‡, Jiang Diao1,3, Jili Yue1,3, Guangsheng Huang1,3 et al.

Jingfeng Wang1,3 and Fusheng Pan1,3,5

  • *These authors contributed equally to this work
  • †Contact author: hongyi.li@cqu.edu.cn
  • ‡Contact author: xie.zhang@nwpu.edu.cn
PDF

PRX Energy 4, 033008 – Published 19 August, 2025

DOI: https://doi.org/10.1103/9wnj-xv2w

Abstract

Magnesium-ion batteries (MIBs) are promising next-generation energy storage devices. Vanadium oxides are promising cathode materials for MIBs due to their rich chemical valences and versatile structures. However, vanadium oxide cathodes face challenges such as low structural stability, slow Mg2+ diffusion kinetics, and low electrical conductivity. The work reported herein used hydrothermal synthesis to pre-intercalate H2O molecules and Mg2+ into V2O5 interlayers to stabilize the lamellar structure and modulate V 3d orbital splitting, leading to a Mg0.2V2O5⋅1.5H2O cathode (MVOH1). The V 3d orbital splitting facilitates electron hopping between V4+ and V5+ cations, leading to the enhanced conductivity of MVOH1; it also makes it easier for V atoms to acquire and lose electrons during discharging and charging, leading to high capacity and high rate capability of MVOH1. Consequently, the MVOH1 cathode exhibited a high specific capacity of 300 mA h g−1 at a current density of 0.05 A g−1 and retained a specific capacity of 85 mA h g−1 at 10 A g−1; the capacity and rate capability surpass those of previously reported V2O5 cathode materials. The aqueous MIB based on MVOH1 demonstrated an ultralong lifespan of 11 000 cycles, which is significantly longer than that of previously reported aqueous MIBs. This study highlights the synergistic effect of regulating interlayer spacing and V 3d orbital splitting on electrochemical performance, which is crucial for developing more efficient and more durable energy storage systems.

View figure in article

Physics Subject Headings (PhySH)

Popular Summary

Magnesium-ion batteries are promising secondary batteries, but they suffer from relatively low cathode capacity and short lifespan due to sluggish Mg2+ migration kinetics. Current strategies focus on the enlargement of the Mg2+ migration pathway, overlooking opportunities unlocked by changes to the transition metal orbitals. Here the authors investigate the effect of vanadium 3d orbital splitting on the Mg2+ migration kinetics in a V2O5 cathode. They find that modulating the V 3d orbital splitting increases the electronic conductivity and electron-accepting capability of V2O5, leading to ultrahigh capacity and ultralong lifespan. Such cathode material design incorporating transition metal orbital splitting can be a strategy to boost battery performance.

Article Text

Supplemental Material

References (48)

  1. G.-T. Park, B. Namkoong, S.-B. Kim, J. Liu, C. S. Yoon, and Y.-K. Sun, Introducing high-valence elements into cobalt-free layered cathodes for practical lithium-ion batteries, Nat. Energy 7, 946 (2022).
  2. J. Mao, C. Ye, S. Zhang, F. Xie, R. Zeng, K. Davey, Z. Guo, and S. Qiao, Toward practical lithium-ion battery recycling: adding value, tackling circularity and recycling-oriented design, Energy Environ. Sci. 15, 2732 (2022).
  3. X. Lai, Y. Huang, H. Gu, C. Deng, X. Han, X. Feng, and Y. Zheng, Turning waste into wealth: A systematic review on echelon utilization and material recycling of retired lithium-ion batteries, Energy Storage Mater. 40, 96 (2021).
  4. J. Zhang, Z. Chang, Z. Zhang, A. Du, S. Dong, Z. Li, G. Li, and G. Cui, Current design strategies for rechargeable magnesium-based batteries, ACS Nano 15, 15594 (2021).
  5. L. Wang, Z. Li, Z. Meng, Y. Xiu, B. Dasari, Z. Zhao-Karger, and M. Fichtner, Designing gel polymer electrolyte with synergetic properties for rechargeable magnesium batteries, Energy Storage Mater. 48, 155 (2022).
  6. R. Mohtadi, O. Tutusaus, T. S. Arthur, Z. Zhao-Karger, and M. Fichtner, The metamorphosis of rechargeable magnesium batteries, Joule 5, 581 (2021).
  7. F. Liu, T. Wang, X. Liu, and L. Z. Fan, Challenges and recent progress on key materials for rechargeable magnesium batteries, Adv. Energy Mater. 11, 2000787 (2020).
  8. S. Chen, S. Fan, H. Li, Y. Shi, and H. Y. Yang, Recent advances in kinetic optimizations of cathode materials for rechargeable magnesium batteries, Coord. Chem. Rev. 466, 214597 (2022).
  9. Z. Guo, S. Zhao, T. Li, D. Su, S. Guo, and G. Wang, Recent advances in rechargeable magnesium-based batteries for high-efficiency energy storage, Adv. Energy Mater. 10, 1903591 (2020).
  10. X.-F. Ma, H.-Y. Li, W. Ren, D. Gao, F. Chen, J. Diao, B. Xie, G. Huang, J. Wang, and F. Pan, A critical review of vanadium-based electrode materials for rechargeable magnesium batteries, J. Mater. Sci. Technol. 153, 56 (2023).
  11. F. Chen, B.-Q. Zhao, K. Huang, X.-F. Ma, H.-Y. Li, X. Zhang, J. Diao, J. Yue, G. Huang, J. Wang, and F. Pan, Dual-defect engineering strategy enables high-durability rechargeable magnesium-metal batteries, Nano-Micro Lett. 16, 184 (2024).
  12. F. Ming, H. Liang, Y. Lei, S. Kandambeth, M. Eddaoudi, and H. N. Alshareef, Layered MgxV2O5⋅nH2O as cathode material for high-performance aqueous zinc ion batteries, ACS Energy Lett. 3, 2602 (2018).
  13. M. M. Huie, D. C. Bock, E. S. Takeuchi, A. C. Marschilok, and K. J. Takeuchi, Cathode materials for magnesium and magnesium-ion based batteries, Coord. Chem. Rev. 287, 15 (2015).
  14. H. Tang, Z. Peng, L. Wu, F. Xiong, C. Pei, Q. An, and L. Mai, Vanadium-based cathode materials for rechargeable multivalent batteries: Challenges and opportunities, Electrochem. Energy Rev. 1, 169 (2018).
  15. N. Sa, H. Wang, D. L. Proffit, A. L. Lipson, B. Key, M. Liu, Z. Feng, T. T. Fister, Y. Ren, C.-J. Sun, J. T. Vaughey, P. A. Fenter, K. A. Persson, and A. K. Burrell, Is alpha-V2O5 a cathode material for Mg insertion batteries?, J. Power Sources 323, 44 (2016).
  16. M. Tian, C. Liu, J. Zheng, X. Jia, E. P. Jahrman, G. T. Seidler, D. Long, M. Atif, M. Alsalhi, and G. Cao, Structural engineering of hydrated vanadium oxide cathode by K+ incorporation for high-capacity and long-cycling aqueous zinc ion batteries, Energy Storage Mater. 29, 9 (2020).
  17. X. F. Ma, B. Q. Zhao, H. Liu, J. Tan, H. Y. Li, X. Zhang, J. Diao, J. Yue, G. Huang, J. Wang, and F. Pan, H2O-Mg2+ waltz-like shuttle enables high-capacity and ultralong-life magnesium-ion batteries, Adv. Sci. 11, 2401005 (2024).
  18. X. Zhao, L. Li, L. Zheng, L. Fan, Y. Yi, G. Zhang, C. Han, and B. Li, 3d-orbital regulation of transition metal intercalated vanadate as optimized cathodes for calcium-ion batteries, Adv. Funct. Mater. 34, 2309753 (2023).
  19. H. J. Kim, A. Konarov, J. H. Jo, J. U. Choi, K. Ihm, H. K. Lee, J. Kim, and S. T. Myung, Controlled oxygen redox for excellent power capability in layered sodium-based compounds, Adv. Energy Mater. 9, 1901181 (2019).
  20. Q. Zong, Y. Zhuang, C. Liu, Q. Kang, Y. Wu, J. Zhang, J. Wang, D. Tao, Q. Zhang, and G. Cao, Dual effects of metal and organic ions co-intercalation boosting the kinetics and stability of hydrated vanadate cathodes for aqueous zinc-ion batteries, Adv. Energy Mater. 13, 2301480 (2023).
  21. See Supplemental Material at http://link.aps.org/supplemental/10.1103/9wnj-xv2w for structural characterizations (including XRD, Raman spectroscopy, FTIR spectroscopy, XPS, HRTEM, and STEM-EDS), electrochemical data (such as charge-discharge curves, Mg2+ diffusion coefficients, and cycle performance), quantitative analysis of V 3d orbital splitting and relative conductivity, and performance comparisons with previously reported materials.
  22. G. Kresse and J. Furthmüller, Efficient iterative schemes for ab initio total-energy calculations using a plane-wave basis set, Phys. Rev. B 54, 11169 (1996).
  23. P. E. Blöchl, Projector augmented-wave method, Phys. Rev. B 50, 17953 (1994).
  24. V. I. Anisimov, J. Zaanen, and O. K. Andersen, Band theory and Mott insulators: Hubbard U instead of Stoner I, Phys. Rev. B 44, 943 (1991).
  25. K. Momma and F. Izumi, VESTA 3 for three-dimensional visualization of crystal, volumetric and morphology data, J. Appl. Crystallogr. 44, 1272 (2011).
  26. H. Geng, M. Cheng, B. Wang, Y. Yang, Y. Zhang, and C. C. Li, Electronic structure regulation of layered vanadium oxide via interlayer doping strategy toward superior high-rate and low-temperature zinc-ion batteries, Adv. Funct. Mater. 30, 1907684 (2019).
  27. W. Zhou, J. Chen, M. Chen, A. Wang, A. Huang, X. Xu, J. Xu, and C.-P. Wong, An environmentally adaptive quasi-solid-state zinc-ion battery based on magnesium vanadate hydrate with commercial-level mass loading and anti-freezing gel electrolyte, J. Mater. Chem. A 8, 8397 (2020).
  28. P. He, G. Zhang, X. Liao, M. Yan, X. Xu, Q. An, J. Liu, and L. Mai, Sodium ion stabilized vanadium oxide nanowire cathode for high-performance zinc-ion batteries, Adv. Energy Mater. 8, 1702463 (2018).
  29. P. He, Y. Quan, X. Xu, M. Yan, W. Yang, Q. An, L. He, and L. Mai, High-performance aqueous zinc-ion battery based on layered H2V3O8 nanowire cathode, Small 13, 1702551 (2017).
  30. J. Li, K. McColl, X. Lu, S. Sathasivam, H. Dong, L. Kang, Z. Li, S. Zhao, A. G. Kafizas, R. Wang, D. J. L. Brett, P. R. Shearing, F. Corà, G. He, C. J. Carmalt, and I. P. Parkin, Multi-scale investigations of δ-Ni0.25V2O5⋅nH2O cathode materials in aqueous zinc-ion batteries, Adv. Energy Mater. 10, 2000058 (2020).
  31. Y. Zhang, G. Liu, C. Zhang, Q. Chi, T. Zhang, Y. Feng, K. Zhu, Y. Zhang, Q. Chen, and D. Cao, Low-cost MgFexMn2−xO4 cathode materials for high-performance aqueous rechargeable magnesium-ion batteries, Chem. Eng. J. 392, 123652 (2020).
  32. R. Baddour-Hadjean, A. Marzouk, and J. P. Pereira-Ramos, Structural modifications of LixV2O5 in a composite cathode (0 ≤ x < 2) investigated by Raman microspectrometry, J. Raman Spectrosc. 43, 153 (2012).
  33. X. Li, L. Ma, Y. Zhao, Q. Yang, D. Wang, Z. Huang, G. Liang, F. Mo, Z. Liu, and C. Zhi, Hydrated hybrid vanadium oxide nanowires as the superior cathode for aqueous Zn battery, Mater. Today Energy 14, 100361 (2019).
  34. Q. Wei, J. Liu, W. Feng, J. Sheng, X. Tian, L. He, Q. An, and L. Mai, Hydrated vanadium pentoxide with superior sodium storage capacity, J. Mater. Chem. A 3, 8070 (2015).
  35. E. C. Zampronio, T. A. F. Lassali, and H. P. Oliveira, Synthesis, characterization and electrochemical properties of the V2O5⋅nH2O/AlO(OH)⋅nH2O xerogel composite, Electrochim. Acta 51, 257 (2005).
  36. W. Chen, Synthesis of vanadium oxide nanotubes from V2O5 sols, Mater. Lett. 58, 2275 (2004).
  37. S. Kundu, B. Satpati, T. Kar, and S. K. Pradhan, Microstructure characterization of hydrothermally synthesized PANI/V2O5⋅nH2O heterojunction photocatalyst for visible light induced photodegradation of organic pollutants and non-absorbing colorless molecules, J. Hazard. Mater. 339, 161 (2017).
  38. C. V. Subba Reddy, S.-i. Mho, R. R. Kalluru, and Q. L. Williams, Hydrothermal synthesis of hydrated vanadium oxide nanobelts using poly (ethylene oxide) as a template, J. Power Sources 179, 854 (2008).
  39. X. Sun, V. Duffort, B. L. Mehdi, N. D. Browning, and L. F. Nazar, Investigation of the mechanism of Mg insertion in birnessite in nonaqueous and aqueous rechargeable Mg-ion batteries, Chem. Mater. 28, 534 (2016).
  40. C. Xia, J. Guo, P. Li, X. Zhang, and H. N. Alshareef, Highly Stable aqueous zinc-ion storage using a layered calcium vanadium oxide bronze cathode, Angew. Chem., Int. Ed. 57, 3943 (2018).
  41. Y. Chen, Q. Li, P. Wang, X. Liao, J. Chen, X. Zhang, Q. Zheng, D. Lin, and K. H. Lam, high-energy-density cathode achieved via the activation of a three-electron reaction in sodium manganese vanadium phosphate for sodium-ion batteries, Small 19, e2304002 (2023).
  42. Y. Zhou, G. Xu, J. Lin, Y. Zhang, G. Fang, J. Zhou, X. Cao, and S. Liang, Reversible multielectron redox chemistry in a NASICON-type cathode toward high-energy-density and long-life sodium-ion full batteries, Adv. Mater. 35, e2304428 (2023).
  43. S. Liu, X. Liu, S. Zhao, Y. Liu, L. Li, Q. Ding, Y. Li, Z. Lin, J. Luo, and M. Hong, An exceptional peroxide birefringent material resulting from d–π interactions, Angew. Chem., Int. Ed. 59, 9414 (2020).
  44. X. Deng, Y. Xu, Q. An, F. Xiong, S. Tan, L. Wu, and L. Mai, Manganese ion pre-intercalated hydrated vanadium oxide as a high-performance cathode for magnesium ion batteries, J. Mater. Chem. A 7, 10644 (2019).
  45. P. Simon, Y. Gogotsi, and B. Dunn, Where do batteries end and supercapacitors begin?, Science 343, 1210 (2014).
  46. S. W. Knipe, J. R. Mycroft, A. R. Pratt, H. W. Nesbitt, and G. M. Bancroft, X-ray photoelectron spectroscopic study of water adsorption on iron sulphide minerals, Geochim. Cosmochim. Acta 59, 1079 (1995).
  47. M. Huang, X. Wang, J. Wang, J. Meng, X. Liu, Q. He, L. Geng, Q. An, J. Yang, and L. Mai, Proton/Mg2+ co-insertion chemistry in aqueous Mg-ion batteries: From the interface to the inner, Angew. Chem., Int. Ed. 62, e202308961 (2023).
  48. X.-F. Ma, B. Zhao, Q. Zhong, H. Liu, H.-Y. Li, X. Zhang, J. Diao, J. Yue, G. Huang, J. Wang, and F. Pan, Enhancing capacity and rate performance of lamellar V2O5 cathode materials by modulating vanadium 3d orbital splitting, Zenodo, dataset (2025). https://doi.org/10.5281/zenodo.16332643.

Outline

Information

PRX Energy 4, 033008– Published 19 August, 2025
  • Received 14 January 2025
  • Revised 8 May 2025
  • Accepted 21 July 2025
