Significance of Microtearing Turbulence in Turbulence-Reduced High-Density-Gradient Plasmas in Wendelstein 7-X

H. Cu-Castillo1,*, A. Bañón Navarro1, G. Merlo1, F. Reimold2, T. Romba2, O. Ford2, S. Bannmann2, L. Vanó2, M. Wappl2 et al.

J. Geiger2, A. Goodman2, A. Zocco2, F. Jenko1, and W7-X Team†

  • *Contact author: hugo.cu.castillo@ipp.mpg.de
  • †See Supplemental Material [1] for the W7-X Team.
PDF

Phys. Rev. Lett. 137, 035102 – Published 14 July, 2026

DOI: https://doi.org/10.1103/nd3p-yb9t

Abstract

Gyrokinetic simulations of a turbulence-reduced Wendelstein 7-X discharge—characterized by a steep density gradient, moderate temperature gradients, and low plasma beta—show that microtearing mode (MTM) turbulence dominates transport. The simulated heat and particle fluxes agree with experimental measurements, leaving MTMs as the only mode consistent with the data. These conditions, the quasi-isodynamic and nearly max-J magnetic configuration of the Wendelstein 7-X stabilize ion temperature gradient modes and density-gradient-driven trapped-electron modes, while moderate collisionality and low magnetic shear further enable MTM growth. Further nonlinear scans of the density gradient reveal a significant reduction in turbulent transport at the experimentally observed threshold, which we identify as an ion temperature gradient to MTM-dominated turbulence transition. These findings provide a robust explanation for the turbulence suppression and deepen our understanding of low turbulent transport regimes in optimized stellarators.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (52)

  1. See Supplemental Material at http://link.aps.org/supplemental/10.1103/nd3p-yb9t for the members of the W7-X team.
  2. S. Bannmann (The W7-X Team), Phys. Rev. E (to be published), 10.1103/q59k-8m26.
  3. S, A. Bozhenkov (The W7-X Team), Plasma Phys. Controlled Fusion 68, 055015 (2026).
  4. C. D. Beidler et al. (The W7-X Team), Nature (London) 596, 221 (2021).
  5. T. Klinger et al., Nucl. Fusion 59, 112004 (2019).
  6. T. Sunn Pedersen et al., Nucl. Fusion 62, 042022 (2022).
  7. F. Wilms, A. Bañón Navarro, T. Windisch, S. Bozhenkov, F. Warmer, G. Fuchert, O. Ford, D. Zhang, T. Stange, F. Jenko (The W7-X Team), Nucl. Fusion 64, 096040 (2024).
  8. D. L. C. Agapito Fernando et al. (The W7-X Team), Phys. Plasmas 32, 073904 (2025).
  9. F. Wilms, A. B. Navarro, G. Merlo, A. Di Siena, G. Weir, T. Windisch, S. Bozhenkov, G. Fuchert, O. Ford, D. Zhang, T. Stange, E. Pasch, T. Romba, P. Z. Pölöskei, A. Langenberg, N. Pablant, F. Jenko (The W7-X Team), Phys. Plasmas 32, 072505 (2025).
  10. S. Bozhenkov et al. (The W7-X Team), Nucl. Fusion 60, 066011 (2020).
  11. O. Ford et al. (The W7-X Team), Nucl. Fusion 64, 086067 (2024).
  12. M. Wappl, S. A. Bozhenkov, T. Andreeva, S. Bannmann, H. M. Smith, R. C. Wolf (The W7-X Team), Plasma Phys. Controlled Fusion 67, 075025 (2025).
  13. S. Bannmann, O. Ford, P. Poloskei, J. Svensson, A. Pavone, S. Kwak, U. Hoefel, E. Pasch, G. Fuchert, H. Smith, S. Lazerson, P. McNeely, N. Rust, D. Hartmann, R. Wolf (The W7-X Team), Nucl. Fusion 64, 106015 (2024).
  14. T. Romba, F. Reimold, R. Jaspers, O. Ford, L. Vanó, T. Klinger (The W7-X Team), Nucl. Fusion 63, 076023 (2023).
  15. T. Romba, F. Reimold, S. Bannmann, T. Bleher, O. P. Ford, P. Z. Poloskei, M. Wappl (The W7-X Team), Plasma Phys. Controlled Fusion 67, 065016 (2025).
  16. N. T. Gladd, J. F. Drake, C. L. Chang, and C. S. Liu, Phys. Fluids 23, 1182 (1980).
  17. J. F. Drake, N. T. Gladd, C. S. Liu, and C. L. Chang, Phys. Rev. Lett. 44, 994 (1980).
  18. J. F. Drake and Y. C. Lee, Phys. Fluids 20, 1341 (1977).
  19. A. Zocco, N. F. Loureiro, D. Dickinson, R. Numata, and C. M. Roach, Plasma Phys. Controlled Fusion 57, 065008 (2015).
  20. W. Guttenfelder, J. Candy, S. M. Kaye, W. M. Nevins, E. Wang, R. E. Bell, G. W. Hammett, B. P. LeBlanc, D. R. Mikkelsen, and H. Yuh, Phys. Rev. Lett. 106, 155004 (2011).
  21. X. Jian, C. Holland, J. Candy, E. Belli, V. Chan, A. M. Garofalo, and S. Ding, Phys. Rev. Lett. 123, 225002 (2019).
  22. D. Hatch, M. Kotschenreuther, S. Mahajan, M. Pueschel, C. Michoski, G. Merlo, E. Hassan, A. Field, L. Frassinetti, C. Giroud, J. Hillesheim, C. Maggi, C. Perez von Thun, C. Roach, S. Saarelma, D. Jarema, F. Jenko, and J. Contributors, Nucl. Fusion 61, 036015 (2021).
  23. F. Jenko, W. Dorland, M. Kotschenreuther, and B. N. Rogers, Phys. Plasmas 7, 1904 (2000).
  24. H. Yamada, J. Harris, A. Dinklage, E. Ascasibar, F. Sano, S. Okamura, J. Talmadge, U. Stroth, A. Kus, S. Murakami, M. Yokoyama, C. Beidler, V. Tribaldos, K. Watanabe, and Y. Suzuki, Nucl. Fusion 45, 1684 (2005).
  25. M. Beurskens et al. (The W7-X Team), Nucl. Fusion 61, 116072 (2021).
  26. F. Merz, Gyrokinetic simulation of multimode plasma turbulence, Ph.D. thesis, Westfälischen Wilhelms-Universität Münster, 2009.
  27. M. Li, B. N. Breizman, and L. Zheng, J. Comput. Phys. 326, 334 (2016).
  28. M. A. Beer, S. C. Cowley, and G. W. Hammett, Phys. Plasmas 2, 2687 (1995).
  29. M. F. Martin, M. Landreman, P. Xanthopoulos, N. R. Mandell, and W. Dorland, Plasma Phys. Controlled Fusion 60, 095008 (2018).
  30. P. Manas, Y. Camenen, S. Benkadda, W. A. Hornsby, and A. G. Peeters, Phys. Plasmas 22, 062302 (2015).
  31. G. G. Plunk, J. W. Connor, and P. Helander, J. Plasma Phys. 83, 715830404 (2017).
  32. J. H. E. Proll, P. Xanthopoulos, and P. Helander, Phys. Plasmas 20, 122506 (2013).
  33. W. Guttenfelder, J. Candy, S. M. Kaye, W. M. Nevins, R. E. Bell, G. W. Hammett, B. P. LeBlanc, and H. Yuh, Phys. Plasmas 19, 022506 (2012).
  34. X. Jian, C. Holland, J. Candy, S. Ding, E. Belli, V. Chan, G. M. Staebler, A. M. Garofalo, J. Mcclenaghan, and P. Snyder, Phys. Plasmas 28, 042501 (2021).
  35. J. H. E. Proll, P. Helander, J. W. Connor, and G. G. Plunk, Phys. Rev. Lett. 108, 245002 (2012).
  36. D. Carralero, T. Estrada, E. Maragkoudakis, T. Windisch, J. Alonso, M. Beurskens, S. Bozhenkov, I. Calvo, H. Damm, O. Ford, G. Fuchert, J. García-Regaña, N. Pablant, E. Sánchez, E. Pasch, J. Velasco (The W7-X Team), Nucl. Fusion 61, 096015 (2021).
  37. F. Jenko and B. D. Scott, Phys. Plasmas 6, 2418 (1999).
  38. M. Kotschenreuther, X. Liu, D. Hatch, S. Mahajan, L. Zheng, A. Diallo, R. Groebner, the DIII-D TEAM, J. Hillesheim, C. Maggi, C. Giroud, F. Koechl, V. Parail, S. Saarelma, E. Solano, A. Chankin, and J. Contributors, Nucl. Fusion 59, 096001 (2019).
  39. H. Doerk, F. Jenko, M. J. Pueschel, and D. R. Hatch, Phys. Rev. Lett. 106, 155003 (2011).
  40. P. Xanthopoulos, S. A. Bozhenkov, M. N. Beurskens, H. M. Smith, G. G. Plunk, P. Helander, C. D. Beidler, J. A. Alcusón, A. Alonso, A. Dinklage, O. Ford, G. Fuchert, J. Geiger, J. H. E. Proll, M. J. Pueschel, Y. Turkin, F. Warmer (The W7-X Team), Phys. Rev. Lett. 125, 075001 (2020).
  41. P. Costello, J. Proll, G. Plunk, M. Pueschel, and J. Alcusón, J. Plasma Phys. 89, 905890402 (2023).
  42. J. Proll, G. Plunk, B. Faber, T. Görler, P. Helander, I. McKinney, M. Pueschel, H. Smith, and P. Xanthopoulos, J. Plasma Phys. 88, 905880112 (2022).
  43. L. Podavini, A. Zocco, J. García-Regaña, M. Barnes, F. Parra, A. Mishchenko, and P. Helander, J. Plasma Phys. 90, 905900414 (2024).
  44. H. Thienpondt, J. García-Regaña, I. Calvo, G. Acton, and M. Barnes, Nucl. Fusion 65, 016062 (2025).
  45. M. C. L. Morren, J. H. E. Proll, J. van Dijk, and M. J. Pueschel, Phys. Plasmas 31, 052508 (2024).
  46. J. Duff, B. Faber, C. Hegna, M. Pueschel, and P. Terry, Nucl. Fusion 65, 046020 (2025).
  47. J. D. Huba and S. P. Gary, Phys. Fluids 25, 1821 (1982).
  48. D. E. Hastings and J. E. McCune, Phys. Fluids 25, 509 (1982).
  49. A. Zocco, L. Podavini, F. Wilms, A. Bañón Navarro, and F. Jenko, Phys. Rev. Res. 6, 033099 (2024).
  50. J. Lion et al., Fusion Eng. Des. 214, 114868 (2025).
  51. C. Hegna, D. Anderson, E. Andrew, A. Ayilaran, A. Bader, T. Bohm, K. C. Mata, J. Canik, L. Carbajal, A. Cerfon et al., J. Plasma Phys. 91, E76 (2025).
  52. L. Baylor, A. Geraud, W. Houlberg, D. Frigione, M. Gadeberg, T. Jernigan, J. D. Kloe, P. Kupschus, B. Kuteev, P. Lang, A. Oomens, A. Qualls, K. Sato, and G. Schmidt, Nucl. Fusion 37, 445 (1997).

Outline

Information

Phys. Rev. Lett. 137, 035102– Published 14 July, 2026
  • Received 20 October 2025
  • Revised 20 February 2026
  • Accepted 21 April 2026
Crossmark - Check for updates button
Creative Commons Logo

Published by the American Physical Society under the terms of the Creative Commons Attribution 4.0 International license. Further distribution of this work must maintain attribution to the author(s) and the published article’s title, journal citation, and DOI. Open access publication funded by the Max Planck Society.
