First-Principles Explanation of the Drift Configuration Dependence of the Radial Electric Field and High-Confinement Access in Tokamaks

B. J. Frei, R. Bilato, O. Grover, W. Zholobenko, C. Angioni, M. Bergmann, P. Ulbl, F. Jenko, and the ASDEX Upgrade Team*

PDF

Phys. Rev. Lett. 137, 035103 – Published 15 July, 2026

DOI: https://doi.org/10.1103/m911-g6kc

Abstract

The origin of the difference in the high-confinement (H-mode) power threshold between favorable and unfavorable drift configurations in tokamaks—experimentally linked to a deeper radial electric field (Er) well in the former—remains unresolved. Using first-principles gyrokinetic simulations of edge and scrape-off-layer turbulence in the ASDEX Upgrade tokamak, we show that turbulence-driven poloidal flows generate this deeper Er well in the favorable configuration through enhanced nonlinear turbulence-mean flow energy transfer. This transfer is significantly weaker in the unfavorable case, yielding a shallower Er well, while turbulence intensity is simultaneously higher. Within the turbulence-flow shear suppression paradigm, the combination of stronger shear and reduced turbulence facilitates H-mode access in the favorable configuration. These results provide the first validated, self-consistent full-f gyrokinetic explanation of how drift configuration controls the nonlinear dynamics of profiles, Er, flows, and turbulence, thereby setting the H-mode power threshold.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (43)

  1. F. Ryter, R. Granetz, M. Greenwald, O. Kardaun, A. Kus, U. Stroth, J. Kollermeyer, S. Fielding, M. Valovic, J. DeBoo et al., H mode power threshold database for ITER, Nucl. Fusion 36, 1217 (1996).
  2. G. McKee, P. Gohil, D. Schlossberg, J. Boedo, K. Burrell, J. Degrassie, R. Groebner, R. Moyer, C. Petty, T. Rhodes et al., Dependence of the L-to H-mode power threshold on toroidal rotation and the link to edge turbulence dynamics, Nucl. Fusion 49, 115016 (2009).
  3. F. Ryter, R. Fischer, J. Fuchs, T. Happel, R. McDermott, E. Viezzer, E. Wolfrum, L. B. Orte, M. Bernert, A. Burckhart et al., I-mode studies at ASDEX Upgrade: L-I and I-H transitions, pedestal and confinement properties, Nucl. Fusion 57, 016004 (2016).
  4. I. Cziegler, A. E. Hubbard, J. W. Hughes, J. L. Terry, and G. R. Tynan, Turbulence nonlinearities shed light on geometric asymmetry in tokamak confinement transitions, Phys. Rev. Lett. 118, 105003 (2017).
  5. U. Plank, D. Brida, G. Conway, T. Happel, A. Hubbard, T. Pütterich, C. Angioni, M. Cavedon, R. Dux, T. Eich et al., Experimental study of the edge radial electric field in different drift configurations and its role in the access to H-mode at ASDEX Upgrade, Phys. Plasmas 30 (2023).
  6. T. Carlstrom, R. Groebner, C. Fenzi, G. McKee, R. Moyer, and T. Rhodes, Evidence for the role of velocity shear on the L-H transition in DIII-D, Plasma Phys. Controlled Fusion 44, A333 (2002).
  7. J. Schirmer, G. Conway, H. Zohm, and W. Suttrop (ASDEX Upgrade Team), The radial electric field and its associated shear in the ASDEX Upgrade tokamak, Nucl. Fusion 46, S780 (2006).
  8. L. Vermare, P. Hennequin, C. Honoré, M. Peret, G. Dif-Pradalier, X. Garbet, J. Gunn, C. Bourdelle, F. Clairet, J. Morales et al., Formation of the radial electric field profile in the WEST tokamak, Nucl. Fusion 62, 026002 (2021).
  9. Z. Yan, G. McKee, L. Schmitz, P. Gohil, and S. Haskey (DIII-D Team), Turbulence characteristics and flow dynamics impacts on the H-mode transition in favourable magnetic geometry with lower power threshold, Phil. Trans. R. Soc. A 381, 20210240 (2023).
  10. U. Plank, R. McDermott, G. Birkenmeier, N. Bonanomi, M. Cavedon, G. Conway, T. Eich, M. Griener, O. Grover, P. Schneider et al., Overview of L-to H-mode transition experiments at ASDEX Upgrade, Plasma Phys. Controlled Fusion 65, 014001 (2023).
  11. T. Versloot, P. De Vries, C. Giroud, M. Brix, M. Von Hellermann, P. Lomas, D. Moulton, M. O’Mullane, I. Nunes, A. Salmi et al., Momentum losses by charge exchange with neutral particles in H-mode discharges at JET, Plasma Phys. Controlled Fusion 53, 065017 (2011).
  12. R. W. Brzozowski, F. Jenko, R. Bilato, and M. Cavedon (ASDEX Upgrade Team), A geometric model of ion orbit loss under the influence of a radial electric field, Phys. Plasmas 26 (2019).
  13. H. Zhu, T. Stoltzfus-Dueck, R. Hager, S. Ku, and C.-S. Chang, Effects of collisional ion orbit loss on tokamak radial electric field and toroidal rotation in an L-mode plasma, Nucl. Fusion 63, 066009 (2023).
  14. B. LaBombard, J. Rice, A. Hubbard, J. Hughes, M. Greenwald, R. Granetz, J. Irby, Y. Lin, B. Lipschultz, E. Marmar et al., Transport-driven scrape-off layer flows and the x-point dependence of the L-H power threshold in Alcator C-Mod, Phys. Plasmas 12 (2005).
  15. C. Hidalgo, C. Silva, M. A. Pedrosa, E. Sánchez, H. Fernandes, and C. A. F. Varandas, Radial structure of Reynolds stress in the plasma boundary of tokamak plasmas, Phys. Rev. Lett. 83, 2203 (1999).
  16. P. H. Diamond, S.-I. Itoh, K. Itoh, and T. S. Hahm, Zonal flows in plasma—A review, Plasma Phys. Controlled Fusion 47, R35 (2005).
  17. N. Fedorczak, P. Diamond, G. Tynan, and P. Manz, Shear-induced Reynolds stress at the edge of L-mode tokamak plasmas, Nucl. Fusion 52, 103013 (2012).
  18. N. Fedorczak, P. Ghendrih, P. Hennequin, G. Tynan, P. Diamond, and P. Manz, Dynamics of tilted eddies in a transversal flow at the edge of tokamak plasmas and the consequences for L-H transition, Plasma Phys. Controlled Fusion 55, 124024 (2013).
  19. B. Schmid, P. Manz, M. Ramisch, and U. Stroth, Spatio-temporal structure of turbulent Reynolds stress zonal flow drive in 3D magnetic configuration, New J. Phys. 19, 055003 (2017).
  20. O. Grover, T. Eich, P. Manz, W. Zholobenko, T. Happel, T. Body, U. Plank, and P. Ulbl (ASDEX Upgrade Team), Reduced model for H-mode sustainment in unfavorable drift configuration in ASDEX Upgrade, Nucl. Fusion 64, 056020 (2024).
  21. P. Manz, A. Stegmeir, B. Schmid, T. Ribeiro, G. Birkenmeier, N. Fedorczak, S. Garland, K. Hallatschek, M. Ramisch, and B. Scott, Magnetic configuration effects on the Reynolds stress in the plasma edge, Phys. Plasmas 25 (2018).
  22. R. Fischer, C. Fuchs, B. Kurzan, W. Suttrop, and E. Wolfrum (ASDEX Upgrade Team), Integrated data analysis of profile diagnostics at ASDEX Upgrade, Fusion Sci. Technol. 58, 675 (2010).
  23. A. Peeters, Reduced charge state equations that describe Pfirsch Schlüter impurity transport in tokamak plasma, Phys. Plasmas 7, 268 (2000).
  24. D. Michels, A. Stegmeir, P. Ulbl, D. Jarema, and F. Jenko, gene-x: A full-f gyrokinetic turbulence code based on the flux-coordinate independent approach, Comput. Phys. Commun. 264, 107986 (2021).
  25. B. Frei, P. Ulbl, J. Trilaksono, and F. Jenko, Spectrally accelerated edge and scrape-off layer gyrokinetic turbulence simulations, Comput. Phys. Commun. 316, 109817 (2025).
  26. Y. B. Kim, P. H. Diamond, and R. J. Groebner, Neoclassical poloidal and toroidal rotation in tokamaks, Phys. Fluids B 3, 2050 (1991).
  27. E. Belli and J. Candy, Kinetic calculation of neoclassical transport including self-consistent electron and impurity dynamics, Plasma Phys. Controlled Fusion 50, 095010 (2008).
  28. G. Dif-Pradalier, V. Grandgirard, Y. Sarazin, X. Garbet, and P. Ghendrih, Interplay between gyrokinetic turbulence, flows, and collisions: Perspectives on transport and poloidal rotation, Phys. Rev. Lett. 103, 065002 (2009).
  29. R. D. Hazeltine and J. D. Meiss, Plasma Confinement (Courier Corporation, New York, 2013).
  30. B. J. Frei, P. Ulbl, C. Pitzal, W. Zholobenko, and F. Jenko, Turbulence and transport in spectrally accelerated full-f gyrokinetic simulations, Nucl. Fusion 65, 116026 (2025).
  31. G. D. Conway, A. I. Smolyakov, and T. Ido, Geodesic acoustic modes in magnetic confinement devices, Nucl. Fusion 62, 013001 (2021).
  32. R. Bielajew, U. Plank, G. Conway, A. Hubbard, P. Rodriguez-Fernandez, B. Vanovac, C. Yoo, and A. White (ASDEX Upgrade Team), Edge radiated temperature fluctuations across confinement regime transitions in favorable and unfavorable drift configurations at ASDEX Upgrade, Nucl. Fusion 63, 126022 (2023).
  33. N. Bonanomi, C. Angioni, G. Conway, T. Happel, U. Plank, P. Schneider, and G. Staebler (ASDEX Upgrade Team and EUROFusion MST1 Team), From L-mode to the L–H transition, experiments on ASDEX upgrade and related gyrokinetic simulations, Phys. Plasmas 31 (2024).
  34. A. Favre, Equations des gaz turbulents compressibles, J. Mec. 4 (1965).
  35. M. Held, M. Wiesenberger, R. Kube, and A. Kendl, Non-Oberbeck–Boussinesq zonal flow generation, Nucl. Fusion 58, 104001 (2018).
  36. P. Manz, M. Xu, N. Fedorczak, S. Thakur, and G. Tynan, Spatial redistribution of turbulent and mean kinetic energy, Phys. Plasmas 19 (2012).
  37. M. Cavedon, T. Happel, P. Hennequin, R. Dux, K. Höfler, U. Plank, T. Pütterich, U. Stroth, E. Viezzer, and E. Wolfrum, The radial localization of the transition from low to high confinement mode in the ASDEX Upgrade tokamak, Plasma Phys. Controlled Fusion 66, 025011 (2024).
  38. S. Rienäcker, P. Hennequin, L. Vermare, C. Honoré, S. Coda, B. Labit, B. Vincent, Y. Wang, L. Frassinetti, O. Panico et al., Survey of the edge radial electric field in L-mode TCV plasmas using Doppler backscattering, Plasma Phys. Controlled Fusion 67, 065003 (2025).
  39. B. Scott, The geodesic transfer effect on zonal flows in tokamak edge turbulence, Phys. Lett. A 320, 53 (2003).
  40. B. D. Scott, Energetics of the interaction between electromagnetic E×B turbulence and zonal flows, New J. Phys. 7, 92 (2005).
  41. G. D. Conway, C. Angioni, F. Ryter, P. Sauter, and J. Vicente (ASDEX Upgrade Team), Mean and oscillating plasma flows and turbulence interactions across the L-H confinement transition, Phys. Rev. Lett. 106, 065001 (2011).
  42. A. Smolyakov, P. Diamond, and M. Medvedev, Role of ion diamagnetic effects in the generation of large scale flows in toroidal ion temperature gradient mode turbulence, Phys. Plasmas 7, 3987 (2000).
  43. Y. Sarazin, G. Dif-Pradalier, X. Garbet, P. Ghendrih, A. Berger, C. Gillot, V. Grandgirard, K. Obrejan, R. Varennes, L. Vermare et al., Key impact of phase dynamics and diamagnetic drive on Reynolds stress in magnetic fusion plasmas, Plasma Phys. Controlled Fusion 63, 064007 (2021).
