Element-Selective Probing of Ultrafast Ferromagnetic-Antiferromagnetic Order Dynamics in Fe/CoO Bilayers

Chowdhury S. Awsaf1, Sangeeta Thakur1, Markus Weißenhofer1,2, Jendrik Gördes1, Marcel Walter1, Mohamad-Assaad Mawass3,*, Niko Pontius3, Christian Schüßler-Langeheine3, Peter M. Oppeneer2 et al.

Wolfgang Kuch1,†

  • *Present address: Department of Mathematics and Physics, American University of Ras Al Khaimah, Ras Al Khaimah, United Arab Emirates.
  • †Contact author: kuch@physik.fu-berlin.de
PDF

Phys. Rev. Lett. 136, 126705 – Published 27 March, 2026

DOI: https://doi.org/10.1103/gcwk-tsj5

Abstract

The ultrafast magnetization dynamics of an epitaxial Fe/CoO bilayer on Ag(001) is examined in an element-resolved way by resonant soft-x-ray reflectivity. The transient magnetic linear dichroism at the Co L2 edge and the magnetic circular dichroism at the Fe L3 edge measured in reflection in a pump–probe experiment with 120 fs temporal resolution show the loss of antiferromagnetic and ferromagnetic order in CoO and Fe, respectively, both within 300 fs after excitation with 60 fs light pulses of 800 and 400 nm wavelengths. A comparison to spin-dynamics simulations using an atomistic spin model shows that direct energy transfer from the laser-excited electrons in Fe to the magnetic moments in CoO provides the dominant demagnetization channel in the case of 800-nm excitation.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (69)

  1. E. Beaurepaire, J.-C. Merle, A. Daunois, and J.-Y. Bigot, Ultrafast spin dynamics in ferromagnetic nickel, Phys. Rev. Lett. 76, 4250 (1996).
  2. B. Koopmans, G. Malinowski, F. Dalla Longa, D. Steiauf, M. Fähnle, T. Roth, M. Cinchetti, and M. Aeschlimann, Explaining the paradoxical diversity of ultrafast laser-induced demagnetization, Nat. Mater. 9, 259 (2010).
  3. M. Battiato, K. Carva, and P. M. Oppeneer, Superdiffusive spin transport as a mechanism of ultrafast demagnetization, Phys. Rev. Lett. 105, 027203 (2010).
  4. E. Carpene, E. Mancini, C. Dallera, M. Brenna, E. Puppin, and S. De Silvestri, Dynamics of electron-magnon interaction and ultrafast demagnetization in thin iron films, Phys. Rev. B 78, 174422 (2008).
  5. M. Krauß, T. Roth, S. Alebrand, D. Steil, M. Cinchetti, M. Aeschlimann, and H. C. Schneider, Ultrafast demagnetization of ferromagnetic transition metals: The role of the Coulomb interaction, Phys. Rev. B 80, 180407(R) (2009).
  6. J. K. Dewhurst, P. Elliott, S. Shallcross, E. K. U. Gross, and S. Sharma, Laser-induced intersite spin transfer, Nano Lett. 18, 1842 (2018).
  7. K. Holldack, N. Pontius, E. Schierle, T. Kachel, V. Soltwisch, R. Mitzner, T. Quast, G. Springholz, and E. Weschke, Ultrafast dynamics of antiferromagnetic order studied by femtosecond resonant soft x-ray diffraction, Appl. Phys. Lett. 97, 062502 (2010).
  8. A. Kirilyuk, A. V. Kimel, and T. Rasing, Ultrafast optical manipulation of magnetic order, Rev. Mod. Phys. 82, 2731 (2010).
  9. A. Kirilyuk, A. V. Kimel, and T. Rasing, Laser-induced magnetization dynamics and reversal in ferrimagnetic alloys, Rep. Prog. Phys. 76, 026501 (2013).
  10. J. Walowski and M. Münzenberg, Perspective: Ultrafast magnetism and THz spintronics, J. Appl. Phys. 120, 140901 (2016).
  11. M. Buzzi, M. Först, R. Mankowsky, and A. Cavalleri, Probing dynamics in quantum materials with femtosecond x-rays, Nat. Rev. Mater. 3, 299 (2018).
  12. K. Carva, P. Baláž, and I. Radu, Laser-Induced Ultrafast Magnetic Phenomena, in Handbook of Magnetic Materials (Elsevier, New York, 2017), Vol. 26, pp. 291–463.
  13. C. Wang and Y. Liu, Ultrafast optical manipulation of magnetic order in ferromagnetic materials, Nano Converg. 7, 1 (2020).
  14. P. Scheid, Q. Remy, S. Lebègue, G. Malinowski, and S. Mangin, Light induced ultrafast magnetization dynamics in metallic compounds, J. Magn. Magn. Mater. 560, 169596 (2022).
  15. X. Marti et al., Room-temperature antiferromagnetic memory resistor, Nat. Mater. 13, 367 (2014).
  16. P. Wadley et al., Electrical switching of an antiferromagnet, Science 351, 587 (2016).
  17. D. Kriegner, K. Výborný, K. Olejník, H. Reichlová, V. Novák, X. Marti, J. Gazquez, V. Saidl, P. Němec, V. V. Volobuev, G. Springholz, V. Holý, and T. Jungwirth, Multiple-stable anisotropic magnetoresistance memory in antiferromagnetic MnTe, Nat. Commun. 7, 11623 (2016).
  18. K. Olejník, V. Schuler, X. Martí, V. Novák, Z. Kašpar, P. Wadley, R. P. Campion, K. W. Edmonds, B. L. Gallagher, J. Garcés, M. Baumgartner, P. Gambardella, and T. Jungwirth, Antiferromagnetic CuMnAs multi-level memory cell with microelectronic compatibility, Nat. Commun. 8, 15434 (2017).
  19. T. Jungwirth, X. Marti, P. Wadley, and J. Wunderlich, Antiferromagnetic spintronics, Nat. Nanotechnol. 11, 231 (2016).
  20. V. Baltz, A. Manchon, M. Tsoi, T. Moriyama, T. Ono, and Y. Tserkovnyak, Antiferromagnetic spintronics, Rev. Mod. Phys. 90, 015005 (2018).
  21. P. Němec, M. Fiebig, T. Kampfrath, and A. V. Kimel, Antiferromagnetic opto-spintronics, Nat. Phys. 14, 229 (2018).
  22. D. Xiong, Y. Jiang, K. Shi, A. Du, Y. Yao, Z. Guo, D. Zhu, K. Cao, S. Peng, W. Cai, D. Zhu, and W. Zhao, Antiferromagnetic spintronics: An overview and outlook, Fundam. Res. 2, 522 (2022).
  23. L. Rettig, C. Dornes, N. Thielemann-Kühn, N. Pontius, H. Zabel, D. L. Schlagel, T. A. Lograsso, M. Chollet, A. Robert, M. Sikorski, S. Song, J. M. Glownia, C. Schüßler-Langeheine, S. L. Johnson, and U. Staub, Itinerant and localized magnetization dynamics in antiferromagnetic Ho, Phys. Rev. Lett. 116, 257202 (2016).
  24. N. Thielemann-Kühn, D. Schick, N. Pontius, C. Trabant, R. Mitzner, K. Holldack, H. Zabel, A. Föhlisch, and C. Schüßler-Langeheine, Ultrafast and energy-efficient quenching of spin order: Antiferromagnetism beats ferromagnetism, Phys. Rev. Lett. 119, 197202 (2017).
  25. I. Kumberg, E. Golias, N. Pontius, R. Hosseinifar, K. Frischmuth, I. Gelen, T. Shinwari, S. Thakur, C. Schüßler-Langeheine, P. M. Oppeneer, and W. Kuch, Accelerating the laser-induced demagnetization of a ferromagnetic film by antiferromagnetic order in an adjacent layer, Phys. Rev. B 102, 214418 (2020).
  26. E. Golias, I. Kumberg, I. Gelen, S. Thakur, J. Gördes, R. Hosseinifar, Q. Guillet, J. K. Dewhurst, S. Sharma, C. Schüßler-Langeheine, N. Pontius, and W. Kuch, Ultrafast optically induced ferromagnetic state in an elemental antiferromagnet, Phys. Rev. Lett. 126, 107202 (2021).
  27. A. Eschenlohr, Spin dynamics at interfaces on femtosecond timescales, J. Phys. Condens. Matter 33, 013001 (2020).
  28. F. Hellman et al., Interface-induced phenomena in magnetism, Rev. Mod. Phys. 89, 025006 (2017).
  29. V. Saidl et al., Optical determination of the Néel vector in a CuMnAs thin-film antiferromagnet, Nat. Photonics 11, 91 (2017).
  30. Z. Zheng, J. Y. Shi, Q. Li, T. Gu, H. Xia, L. Q. Shen, F. Jin, H. C. Yuan, Y. Z. Wu, L. Y. Chen, and H. B. Zhao, Magneto-optical probe of ultrafast spin dynamics in antiferromagnetic CoO thin films, Phys. Rev. B 98, 134409 (2018).
  31. P. M. Oppeneer, H.-C. Mertins, D. Abramsohn, A. Gaupp, W. Gudat, J. Kuneš, and C. M. Schneider, Buried antiferromagnetic films investigated by X-ray magneto-optical reflection spectroscopy, Phys. Rev. B 67, 052401 (2003).
  32. See Supplemental Material at http://link.aps.org/supplemental/10.1103/gcwk-tsj5 for details of sample preparation, beamline parameters, simulations and the parameters, which includes Refs. [31,33–60].
  33. R. Abrudan, J. Miguel, M. Bernien, C. Tieg, M. Piantek, J. Kirschner, and W. Kuch, Structural and magnetic properties of epitaxial Fe/CoO bilayers on Ag(001), Phys. Rev. B 77, 014411 (2008).
  34. S. Wust, C. Seibel, H. Meer, P. Herrgen, C. Schmitt, L. Baldrati, R. Ramos, T. Kikkawa, E. Saitoh, O. Gomonay, J. Sinova, Y. Mokrousov, H. C. Schneider, M. Kläui, B. Rethfeld, B. Stadtmüller, and M. Aeschlimann, Indirect optical manipulation of the antiferromagnetic order of insulating NiO by ultrafast interfacial energy transfer, arXiv:2205.02686.
  35. U. Nowak, Classical spin models, in Handbook of Magnetism and Advanced Magnetic Materials, edited by H. Kronmüller and S. Parkin (John Wiley & Sons, Ltd, New York, 2007).
  36. D. A. Garanin, Self-consistent Gaussian approximation for classical spin systems: Thermodynamics, Phys. Rev. B 53, 11593 (1996).
  37. L. D. Landau and E. M. Lifshitz, On the theory of the dispersion of magnetic permeability in ferromagnetic bodies, Phys. Z. Sowjet. 8, 153 (1935).
  38. W. F. Brown, Thermal fluctuations of a single-domain particle, Phys. Rev. 130, 1677 (1963).
  39. T. L. Gilbert, A phenomenological theory of damping in ferromagnetic materials, IEEE Trans. Magn. 40, 3443 (2004).
  40. D. Zahn, F. Jakobs, Y. W. Windsor, H. Seiler, T. Vasileiadis, T. A. Butcher, Y. Qi, D. Engel, U. Atxitia, J. Vorberger, and R. Ernstorfer, Lattice dynamics and ultrafast energy flow between electrons, spins, and phonons in a 3d ferromagnet, Phys. Rev. Res. 3, 023032 (2021).
  41. D. Zahn, F. Jakobs, H. Seiler, T. A. Butcher, D. Engel, J. Vorberger, U. Atxitia, Y. W. Windsor, and R. Ernstorfer, Intrinsic energy flow in laser-excited 3d ferromagnets, Phys. Rev. Res. 4, 013104 (2022).
  42. H.-C. Mertins, P. M. Oppeneer, J. Kuneš, A. Gaupp, D. Abramsohn, and F. Schäfers, Observation of the X-ray magneto-optical Voigt effect, Phys. Rev. Lett. 87, 047401 (2001).
  43. S. Macke and E. Goering, Magnetic reflectometry of heterostructures, J. Phys. Condens. Matter 26, 363201 (2014).
  44. https://www.remagx.org/.
  45. B. Henke, E. Gullikson, and J. Davis, X-ray interactions: Photoabsorption, scattering, transmission, and reflection at E=50–30000  eV, Z=1–92, At. Data Nucl. Data Tables 54, 181 (1993).
  46. S. Brück, Magnetic resonant reflectometry on exchange bias systems, Ph.D. thesis, Universität Stuttgart, 2009, p. 92 ff, 10.18419/opus-6723.
  47. I. Kumberg, E. Golias, S. E. Hadjadj, R. Hosseinifar, S. Thakur, T. Shinwari, I. Gelen, N. Pontius, C. Schüßler-Langeheine, C. von Korff Schmising, S. Sharma, and W. Kuch, Ultrafast laser-induced magneto-optical changes in resonant magnetic x-ray reflectivity, Phys. Rev. B 108, 054439 (2023).
  48. J. Kuneš and P. M. Oppeneer, Anisotropic x-ray magnetic linear dichroism at the L2,3 edges of cubic Fe, Co, and Ni: Ab initio calculations and model theory, Phys. Rev. B 67, 024431 (2003).
  49. K. Ohta and H. Ishida, Matrix formalism for calculation of the light beam intensity in stratified multilayered films, and its use in the analysis of emission spectra, Appl. Opt. 29, 2466 (1990).
  50. P. B. Johnson and R. W. Christy, Optical constants of transition metals: Ti, V, Cr, Mn, Fe, Co, Ni, and Pd, Phys. Rev. B 9, 5056 (1974).
  51. P. B. Johnson and R. W. Christy, Optical constants of the noble metals, Phys. Rev. B 6, 4370 (1972).
  52. R. J. Powell and W. E. Spicer, Optical properties of NiO and CoO, Phys. Rev. B 2, 2182 (1970).
  53. T. Chirac, J.-Y. Chauleau, P. Thibaudeau, O. Gomonay, and M. Viret, Ultrafast antiferromagnetic switching in NiO induced by spin transfer torques, Phys. Rev. B 102, 134415 (2020).
  54. U. Ritzmann, P. Baláž, P. Maldonado, K. Carva, and P. M. Oppeneer, High-frequency magnon excitation due to femtosecond spin-transfer torques, Phys. Rev. B 101, 174427 (2020).
  55. M. Weißenhofer, F. Foggetti, U. Nowak, and P. M. Oppeneer, Néel vector switching and terahertz spin-wave excitation in Mn2Au due to femtosecond spin-transfer torques, Phys. Rev. B 107, 174424 (2023).
  56. Y. Tserkovnyak, A. Brataas, and Gerrit E. W. Bauer, Spin pumping and magnetization dynamics in metallic multilayers, Phys. Rev. B 66, 224403 (2002).
  57. U. Ritzmann, P. M. Oppeneer, and P. Maldonado, Theory of out-of-equilibrium electron and phonon dynamics in metals after femtosecond laser excitation, Phys. Rev. B 102, 214305 (2020).
  58. NIST Chemistry Webbook, SRD 69, https://webbook.nist.gov/cgi/cbook.cgi?ID=C1307966&Type=JANAFS&Table=on (2022) [Accessed: November 24, 2023].
  59. J. Kübler, Magnetic moments of ferromagnetic and antiferromagnetic bcc and fcc iron, Phys. Lett. 81A, 81 (1981).
  60. D. Herrmann-Ronzaud, P. Burlet, and J. Rossat-Mignod, Equivalent type-II magnetic structures: CoO, a collinear antiferromagnet, J. Phys. C 11, 2123 (1978).
  61. H.-C. Mertins, D. Abramsohn, A. Gaupp, F. Schäfers, W. Gudat, O. Zaharko, H. Grimmer, and P. M. Oppeneer, Resonant magnetic reflection coefficients at the Fe 2p edge obtained with linearly and circularly polarized soft x rays, Phys. Rev. B 66, 184404 (2002).
  62. X. Ma, F. Fang, Q. Li, J. Zhu, Y. Yang, Y. Z. Wu, H. B. Zhao, and G. Lüpke, Ultrafast spin exchange-coupling torque via photo-excited charge-transfer processes, Nat. Commun. 6, 8800 (2015).

  63. Direct excitation of the CoO layer at 800 nm pump across the band gap by two-photon absorption can be ruled out from the fluence dependence of the CoO sublattice demagnetization; see Ref. [32].

  64. J. Miguel, R. Abrudan, M. Bernien, M. Piantek, C. Tieg, J. Kirschner, and W. Kuch, Magnetic domain coupling study in single-crystalline Fe/CoO bilayers, J. Phys. Condens. Matter 21, 185004 (2009).
  65. K. Carva, D. Legut, and P. M. Oppeneer, Influence of laser-excited electron distributions on the x-ray magnetic circular dichroism spectra: Implications for femtosecond demagnetization in Ni, Europhys. Lett. 86, 57002 (2009).
  66. K. Yao, F. Willems, C. von Korff Schmising, I. Radu, C. Strüber, D. Schick, D. Engel, A. Tsukamoto, J. K. Dewhurst, S. Sharma, and S. Eisebitt, Distinct spectral response in M-edge magnetic circular dichroism, Phys. Rev. B 102, 100405(R) (2020).
  67. N. Kazantseva, U. Nowak, R. W. Chantrell, J. Hohlfeld, and A. Rebei, Slow recovery of the magnetisation after a sub-picosecond heat pulse, Europhys. Lett. 81, 27004 (2007).
  68. W. Chen, M. Sigrist, J. Sinova, and D. Manske, Minimal model of spin-transfer torque and spin pumping caused by the spin Hall effect, Phys. Rev. Lett. 115, 217203 (2015).
  69. C. S. Awsaf, S. Thakur, M. Weißenhofer, J. Gördes, M. Walter, M.-A. Mawass, N. Pontius, C. Schüßler-Langeheine, P. M. Oppeneer, and W. Kuch, 10.5281/zenodo.15497443 (2026).

Outline

Information

Phys. Rev. Lett. 136, 126705– Published 27 March, 2026
  • Received 26 August 2024
  • Revised 24 November 2025
  • Accepted 25 February 2026
