Statistical Limitations on Detecting Diamagnetic Suppression of Reconnection at Earth’s Magnetopause

Nicolas Aunai1,*, Bayane Michotte de Welle2,†, Ambre Ghisalberti1,‡, and Benoit Lavraud3,§

  • *Contact author: nicolas.aunai@lpp.polytechnique.fr
  • †Contact author: bayane.michottedewelle@nasa.gov
  • ‡Contact author: ambre.ghisalberti@lpp.polytechnique.fr
  • §Contact author: benoit.lavraud@u-bordeaux.fr
PDF

Phys. Rev. Lett. 137, 165201 – Published 15 October, 2026

DOI: https://doi.org/10.1103/rlxh-smd1

Abstract

The occurrence of magnetic reconnection is of pivotal importance regarding the evolution of many magnetized astrophysical systems. Among others, the mechanism known as “diamagnetic suppression” can prevent reconnection from developing. Over the last decade, many studies evidenced a statistical correlation of the magnetic shear and plasma beta for current sheets interpreted as reconnecting or not, consistent with predictions of the diamagnetic suppression theory. The strength of the observed correlations has suggested that diamagnetic suppression is the dominant mechanism controlling whether reconnection occurs or not, in many space plasma environments, from planetary magnetospheres to the solar wind and heliopause. Here, we show that there exists a possible observational bias, operating at least in the context of the Earth’s magnetopause, that can lead to a similar statistical correlation because outflow speeds expected from magnetic reconnection strongly depend on both the magnetic shear and plasma β. Low velocity jets become increasingly difficult to observe when they become comparable to the surrounding flow fluctuation level. We conclude that the role of diamagnetic suppression at the Earth’s magnetopause remains unclear.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (60)

  1. R. Wang, S. Lu, S. Wang, X. Li, and Q. Lu, Recent progress on magnetic reconnection by in situ measurements, Rev. Mod. Plasma Phys. 7, 27 (2023).
  2. M. Hesse and P. A. Cassak, Magnetic reconnection in the space sciences: Past, present, and future, J. Geophys. Res. Space Phys. 125, e25935 (2020).
  3. K. J. Hwang, R. Nakamura, J. P. Eastwood, S. A. Fuselier, H. Hasegawa, T. Nakamura, B. Lavraud, K. Dokgo, D. L. Turner, R. E. Ergun, and P. H. Reiff, Cross-scale processes of magnetic reconnection, Space Sci. Rev. 219, 71 (2023).
  4. P. A. Cassak, Inside the black box: Magnetic reconnection and the magnetospheric multiscale mission, Space Weather 14, 186 (2016).
  5. P. A. Cassak, Y. H. Liu, and M. A. Shay, A review of the 0.1 reconnection rate problem, J. Plasma Phys. 83, 715830501 (2017).
  6. J. P. Eastwood, H. Hietala, G. Toth, T. D. Phan, and M. Fujimoto, What controls the structure and dynamics of Earth’s magnetosphere?, Space Sci. Rev. 188, 251 (2015).
  7. K. J. Trattner, S. M. Petrinec, and S. A. Fuselier, The location of magnetic reconnection at Earth’s magnetopause, Space Sci. Rev. 217, 41 (2021).
  8. J. T. Gosling, R. M. Skoug, D. J. McComas, and C. W. Smith, Direct evidence for magnetic reconnection in the solar wind near 1 AU, J. Geophys. Res. Space Phys. 110, A01107 (2005).
  9. T. D. Phan, J. T. Gosling, G. Paschmann, C. Pasma, J. F. Drake, M. Øieroset, D. Larson, R. P. Lin, and M. S. Davis, The dependence of magnetic reconnection on plasma β and magnetic shear: Evidence from solar wind observations, Astrophys. J. Lett. 719, L199 (2010).
  10. B. Lavraud, A. Ruffenach, A. P. Rouillard, P. Kajdic, W. B. Manchester, and N. Lugaz, Geo-effectiveness and radial dependence of magnetic cloud erosion by magnetic reconnection, J. Geophys. Res. Space Phys. 119, 26 (2014).
  11. N. Fargette, B. Lavraud, A. P. Rouillard, P. S. Houdayer, T. D. Phan, M. Øieroset, J. P. Eastwood, G. Nicolaou, A. Fedorov, P. Louarn, C. J. Owen, and T. S. Horbury, Clustering of magnetic reconnection exhausts in the solar wind: An automated detection study, Astron. Astrophys. 674, A98 (2023).
  12. D. J. Gershman, S. A. Fuselier, I. J. Cohen, D. L. Turner, Y.-H. Liu, L.-J. Chen, T. D. Phan, J. E. Stawarz, G. A. DiBraccio, A. Masters, R. W. Ebert, W. Sun, Y. Harada, and M. Swisdak, Magnetic reconnection at planetary bodies and astrospheres, Space Sci. Rev. 220, 7 (2024).
  13. H. Ji, J. Yoo, W. Fox, M. Yamada, M. Argall, J. Egedal, Y. H. Liu, R. Wilder, S. Eriksson, W. Daughton, K. Bergstedt, S. Bose, J. Burch, R. Torbert, J. Ng, and L. J. Chen, Laboratory study of collisionless magnetic reconnection, Space Sci. Rev. 219, 76 (2023).
  14. M. Swisdak, B. N. Rogers, J. F. Drake, and M. A. Shay, Diamagnetic suppression of component magnetic reconnection at the magnetopause, J. Geophys. Res. Space Phys. 108, 1218 (2003).
  15. M. Swisdak, M. Opher, J. F. Drake, and F. Alouani Bibi, The vector direction of the interstellar magnetic field outside the heliosphere, Astrophys. J. 710, 1769 (2010).
  16. T. D. Phan, G. Paschmann, J. T. Gosling, M. Øieroset, M. Fujimoto, J. F. Drake, and V. Angelopoulos, The dependence of magnetic reconnection on plasma β and magnetic shear: Evidence from magnetopause observations, Geophys. Res. Lett. 40, 11 (2013).
  17. L. Trenchi, M. F. Marcucci, and R. C. Fear, The effect of diamagnetic drift on motion of the dayside magnetopause reconnection line, Geophys. Res. Lett. 42, 6129 (2015).
  18. E. A. Atz, B. M. Walsh, J. M. Broll, and Y. Zou, The spatial extent of magnetopause magnetic reconnection from in situ THEMIS measurements, J. Geophys. Res. Space Phys. 127, e2022JA030894 (2022).
  19. B. U. O. Sonnerup, I. Papamastorakis, G. Paschmann, and H. Luehr, Magnetopause properties from AMPTE/IRM observations of the convection electric field: Method development, J. Geophys. Res. 92, 12137 (1987).
  20. J. T. Gosling and T. D. Phan, Magnetic reconnection in the solar wind at current sheets associated with extremely small field shear angles, Astrophys. J. Lett. 763, L39 (2013).
  21. T. D. Phan et al., Parker solar probe in situ observations of magnetic reconnection exhausts during encounter 1, Astrophys. J. Suppl. Ser. 246, 34 (2020).
  22. T. D. Phan et al., Parker solar probe in situ observations of magnetic reconnection exhausts during encounter 1, Astrophys. J. Suppl. Ser. 246, 34 (2020).
  23. M. Akhavan-Tafti, J. Kasper, J. Huang, and S. Bale, Discontinuity analysis of the leading switchback transition regions, Astron. Astrophys. 650, A4 (2021).
  24. B. Lavraud et al., Magnetic reconnection as a mechanism to produce multiple thermal proton populations and beams locally in the solar wind, Astron. Astrophys. 656, A37 (2021).
  25. A. B. Lotekar, I. Y. Vasko, T. Phan, S. D. Bale, T. A. Bowen, J. Halekas, A. V. Artemyev, Y. V. Khotyaintsev, and F. S. Mozer, Kinetic-scale current sheets in near-sun solar wind: Properties, scale-dependent features and reconnection onset, Astrophys. J. 929, 58 (2022).
  26. S. Eriksson, M. Swisdak, J. M. Weygand, A. Mallet, D. L. Newman, G. Lapenta, I. Wilson, Lynn B., D. L. Turner, and B. Larsen, Characteristics of multi-scale current sheets in the solar wind at 1 au associated with magnetic reconnection and the case for a heliospheric current sheet avalanche, Astrophys. J. 933, 181 (2022).
  27. I. Y. Vasko, K. Alimov, T. D. Phan, F. S. Mozer, and A. V. Artemyev, Kinetic-scale current sheets in the solar wind at 5 AU, J. Geophys. Res. Space Phys. 129, e2024JA032586 (2024).
  28. G. A. Dibraccio, J. A. Slavin, S. A. Boardsen, B. J. Anderson, H. Korth, T. H. Zurbuchen, J. M. Raines, D. N. Baker, R. L. McNutt, and S. C. Solomon, MESSENGER observations of magnetopause structure and dynamics at Mercury, J. Geophys. Res. Space Phys. 118, 997 (2013).
  29. S. A. Fuselier et al., Large-scale characteristics of reconnection diffusion regions and associated magnetopause crossings observed by MMS, J. Geophys. Res. Space Phys. 122, 5466 (2017).
  30. M. Øieroset et al., Reconnection with magnetic flux pileup at the interface of converging jets at the magnetopause, Geophys. Res. Lett. 46, 1937 (2019).
  31. D. Koga, W. D. Gonzalez, V. M. Souza, F. R. Cardoso, C. Wang, and Z. K. Liu, Dayside magnetopause reconnection: Its dependence on solar wind and magnetosheath conditions, J. Geophys. Res. Space Phys. 124, 8778 (2019).
  32. Y. Vernisse et al., Latitudinal dependence of the Kelvin-Helmholtz instability and beta dependence of vortex-induced high-guide field magnetic reconnection, J. Geophys. Res. Space Phys. 125, e27333 (2020).
  33. S. Toledo-Redondo, K. J. Hwang, C. P. Escoubet, B. Lavraud, J. Fornieles, N. Aunai, R. C. Fear, J. Dargent, H. S. Fu, S. A. Fuselier, K. J. Genestreti, Y. V. Khotyaintsev, W. Y. Li, C. Norgren, and T. D. Phan, Solar wind—magnetosphere coupling during radial interplanetary magnetic field conditions: Simultaneous multi-point observations, J. Geophys. Res. Space Phys. 126, e29506 (2021).
  34. K. Maheshwari, T. D. Phan, M. Øieroset, N. Fargette, B. Lavraud, J. L. Burch, R. J. Strangeway, D. J. Gershman, and B. L. Giles, Investigation of the diamagnetic drift condition for the suppression of magnetic reconnection in 3D interlinked reconnection events with magnetic flux pileup, Astrophys. J. 940, 177 (2022).
  35. K. J. Genestreti et al., Multiscale observation of magnetotail reconnection onset: 1. Macroscopic dynamics, J. Geophys. Res. Space Phys. 128, e2023JA031758 (2023).
  36. M. Desroche, F. Bagenal, P. A. Delamere, and N. Erkaev, Conditions at the expanded Jovian magnetopause and implications for the solar wind interaction, J. Geophys. Res. Space Phys. 117, A07202 (2012).
  37. D. A. Ranquist, F. Bagenal, R. J. Wilson, G. Hospodarsky, R. W. Ebert, F. Allegrini, P. Valek, D. J. McComas, J. E. P. Connerney, W. S. Kurth, and S. J. Bolton, Survey of Jupiter’s dawn magnetosheath using Juno, J. Geophys. Res. Space Phys. 124, 9106 (2019).
  38. D. J. Gershman and G. A. DiBraccio, Solar cycle dependence of solar wind coupling with giant planet magnetospheres, Geophys. Res. Lett. 47, e89315 (2020).
  39. J. Montgomery, R. W. Ebert, G. Clark, S. A. Fuselier, F. Allegrini, F. Bagenal, S. J. Bolton, G. A. DiBraccio, and R. J. Wilson, Investigating the occurrence of magnetic reconnection at Jupiter’s dawn magnetopause during the Juno era, Geophys. Res. Lett. 49, e99141 (2022).
  40. N. Kaweeyanun, A. Masters, and X. Jia, Favorable conditions for magnetic reconnection at Ganymede’s upstream magnetopause, Geophys. Res. Lett. 47, e86228 (2020).
  41. A. Masters, J. P. Eastwood, M. Swisdak, M. F. Thomsen, C. T. Russell, N. Sergis, F. J. Crary, M. K. Dougherty, A. J. Coates, and S. M. Krimigis, The importance of plasma β conditions for magnetic reconnection at Saturn’s magnetopause, Geophys. Res. Lett. 39, L08103 (2012).
  42. R. P. Sawyer, S. A. Fuselier, J. Mukherjee, and S. M. Petrinec, An investigation of flow shear and diamagnetic drift effects on magnetic reconnection at Saturn’s dawnside magnetopause, J. Geophys. Res. Space Phys. 124, 8457 (2019).
  43. S. A. Fuselier, R. Frahm, W. S. Lewis, A. Masters, J. Mukherjee, S. M. Petrinec, and I. J. Sillanpaa, The location of magnetic reconnection at Saturn’s magnetopause: A comparison with Earth, J. Geophys. Res. Space Phys. 119, 2563 (2014).
  44. S. A. Fuselier, S. M. Petrinec, R. P. Sawyer, J. Mukherjee, and A. Masters, Suppression of magnetic reconnection at Saturn’s low-latitude magnetopause, J. Geophys. Res. Space Phys. 125, e27895 (2020).
  45. I. Cheng, N. Achilleos, A. Masters, G. Lewis, M. Kane, and P. Guio, Electron bulk heating at Saturn’s magnetopause, J. Geophys. Res. Space Phys. 126, e28800 (2021).
  46. W. Mo, S. K. Vines, R. C. Allen, C. M. Jackman, and C. Paranicas, Magnetopause dynamics at Saturn as observed by Cassini, J. Geophys. Res. Space Phys. 128, e2022JA031258 (2023).
  47. A. Masters, Magnetic reconnection at Uranus’ magnetopause, J. Geophys. Res. Space Phys. 119, 5520 (2014).
  48. A. Masters, Magnetic reconnection at Neptune’s magnetopause, J. Geophys. Res. Space Phys. 120, 479 (2015).
  49. S. A. Fuselier and I. H. Cairns, Reconnection at the heliopause: Predictions for Voyager 2, J. Phys. Conf. Ser. 900, 012007 (2017).
  50. L. Trenchi, M. F. Marcucci, G. Pallocchia, G. Consolini, M. B. Bavassano Cattaneo, A. M. di Lellis, H. RèMe, L. Kistler, C. M. Carr, and J. B. Cao, Occurrence of reconnection jets at the dayside magnetopause: Double Star observations, J. Geophys. Res. Space Phys. 113, A07S10 (2008).
  51. C. Pollock et al., Fast plasma investigation for magnetospheric multiscale, Space Sci. Rev. 199, 331 (2016).
  52. C. T. Russell et al., The magnetospheric multiscale magnetometers, Space Sci. Rev. 199, 189 (2016).
  53. G. Nguyen, N. Aunai, B. M. d. Welle, A. Jeandet, B. Lavraud, and D. Fontaine, Massive multi-mission statistical study and analytical modeling of the Earth’s magnetopause: 1. A gradient boosting based automatic detection of near-earth regions, J. Geophys. Res. Space Phys. 127, e2021JA029773 (2022).
  54. B. Michotte de Welle, N. Aunai, G. Nguyen, B. Lavraud, V. Génot, A. Jeandet, and R. Smets, Global three-dimensional draping of magnetic field lines in Earth’s magnetosheath from in-situ spacecraft measurements, J. Geophys. Res. Space Phys. 127, e2022JA030996 (2022).
  55. B. Michotte de Welle, N. Aunai, B. Lavraud, V. Génot, A. Jeandet, G. Nguyen, A. Ghisalberti, and R. Smets, Spatial distribution of plasma density and magnetic field amplitude in the dayside magnetosheath as a function of the IMF orientation, Front. Astron. Space Sci. 11, 1427791 (2024).
  56. B. Michotte de Welle, N. Aunai, B. Lavraud, V. Génot, G. Nguyen, A. Ghisalberti, R. Smets, and A. Jeandet, Global environmental constraints on magnetic reconnection at the magnetopause from in situ measurements, J. Geophys. Res. Space Phys. 129, e2023JA032098 (2024).
  57. P. A. Cassak and M. A. Shay, Scaling of asymmetric magnetic reconnection: General theory and collisional simulations, Phys. Plasmas 14, 2114 (2007).
  58. See Supplemental Material at http://link.aps.org/supplemental/10.1103/rlxh-smd1 for figures in the same format as Fig. 3 are provided as Supplemental Material [58] to show how the distribution of nonobservable and observable computed outflow speeds evolve as the observability threshold is changed from σvmsh.
  59. https://cdaweb.gsfc.nasa.gov.
  60. https://github.com/sciqlop/speasy.

Outline

Information

Phys. Rev. Lett. 137, 165201– Published 15 October, 2026
  • Received 30 November 2025
  • Accepted 2 June 2026
