Wavefront Mapping for Absolute Atom Interferometry

Joseph Junca1,2, John Kitching1, and William McGehee1,*

  • *Contact author: william.mcgehee@nist.gov
PDF

Phys. Rev. Lett. 136, 143402 – Published 10 April, 2026

DOI: https://doi.org/10.1103/2c2j-qhkd

Abstract

Wavefront distortions are a leading source of systematic uncertainty in light-pulse atom interferometry, limiting absolute measurements of gravitational acceleration at the 30  nm/s2 level. Here, we demonstrate in situ spatially resolved measurement of the interferometer phase in a Mach-Zehnder atom interferometer as a tool to characterize and correct wavefront bias. By introducing controllable curvature of the Raman light using an adjustable collimation retro-reflector, we show that the bias due to parabolic wavefront curvature can be measured with 1 mrad uncertainty and that finite-size corrections impact the measured phase curvature. This measurement process could be adopted in optimized atom interferometer gravimeters to reduce wavefront bias uncertainty below the nm/s2 level.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (43)

  1. A. D. Cronin, J. Schmiedmayer, and D. E. Pritchard, Atom interferometers, Rev. Mod. Phys. 81, 1051 (2009).
  2. S. Abend, M. Gersemann, C. Schubert, D. Schlippert, E. M. Rasel, M. Zimmermann, M. A. Efremov, A. Roura, F. A. Narducci, and W. P. Schleich, Atom interferometry and its applications, in Foundations of Quantum Theory (IOS Press, Varenna, Italy, 2019), pp. 345–392.
  3. A. Peters, K. Y. Chung, and S. Chu, Measurement of gravitational acceleration by dropping atoms, Nature (London) 400, 849 (1999).
  4. T. Zhang, L. L. Chen, Y. B. Shu, W. J. Xu, Y. Cheng, Q. Luo, Z. K. Hu, and M. K. Zhou, Ultrahigh-sensitivity Bragg atom gravimeter and its application in testing Lorentz violation, Phys. Rev. Appl. 20, 014067 (2023).
  5. D. Savoie, M. Altorio, B. Fang, L. A. Sidorenkov, R. Geiger, and A. Landragin, Interleaved atom interferometry for high-sensitivity inertial measurements, Sci. Adv. 4, eaau7948 (2018).
  6. G. Rosi, F. Sorrentino, L. Cacciapuoti, M. Prevedelli, and G. M. Tino, Precision measurement of the Newtonian gravitational constant using cold atoms, Nature (London) 510, 518 (2014).
  7. L. Morel, Z. Yao, P. Cladé, and S. Guellati-Khélifa, Determination of the fine-structure constant with an accuracy of 81 parts per trillion, Nature (London) 588, 61 (2020).
  8. S. Dimopoulos, P. W. Graham, J. M. Hogan, and M. A. Kasevich, Testing general relativity with atom interferometry, Phys. Rev. Lett. 98, 111102 (2007).
  9. D. O. Sabulsky, I. Dutta, E. A. Hinds, B. Elder, C. Burrage, and E. J. Copeland, Experiment to detect dark energy forces using atom interferometry, Phys. Rev. Lett. 123, 061102 (2019).
  10. P. Asenbaum, C. Overstreet, M. Kim, J. Curti, and M. A. Kasevich, Atom-interferometric test of the equivalence principle at the 10−12 level, Phys. Rev. Lett. 125, 191101 (2020).
  11. T. M. Niebauer, G. S. Sasagawa, J. E. Faller, R. Hilt, and F. Klopping, A new generation of absolute gravimeters, Metrologia 32, 159 (1995).
  12. O. Francis et al., The European Comparison of Absolute Gravimeters 2011 (ECAG-2011) in Walferdange, Luxembourg: Results and recommendations, Metrologia 50, 257 (2013).
  13. T. Farah, C. Guerlin, A. Landragin, Ph. Bouyer, S. Gaffet, F. Pereira Dos Santos, and S. Merlet, Underground operation at best sensitivity of the mobile LNE-SYRTE cold atom gravimeter, Gyroscopy Navig. 5, 266 (2014).
  14. R. Geiger, A. Landragin, S. Merlet, and F. Pereira Dos Santos, High-accuracy inertial measurements with cold-atom sensors, AVS Quantum Sci. 2, 024702 (2020).
  15. L. Antoni-Micollier, D. Carbone, V. Ménoret, J. Lautier-Gaud, T. King, F. Greco, A. Messina, D. Contrafatto, and B. Desruelle, Detecting volcano-related underground mass changes with a quantum gravimeter, Geophys. Res. Lett. 49, e2022GL097814 (2022).
  16. F. A. Narducci, A. T. Black, and J. H. Burke, Advances toward fieldable atom interferometers, Adv. Phys. X 7, 1946426 (2022).
  17. P. Gillot, B. Cheng, A. Imanaliev, S. Merlet, and F. Pereira Dos Santos, The LNE-SYRTE cold atom gravimeter, in 2016 European Frequency and Time Forum (EFTF) (York, UK, 2016) pp. 1–3.
  18. C. Freier, M. Hauth, V. Schkolnik, B. Leykauf, M. Schilling, H. Wziontek, H.-G. Scherneck, J. Müller, and A. Peters, Mobile quantum gravity sensor with unprecedented stability, J. Phys. Conf. Ser. 723, 012050 (2016).
  19. D. S. Durfee, Y. K. Shaham, and M. A. Kasevich, Long-term stability of an area-reversible atom-interferometer sagnac gyroscope, Phys. Rev. Lett. 97, 240801 (2006).
  20. A. Gauguet, T. E. Mehlstäubler, T. Lévèque, J. Le Gouët, W. Chaibi, B. Canuel, A. Clairon, F. P. Dos Santos, and A. Landragin, Off-resonant raman transition impact in an atom interferometer, Phys. Rev. A 78, 043615 (2008).
  21. A. Gauguet, B. Canuel, T. Lévèque, W. Chaibi, and A. Landragin, Characterization and limits of a cold-atom Sagnac interferometer, Phys. Rev. A 80, 063604 (2009).
  22. A. Louchet-Chauvet, T. Farah, Q. Bodart, A. Clairon, A. Landragin, S. Merlet, and F. P. D. Santos, The influence of transverse motion within an atomic gravimeter, New J. Phys. 13, 065025 (2011).
  23. V. Schkolnik, B. Leykauf, M. Hauth, C. Freier, and A. Peters, The effect of wavefront aberrations in atom interferometry, Appl. Phys. B 120, 311 (2015).
  24. M. K. Zhou, Q. Luo, L. L. Chen, X. C. Duan, and Z. K. Hu, Observing the effect of wave-front aberrations in an atom interferometer by modulating the diameter of Raman beams, Phys. Rev. A 93, 043610 (2016).
  25. R. Karcher, A. Imanaliev, S. Merlet, and F. P. D. Santos, Improving the accuracy of atom interferometers with ultracold sources, New J. Phys. 20, 113041 (2018).
  26. L. Pagot, S. Merlet, and F. P. D. Santos, Influence of optical aberrations on the accuracy of an atomic gravimeter, Opt. Express 33, 18843 (2025).
  27. Q. Luo, L. Li, H. Zhou, L. Chen, X. Duan, Z. Hu and M. Zhou, Evaluating the effect of wavefront aberrations in an atom gravimeter, Metrologia 62, 055006 (2025).
  28. W.-J. Xu, J. Liu, Q. Luo, Z.-K. Hu, and M.-K. Zhou, In Situ measurement of the wavefront phase shift in an atom interferometer, Phys. Rev. Appl. 22, 054014 (2024).
  29. S. Gaudout, R. Si-Ahmed, C. Debavelaere, M. Door, P. Cladé, and S. Guellati-Khelifa, Probing the spatial distribution of k-vectors in situ with Bose-Einstein condensates, arXiv:2507.19157.
  30. S. M. Dickerson, J. M. Hogan, A. Sugarbaker, David M. S. Johnson, and M. A. Kasevich, Multiaxis inertial sensing with long-time point source atom interferometry, Phys. Rev. Lett. 111, 083001 (2013).
  31. S. Seckmeyer, H. Ahlers, J.-N. Kirsten-Siemß, M. Gersemann, E. M. Rasel, S. Abend, and N. Gaaloul, Spatially resolved phase reconstruction for atom interferometry, Eur. Phys. J. Quantum Technol. 12, 34 (2025).
  32. Y.-J. Chen, A. Hansen, G. W. Hoth, E. Ivanov, B. Pelle, J. Kitching, and E. A. Donley, Single-source multiaxis cold-atom interferometer in a centimeter-scale cell, Phys. Rev. Appl. 12, 014019 (2019).
  33. See Supplemental Material at http://link.aps.org/supplemental/10.1103/2c2j-qhkd for derivations of the main equations and additional experimental details.
  34. A. Peters, K. Y. Chung, and S. Chu, High-precision gravity measurements using atom interferometry, Metrologia 38, 25 (2001).
  35. G. W. Hoth, B. Pelle, S. Riedl, J. Kitching, and E. A. Donley, Point source atom interferometry with a cloud of finite size, Appl. Phys. Lett. 109, 071113 (2016).
  36. J. M. Hogan, D. M. S. Johnson, and M. A. Kasevich, Light-pulse atom interferometry, in Atom Optics and Space Physics (IOS Press, Varenna, Italy, 2009), pp. 411–447.
  37. P. Gillot, B. Cheng, S. Merlet, and F. Pereira Dos Santos, Limits to the symmetry of a Mach-Zehnder-type atom interferometer, Phys. Rev. A 93, 013609 (2016).
  38. D. S. Weiss, B. C. Young, and S. Chu, Precision measurement of ℏ/mCs based on photon recoil using laser-cooled atoms and atomic interferometry, Appl. Phys. B 59, 217 (1994).
  39. G. W. Hoth, Development and characterization of an interferometer based on an expanding ball of atoms, Ph.D. thesis, University of Colorado Boulder, 2016.
  40. W. M. Itano, J. C. Bergquist, J. J. Bollinger, J. M. Gilligan, D. J. Heinzen, F. L. Moore, M. G. Raizen, and D. J. Wineland, Quantum projection noise: Population fluctuations in two-level systems, Phys. Rev. A 47, 3554 (1993).
  41. J. Li, T. Kovachy, J. Bonacum, and S. M. Shahriar, Sensitivity of a point-source-interferometry-based inertial measurement unit employing large momentum transfer and launched atoms, Atoms 12, 32 (2024).
  42. M. Abe et al., Matter-wave Atomic Gradiometer Interferometric Sensor (MAGIS-100), Quantum Sci. Technol. 6, 044003 (2021).
  43. J. M. Hogan, D. M. S. Johnson, S. Dickerson, T. Kovachy, A. Sugarbaker, S.-w. Chiow, P. W. Graham, M. A. Kasevich, B. Saif, S. Rajendran, P. Bouyer, B. D. Seery, L. Feinberg, and R. Keski-Kuha, An atomic gravitational wave interferometric sensor in low earth orbit (AGIS-LEO), Gen. Relativ. Gravit. 43, 1953 (2011).
