High-Resolution Spectroscopy of Yb173+ Ions

J. Jiang1,*, A. V. Viatkina1,2, Saaswath JK1, M. Steinel1, M. Filzinger1, E. Peik1, S. G. Porsev3, M. S. Safronova3, A. Surzyhkov1,2,4 et al.

N. Huntemann1,†

  • *Contact author: jian.jiang@ptb.de
  • †Contact author: nils.huntemann@ptb.de
PDF

Phys. Rev. Lett. 136, 023001 – Published 14 January, 2026

DOI: https://doi.org/10.1103/rcdh-s4d7

Abstract

Compared to other stable isotopes of Yb+, Yb+173 has a richer hyperfine structure, which leads to more favorable clock transitions, spectroscopic techniques for probing new physics, and more sophisticated quantum computing architectures. However, to date, its electronic spectrum remains poorly characterized. Here, we report on efficient laser cooling, state preparation, and detection of a single trapped Yb173+ ion. The previously unobserved S21/2→D23/2 electric quadrupole transition at 436 nm is coherently excited, and the isotope shift between Yb171+ on this transition is determined with an uncertainty of 1.4 Hz. Using microwave spectroscopy, we resolve the hyperfine structure (HFS) of the D23/2 state with a relative uncertainty below 10−8. From the HFS measurement data, we infer for Yb173 a nuclear magnetic octupole moment Ω=−0.062(8)(b×μN) with uncertainty reduced by more than 2 orders of magnitude compared to previous studies. The data also allow us to determine hyperfine anomalies for the S21/2 and D23/2 states.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (54)

  1. I. Counts, J. Hur, D. P. L. Aude Craik, H. Jeon, C. Leung, J. C. Berengut, A. Geddes, A. Kawasaki, W. Jhe, and V. Vuletić, Evidence for nonlinear isotope shift in Yb+ search for new boson, Phys. Rev. Lett. 125, 123002 (2020).
  2. J. Hur, D. P. L. Aude Craik, I. Counts, E. Knyazev, L. Caldwell, C. Leung, S. Pandey, J. C. Berengut, A. Geddes, W. Nazarewicz, P.-G. Reinhard, A. Kawasaki, H. Jeon, W. Jhe, and V. Vuletić, Evidence of two-source king plot nonlinearity in spectroscopic search for new boson, Phys. Rev. Lett. 128, 163201 (2022).
  3. M. Door et al., Probing new bosons and nuclear structure with ytterbium isotope shifts, Phys. Rev. Lett. 134, 063002 (2025).
  4. C. Tamm, N. Huntemann, B. Lipphardt, V. Gerginov, N. Nemitz, M. Kazda, S. Weyers, and E. Peik, Cs-based optical frequency measurement using cross-linked optical and microwave oscillators, Phys. Rev. A 89, 023820 (2014).
  5. J. Stuhler et al., Opticlock: Transportable and easy-to-operate optical single-ion clock, Measurement: Sensors 18, 100264 (2021).
  6. N. Huntemann, C. Sanner, B. Lipphardt, C. Tamm, and E. Peik, Single-ion atomic clock with 3×10−18 systematic uncertainty, Phys. Rev. Lett. 116, 063001 (2016).
  7. A. Tofful, C. F. A. Baynham, E. A. Curtis, A. O. Parsons, B. I. Robertson, M. Schioppo, J. Tunesi, H. S. Margolis, R. J. Hendricks, J. Whale, R. C. Thompson, and R. M. Godun, Yb+171 optical clock with 2.2×10−18 systematic uncertainty and absolute frequency measurements, Metrologia 61, 045001 (2024).
  8. C. Sanner, N. Huntemann, R. Lange, C. Tamm, E. Peik, M. S. Safronova, and S. G. Porsev, Optical clock comparison for Lorentz symmetry testing, Nature (London) 567, 204 (2019).
  9. R. Lange, N. Huntemann, J. M. Rahm, C. Sanner, H. Shao, B. Lipphardt, C. Tamm, S. Weyers, and E. Peik, Improved limits for violations of local position invariance from atomic clock comparisons, Phys. Rev. Lett. 126, 011102 (2021).
  10. M. Filzinger, S. Dörscher, R. Lange, J. Klose, M. Steinel, E. Benkler, E. Peik, C. Lisdat, and N. Huntemann, Improved limits on the coupling of ultralight bosonic dark matter to photons from optical atomic clock comparisons, Phys. Rev. Lett. 130, 253001 (2023).
  11. G. N. Nop, D. Paudyal, and J. D. H. Smith, Ytterbium ion trap quantum computing: The current state-of-the-art, AVS Quantum Sci. 3, 044101 (2021).
  12. K. Wright et al., Benchmarking an 11-qubit quantum computer, Nat. Commun. 10, 5464 (2019).
  13. V. A. Dzuba and V. V. Flambaum, Calculation of nuclear-spin-dependent parity nonconservation in s–d transitions of Ba+, Yb+, and Ra+ ions, Phys. Rev. A 83, 052513 (2011).
  14. V. A. Dzuba and V. V. Flambaum, Hyperfine-induced electric dipole contributions to the electric octupole and magnetic quadrupole atomic clock transitions, Phys. Rev. A 93, 052517 (2016).
  15. D. Xiao, J. Li, W. C. Campbell, T. Dellaert, P. McMillin, A. Ransford, C. Roman, and A. Derevianko, Hyperfine structure of Yb173+: Toward resolving the Yb173 nuclear-octupole-moment puzzle, Phys. Rev. A 102, 022810 (2020).
  16. D. T. C. Allcock, W. C. Campbell, J. Chiaverini, I. L. Chuang, E. R. Hudson, I. D. Moore, A. Ransford, C. Roman, J. M. Sage, and D. J. Wineland, OMG blueprint for trapped ion quantum computing with metastable states, Appl. Phys. Lett. 119, 214002 (2021).
  17. S. P. Jain, E. R. Hudson, W. C. Campbell, and V. V. Albert, Absorption-emission codes for atomic and molecular quantum information platforms, Phys. Rev. Lett. 133, 260601 (2024).
  18. B. K. Sahoo and B. P. Das, Parity nonconservation in ytterbium ion, Phys. Rev. A 84, 010502(R) (2011).
  19. B. M. Roberts and J. S. M. Ginges, Hyperfine anomaly in heavy atoms and its role in precision atomic searches for new physics, Phys. Rev. A 104, 022823 (2021).
  20. A. Münch, M. Berkler, C. Gerz, D. Wilsdorf, and G. Werth, Precise ground-state hyperfine splitting in Yb173II, Phys. Rev. A 35, 4147 (1987).
  21. C. Roman, Expanding the Yb+171 toolbox: The F27/2 state as resource for quantum information science, Ph.D. thesis, University of California, Los Angeles, 2021.
  22. T. Dellaert, Metastable states, magic polarization, and hyperfine spectroscopy in Yb171+ and Yb173+, Ph.D. thesis, University of California, Los Angeles, 2025.
  23. A. Bohr and V. F. Weisskopf, The influence of nuclear structure on the hyperfine structure of heavy elements, Phys. Rev. 77, 94 (1950).
  24. C. Tamm, D. Engelke, and V. Bühner, Spectroscopy of the electric-quadrupole transition S21/2(F=0)−2D3/2(F=2) in trapped Yb+171, Phys. Rev. A 61, 053405 (2000).
  25. See Supplemental Material at http://link.aps.org/supplemental/10.1103/rcdh-s4d7 for more details, which includes Refs. [15,26–31].
  26. M. Abdel-Hafiz et al., Guidelines for developing optical clocks with 10−18 fractional frequency uncertainty, arXiv:1906.11495.
  27. D. Leibfried, R. Blatt, C. Monroe, and D. Wineland, Quantum dynamics of single trapped ions, Rev. Mod. Phys. 75, 281 (2003).
  28. M. G. Kozlov, S. G. Porsev, and V. V. Flambaum, Manifestation of the nuclear anapole moment in the M1 transitions in bismuth, J. Phys. B 29, 689 (1996).
  29. M. G. Kozlov, S. G. Porsev, M. S. Safronova, and I. I. Tupitsyn, ci-mbpt: A package of programs for relativistic atomic calculations based on a method combining configuration interaction and many-body perturbation theory, Comput. Phys. Commun. 195, 199 (2015).
  30. Yu. Ralchenko, A. Kramida, J. Reader, and the NIST ASD Team, NIST Atomic Spectra Database (version 4.1), http://physics.nist.gov/asd (2011).
  31. M. Roberts, P. Taylor, S. V. Gateva-Kostova, R. B. M. Clarke, W. R. C. Rowley, and P. Gill, Measurement of the S21/2−2D5/2 clock transition in a single Yb+171 ion, Phys. Rev. A 60, 2867 (1999).
  32. M. Johanning, A. Braun, D. Eiteneuer, C. Paape, C. Balzer, W. Neuhauser, and C. Wunderlich, Resonance-enhanced isotope-selective photoionization of YbI for ion trap loading, Appl. Phys. B 103, 327 (2011).
  33. D. J. Berkeland and M. G. Boshier, Destabilization of dark states and optical spectroscopy in Zeeman-degenerate atomic systems, Phys. Rev. A 65, 033413 (2002).
  34. J. Keller, H. L. Partner, T. Burgermeister, and T. E. Mehlstäubler, Precise determination of micromotion for trapped-ion optical clocks, J. Appl. Phys. 118, 104501 (2015).
  35. C.-w. Chou, C. Kurz, D. B. Hume, P. N. Plessow, D. R. Leibrandt, and D. Leibfried, Preparation and coherent manipulation of pure quantum states of a single molecular ion, Nature (London) 545, 203 (2017).
  36. G. Breit and I. I. Rabi, Measurement of nuclear spin, Phys. Rev. 38, 2082 (1931).
  37. B. Fawcett and M. Wilson, Computed oscillator strengths, Landé g values, and lifetimes in Yb II, At. Data Nucl. Data Tables 47, 241 (1991).
  38. G. H. Gossel, V. A. Dzuba, and V. V. Flambaum, Calculation of strongly forbidden m1 transitions and g-factor anomalies in atoms considered for parity-nonconservation measurements, Phys. Rev. A 88, 034501 (2013).
  39. M. Schacht, J. R. Danielson, S. Rahaman, J. R. Torgerson, J. Zhang, and M. M. Schauer, Yb171+ 5D3/2 hyperfine state detection and F=2 lifetime, J. Phys. B 48, 065003 (2015).
  40. H. Shao, H. Yue, Z. Ma, Y. Huang, H. Guan, and K. Gao, Precision determination of the 5d2d3/2 state lifetime of single Yb174+ ion, Phys. Rev. Res. 5, 023193 (2023).
  41. C. Schwartz, Theory of hyperfine structure, Phys. Rev. 97, 380 (1955).
  42. J. Z. Han, N. C. Xin, J. W. Zhang, Y. M. Yu, J. G. Li, L. Qian, and L. J. Wang, Determination of the ground-state hyperfine splitting of trapped Yb171+ ions, Appl. Phys. Lett. 125, 084002 (2024).
  43. P. Phoonthong, M. Mizuno, K. Kido, and N. Shiga, Determination of the absolute microwave frequency of laser-cooled Yb171+, Appl. Phys. B 117, 673 (2014).
  44. R. Blatt, H. Schnatz, and G. Werth, Precise determination of the Yb171+ ground state hyperfine separation, Z. Phys. A At. Nucl. 312, 143 (1983).
  45. A. K. Singh, D. Angom, and V. Natarajan, Observation of the nuclear magnetic octupole moment of Yb173 from precise measurements of the hyperfine structure in the P23 state, Phys. Rev. A 87, 012512 (2013).
  46. S. A. Williams, Magnetic octupole moments of axially symmetric deformed nuclei, Phys. Rev. 125, 340 (1962).
  47. R. P. de Groote, S. Kujanpää, A. Koszorús, J. G. Li, and I. D. Moore, Magnetic octupole moment of Yb173 using collinear laser spectroscopy, Phys. Rev. A 103, 032826 (2021).
  48. S. A. Blundell, W. R. Johnson, and J. Sapirstein, Relativistic all-order calculations of energies and matrix elements in cesium, Phys. Rev. A 43, 3407 (1991).
  49. E. Kahl and J. Berengut, ambit: A programme for high-precision relativistic atomic structure calculations, Comput. Phys. Commun. 238, 232 (2019).
  50. N. J. Stone (International Atomic Energy Agency), Table of Nuclear Magnetic Dipole and Electric Quadrupole Moments (International Nuclear Data Committee, Vienna (Austria), 2014), https://doi.org/10.61092/iaea.zhrz-3g5j.
  51. N. Fortson, Possibility of measuring parity nonconservation with a single trapped atomic ion, Phys. Rev. Lett. 70, 2383 (1993).
  52. B. Roberts, V. Dzuba, and V. Flambaum, Parity and time-reversal violation in atomic systems, Annu. Rev. Nucl. Part. Sci. 65, 63 (2015).
  53. M. S. Safronova, D. Budker, D. DeMille, D. F. J. Kimball, A. Derevianko, and C. W. Clark, Search for new physics with atoms and molecules, Rev. Mod. Phys. 90, 025008 (2018).
  54. J. Jiang and N. Huntemann, Experimental data for “High-resolution spectroscopy of Yb+173 ions,” Zenodo, 10.5281/zenodo.18017487 (2025).
