Coherent Ionization of Atoms by Dense Beams of Extreme Relativistic Electrons

S. Kim, C. Müller, and A. B. Voitkiv

PDF

Phys. Rev. Lett. 136, 213202 – Published 27 May, 2026

DOI: https://doi.org/10.1103/knz2-4fw4

Abstract

Ionization is one of the basic physical processes, occurring when charged particles penetrate atomic matter. Here, we predict a novel ionization mechanism, arising in collisions with very dense and compact beams of extreme relativistic electrons, in which a significant fraction of the beam electrons acts coherently as a single “superprojectile.” We compare this mechanism with the tunnel and overbarrier ionization and ionization by individual electrons, demonstrating that it can strongly dominate the ionization process. We also show that this mechanism and the tunnel ionization are very sensitive to the spatiotemporal structure of the beam that can be used for analyzing the beam properties.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (51)

  1. R. E. Taylor, Deep inelastic scattering: The early years, Rev. Mod. Phys. 63, 573 (1991).
  2. D. S. Armstrong and R. D. McKeown, Parity-violating electron scattering and the electric and magnetic strange form factors of the nucleon, Annu. Rev. Nucl. Part. Sci. 62, 337 (2012).
  3. J. Arrington, N. Fomin, and A. Schmidt, Progress in understanding short-range structure in nuclei: An experimental perspective, Annu. Rev. Nucl. Part. Sci. 72, 307 (2022).
  4. V. Shiltsev and F. Zimmermann, Modern and future colliders, Rev. Mod. Phys. 93, 015006 (2021).
  5. A. Novikova, Probing matter with relativistic electron beams, Nat. Rev. Phys. 1, 363 (2019).
  6. J. Feldhaus, J. Arthur, and J. B. Hastings, X-ray free-electron lasers, J. Phys. B 38, S799 (2005).
  7. C. Pellegrini, A. Marinelli, and S. Reiche, The physics of x-ray free-electron lasers, Rev. Mod. Phys. 88, 015006 (2016).
  8. M. C. Downer, R. Zgadzaj, A. Debus, U. Schramm, and M. C. Kaluza, Diagnostics for plasma-based electron accelerators, Rev. Mod. Phys. 90, 035002 (2018).
  9. E. Esarey, C. B. Schroeder, and W. P. Leemans, Physics of laser-driven plasma-based electron accelerators, Rev. Mod. Phys. 81, 1229 (2009).
  10. T. Tajima, X. Q. Yan, and T. Ebisuzaki, Wakefield acceleration, Rev. Mod. Plasma Phys. 4, 7 (2020).
  11. E. Gschwendtner and P. Muggli, Plasma wakefield accelerators, Nat. Rev. Phys. 1, 246 (2019).
  12. C. A. Lindstrøm, S. Corde, R. D’Arcy, S. Gessner, M. Gilljohann, M. J. Hogan, and J. Osterhoff, Beam-driven plasma-wakefield acceleration, arXiv:2504.05558.
  13. J. P. Couperus, R. Pausch, A. Köhler, O. Zarini, J. M. Krämer, M. Garten, A. Huebl, R. Gebhardt, U. Helbig, S. Bock, K. Zeil, A. Debus, M. Bussmann, U. Schramm, and A. Irman, Demonstration of a beam loaded nanocoulomb-class laser wakefield accelerator, Nat. Commun. 8, 487 (2017).
  14. C. Emma, N. Majernik, K. K. Swanson, R. Ariniello, S. Gessner, R. Hessami, M. J. Hogan, A. Knetsch, K. A. Larsen, A. Marinelli, B. O’Shea, S. Perez, I. Rajkovic, R. Robles, D. Storey, and G. Yocky, Experimental generation of extreme electron beams for advanced accelerator applications, Phys. Rev. Lett. 134, 085001 (2025).
  15. A. F. Habib, Th. Heinemann, G. G. Manahan, D. Ullmann, P. Scherkl, A. Knetsch, A. Sutherland, A. Beaton, D. Campbell, L. Rutherford et al., Plasma photocathodes, Ann. Phys. (Berlin) 535, 2200655 (2023).
  16. A. Deng, O. S. Karger, T. Heinemann, A. Knetsch, P. Scherkl, G. G. Manahan, A. Beaton, D. Ullmann, G. Wittig, A. F. Habib et al., Generation and acceleration of electron bunches from a plasma photocathode, Nat. Phys. 15, 1156 (2019).
  17. A. F. Habib, G. G. Manahan, P. Scherkl, T. Heinemann, A. Sutherland, R. Altuiri, B. M. Alotaibi, M. Litos, J. Cary, T. Raubenheimer et al., Attosecond-Angstrom free-electron-laser towards the cold beam limit, Nat. Commun. 14, 1054 (2023).
  18. J. B. Rosenzweig, G. Andonian, P. Bucksbaum, M. Ferrario, S. Full, A. Fukusawa, E. Hemsing, B. Hidding, M. Hogan, P. Krejcik, P. Muggli, G. Marcus, A. Marinelli, P. Musumeci, B. O’Shea, C. Pellegrini, D. Schiller, and G. Travish, Teravolt-per-meter beam and plasma fields from low-charge femtosecond electron beams, Nucl. Instrum. Methods Phys. Res., Sect. A 653, 98 (2011).
  19. S. Kuschel et al., Demonstration of passive plasma lensing of a laser wakefield accelerated electron bunch, Phys. Rev. Accel. Beams 19, 071301 (2016).
  20. C. Thaury, E. Guillaume, A. Döpp, R. Lehe, A. Lifschitz, K. Ta Phuoc, J. Gautier, J.-P. Goddet, A. Tafzi, A. Flacco et al., Demonstration of relativistic electron beam focusing by a laser-plasma lens, Nat. Commun. 6, 6860 (2015).
  21. C. E. Doss, E. Adli, R. Ariniello, J. Cary, S. Corde, B. Hidding, M. J. Hogan, K. Hunt-Stone, C. Joshi, K. A. Marsh et al., Laser-ionized, beam-driven, underdense, passive thin plasma lens, Phys. Rev. Accel. Beams 22, 111001 (2019).
  22. Y.-Y. Chang, J. C. Cabadağ, A. Debus, A. Ghaith, M. LaBerge, R. Pausch, S. Schöbel, P. Ufer, U. Schramm, and A. Irman, Reduction of the electron-beam divergence of laser wakefield accelerators by integrated plasma lenses, Phys. Rev. Appl. 20, L061001 (2023).
  23. E. G. Gelfer, A. M. Fedotov, O. Klimo, and S. Weber, Coherent radiation of an electron bunch colliding with an intense laser pulse, Phys. Rev. Res. 6, L032013 (2024).
  24. M. J. Quin, A. Di Piazza, and M. Tamburini, Coherent frequency combs from electrons colliding with a laser pulse, Plasma Phys. Controlled Fusion 67, 055008 (2025).

  25. We have also performed calculations by describing beam electrons by Dirac plane-wave states. After the averaging over spin states of the incident electron and summing over spin states of the scattered electron (taking into account that the scattering angle is very small), the resulting cross sections fully coincide with those which are obtained by using the semiclassical approach.

  26. J. Eichler, Lectures on Ion-Atom Collisions (Elsevier, New York 2005).
  27. R. Moshammer, W. Schmitt, J. Ullrich, H. Kollmus, A. Cassimi, R. Dörner, O. Jagutzki, R. Mann, R. E. Olson et al., Ionization of helium in the attosecond equivalent light pulse of 1 GeV/Nucleon U92+ projectiles, Phys. Rev. Lett. 79, 3621 (1997).
  28. A. B. Voitkiv, B. Najjari, R. Moshammer, and J. Ullrich, Helium single ionization in relativistic collisions with highly charged ions, Phys. Rev. A 65, 032707 (2002); A. B. Voitkiv and B. Najjari, Ionization of helium by relativistic highly charged ions within the symmetric eikonal approximation, J. Phys. B 37, 4831 (2004).

  29. λ∥ and λ⊥ can be viewed as the longitudinal and transverse wavelengths, respectively, of the equivalent photon.

  30. A. B. Voitkiv and J. Ullrich, On the inter-relation between ionization of light atoms by virtual and real photons, J. Phys. B 34, 4513 (2001).

  31. For instance, for single ionization of He(1s2) α1=12.289 and α2=2.08 [32].

  32. M. Inokuti, Inelastic collisions of fast charged particles with atoms and molecules-the Bethe theory revisited, Rev. Mod. Phys. 43, 297 (1972); 50, 23 (1978).
  33. E. Fermi, Über die Theorie des Stoßes zwischen Atomen und elektrisch geladenen Teilchen, Z. Phys. 29, 315 (1924); C. F. von Weizsäcker, Ausstrahlung bei Stößen sehr schneller Elektronen, 88, 612 (1934); E. J. Williams, Nature of the high energy particles of penetrating radiation and status of ionization and radiation formulae, Phys. Rev. 45, 729 (1934).
  34. J. D. Jackson, Classical Electrodynamics, 3rd ed., (Wiley, New York, 1999).
  35. L. D. Landau and E. M. Lifshitz, Quantum Mechanics (Pergamon, New York, 1965).
  36. M. V. Ammosov, N. B. Delone, and V. P. Krainov, Tunnel ionization of complex atoms and of atomic ions in an alternating electromagnetic field, Zh. Eksp. Teor. Fiz. 91, 2008 (1986) [Sov. Phys. JETP 64, 1191 (1987)].
  37. G. G. Manahan, A. Deng, O. Karger, Y. Xi, A. Knetsch, M. Litos, G. Wittig, T. Heinemann, J. Smith, Z. M. Sheng, D. A. Jaroszynski, G. Andonian, D. L. Bruhwiler, J. B. Rosenzweig, and B. Hidding, Hot spots and dark current in advanced plasma wakefield accelerators, Phys. Rev. Accel. Beams 19, 011303 (2016).
  38. See End Matter.
  39. A. B. Voitkiv, Basic atomic processes in high-energy ion–atom collisions, in Springer Handbook of Atomic, Molecular, and Optical Physics, 2nd ed., edited by Gordon W. F. Drake (Springer, New York, 2023), Chap. 57.

  40. We note that a typical size of a gas target in experiments on fast electron-atom and ion-atom collisions does not exceed several millimeters.

  41. In this estimate, a normalized emittance of εn=0.5  mm·mrad was assumed.

  42. T. Heinemann and B. Hidding (private communication).

  43. Our estimates show that the effect of the beam energy spread and fluctuation on the cross section can be neglected if ΔE/E=Δγ/γ≪1, where E=mec2γ and ΔE=mec2Δγ are the mean electron energy and its spread or fluctuation, respectively.

  44. L. D. Landau and E. M. Lifshitz, Electrodynamics of Continuous Media (Pergamon Press, New York, 1984), see Sec. 85.

  45. To illustrate items (i)–(iii), we note the following. Suppose that an electron beam, which moves along the z axis, enters a magnetic field B0, which is perpendicular to this axis and acts on a distance l0 along it. Then, at a distance D downstream from the magnetic field, the radiation, which was emitted by the beam in this field, will spread over the area S≃π(l0+D)2(e0B0l0/mec2γ)2. For instance, at γ=2000, B0≃1  T, l0≃1  m, and D≃1  m, we obtain S≃1 m2. This is about 104–105 times larger than the area s0≃10–100  mm2 of a typical gas target used in experiments on ionization by fast projectiles, meaning that essentially all emitted radiation misses the target. Moreover, the spectrum of the radiation spreads over a very broad energy range, maximizing at about 700 eV. Such energies are large on the scale of helium atoms, which means that the radiation would not be efficient in ionizing helium atoms even if a significant fraction of it would penetrate the target.

  46. Radiation occurs also when the electron beam is produced inside a plasma. However, the fields acting on the electrons are there so strong (effectively corresponding to magnetic fields of ∼103  T) that the spectrum of the emitted radiation is in the range of ∼100  keV–1  MeV. Such radiation cannot be absorbed by light atoms and can ionize them only via Compton scattering whose cross section is very small (≲10−24  cm2), making this process unimportant for target ionization.

  47. A. Gonoskov, T. G. Blackburn, M. Marklund, and S. S. Bulanov, Charged particle motion and radiation in strong electromagnetic fields, Rev. Mod. Phys. 94, 045001 (2022).
  48. M. Abramowitz and I. Stegun, Handbook of Mathematical Functions (Dover Publications, Inc., New York, 1965).
  49. F. Martin and A. Salin, Accurate evaluation of multiple-excitation cross sections from one-electron amplitudes, Phys. Rev. A 55, 2004 (1997).
  50. S. Remme, A. B. Voitkiv, G. Pretzler, and C. Müller, Phenomenological rate formulas for over-barrier ionization of hydrogen and helium atoms in strong constant electric fields, J. Phys. B 58, 195602 (2025); X. M. Tong and C. D. Lin, Empirical formula for static field ionization rates of atoms and molecules by lasers in the barrier-suppression regime, 38, 2593 (2005).
  51. A. Scrinzi, M. Geissler, and T. Brabec, Ionization above the Coulomb barrier, Phys. Rev. Lett. 83, 706 (1999).
