Direct Observation of the Optical Magnus Effect with a Trapped Ion

Philip Leindecker1,2,*,†, Louis P. H. Gallagher3,*, Edgar Brucke1,2, Dominique Zehnder1,2, Luka Milanovic1,2, Matteo Marinelli1,2,4, Rene Gerritsma3,5, Robert J. C. Spreeuw3,5, Jonathan Home2,6 et al.

Cornelius Hempel1,2,6

  • *These authors contributed equally to this work.
  • †Contact author: pleindecker@ethz.ch
PDF

Phys. Rev. Lett. 137, 063202 – Published 6 August, 2026

DOI: https://doi.org/10.1103/kj5p-qqs5

Abstract

We directly observe and spatially map an optical analog of the Magnus effect, where intrinsic spin-orbit-like coupling of light generates a spin-dependent transverse displacement of the atom-light interaction profile for a Ca+40 ion. Probed on a quadrupole transition using a tightly focused beam, we observe displacements of the maximum in the profile of the effective interaction by several 100 nm originating from intrinsic longitudinal electric field components beyond the paraxial approximation. The tight focus of the beam induces additional transverse polarization gradients, which we characterize through a phase-sensitive measurement and spatial maps for different beam configurations. The results establish the physical basis of polarization-gradient interactions relevant to optical tweezer-based quantum control.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (45)

  1. G. Magnus, Ueber die abweichung der geschosse, und: Ueber eine auffallende erscheinung bei rotirenden körpern, Ann. Phys. (Berlin) 164, 1 (1853).
  2. R. J. C. Spreeuw, Off-axis dipole forces in optical tweezers by an optical analog of the Magnus effect, Phys. Rev. Lett. 125, 233201 (2020).
  3. R. J. C. Spreeuw, Spiraling light: From donut modes to a Magnus effect analogy, Nanophotonics 11, 633 (2022).
  4. Y. Zhao, J. S. Edgar, Gavin D. M. Jeffries, D. McGloin, and D. T. Chiu, Spin-to-orbital angular momentum conversion in a strongly focused optical beam, Phys. Rev. Lett. 99, 073901 (2007).
  5. T. A. Nieminen, A. B. Stilgoe, N. R. Heckenberg, and H. Rubinsztein-Dunlop, Angular momentum of a strongly focused Gaussian beam, J. Opt. A 10, 115005 (2008).
  6. K. Y. Bliokh, F. J. Rodríguez-Fortuño, F. Nori, and A. V. Zayats, Spin–orbit interactions of light, Nat. Photonics 9, 796 (2015).
  7. M. Neugebauer, J. S. Eismann, T. Bauer, and P. Banzer, Magnetic and electric transverse spin density of spatially confined light, Phys. Rev. X 8, 021042 (2018).
  8. J. S. Eismann, P. Banzer, and M. Neugebauer, Spin-orbit coupling affecting the evolution of transverse spin, Phys. Rev. Res. 1, 033143 (2019).
  9. Louis P. H. Gallagher, M. Mazzanti, Zeger E. D. Ackerman, A. Safavi-Naini, R. Gerritsma, and Robert J. C. Spreeuw, Nonparaxial effects on laser-qubit operations, Phys. Rev. Res. 8, 013077 (2026).
  10. C. T. Schmiegelow, J. Schulz, H. Kaufmann, T. Ruster, U. G. Poschinger, and F. Schmidt-Kaler, Transfer of optical orbital angular momentum to a bound electron, Nat. Commun. 7, 12998 (2016).
  11. A. Afanasev, C. E. Carlson, C. T. Schmiegelow, J. Schulz, F. Schmidt-Kaler, and M. Solyanik, Experimental verification of position-dependent angular-momentum selection rules for absorption of twisted light by a bound electron, New J. Phys. 20, 023032 (2018).
  12. G. F. Quinteiro, F. Schmidt-Kaler, and C. T. Schmiegelow, Twisted-light–ion interaction: The role of longitudinal fields, Phys. Rev. Lett. 119, 253203 (2017).
  13. M. Verde, C. T. Schmiegelow, U. Poschinger, and F. Schmidt-Kaler, Trapped atoms in spatially-structured vector light fields, Sci. Rep. 13, 21283 (2023).
  14. K. N. Blodgett, S. S. Phatak, M. R. Chen, D. Peana, C. Pritts, and J. D. Hood, Narrow-line electric quadrupole cooling and background-free imaging of a single CS atom with spatially structured light, Phys. Rev. A 112, 043109 (2025).
  15. F. Stopp, M. Verde, M. Katz, M. Drechsler, C. T. Schmiegelow, and F. Schmidt-Kaler, Coherent transfer of transverse optical momentum to the motion of a single trapped ion, Phys. Rev. Lett. 129, 263603 (2022).
  16. G. Araneda, S. Walser, Y. Colombe, D. B. Higginbottom, J. Volz, R. Blatt, and A. Rauschenbeutel, Wavelength-scale errors in optical localization due to spin–orbit coupling of light, Nat. Phys. 15, 17 (2019).
  17. K.-P. Wang, J. Zhuang, X.-D. He, R.-J. Guo, C. Sheng, P. Xu, M. Liu, J. Wang, and M.-S. Zhan, High-fidelity manipulation of the quantized motion of a single atom via Stern–Gerlach splitting, Chin. Phys. Lett. 37, 044209 (2020).
  18. G. Unnikrishnan, P. Ilzhöfer, A. Scholz, C. Hölzl, A. Götzelmann, R. K. Gupta, J. Zhao, J. Krauter, S. Weber, N. Makki, H. P. Büchler, T. Pfau, and F. Meinert, Coherent control of the fine-structure qubit in a single alkaline-earth atom, Phys. Rev. Lett. 132, 150606 (2024).
  19. J. D. Thompson, T. G. Tiecke, A. S. Zibrov, V. Vuletić, and M. D. Lukin, Coherence and Raman sideband cooling of a single atom in an optical tweezer, Phys. Rev. Lett. 110, 133001 (2013).
  20. M. Mazzanti, R. Gerritsma, R. J. C. Spreeuw, and A. Safavi-Naini, Trapped ions quantum logic gate with optical tweezers and the Magnus effect, Phys. Rev. Res. 5, 033036 (2023).
  21. J.-M. Cui, Y. Chen, Y.-F. Zhou, Q. Long, E.-T. An, R. He, Y.-F. Huang, C.-F. Li, and G.-C. Guo, Transverse polarization gradient entangling gates for trapped-ion quantum computation, Phys. Rev. Lett. 135, 260604 (2025).
  22. X. Mai, L. Zhang, Q. Yu, J. Zhang, and Y. Lu, Scalable entangling gates on ion qubits via structured light addressing, arXiv:2506.19535.
  23. D. Barredo, S. De Léséleuc, V. Lienhard, T. Lahaye, and A. Browaeys, An atom-by-atom assembler of defect-free arbitrary two-dimensional atomic arrays, Science 354, 1021 (2016).
  24. M. Endres, H. Bernien, A. Keesling, H. Levine, E. R. Anschuetz, A. Krajenbrink, C. Senko, V. Vuletić, M. Greiner, and M. D. Lukin, Atom-by-atom assembly of defect-free one-dimensional cold atom arrays, Science 354, 1024 (2016).
  25. A. M. Kaufman and K.-K. Ni, Quantum science with optical tweezer arrays of ultracold atoms and molecules, Nat. Phys. 17, 1324 (2021).
  26. A. Urech, Ivo H. A. Knottnerus, Robert J. C. Spreeuw, and F. Schreck, Narrow-line imaging of single strontium atoms in shallow optical tweezers, Phys. Rev. Res. 4, 023245 (2022).
  27. D. Bluvstein, S. J. Evered, A. A. Geim, S. H. Li, H. Zhou, T. Manovitz, S. Ebadi, M. Cain, M. Kalinowski, D. Hangleiter et al., Logical quantum processor based on reconfigurable atom arrays, Nature (London) 626, 58 (2024).
  28. L. Pause, L. Sturm, M. Mittenbühler, S. Amann, T. Preuschoff, D. Schäffner, M. Schlosser, and G. Birkl, Supercharged two-dimensional tweezer array with more than 1000 atomic qubits, Optica 11, 222 (2024).
  29. T. Olsacher, L. Postler, P. Schindler, T. Monz, P. Zoller, and L. M. Sieberer, Scalable and parallel tweezer gates for quantum computing with long ion strings, PRX Quantum 1, 020316 (2020).
  30. M. Mazzanti, R. X. Schüssler, J. D. Arias Espinoza, Z. Wu, R. Gerritsma, and A. Safavi-Naini, Trapped ion quantum computing using optical tweezers and electric fields, Phys. Rev. Lett. 127, 260502 (2021).
  31. D. Schwerdt, L. Peleg, Y. Shapira, N. Priel, Y. Florshaim, A. Gross, A. Zalic, G. Afek, N. Akerman, A. Stern, A. B. Kish, and R. Ozeri, Scalable architecture for trapped-ion quantum computing using rf traps and dynamic optical potentials, Phys. Rev. X 14, 041017 (2024).
  32. D. Schwerdt, L. Peleg, G. Dekel, L. Rajagopal, O. Matoki, A. Gross, Y. Shapira, N. Akerman, and R. Ozeri, Optical tweezer-controlled entanglement gates with trapped-ion qubits, Phys. Rev. Lett. 136, 020604 (2026).
  33. I. Pogorelov, T. Feldker, C. D. Marciniak, L. Postler, G. Jacob, O. Krieglsteiner, V. Podlesnic, M. Meth, V. Negnevitsky, M. Stadler, B. Höfer, C. Wächter, K. Lakhmanskiy, R. Blatt, P. Schindler, and T. Monz, Compact ion-trap quantum computing demonstrator, PRX Quantum 2, 020343 (2021).
  34. L. Novotny and B. Hecht, Principles of Nano-Optics (Cambridge University Press, Cambridge, England, 2012).
  35. A. Aiello, P. Banzer, M. Neugebauer, and G. Leuchs, From transverse angular momentum to photonic wheels, Nat. Photonics 9, 789 (2015).
  36. E. Brucke, M. Wagener et al., Monolithic segmented 3D ion trap fabricated by selective laser etching of fused silica (to be published).
  37. A. H. Myerson, D. J. Szwer, S. C. Webster, D. T. C. Allcock, M. J. Curtis, G. Imreh, J. A. Sherman, D. N. Stacey, A. M. Steane, and D. M. Lucas, High-fidelity readout of trapped-ion qubits, Phys. Rev. Lett. 100, 200502 (2008).
  38. A. H. Burrell, High fidelity readout of trapped ion qubits, Ph.D. thesis, University of Oxford, 2010.
  39. C. Roos, Controlling the quantum state of trapped ions, Ph.D. thesis, Universität Innsbruck, 2000.
  40. P. Leindecker, L. P. H. Gallagher, and C. Hempel, Data for “Direct observation of the optical Magnus effect with a trapped ion”, Zenodo, 10.5281/zenodo.21281678 (2026).
  41. L. T. Vuong, A. J. L. Adam, J. M. Brok, P. C. M. Planken, and H. P. Urbach, Electromagnetic spin-orbit interactions via scattering of subwavelength apertures, Phys. Rev. Lett. 104, 083903 (2010).
  42. Y. Zhao, J. S. Edgar, Gavin D. M. Jeffries, D. McGloin, and D. T. Chiu, Spin-to-orbital angular momentum conversion in a strongly focused optical beam, Phys. Rev. Lett. 99, 073901 (2007).
  43. L. Marrucci, C. Manzo, and D. Paparo, Optical spin-to-orbital angular momentum conversion in inhomogeneous anisotropic media, Phys. Rev. Lett. 96, 163905 (2006).
  44. M. Weissbluth, Atoms and Molecules (Elsevier, New York, 2012).
  45. A. Kreuter, C. Becher, G. P. T. Lancaster, A. B. Mundt, C. Russo, H. Häffner, C. Roos, W. Hänsel, F. Schmidt-Kaler, R. Blatt, and M. S. Safronova, Experimental and theoretical study of the 3d2d–level lifetimes of Ca40+, Phys. Rev. A 71, 032504 (2005).
