Terahertz Field Control of Electronic-Ferroelectric Anisotropy at Room Temperature in LuFe2O4

Hirotake Itoh1,*,†, Ryusei Minakami1, Hongwu Yu2, Ryohei Tsuruoka1, Tatsuya Amano1, Yohei Kawakami1, Shin-ya Koshihara2, Kosuke Fujiwara3,‡, Naoshi Ikeda3 et al.

Yoichi Okimoto2,§ and Shinichiro Iwai1,║

  • *Contact author: hri@kwansei.ac.jp
  • †Present address: Department of Physics and Astronomy, Kwansei Gakuin University, Sanda 669-1330, Japan.
  • ‡Present address: National Institutes for Quantum and Radiological Science and Technology, Sayo 679-5148, Japan.
  • §Contact author: okimoto.y.aa@m.titech.ac.jp
  • ║Contact author: s-iwai@tohoku.ac.jp
PDF

Phys. Rev. Lett. 135, 106504 – Published 4 September, 2025

DOI: https://doi.org/10.1103/fryl-jjnj

Abstract

Electronic ferroelectrics, with polarization P induced by strongly correlated charges, are expected to show ultrafast, huge, and flexible responses required in future optoelectronics. Although the challenges for ultrafast manipulation of such a polarization are ongoing, the expected advantages have been unclear. In this Letter, we demonstrate an unprecedentedly large increase by a factor of 2.7 in optical second harmonic generation at room temperature in the prototypical electronic ferroelectrics, the rare-earth ferrite LuFe2O4, by applying a terahertz field of 260  kV/cm. The transient anisotropy indicates that the direction of macroscopic polarization can be controlled three dimensionally on subpicosecond timescales, offering additional degrees of freedom in controlling polarization. Although the polarization response is in phase concerning the terahertz field, its sensitivity increased with delay, indicating that cooperative interactions among microscopic domains play an important role in the unprecedented response.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (60)

  1. P. Monceau, F. Y. Nad, and S. Brazovskii, Phys. Rev. Lett. 86, 4080 (2001).
  2. N. Ikeda, H. Ohsumi, K. Ohwada, K. Ishii, T. Inami, K. Kakurai, Y. Murakami, K. Yoshii, S. Mori, Y. Horibe, and H. Kitô, Nature (London) 436, 1136 (2005).
  3. K. Yamamoto, S. Iwai, S. Boyko, A. Kashiwazaki, F. Hiramatsu, C. Okabe, N. Nishi, and K. Yakushi, J. Phys. Soc. Jpn. 77, 074709 (2008).
  4. J. Valasek, Phys. Rev. 17, 475 (1921).
  5. T. Portengen, T. Östreich, and L. J. Sham, Phys. Rev. B 54, 17452 (1996).
  6. J. van den Brink and D. I. Khomskii, J. Phys. Condens. Matter 20, 434217 (2008).
  7. S. Ishihara, J. Phys. Soc. Jpn. 79, 011010 (2010).
  8. D. N. Basov, R. D. Averitt, and D. Hsieh, Nat. Mater. 16, 1077 (2017).
  9. A. De la Torre, D. M. Kennes, M. Claassen, S. Gerber, J. W. McIver, and M. A. Sentef, Rev. Mod. Phys. 93, 041002 (2021).
  10. S. Koshihara, T. Ishikawa, Y. Okimoto, K. Onda, R. Fukaya, M. Hada, Y. Hayashi, S. Ishihara, and T. Luty, Phys. Rep. 942, 1 (2022).
  11. G. Catalan, A. Lubk, A. H. G. Vlooswijk, E. Snoeck, C. Magen, A. Janssens, G. Rispens, G. Rijnders, D. H. A. Blank, and B. Noheda, Nat. Mater. 10, 963 (2011).
  12. E. Collet, M.-H. Lemée-Cailleau, M. B.-L. Cointe, H. Cailleau, M. Wulff, T. Luty, S.-Y. Koshihara, M. Meyer, L. Toupet, P. Rabiller, and S. Techert, Science 300, 612 (2003).
  13. T. Miyamoto, H. Yada, H. Yamakawa, and H. Okamoto, Nat. Commun. 4, 2586 (2013).
  14. H. Itoh, K. Itoh, K. Goto, K. Yamamoto, K. Yakushi, and S. Iwai, Appl. Phys. Lett. 104, 173302 (2014).
  15. H. Yamakawa, T. Miyamoto, T. Morimoto, H. Yada, Y. Kinoshita, M. Sotome, N. Kida, K. Yamamoto, K. Iwano, Y. Matsumoto, S. Watanabe, Y. Shimoi, M. Suda, H. M. Yamamoto, H. Mori, and H. Okamoto, Sci. Rep. 6, 20571 (2016).
  16. T. Morimoto, T. Miyamoto, H. Yamakawa, T. Terashige, T. Ono, N. Kida, and H. Okamoto, Phys. Rev. Lett. 118, 107602 (2017).
  17. H. Itoh, R. Fujiwara, Y. Kawakami, K. Yamamoto, Y. Nakamura, H. Kishida, and S. Iwai, Appl. Phys. Lett. 112, 093302 (2018).
  18. H. Itoh, H. Obatake, R. Fujiwara, Y. Kawakami, K. Yamamoto, M. Dressel, and S. Iwai, Phys. Rev. Res. 3, L032043 (2021).
  19. N. Ikeda, T. Nagata, J. Kano, and S. Mori, J. Phys. Condens. Matter 27, 053201 (2015).
  20. K. Fujiwara, Y. Fukada, Y. Okuda, R. Seimiya, N. Ikeda, K. Yokoyama, H. Yu, S. Koshihara, and Y. Okimoto, Sci. Rep. 11, 4277 (2021).
  21. See Supplemental Material at http://link.aps.org/supplemental/10.1103/fryl-jjnj for (1) an overview of research on RFe2O4, (2) the experiment setup, (3) SHG anisotropy and conversion efficiency in the steady state, (4) terahertz-induced dynamics of SHG anisotropy, (5) terahertz-induced effects on the fundamental frequency pulse, (6) fitting analysis of the SHG anisotropy, (7) on the possibility of a multidomain state, (8) analysis based on third-order nonlinear susceptibility, and (9) transient sensitivity.
  22. M. Angst, R. P. Hermann, A. D. Christianson, M. D. Lumsden, C. Lee, M.-H. Whangbo, J.-W. Kim, P. J. Ryan, S. E. Nagler, W. Tian, R. Jin, B. C. Sales, and D. Mandrus, Phys. Rev. Lett. 101, 227601 (2008).
  23. M. Angst, Phys. Status Solidi RRL 7, 383 (2013).
  24. A. Ruff, S. Krohns, F. Schrettle, V. Tsurkan, P. Lunkenheimer, and A. Loidl, Eur. Phys. J. B 85, 290 (2012).
  25. D. Niermann, F. Waschkowski, J. de Groot, M. Angst, and J. Hemberger, Phys. Rev. Lett. 109, 016405 (2012).
  26. J. de Groot, T. Mueller, R. A. Rosenberg, D. J. Keavney, Z. Islam, J.-W. Kim, and M. Angst, Phys. Rev. Lett. 108, 187601 (2012).
  27. J. Bourgeois, M. Hervieu, M. Poienar, A. M. Abakumov, E. Elkaïm, M. T. Sougrati, F. Porcher, F. Damay, J. Rouquette, G. Van Tendeloo, A. Maignan, J. Haines, and C. Martin, Phys. Rev. B 85, 064102 (2012).
  28. A. J. Hearmon, D. Prabhakaran, H. Nowell, F. Fabrizi, M. J. Gutmann, and P. G. Radaelli, Phys. Rev. B 85, 014115 (2012).
  29. X. S. Xu, J. de Groot, Q.-C. Sun, B. C. Sales, D. Mandrus, M. Angst, A. P. Litvinchuk, and J. L. Musfeldt, Phys. Rev. B 82, 014304 (2010).
  30. A. Glamazda, K.-Y. Choi, P. Lemmens, D. Wulferding, S. Park, and S.-W. Cheong, Phys. Rev. B 87, 144416 (2013).
  31. K. Fujiwara, T. Karasudani, K. Kakurai, W. T. Lee, K. C. Rule, A. J. Studer, and N. Ikeda, J. Phys. Soc. Jpn. 88, 044701 (2019).
  32. H. Yu, Y. Okimoto, A. Morita, S. Shimanuki, K. Takubo, T. Ishikawa, S. Koshihara, R. Minakami, H. Itoh, S. Iwai, N. Ikeda, T. Sakagami, M. Nozaki, and T. Fujii, Materials 16, 1989 (2023).
  33. Y. Fukada and N. Ikeda, J. Phys. Soc. Jpn. 90, 113705 (2021).
  34. S. Konishi, D. Urushihara, T. Hayakawa, K. Fukuda, T. Asaka, K. Ishii, N. Naoda, M. Okada, H. Akamatsu, H. Hojo, M. Azuma, and K. Tanaka, Phys. Rev. B 108, 014105 (2023).
  35. H. Itoh, K. Itoh, K. Anjyo, H. Nakaya, H. Akahama, D. Ohishi, S. Saito, T. Kambe, S. Ishihara, N. Ikeda, and S. Iwai, J. Lumin. 133, 149 (2013).
  36. H. Yu, Y. Fukada, G. Nishida, K. Takubo, T. Ishikawa, S. Koshihara, N. Ikeda, and Y. Okimoto, Phys. Rev. Mater. 8, 064402 (2024).
  37. J. Lee, S. A. Trugman, C. D. Batista, C. L. Zhang, D. Talbayev, X. S. Xu, S.-W. Cheong, D. A. Yarotski, A. J. Taylor, and R. P. Prasankumar, Sci. Rep. 3, 2654 (2013).
  38. J. Lee, S. A. Trugman, C. L. Zhang, D. Talbayev, X. S. Xu, S.-W. Cheong, D. A. Yarotski, A. J. Taylor, and R. P. Prasankumar, Appl. Phys. Lett. 107, 042906 (2015).
  39. V. Bilyk, E. Mishina, N. Sherstyuk, A. Bush, A. Ovchinnikov, and M. Agranat, Phys. Status Solidi RRL 15, 2000460 (2021).
  40. T. Umanodan, K. Kaneshima, K. Takeuchi, N. Ishii, J. Itatani, H. Hirori, Y. Sanari, K. Tanaka, Y. Kanemitsu, T. Ishikawa, S. Koshihara, S. Horiuchi, and Y. Okimoto, J. Phys. Soc. Jpn. 88, 013705 (2019).
  41. Y. Okimoto, S. Naruse, R. Fukaya, T. Ishikawa, S. Koshihara, K. Oka, M. Azuma, K. Tanaka, and H. Hirori, Phys. Rev. Appl. 7, 064016 (2017).
  42. A. von Hoegen, R. Mankowsky, M. Fechner, M. Först, and A. Cavalleri, Nature (London) 555, 79 (2018).
  43. T. Miyamoto, D. Hata, T. Morimoto, H. Yamakawa, N. Kida, T. Terashige, K. Iwano, H. Kishida, S. Horiuchi, and H. Okamoto, Sci. Rep. 8, 15014 (2018).
  44. N. Sono, Y. Kinoshita, N. Kida, T. Ito, H. Okamoto, and T. Miyamoto, J. Phys. Soc. Jpn. 90, 033703 (2021).
  45. I. Katayama, H. Aoki, J. Takeda, H. Shimosato, M. Ashida, R. Kinjo, I. Kawayama, M. Tonouchi, M. Nagai, and K. Tanaka, Phys. Rev. Lett. 108, 097401 (2012).
  46. F. Chen et al., Phys. Rev. B 94, 180104(R) (2016).
  47. X. Li, T. Qiu, J. Zhang, E. Baldini, J. Lu, A. M. Rappe, and K. A. Nelson, Science 364, 1079 (2019).
  48. K. Asada, T. Miyamoto, H. Yamakawa, J. Hirata, N. Takamura, T. Morimoto, K. Suzuki, T. Otaki, N. Kida, T. Nakamura, and H. Okamoto, Phys. Rev. B 104, 195148 (2021).
  49. Y. Okimoto, P. Xia, J. Itatani, H. Matsushima, T. Ishikawa, S. Koshihara, and S. Horiuchi, APL Mater. 10, 090702 (2022).
  50. J. F. Scott, Science 315, 954 (2007).
  51. T. Kampfrath, K. Tanaka, and K. A. Nelson, Nat. Photonics 7, 680 (2013).
  52. J. A. Fülöp, S. Tzortzakis, and T. Kampfrath, Adv. Opt. Mater. 8, 1900681 (2020).

  53. There are also studies of films. A BiFeO3 film showed an 8% increase at 0.4  MV/cm [54], while a ferroelectric-paraelectric-composite Sm−BiFeO3 device with field-enhancing slit-structured electrodes marked ∼220× increase [54]. A Ba0.8Sr0.2TiO3 film showed ∼140× increase at 1  MV/cm [55].

  54. F. Chen, J. Goodfellow, S. Liu, I. Grinberg, M. C. Hoffmann, A. R. Damodaran, Y. Zhu, P. Zalden, X. Zhang, I. Takeuchi, A. M. Rappe, L. W. Martin, H. Wen, and A. M. Lindenberg, Adv. Mater. 27, 6371 (2015).
  55. K. Grishunin, V. Bilyk, N. Sherstyuk, V. Mukhortov, A. Ovchinnikov, O. Chefonov, M. Agranat, E. Mishina, and A. V. Kimel, Sci. Rep. 9, 697 (2019).
  56. M. Cornet, J. Degert, E. Abraham, and E. Freysz, Opt. Lett. 39, 5921 (2014).
  57. K. A. Grishunin, N. A. Ilyin, N. E. Sherstyuk, E. D. Mishina, A. Kimel, V. M. Mukhortov, A. V. Ovchinnikov, O. V. Chefonov, and M. B. Agranat, Sci. Rep. 7, 687 (2017).
  58. Y. Ogawa, S. Koshihara, K. Koshino, T. Ogawa, C. Urano, and H. Takagi, Phys. Rev. Lett. 84, 3181 (2000).
  59. H. Watanabe, H. Hirori, G. Molnár, A. Bousseksou, and K. Tanaka, Phys. Rev. B 79, 180405(R) (2009).
  60. T. Amano et al., Nat. Phys. 20, 1778 (2024).
