Detecting the QCD Axion via the Ferroaxionic Force with Piezoelectric Materials

Asimina Arvanitaki1,*, Jonathan Engel2,†, Andrew A. Geraci3,‡, Alexander Hepburn2,§, Amalia Madden4,1,∥, and Ken Van Tilburg5,6,¶

  • *Contact author: aarvanitaki@perimeterinstitute.ca
  • †Contact author: engelj@physics.unc.edu
  • ‡Contact author: andrew.geraci@northwestern.edu
  • §Contact author: ahepburn@unc.edu
  • ∥Contact author: amadden@kitp.ucsb.edu
  • Contact author: kenvt@nyu.edu kvantilburg@flatironinstitute.org
PDF

Phys. Rev. Lett. 136, 081803 – Published 26 February, 2026

DOI: https://doi.org/10.1103/6xw1-1715

Abstract

We show that piezoelectric materials can be used to source virtual QCD axions, generating a new axion-mediated force. Spontaneous parity violation within the piezoelectric crystal combined with time-reversal violation from aligned spins provide the necessary symmetry breaking to produce an effective in-medium scalar coupling of the axion to nucleons up to seven orders of magnitude larger than that in vacuum. We propose a detection scheme based on nuclear spin precession caused by the axion’s pseudoscalar coupling to nuclear spins. This signal is resonantly enhanced when the distance between the source crystal and the spin sample is modulated at the spin precession frequency. Using this effect, future experimental setups can be sensitive to the QCD axion in the unexplored mass range from 10−5  eV to 10−2  eV.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (58)

  1. R. D. Peccei and H. R. Quinn, Phys. Rev. Lett. 38, 1440 (1977).
  2. S. Weinberg, Phys. Rev. Lett. 40, 223 (1978).
  3. F. Wilczek, Phys. Rev. Lett. 40, 279 (1978).
  4. M. Dine and W. Fischler, Phys. Lett. 120B, 137 (1983).
  5. J. Preskill, M. B. Wise, and F. Wilczek, Phys. Lett. 120B, 127 (1983).
  6. P. Svrcek and E. Witten, J. High Energy Phys. 06 (2006) 051.
  7. A. Arvanitaki, S. Dimopoulos, S. Dubovsky, N. Kaloper, and J. March-Russell, Phys. Rev. D 81, 123530 (2010).
  8. J. Moody and F. Wilczek, Phys. Rev. D 30, 130 (1984).
  9. A. Arvanitaki and A. A. Geraci, Phys. Rev. Lett. 113, 161801 (2014).
  10. A. Geraci, H. Fosbinder-Elkins, C. Lohmeyer, J. Dargert, M. Cunningham, M. Harkness, E. Levenson-Falk, S. Mumford, A. Kapitulnik, A. Arvanitaki et al., arXiv:1710.05413.
  11. A. Arvanitaki, A. Madden, and K. Van Tilburg, Phys. Rev. D 109, 072009 (2024).
  12. P. W. Graham and S. Rajendran, Phys. Rev. D 88, 035023 (2013).
  13. D. Budker, P. W. Graham, M. Ledbetter, S. Rajendran, and A. Sushkov, Phys. Rev. X 4, 021030 (2014).
  14. https://github.com/kenvantilburg/ferroaxionic-effect.
  15. G. G. Di Cortona, E. Hardy, J. P. Vega, and G. Villadoro, J. High Energy Phys. 1 (2016) 34.
  16. H. Georgi and L. Randall, Nucl. Phys. B276, 241 (1986).
  17. S. Okawa, M. Pospelov, and A. Ritz, Phys. Rev. D 105, 075003 (2022).
  18. C. Abel et al., Phys. Rev. Lett. 124, 081803 (2020).
  19. J. E. Kim, Phys. Rev. Lett. 43, 103 (1979).
  20. M. A. Shifman, A. I. Vainshtein, and V. I. Zakharov, Nucl. Phys. B166, 493 (1980).
  21. M. Dine, W. Fischler, and M. Srednicki, Phys. Lett. 104B, 199 (1981).
  22. A. R. Zhitnitsky, Sov. J. Nucl. Phys. 31, 260 (1980).
  23. I. B. Khriplovich and S. K. Lamoreaux, CP Violation Without Strangeness: Electric Dipole Moments of Particles, Atoms, and Molecules (1997).
  24. V. B. Berestetskii, E. M. Lifshitz, and L. P. Pitaevskii, Quantum Electrodynamics, Course of Theoretical Physics, Vol. 4 (Pergamon Press, Oxford, 1982).
  25. J. Nye, Physical Properties of Crystals: Their Representation by Tensors and Matrices, Oxford Science Publications (Clarendon Press, Oxford, 1985).
  26. L. V. Skripnikov and A. V. Titov, J. Chem. Phys. 145, 054115 (2016).
  27. See Supplemental Material at http://link.aps.org/supplemental/10.1103/6xw1-1715 for the numerical evaluation of the magnetic quadrupole moment matrix elements.
  28. J. Engel, J. L. Friar, and A. C. Hayes, Phys. Rev. C 61, 035502 (2000).
  29. V. V. Flambaum, I. B. Khriplovich, and O. P. Sushkov, Sov. Phys. JETP 60, 873 (1984), https://www.jetp.ras.ru/cgi-bin/dn/e_060_05_0873.pdf.
  30. S. Ban, J. Dobaczewski, J. Engel, and A. Shukla, Phys. Rev. C 82, 015501 (2010).
  31. O. P. Sushkov, Phys. Rev. C 110, 015501 (2024).
  32. J. de Vries, E. Epelbaum, L. Girlanda, A. Gnech, E. Mereghetti, and M. Viviani, Front. Phys. 8, 218 (2020).
  33. V. V. Flambaum and H. Feldmeier, Phys. Rev. C 101, 015502 (2020).
  34. H. Fosbinder-Elkins, Y. Kim, J. Dargert, M. Harkness, A. Geraci, E. Levenson-Falk, S. Mumford, A. Fang, A. Kapitulnik, A. Matlashov et al., Quantum Sci. Technol. 7, 014002 (2022).
  35. https://www.jpe innovations.com/, Janssen precision engineering (2024).
  36. L. M. Kovba and A. N. G. Golubenko, J. Struct. Chem. 1, 367 (1960).
  37. D. L. Janes, R. E. Bodnar, and A. L. Taylor, J. Appl. Phys. 49, 1452 (2008).
  38. Materials Project, mp-1199332 (2026), https://next-gen.materialsproject.org/materials/mp-1199332.
  39. A. Jain, S. P. Ong, G. Hautier, W. Chen, W. D. Richards, S. Dacek, S. Cholia, D. Gunter, D. Skinner, G. Ceder, and K. a. Persson, APL Mater. 1, 011002 (2013).
  40. F. D. Colegrove, L. D. Schearer, and G. K. Walters, Phys. Rev. 132, 2561 (1963).
  41. J. L. Flowers, B. W. Petley, and M. G. Richards, Metrologia 30, 75 (1993).
  42. E. Boyers, Prospects for spin squeezing in nuclear magnetic resonance dark matter searches (2022).
  43. M. Malnou, D. A. Palken, B. M. Brubaker, L. R. Vale, G. C. Hilton, and K. W. Lehnert, Phys. Rev. X 9, 021023 (2019).
  44. C. M. Caves, Phys. Rev. D 23, 1693 (1981).
  45. A. Caputo and G. Raffelt, Proc. Sci., COSMICWISPers (2024) 041 [arXiv:2401.13728].
  46. C. Lohmeyer et al. (ARIADNE Collaboration), Springer Proc. Phys. 245, 71 (2020).
  47. A. Madden and K. V. Tilburg, kenvantilburg/ferroaxionic-effect: Ferroaxionic Effect Repository v1.0 (2026), https://zenodo.org/records/18664384.
  48. G. Woodgate, Elementary Atomic Structure, Oxford Science Publications (Clarendon Press, Oxford, 1980).
  49. S. G. Zemlyanoi, D. V. Karaivanov, Y. P. Gangrsky, K. P. Marinova, B. N. Markov, and J. Badamsambuu, Hyperfine Interact. 196, 107 (2010).
  50. J. A. Stone and W. L. Pillinger, Phys. Rev. 165, 1319 (1968).
  51. K. Uhlig and W. Hehn, Cryogenics 37, 279 (1997).
  52. M. E. Hayden, E. Baudin, G. Tastevin, and P. J. Nacher, Phys. Rev. Lett. 99, 137602 (2007).
  53. M. P. Ledbetter and M. V. Romalis, Phys. Rev. Lett. 89, 287601 (2002).
  54. H. Fosbinder-Elkins et al., Quantum Sci. Technol. 7, 014002 (2022).
  55. D. L. Janes, R. E. Bodnar, and A. L. Taylor, J. Appl. Phys. 49, 1452 (1978).
  56. J. R. Claycomb and J. H. Miller, Rev. Sci. Instrum. 70, 4562 (1999).
  57. C. KAGRA, Prog. Theor. Exp. Phys. 2023, 10A101 (2022).
  58. T. Deshpande, A. Ionescu, N. Miller, Z. Wang, G. Gabrielse, A. A. Geraci, and T. Kovachy, Phys. Rev. Lett. 135, 261001 (2025).
