Resonant Excitation of Surface Plasmon for Wakefield Acceleration by Beating GW Lasers on Smooth Cylindrical Surface

Bifeng Lei1,2,*, Hao Zhang1,2, Alexandre Bonatto3, Bin Liu4, Javier Resta-López5,6, Matt Zepf7,8, Guoxing Xia9,2, and Carsten Welsch1,2

  • *Contact author: bifeng.lei@liverpool.ac.uk
PDF

Phys. Rev. Lett. 137, 105002 – Published 4 September, 2026

DOI: https://doi.org/10.1103/2dkn-db5z

Abstract

We present a theoretical and numerical study of resonant surface-plasmon (SP) excitation driven by the beating of two copropagating laser pulses on a smooth cylindrical plasma-vacuum interface. Analytical formulas for the SP dispersion relation, field amplitude, geometric coupling factor, and resonance conditions are derived and validated by fully three-dimensional particle-in-cell simulations. We show that the curvature-modified SP dispersion enables the optical beat wave to resonantly drive an axial SP wakefield that leaks into the vacuum channel. This enables a grating-free surface-plasmon phase-matching mechanism, which is not available on a smooth planar interface. Under matched resonance conditions, few-gigawatt (GW) lasers can drive tens of GV/m SP wakefields and initiate electron trapping, while tens to hundreds of GW drivers can reach sub-TV/m fields. It therefore opens a low-power, grating-free route toward portable laser-driven surface plasma wakefield accelerators.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (29)

  1. R. H. Ritchie, Plasma losses by fast electrons in thin films, Phys. Rev. 106, 874 (1957).
  2. R. W. Wood, XLII. On a remarkable case of uneven distribution of light in a diffraction grating spectrum, Philos. Mag. 4, 396 (1902).
  3. U. Fano, The theory of anomalous diffraction gratings and of quasi-stationary waves on metallic surfaces (Sommerfeld’s waves), J. Opt. Soc. Am. 31, 213 (1941).
  4. A. Otto, Excitation of nonradiative surface plasma waves in silver by the method of frustrated total reflection, Z. Phys. A 216, 398 (1968).
  5. X. F. Shen, A. Pukhov, and B. Qiao, Monoenergetic high-energy ion source via femtosecond laser interacting with a microtape, Phys. Rev. X 11, 041002 (2021).
  6. J. Sarma, A. McIlvenny, N. Das, M. Borghesi, and A. Macchi, Surface plasmon-driven electron and proton acceleration without grating coupling, New J. Phys. 24, 073023 (2022).
  7. A. McCay, A. McIlvenny, A. Macchi, L. Romagnani, P. Martin, O. Cavanagh, D. P. Molloy, L. Lancia, T. Dzelzainis, H. Ahmed, J. Sarma, S. Kar, D. Margarone, and M. Borghesi, Surface wave electron acceleration from flat foils at parallel laser incidence, Phys. Rev. Lett. 135, 145001 (2025).
  8. B. Lei, H. Zhang, D. Seipt, A. Bonatto, B. Qiao, J. Resta-López, G. Xia, and C. Welsch, Coherent synchrotron radiation by excitation of surface plasmon polariton on near-critical solid microtube surface, Phys. Rev. Lett. 135, 205001 (2025).
  9. B. Lei, H. Zhang, C. Bonţoiu, A. Bonatto, P. Martín-Luna, B. Liu, J. Resta López, G. Xia, and C. Welsch, Leaky surface plasmon-based wakefield acceleration in nanostructured carbon nanotubes, Plasma Phys. Controlled Fusion 67, 065036 (2025).
  10. G. I. Stegeman, R. F. Wallis, and A. A. Maradudin, Excitation of surface polaritons by end-fire coupling, Opt. Lett. 8, 386 (1983).
  11. L. Fedeli, A. Sgattoni, G. Cantono, D. Garzella, F. Réau, I. Prencipe, M. Passoni, M. Raynaud, M. Květoň, J. Proska, A. Macchi, and T. Ceccotti, Electron acceleration by relativistic surface plasmons in laser-grating interaction, Phys. Rev. Lett. 116, 015001 (2016).
  12. A. A. Sahai, Nanomaterials based nanoplasmonic accelerators and light-sources driven by particle-beams, IEEE Access 9, 54831 (2021).
  13. B. Lei, H. Zhang, C. Bonţoiu, A. Bonatto, J. Resta-López, G. Xia, B. Qiao, and C. Welsch, 100 s TeV/m-level particle accelerators driven by high-density electron beams in micro structured carbon nanotube forest channel, New J. Phys. 27, 084301 (2025).
  14. C. Bonţoiu, A. Bonatto, Ö. Apsimon, L. Bandiera, G. Cavoto, I. Drebot, G. Gatti, J. Giner-Navarro, B. Lei, P. Martín-Luna, I. Rago, J. Rodríguez Pérez, B. S. Nunes, A. Sytov, C. Valagiannopoulos, C. P. Welsch, G. Xia, J. Zhang, and J. Resta-López, Numerical study of self-injected electron acceleration in CNT structured targets driven by an 800 nm laser, Sci. Rep. 15, 45323 (2025).
  15. T. Tajima and M. Cavenago, Crystal x-ray accelerator, Phys. Rev. Lett. 59, 1440 (1987).
  16. X. Zhang, T. Tajima, D. Farinella, Y. Shin, G. Mourou, J. Wheeler, P. Taborek, P. Chen, F. Dollar, and B. Shen, Particle-in-cell simulation of x-ray wakefield acceleration and betatron radiation in nanotubes, Phys. Rev. Accel. Beams 19, 101004 (2016).
  17. M. Yu, H. H. Funke, J. L. Falconer, and R. D. Noble, High density, vertically-aligned carbon nanotube membranes, Nano Lett. 9, 225 (2009).
  18. G. Aliana-Cervera, D. Mattia, C. Pasquino, R. Veness, and A. J. G. Lunt, Carbon nanotube wires for accelerator applications, Mater. Des. 258, 114606 (2025).
  19. A. Lekosiotis, F. Belli, C. Brahms, M. Sabbah, H. Sakr, I. A. Davidson, F. Poletti, and J. C. Travers, On-target delivery of intense ultrafast laser pulses through hollow-core anti-resonant fibers, Opt. Express 31, 30227 (2023).
  20. E. Esarey, C. B. Schroeder, and W. P. Leemans, Physics of laser-driven plasma-based electron accelerators, Rev. Mod. Phys. 81, 1229 (2009).
  21. W. Horton and T. Tajima, Laser beat-wave accelerator and plasma noise, Phys. Rev. A 31, 3937 (1985).
  22. Y. Kitagawa, T. Matsumoto, T. Minamihata, K. Sawai, K. Matsuo, K. Mima, K. Nishihara, H. Azechi, K. A. Tanaka, H. Takabe, and S. Nakai, Beat-wave excitation of plasma wave and observation of accelerated electrons, Phys. Rev. Lett. 68, 48 (1992).
  23. A. Chamoli, D. N. Gupta, and V. Kumar, Surface plasma wave excitation using laser beat-wave and terahertz generation, Radiat. Eff. Defects Solids 179, 962 (2024).
  24. D. Roa, J. Kuo, H. Moyses, P. Taborek, T. Tajima, G. Mourou, and F. Tamanoi, Fiber-optic based laser wakefield accelerated electron beams and potential applications in radiotherapy cancer treatments, Photonics 9, 403 (2022).
  25. J. L. Vay, A. Almgren, J. Bell, L. Ge, D. P. Grote, M. Hogan, O. Kononenko, R. Lehe, A. Myers, C. Ng, J. Park, R. Ryne, O. Shapoval, M. Thévenet, and W. Zhang, warp-x: A new exascale computing platform for beam–plasma simulations, Nucl. Instrum. Methods Phys. Res., Sect. A 909, 476 (2018).
  26. See Supplemental Material at http://link.aps.org/supplemental/10.1103/2dkn-db5z for additional information on why longitudinal ponderomotive force dominates SP coupling, derivation of coupling coefficient, Ssp, practical estimation of geometric factor Gsp, curvature effect on dispersion relation, experimental alignment, and PIC simulation configurations, which includes Ref. [27].
  27. A. L. Falk, K.-C. Chiu, D. B. Farmer, Q. Cao, J. Tersoff, Y.-H. Lee, P. Avouris, and S.-J. Han, Coherent plasmon and phonon-plasmon resonances in carbon nanotubes, Phys. Rev. Lett. 118, 257401 (2017).
  28. T. M. Antonsen and P. Mora, Self-focusing and Raman scattering of laser pulses in tenuous plasmas, Phys. Rev. Lett. 69, 2204 (1992).
  29. Y. Gao, J. Bin, D. Haffa, C. Kreuzer, J. Hartmann, M. Speicher, F. H. Lindner, T. M. Ostermayr, P. Hilz, T. F. Rösch, S. Lehrack, F. Englbrecht, S. Seuferling, M. Gilljohann, H. Ding, W. Ma, K. Parodi, and J. Schreiber, An automated, 0.5 Hz nano-foil target positioning system for intense laser plasma experiments, High Power Laser Sci. Eng. 5, e12 (2017).
