Lattice QCD Benchmark of Proton Helicity and Flavor-Dependent Unpolarized Transverse Momentum-Dependent Parton Distribution Functions at Physical Quark Masses

Dennis Bollweg1, Xiang Gao2,*, Swagato Mukherjee2, and Yong Zhao3

  • *Contact author: xgao@bnl.gov
PDF

Phys. Rev. Lett. 135, 201901 – Published 12 November, 2025

DOI: https://doi.org/10.1103/tb2w-3tks

Abstract

We present the first lattice QCD calculations of the isovector helicity transverse momentum-dependent parton distribution function (TMDPDF) and the flavor-dependent unpolarized TMDPDFs for up and down quarks in the proton. Our computations utilize domain-wall fermion discretization with physical quark masses. Employing Coulomb-gauge-fixed quark correlation functions within the large-momentum effective theory framework, we access nonperturbative transverse quark separations bT up to approximately 1 fm, corresponding to transverse momenta as low as 200 MeV. Based on the quasi-TMD factorization theorem, we construct renormalization-group–invariant ratios that are equal to the corresponding light-cone TMDPDF ratios. At moderate x, our results reveal that the isovector helicity and unpolarized TMDPDFs exhibit nearly identical transverse structure up to a normalization factor, and the unpolarized distributions display only mild flavor dependence. These findings not only support key trends observed in recent global analyses but also provide robust, nonperturbative constraints that can distinguish between different parameterizations. This Letter establishes a first-principles benchmark for TMDPDFs, offering valuable input for ongoing and future experimental efforts to map the proton’s three-dimensional structure.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (92)

  1. J. Dudek et al., Eur. Phys. J. A 48, 187 (2012).
  2. A. Accardi et al., Eur. Phys. J. A 60, 173 (2024).
  3. J. C. Collins, D. E. Soper, and G. F. Sterman, Nucl. Phys. B250, 199 (1985).
  4. S. Amoroso et al., Acta Phys. Pol. B 53, 12 (2022).
  5. D. Boer et al., arXiv:1108.1713.
  6. A. Accardi et al., Eur. Phys. J. A 52, 268 (2016).
  7. R. Abdul Khalek et al., arXiv:2203.13199.
  8. R. Abir et al., arXiv:2305.14572.
  9. C. T. H. Davies, B. R. Webber, and W. J. Stirling, Nucl. Phys. B256, 413 (1985).
  10. G. A. Ladinsky and C. P. Yuan, Phys. Rev. D 50, R4239 (1994).
  11. F. Landry, R. Brock, P. M. Nadolsky, and C. P. Yuan, Phys. Rev. D 67, 073016 (2003).
  12. A. V. Konychev and P. M. Nadolsky, Phys. Lett. B 633, 710 (2006).
  13. P. Sun, J. Isaacson, C. P. Yuan, and F. Yuan, Int. J. Mod. Phys. A 33, 1841006 (2018).
  14. U. D’Alesio, M. G. Echevarria, S. Melis, and I. Scimemi, J. High Energy Phys. 11 (2014) 098.
  15. A. Bacchetta, F. Delcarro, C. Pisano, M. Radici, and A. Signori, J. High Energy Phys. 06 (2017) 081; 06 (2019) 051(E).
  16. I. Scimemi and A. Vladimirov, Eur. Phys. J. C 78, 89 (2018).
  17. V. Bertone, I. Scimemi, and A. Vladimirov, J. High Energy Phys. 06 (2019) 028.
  18. I. Scimemi and A. Vladimirov, J. High Energy Phys. 06 (2020) 137.
  19. A. Bacchetta, V. Bertone, C. Bissolotti, G. Bozzi, F. Delcarro, F. Piacenza, and M. Radici, J. High Energy Phys. 07 (2020) 117.
  20. F. Hautmann, I. Scimemi, and A. Vladimirov, Phys. Lett. B 806, 135478 (2020).
  21. M. Bury, F. Hautmann, S. Leal-Gomez, I. Scimemi, A. Vladimirov, and P. Zurita, J. High Energy Phys. 10 (2022) 118.
  22. A. Bacchetta, V. Bertone, C. Bissolotti, G. Bozzi, M. Cerutti, F. Piacenza, M. Radici, and A. Signori (MAP (Multi-Dimensional Analyses of Partonic Distributions) Collaboration), J. High Energy Phys. 10 (2022) 127.
  23. J. Isaacson, Y. Fu, and C. P. Yuan, Phys. Rev. D 110, 073002 (2024).
  24. F. Aslan, M. Boglione, J. O. Gonzalez-Hernandez, T. Rainaldi, T. C. Rogers, and A. Simonelli, Phys. Rev. D 110, 074016 (2024).
  25. A. Vladimirov, J. High Energy Phys. 10 (2019) 090.
  26. M. Cerutti, L. Rossi, S. Venturini, A. Bacchetta, V. Bertone, C. Bissolotti, and M. Radici (MAP (Multi-Dimensional Analyses of Partonic Distributions) Collaboration), Phys. Rev. D 107, 014014 (2023).
  27. P. C. Barry, L. Gamberg, W. Melnitchouk, E. Moffat, D. Pitonyak, A. Prokudin, and N. Sato (Jefferson Lab Angular Momentum (JAM) Collaboration), Phys. Rev. D 108, L091504 (2023).
  28. A. Bacchetta, V. Bertone, C. Bissolotti, M. Cerutti, M. Radici, S. Rodini, and L. Rossi (MAP (Multi-Dimensional Analyses of Partonic Distributions) Collaboration), Phys. Rev. Lett. 135, 021904 (2025).
  29. V. Moos, I. Scimemi, A. Vladimirov, and P. Zurita, arXiv:2503.11201.
  30. V. Moos, I. Scimemi, A. Vladimirov, and P. Zurita, J. High Energy Phys. 05 (2024) 036.
  31. A. Bacchetta, V. Bertone, C. Bissolotti, G. Bozzi, M. Cerutti, F. Delcarro, M. Radici, L. Rossi, and A. Signori (MAP Collaboration), J. High Energy Phys. 08 (2024) 232.
  32. K. Yang, T. Liu, P. Sun, Y. Zhao, and B.-Q. Ma, Phys. Rev. Lett. 134, 121902 (2025).
  33. A. Bacchetta, A. Bongallino, M. Cerutti, M. Radici, and L. Rossi, Phys. Rev. Lett. 134, 121901 (2025).
  34. X. Ji, Phys. Rev. Lett. 110, 262002 (2013).
  35. X. Ji, Sci. China Phys. Mech. Astron. 57, 1407 (2014).
  36. X. Ji, Y. Liu, Y. S. Liu, J.-H. Zhang, and Y. Zhao, Rev. Mod. Phys. 93, 035005 (2021).
  37. X. Ji, P. Sun, X. Xiong, and F. Yuan, Phys. Rev. D 91, 074009 (2015).
  38. X. Ji, L.-C. Jin, F. Yuan, J.-H. Zhang, and Y. Zhao, Phys. Rev. D 99, 114006 (2019).
  39. M. A. Ebert, I. W. Stewart, and Y. Zhao, Phys. Rev. D 99, 034505 (2019).
  40. M. A. Ebert, I. W. Stewart, and Y. Zhao, J. High Energy Phys. 09 (2019) 037.
  41. X. Ji, Y. Liu, and Y.-S. Liu, Nucl. Phys. B955, 115054 (2020).
  42. X. Ji, Y. Liu, and Y.-S. Liu, Phys. Lett. B 811, 135946 (2020).
  43. M. A. Ebert, S. T. Schindler, I. W. Stewart, and Y. Zhao, J. High Energy Phys. 09 (2020) 099.
  44. A. A. Vladimirov and A. Schäfer, Phys. Rev. D 101, 074517 (2020).
  45. X. Ji, Y. Liu, A. Schäfer, and F. Yuan, Phys. Rev. D 103, 074005 (2021).
  46. X. Ji and Y. Liu, Phys. Rev. D 105, 076014 (2022).
  47. M. A. Ebert, S. T. Schindler, I. W. Stewart, and Y. Zhao, J. High Energy Phys. 04 (2022) 178.
  48. S. T. Schindler, I. W. Stewart, and Y. Zhao, J. High Energy Phys. 08 (2022) 084.
  49. R. Zhu, Y. Ji, J.-H. Zhang, and S. Zhao, J. High Energy Phys. 02 (2023) 114.
  50. S. Rodini and A. Vladimirov, J. High Energy Phys. 09 (2023) 117.
  51. P. Shanahan, M. Wagman, and Y. Zhao, Phys. Rev. D 102, 014511 (2020).
  52. P. Shanahan, M. Wagman, and Y. Zhao, Phys. Rev. D 104, 114502 (2021).
  53. M. Schlemmer, A. Vladimirov, C. Zimmermann, M. Engelhardt, and A. Schäfer, J. High Energy Phys. 08 (2021) 004.
  54. H.-T. Shu, M. Schlemmer, T. Sizmann, A. Vladimirov, L. Walter, M. Engelhardt, A. Schäfer, and Y.-B. Yang, Phys. Rev. D 108, 074519 (2023).
  55. Q.-A. Zhang et al. (Lattice Parton Collaboration), Phys. Rev. Lett. 125, 192001 (2020).
  56. Y. Li et al., Phys. Rev. Lett. 128, 062002 (2022).
  57. M.-H. Chu et al. (LPC Collaboration), Phys. Rev. D 106, 034509 (2022).
  58. M.-H. Chu et al. (Lattice Parton (LPC) Collaboration), J. High Energy Phys. 08 (2023) 172.
  59. A. Avkhadiev, P. E. Shanahan, M. L. Wagman, and Y. Zhao, Phys. Rev. D 108, 114505 (2023).
  60. A. Avkhadiev, P. E. Shanahan, M. L. Wagman, and Y. Zhao, Phys. Rev. Lett. 132, 231901 (2024).
  61. J.-C. He, M.-H. Chu, J. Hua, X. Ji, A. Schäfer, Y. Su, W. Wang, Y. Yang, J.-H. Zhang, and Q.-A. Zhang (LPC Collaboration), Phys. Rev. D 109, 114513 (2024).
  62. M.-H. Chu et al., Phys. Rev. D 109, L091503 (2024).
  63. L. Walter et al., Phys. Rev. D 111, 094507 (2025).
  64. L. Ma et al. (LPC Collaboration), J. High Energy Phys. 08 (2025) 086.
  65. X. Gao, W.-Y. Liu, and Y. Zhao, Phys. Rev. D 109, 094506 (2024).
  66. Y. Zhao, Phys. Rev. Lett. 133, 241904 (2024).
  67. D. Bollweg, X. Gao, S. Mukherjee, and Y. Zhao, Phys. Lett. B 852, 138617 (2024).
  68. S. Mukherjee, D. Bollweg, X. Gao, and Y. Zhao, Proc. Sci. DIS2024 (2025) 238 [arXiv:2407.10739].
  69. D. Bollweg, X. Gao, J. He, S. Mukherjee, and Y. Zhao, Phys. Rev. D 112, 034501 (2025).
  70. Y. Liu and Y. Su, J. High Energy Phys. 02 (2024) 204.
  71. J. C. Collins and D. E. Soper, Nucl. Phys. B193, 381 (1981); B213, 545(E) (1983).
  72. T. Blum et al. (RBC, UKQCD Collaborations), Phys. Rev. D 108, 054507 (2023).
  73. G. S. Bali, B. Lang, B. U. Musch, and A. Schäfer, Phys. Rev. D 93, 094515 (2016).
  74. X. Gao, N. Karthik, S. Mukherjee, P. Petreczky, S. Syritsyn, and Y. Zhao, Phys. Rev. D 104, 114515 (2021).
  75. X. Gao, L. Jin, C. Kallidonis, N. Karthik, S. Mukherjee, P. Petreczky, C. Shugert, S. Syritsyn, and Y. Zhao, Phys. Rev. D 102, 094513 (2020).
  76. E. Shintani, R. Arthur, T. Blum, T. Izubuchi, C. Jung, and C. Lehner, Phys. Rev. D 91, 114511 (2015).
  77. C. Aubin, T. Blum, C. Tu, M. Golterman, C. Jung, and S. Peris, Phys. Rev. D 101, 014503 (2020).
  78. T. Blum, N. Christ, M. Hayakawa, T. Izubuchi, L. Jin, C. Jung, and C. Lehner, Phys. Rev. Lett. 118, 022005 (2017).
  79. C. Alexandrou, M. Constantinou, K. Hadjiyiannakou, K. Jansen, and F. Manigrasso, Phys. Rev. D 104, 054503 (2021).
  80. C. Alexandrou, S. Bacchio, M. Constantinou, J. Finkenrath, K. Hadjiyiannakou, K. Jansen, G. Koutsou, H. Panagopoulos, and G. Spanoudes, Phys. Rev. D 101, 094513 (2020).
  81. J. Liang, M. Sun, Y.-B. Yang, T. Draper, and K.-F. Liu, Phys. Rev. D 102, 034514 (2020).
  82. See Supplemental Material at http://link.aps.org/supplemental/10.1103/tb2w-3tks for more details of analysis and comparison between CG and GI approaches.
  83. K. Zhang, Y.-K. Huo, X. Ji, A. Schaefer, C.-J. Shi, P. Sun, W. Wang, Y.-B. Yang, and J.-H. Zhang (Lattice Parton Collaboration), Phys. Rev. D 110, 074505 (2024).
  84. X. Gao, A. D. Hanlon, S. Mukherjee, P. Petreczky, Q. Shi, S. Syritsyn, and Y. Zhao, Phys. Rev. D 109, 054506 (2024).
  85. X. Gao, A. D. Hanlon, J. Holligan, N. Karthik, S. Mukherjee, P. Petreczky, S. Syritsyn, and Y. Zhao, Phys. Rev. D 107, 074509 (2023).
  86. Z. Fan, X. Gao, R. Li, H.-W. Lin, N. Karthik, S. Mukherjee, P. Petreczky, S. Syritsyn, Y.-B. Yang, and R. Zhang, Phys. Rev. D 102, 074504 (2020).
  87. X. Gao, A. D. Hanlon, S. Mukherjee, P. Petreczky, P. Scior, S. Syritsyn, and Y. Zhao, Phys. Rev. Lett. 128, 142003 (2022).
  88. X. Ji, Y. Liu, A. Schäfer, W. Wang, Y.-B. Yang, J.-H. Zhang, and Y. Zhao, Nucl. Phys. B964, 115311 (2021).
  89. X. Gao, A. D. Hanlon, N. Karthik, S. Mukherjee, P. Petreczky, P. Scior, S. Shi, S. Syritsyn, Y. Zhao, and K. Zhou, Phys. Rev. D 106, 114510 (2022).
  90. P. A. Boyle, G. Cossu, A. Yamaguchi, and A. Portelli, Proc. Sci. LATTICE2015 (2016) 023.
  91. A. Yamaguchi, P. Boyle, G. Cossu, G. Filaci, C. Lehner, and A. Portelli, Proc. Sci. LATTICE2021 (2022) 035 [arXiv:2203.06777].
  92. C. Lehner et al., grid python toolkit (GPT), https://github.com/lehner/gpt.

Outline

Information

Phys. Rev. Lett. 135, 201901– Published 12 November, 2025
  • Received 23 June 2025
  • Revised 24 September 2025
  • Accepted 20 October 2025
