Fast Turbulence Phase Transition in a Flux-Driven Global Edge-SOL Simulation of a Tokamak Plasma

Wladimir Zholobenko1,*, Frank Jenko1, Kaiyu Zhang1, Philipp Ulbl1, Konrad Eder1, Andreas Stegmeir1, Clemente Angioni1, and Peter Manz2

  • *Contact author: Wladimir.Zholobenko@ipp.mpg.de
PDF

Phys. Rev. Lett. 136, 075101 – Published 19 February, 2026

DOI: https://doi.org/10.1103/b2s6-b5c1

Abstract

A power ramp from L- to H-mode-like conditions is carried out in a 50 ms long global full-f turbulence simulation of ASDEX Upgrade with the grillix code. After 32 ms of slow profile evolution, a sudden change in transport triggers a pedestal buildup within ∼100  μs. This transition results from an abrupt shift from drift-wave (DW) to kinetic-ballooning-mode (KBM) turbulence. The self-consistently evolved E×B flow shear first increases slowly and then sharply. Geodesic acoustic mode and Alfvénic flow oscillations intensify prior to the transition and subsequently die out. This is followed by slow oscillations of the transport and profiles, reminiscent of a dithering I-phase or edge-localized-mode (ELM) cycles observed experimentally. This study paves the way for a better understanding of confinement regime transitions.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (73)

  1. F. Wagner et al., Phys. Rev. Lett. 49, 1408 (1982).
  2. F. Wagner, Plasma Phys. Controlled Fusion 49, B1 (2007).
  3. B. Scott, Plasma Phys. Controlled Fusion 40, 823 (1998).
  4. B. N. Rogers, J. F. Drake, and A. Zeiler, Phys. Rev. Lett. 81, 4396 (1998).
  5. J. W. Connor and H. R. Wilson, Plasma Phys. Controlled Fusion 42, R1 (1999).
  6. C. Bourdelle, Nucl. Fusion 60, 102002 (2020).
  7. T. Eich and P. Manz (ASDEX Upgrade Team), Nucl. Fusion 61, 086017 (2021).
  8. Y. R. Martin and T. Takizuka (ITPA CDBM H-mode Threshold Data Group), J. Phys. Conf. Ser. 123, 012033 (2008).
  9. F. Ryter, S. Rathgeber, L. B. Orte, M. Bernert, G. Conway, R. Fischer, T. Happel, B. Kurzan, R. McDermott, A. Scarabosio, W. Suttrop, E. Viezzer, M. Willensdorfer, and E. Wolfrum (ASDEX Upgrade Team), Nucl. Fusion 53, 113003 (2013).
  10. L. Chôné, P. Beyer, Y. Sarazin, G. Fuhr, C. Bourdelle, and S. Benkadda, Nucl. Fusion 55, 073010 (2015).
  11. J. J. Rasmussen, A. H. Nielsen, J. Madsen, V. Naulin, and G. S. Xu, Plasma Phys. Controlled Fusion 58, 014031 (2015).
  12. S. Ku, C. S. Chang, R. Hager, R. M. Churchill, G. R. Tynan, I. Cziegler, M. Greenwald, J. Hughes, S. E. Parker, M. F. Adams, and E. D’Azevedo, and P. Worley, Phys. Plasmas 25, 056107 (2018).
  13. M. Giacomin and P. Ricci, J. Plasma Phys. 86, 905860502 (2020).
  14. G. Dif-Pradalier, P. Ghendrih, Y. Sarazin, E. Caschera, F. Clairet, Y. Camenen, P. Donnel, X. Garbet, V. Grandgirard, Y. Munschy, L. Vermare, and F. Widmer, Commun. in Phys. 5, 229 (2022).
  15. N. Bonanomi, C. Angioni, G. D. Conway, T. Happel, U. Plank, P. A. Schneider, and G. M. Staebler, Phys. Plasmas 31, 072302 (2024).
  16. A. Stegmeir, A. Ross, T. Body, M. Francisquez, W. Zholobenko, D. Coster, O. Maj, P. Manz, F. Jenko, B. N. Rogers, and K. S. Kang, Phys. Plasmas 26, 052517 (2019).
  17. W. Zholobenko, K. Zhang, A. Stegmeir, J. Pfennig, K. Eder, C. Pitzal, P. Ulbl, M. Griener, L. Radovanovic, and U. Plank, Nucl. Fusion 64, 106066 (2024).
  18. W. Zholobenko, A. Stegmeir, M. Griener, G. D. Conway, T. Body, D. Coster, and F. Jenko, Nucl. Fusion 61, 116015 (2021).
  19. K. Zhang, W. Zholobenko, A. Stegmeir, K. Eder, and F. Jenko, Nucl. Fusion 64, 036016 (2024).
  20. K. Eder, A. Stegmeir, W. Zholobenko, J. Pfennig, D. Brida, G. Grenfell, and F. Jenko, Plasma Phys. Controlled Fusion 67, 065034 (2025).
  21. A. Stegmeir, D. Coster, O. Maj, K. Hallatschek, and K. Lackner, Comput. Phys. Commun. 198, 139 (2016).
  22. A. Stegmeir, T. Body, and W. Zholobenko, Comput. Phys. Commun. 290, 108801 (2023).
  23. W. Zholobenko, J. Pfennig, A. Stegmeir, T. Body, P. Ulbl, and F. Jenko, Nucl. Mater. Energy 34, 101351 (2023).
  24. W. Zholobenko, T. Body, P. Manz, A. Stegmeir, B. Zhu, M. Griener, G. D. Conway, D. Coster, and F. Jenko, Plasma Phys. Controlled Fusion 63, 034001 (2021).
  25. F. Ryter, L. B. Orte, B. Kurzan, R. McDermott, G. Tardini, E. Viezzer, M. Bernert, and R. Fischer (ASDEX Upgrade Team), Nucl. Fusion 54, 083003 (2014).
  26. K. Zhang, W. Zholobenko, A. Stegmeir, K. Eder, and F. Jenko, Comput. Phys. Commun. 314, 109670 (2025).
  27. B. Scott, Contrib. Plasma Phys. 46, 714 (2006).
  28. A. W. Leonard, Phys. Plasmas 21, 092501 (2014).
  29. A. Cathey, M. Hoelzl, K. Lackner, G. Huijsmans, M. Dunne, E. Wolfrum, S. Pamela, F. Orain, and S. Günter, Nucl. Fusion 60, 124007 (2020).
  30. G. D. Conway, C. Angioni, F. Ryter, P. Sauter, and J. Vicente, Phys. Rev. Lett. 106, 065001 (2011).
  31. M. Cavedon, T. Pütterich, E. Viezzer, G. Birkenmeier, T. Happel, F. M. Laggner, P. Manz, F. Ryter, and U. Stroth (ASDEX Upgrade Team), Nucl. Fusion 57, 014002 (2016).
  32. M. Griener, C. Wüthrich, Y. Wang, D. Brida, M. Faitsch, N. Offeddu, and C. Theiler, Nucl. Fusion 65, 016041 (2024).
  33. G. Birkenmeier, M. Cavedon, G. Conway, P. Manz, U. Stroth, R. Fischer, G. Fuchert, T. Happel, F. Laggner, M. Maraschek, A. Medvedeva, V. Nikolaeva, D. Prisiazhniuk, T. Pütterich, F. Ryter, L. Shao, M. Willensdorfer, E. Wolfrum, and H. Zohm, Nucl. Fusion 56, 086009 (2016).
  34. D. Hatch, M. Kotschenreuther, S. Mahajan, P. Valanju, F. Jenko, D. Told, T. Görler, and S. Saarelma, Nucl. Fusion 56, 104003 (2016).
  35. M. Kotschenreuther, X. Liu, D. Hatch, S. Mahajan, L. Zheng, A. Diallo, R. Groebner, J. Hillesheim, C. Maggi, C. Giroud, F. Koechl, V. Parail, S. Saarelma, E. Solano, and A. Chankin, Nucl. Fusion 59, 096001 (2019).
  36. L. A. Leppin, T. Görler, M. Cavedon, M. G. Dunne, E. Wolfrum, and F. Jenko, J. Plasma Phys. 89, 905890605 (2023).
  37. P. Helander and D. J. Sigmar, Collisional Transport in Magnetized Plasmas (Cambridge University Press, Cambridge, England, 2002).
  38. H. Sugama and W. Horton, Phys. Plasmas 5, 2560 (1998).
  39. B. Scott, Turbulence and Instabilities in Magnetised Plasmas, Volume 1: Fluid Drift Turbulence (IOP Publishing, Bristol, 2021).
  40. P. Ulbl, T. Body, W. Zholobenko, A. Stegmeir, J. Pfennig, and F. Jenko, Phys. Plasmas 30, 052507 (2023).
  41. B. Scott, Turbulence and Instabilities in Magnetised Plasmas (IOP Publishing, Bristol, 2021), Vol. 2.
  42. W. Tang, J. Connor, and R. Hastie, Nucl. Fusion 20, 1439 (1980).
  43. K. Aleynikova, A. Zocco, P. Xanthopoulos, P. Helander, and C. Nührenberg, J. Plasma Phys. 84, 745840602 (2018).
  44. A. Zocco, K. Aleynikova, and P. Xanthopoulos, J. Plasma Phys. 84, 745840303 (2018).
  45. H. Doerk, C. Challis, J. Citrin, J. Garcia, T. Görler, and F. Jenko, Plasma Phys. Controlled Fusion 58, 115005 (2016).
  46. D. Dickinson, C. M. Roach, S. Saarelma, R. Scannell, A. Kirk, and H. R. Wilson, Phys. Rev. Lett. 108, 135002 (2012).
  47. P. Snyder, R. Groebner, J. Hughes, T. Osborne, M. Beurskens, A. Leonard, H. Wilson, and X. Xu, Nucl. Fusion 51, 103016 (2011).
  48. G. Grenfell, L. Gil, P. Manz, C. Silva, J. Adamek, D. Brida, G. Conway, T. Eich, M. Faitsch, T. Happel, M. Spolaore, U. Stroth, B. Tal, B. Vanovac, and E. Wolfrum, Nucl. Fusion 64, 104002 (2024).
  49. N. Bonanomi, C. Angioni, P. Crandall, A. D. Siena, C. Maggi, and P. Schneider, Nucl. Fusion 59, 126025 (2019).
  50. A. Di Siena, W. Zholobenko, D. Silvagni, D. Brida, and F. Jenko, Nucl. Fusion 66, 014001 (2025).
  51. P. Manz, G. Birkenmeier, G. Fuchert, M. Cavedon, G. D. Conway, M. Maraschek, A. Medvedeva, F. Mink, B. D. Scott, L. M. Shao, and U. Stroth (ASDEX Upgrade Team), Phys. Plasmas 23, 052302 (2016).
  52. O. Grover, P. Manz, A. Yashin, D. Réfy, J. Seidl, N. Vianello, G. Birkenmeier, E. Solano, M. Sos, P. Bohm, P. Bilkova, M. Hron, and R. Panek (ASDEX Upgrade Team, COMPASS Team, Globus-M Team and JET Contributors), Nucl. Fusion 64, 026001 (2023).
  53. O. Grover, T. Eich, P. Manz, W. Zholobenko, T. Happel, T. Body, U. Plank, and P. Ulbl, Nucl. Fusion 64, 056020 (2024).
  54. H. Biglari, P. H. Diamond, and P. W. Terry, Phys. Fluids B 2, 1 (1990).
  55. R. J. Groebner, K. H. Burrell, and R. P. Seraydarian, Phys. Rev. Lett. 64, 3015 (1990).
  56. K. H. Burrell, Phys. Plasmas 4, 1499 (1997).
  57. G. Dif-Pradalier, V. Grandgirard, Y. Sarazin, X. Garbet, and P. Ghendrih, Phys. Rev. Lett. 103, 065002 (2009).
  58. B. J. Frei, P. Ulbl, C. Pitzal, W. Zholobenko, and F. Jenko, Nucl. Fusion 65, 116026 (2025).
  59. E. Viezzer, T. Pütterich, G. Conway, R. Dux, T. Happel, J. Fuchs, R. McDermott, F. Ryter, B. Sieglin, W. Suttrop, M. Willensdorfer, and E. Wolfrum, Nucl. Fusion 53, 053005 (2013).
  60. P. H. Diamond, S.-I. Itoh, K. Itoh, and T. S. Hahm, Plasma Phys. Controlled Fusion 47, R35 (2005).
  61. M. Held, M. Wiesenberger, R. Kube, and A. Kendl, Nucl. Fusion 58, 104001 (2018).
  62. P. Manz, G. S. Xu, B. N. Wan, H. Q. Wang, H. Y. Guo, I. Cziegler, N. Fedorczak, C. Holland, S. H. Müller, S. C. Thakur, M. Xu, K. Miki, P. H. Diamond, and G. R. Tynan, Phys. Plasmas 19, 072311 (2012).
  63. Y. Sarazin, G. Dif-Pradalier, X. Garbet, P. Ghendrih, A. Berger, C. Gillot, V. Grandgirard, K. Obrejan, R. Varennes, L. Vermare, and T. Cartier-Michaud, Plasma Phys. Controlled Fusion 63, 064007 (2021).
  64. B. D. Scott, New J. Phys. 7, 92 (2005).
  65. W. Zholobenko, A. Stegmeir, T. Body, A. Ross, P. Manz, O. Maj, D. Coster, F. Jenko, M. Francisquez, B. Zhu, and B. Rogers, Contrib. Plasma Phys. 60, e201900131 (2020).
  66. G. Conway, A. Smolyakov, and T. Ido, Nucl. Fusion 62, 013001 (2021).
  67. B. Frei, P. Ulbl, J. Trilaksono, and F. Jenko, Comput. Phys. Commun. 316, 109817 (2025).
  68. M. Bernert, F. Janky, B. Sieglin, A. Kallenbach, B. Lipschultz, F. Reimold, M. Wischmeier, M. Cavedon, P. David, M. Dunne, M. Griener, O. Kudlacek, R. McDermott, W. Treutterer, E. Wolfrum, D. Brida, O. Février, S. Henderson, and M. Komm, Nucl. Fusion 61, 024001 (2020).
  69. K. Eder, W. Zholobenko, A. Stegmeir, M. Bernert, D. Coster, and F. Jenko, Nucl. Fusion 65, 096029 (2025).
  70. G. F. Harrer, M. Faitsch, L. Radovanovic, E. Wolfrum, C. Albert, A. Cathey, M. Cavedon, M. Dunne, T. Eich, R. Fischer, M. Griener, M. Hoelzl, B. Labit, H. Meyer, and F. Aumayr (ASDEX Upgrade Team and EUROfusion MST1 Team), Phys. Rev. Lett. 129, 165001 (2022).
  71. M. Giacomin, P. Ricci, A. Coroado, G. Fourestey, D. Galassi, E. Lanti, D. Mancini, N. Richart, L. Stenger, and N. Varini, J. Comput. Phys. 463, 111294 (2022).
  72. R. Hager, S. Ku, A. Y. Sharma, C. S. Chang, R. M. Churchill, and A. Scheinberg, Phys. Plasmas 29, 112308 (2022).
  73. R. Düll, H. Bufferand, E. Serre, G. Ciraolo, V. Quadri, N. Rivals, F. Schwander, and P. Tamain, J. Comput. Phys. 536, 114052 (2025).
