Black Holes as Telescopes: Discovering Supermassive Binaries through Quasiperiodic Lensed Starlight

Hanxi Wang*

Miguel Zumalacárregui†

Bence Kocsis‡

  • Department of Physics, Astrophysics, University of Oxford, Denys Wilkinson Building, Keble Road, Oxford, OX1 3RH, United Kingdom

  • *Contact author: hanxi.wang@physics.ox.ac.uk
  • †Contact author: miguel.zumalacarregui@aei.mpg.de
  • ‡Contact author: bence.kocsis@physics.ox.ac.uk
PDF

Phys. Rev. Lett. 136, 061403 – Published 12 February, 2026

DOI: https://doi.org/10.1103/1sfl-87t4

Abstract

Supermassive black hole (SMBH) binary systems are an unavoidable outcome of galaxy mergers. Their dynamics encode valuable information about their formation and growth, the composition of their host galactic nuclei, the evolution of galaxies, and the nature of gravity. Many SMBH binaries with separations pc-kpc have been found, but closer (subparsec) binaries remain to be confirmed. Identifying these systems may elucidate how binaries evolve past the “final parsec” until gravitational radiation drives them to coalescence. Methods to discover and characterize SMBH binaries can shed light on these important questions and potentially open new multimessenger channels. Here we show that SMBH binaries in nonactive galactic nuclei can be identified and characterized by the gravitational lensing of individual bright stars, located behind them in the host galaxy. The rotation of “caustics”—regions where sources are hugely magnified due to the SMBH binary’s orbit and inspiral—leads to quasiperiodic lensing of starlight (QPLS). The extreme lensing magnification of individual bright stars produces a significant variation in the host galaxies’ luminosity; their lightcurve traces the orbit of the SMBH binary and its evolution, analogous to the waveforms recorded by gravitational-wave (GW) detectors. QPLS probes the population of sources observable by pulsar timing arrays and space detectors (LISA, TianQin), offering advance warning triggers for merging SMBHs for coincident or follow-up GW detections. SMBH population models predict 1–50 [190–5000](n⋆/pc−3) QPLS binaries with period less than 10[40] yr with comparable masses and redshift z<0.3, where n⋆ is the stellar number density. Additionally, stellar and orbital motion will lead to frequent instances of single or double flares caused by SMBHBs with longer periods. This novel signature can be searched for in a wealth of existing and upcoming time-domain photometric data: identifying quasiperiodic variability in galactic lightcurves will reveal an ensemble of binary systems and illuminate outstanding questions around them.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (105)

  1. M. C. Begelman, R. D. Blandford, and M. J. Rees, Nature (London) 287, 307 (1980).
  2. A. Escala, R. B. Larson, P. S. Coppi, and D. Mardones, Astrophys. J. 607, 765 (2004).
  3. M. Volonteri, Astron. Astrophys. Rev. 18, 279 (2010).
  4. M. Milosavljevic and D. Merritt, Astrophys. J. 596, 860 (2003).
  5. P. A. Seoane et al. (LISA Collaboration), Living Rev. Relativity 26, 2 (2023).
  6. M. Volonteri, F. Haardt, and P. Madau, Astrophys. J. 582, 559 (2003).
  7. J. Kormendy and L. C. Ho, Annu. Rev. Astron. Astrophys. 51, 511 (2013).
  8. G. Alonso-Álvarez, J. M. Cline, and C. Dewar, Phys. Rev. Lett. 133, 021401 (2024).
  9. B. Kocsis, Z. Haiman, and K. Menou, Astrophys. J. 684, 870 (2008).
  10. A. De Rosa et al., New Astron. Rev. 86, 101525 (2019).
  11. D. J. D’Orazio and M. Charisi, arXiv:2310.16896.
  12. T. Bogdanovic, M. C. Miller, and L. Blecha, Living Rev. Relativity 25, 3 (2022).
  13. M. Charisi, S. R. Taylor, J. Runnoe, T. Bogdanovic, and J. R. Trump, Mon. Not. R. Astron. Soc. 510, 5929 (2022).
  14. G. Agazie et al. (NANOGrav Collaboration), Astrophys. J. Lett. 951, L8 (2023).
  15. J. Antoniadis et al. (EPTA and InPTA Collaborations), Astron. Astrophys. 678, A50 (2023).
  16. D. J. Reardon et al. (PPTA Collaboration), Astrophys. J. Lett. 951, L6 (2023).
  17. H. Xu et al., Res. Astron. Astrophys. 23, 075024 (2023).
  18. J. Ellis, M. Fairbairn, G. Hütsi, J. Raidal, J. Urrutia, V. Vaskonen, and H. Veermäe, Phys. Rev. D 109, L021302 (2024).
  19. G. Sato-Polito, M. Zaldarriaga, and E. Quataert, Phys. Rev. D 112, 123018 (2025).
  20. P. Amaro-Seoane et al., arXiv:1702.00786.
  21. M. Colpi et al., arXiv:2402.07571.
  22. J. Luo et al. (TianQin Collaboration), Classical Quantum Gravity 33, 035010 (2016).
  23. J. Luo et al., Classical Quantum Gravity 42, 173001 (2025).
  24. P. Auclair et al., Living Rev. Relativity 26, 5 (2023).
  25. Z. Haiman, B. Kocsis, and K. Menou, Astrophys. J. 700, 1952 (2009).
  26. D. J. D’Orazio, Z. Haiman, and D. Schiminovich, Nature (London) 525, 351 (2015).
  27. M. Charisi, Z. Haiman, D. Schiminovich, and D. J. D’Orazio, Mon. Not. R. Astron. Soc. 476, 461 (2018).
  28. C. Xin, M. Charisi, Z. Haiman, D. Schiminovich, M. J. Graham, D. Stern, and D. J. D’Orazio, Mon. Not. R. Astron. Soc. 489, 819 (2019).
  29. Z. Song, J. Ge, Y. Lu, and X. Ji, Mon. Not. R. Astron. Soc. 493, 588 (2020).
  30. P. Schneider, J. Ehlers, and E. E. Falco, Gravitational Lenses (Springer, Berlin, Heidelberg, 1992).
  31. V. Bozza, Gen. Relativ. Gravit. 42, 2269 (2010).
  32. D. J. D’Orazio and R. Di Stefano, Mon. Not. R. Astron. Soc. 474, 2975 (2018).
  33. J. Davelaar and Z. Haiman, Phys. Rev. Lett. 128, 191101 (2022).
  34. L. Z. Kelley, D. J. D’Orazio, and R. Di Stefano, Mon. Not. R. Astron. Soc. 508, 2524 (2021).
  35. L. M. Krauth, J. Davelaar, Z. Haiman, J. R. Westernacher-Schneider, J. Zrake, and A. MacFadyen, Phys. Rev. D 109, 103014 (2024).
  36. D. L. Król, L. Stawarz, J. Krzesinski, and C. C. Cheung, Astrophys. J. 943, 171 (2023).
  37. N. Li, S. Mao, L. Gao, A. Loeb, and R. Di Stefano, Mon. Not. R. Astron. Soc. 419, 2424 (2012).
  38. Y. D. Hezaveh, P. J. Marshall, and R. D. Blandford, Astrophys. J. Lett. 799, L22 (2015).
  39. S. Mao and B. Paczynski, Astrophys. J. Lett. 374, L37 (1991).
  40. A. Gould and A. Loeb, Astrophys. J. 396, 104 (1992).
  41. B. S. Gaudi, Annu. Rev. Astron. Astrophys. 50, 411 (2012).
  42. J. Miralda-Escude, Astrophys. J. 379, 94 (1991).
  43. P. L. Kelly et al., Nat. Astron. 2, 334 (2018).
  44. J. M. Diego, Astron. Astrophys. 625, A84 (2019).
  45. G. Kauffmann, T. M. Heckman, C. Tremonti, J. Brinchmann, S. Charlot, S. D. M. White, S. E. Ridgway, J. Brinkmann, M. Fukugita, P. B. Hall, Ž. Ivezić, G. T. Richards, and D. P. Schneider, Mon. Not. R. Astron. Soc. 346, 1055 (2003).
  46. P. Schneider and A. Weiss, Astron. Astrophys. 164, 237 (1986).
  47. See Supplemental Material at http://link.aps.org/supplemental/10.1103/1sfl-87t4, Sec. A for details on methods and assumptions used when computing the magnification of the binary lens equation, which includes Refs. [48–56]; Sec. B for details on the topology and size of the caustic curves, which includes Ref. [57]; Sec. C for details on computing the magnification of an extended source near the caustic curve of a binary lens, which includes Ref. [58]; Sec. D for details on the magnification estimate at the trough and near merger for the lensing light curve, which includes Ref. [59]; Sec. F for details on the time duration estimate of caustic crossing; Sec. H for details on detection thresholds, which includes Refs. [60–62]; Sec. I for details on the GW-driven evolution of the binary and the detectability of the GWs of eccentric binaries, which includes Refs. [63–67]; Sec. J for details on the QPLS and caustic crossing rates, which includes Refs. [68,69]; and Sec. K for the special case of multiple QPLS sources.
  48. P. F. Hopkins, N. Murray, E. Quataert, and T. A. Thompson, Mon. Not. R. Astron. Soc. 401, L19 (2010).
  49. J. M. Diego et al., Astrophys. J. 857, 25 (2018).
  50. M. Oguri, J. M. Diego, N. Kaiser, P. L. Kelly, and T. Broadhurst, Phys. Rev. D 97, 023518 (2018).
  51. T. Venumadhav, L. Dai, and J. Miralda-Escudé, Astrophys. J. 850, 49 (2017).
  52. C. V. Müller and J. Miralda-Escudé, Mon. Not. R. Astron. Soc. 536, 1579 (2024).
  53. H. Erdl and P. Schneider, Astron. Astrophys. 268, 453 (1993).
  54. M. Meneghetti, Introduction to Gravitational Lensing: With python Examples (Springer, Cham, 2022).
  55. V. Bozza, Mon. Not. R. Astron. Soc. 408, 2188 (2010).
  56. V. Bozza, E. Khalouei, and E. Bachelet, Mon. Not. R. Astron. Soc. 505, 126 (2021).
  57. V. Bozza, Astron. Astrophys. 359, 1 (2000).
  58. A. O. Petters, H. Levine, and J. Wambsganss, Singularity Theory and Gravitational Lensing (Birkhäuser, Boston, MA, 2001).
  59. O. Pejcha and D. Heyrovský, Astrophys. J. 690, 1772 (2009).
  60. E. C. Bellm et al., Publ. Astron. Soc. Pac. 131, 018002 (2019).
  61. F. B. Bianco et al., Astrophys. J. Suppl. Ser. 258, 1 (2022).
  62. NASA Roman Science Team, Wide field instrument technical information, https://roman.gsfc.nasa.gov/science/WFI_technical.html (2024) (accessed: April 14, 2025).
  63. L. Barack et al., Classical Quantum Gravity 36, 143001 (2019).
  64. I. Mandel, Res. Not. Am. Astron. Soc. 5, 223 (2021).
  65. S. Babak, M. Hewitson, and A. Petiteau, arXiv:2108.01167.
  66. T. Wagg, K. Breivik, and S. E. de Mink, Astrophys. J. Suppl. Ser. 260, 52 (2022).
  67. T. Wagg, K. Breivik, and S. de Mink, J. Open Source Software 7, 3998 (2022).
  68. M. T. Penny, E. Kerins, and S. Mao, Mon. Not. R. Astron. Soc. 417, 2216 (2011).
  69. D. Merritt, Astrophys. J. 648, 976 (2006).

  70. NASA/ESA Hubble Space Telescope, SXS Lensing/Max Planck Institute for Gravitational Physics, and P. Kervella (ESO). Composite figure including NGC 4414, colliding black holes simulation, and O-type star illustration, NGC 4414, Colliding black holes, O-type star (2025), images used under Creative Commons licenses: NGC 4414 image by NASA/ESA, CC BY 3.0; black hole simulation by SXS Lensing/Max Planck Institute for Gravitational Physics, CC BY 4.0; O-type star illustration by P. Kervella (ESO), CC BY-SA 3.0.

  71. https://github.com/whanxi/SMBHB-Lensing-Animations.
  72. A. R. Kaiser and S. T. McWilliams, Classical Quantum Gravity 38, 055009 (2021).
  73. Z. Arzoumanian et al. (NANOGrav Collaboration), Astrophys. J. 914, 121 (2021).
  74. Z. Xuan, S. Naoz, B. Kocsis, and E. Michaely, Astrophys. J. 965, 148 (2024).
  75. B. F. Schutz, Nature (London) 323, 310 (1986).
  76. E. Belgacem et al., J. Cosmol. Astropart. Phys. 07 (2019) 024.
  77. M. J. Graham et al., Publ. Astron. Soc. Pac. 131, 078001 (2019).
  78. S. Miyazaki et al., Publ. Astron. Soc. Jpn. 70, S1 (2018).
  79. H. Aihara et al., Publ. Astron. Soc. Jpn. 70, S4 (2018).
  80. Ž. Ivezić et al., Astrophys. J. 873, 111 (2019).
  81. P. A. Abell et al., arXiv:0912.0201.
  82. NASA Goddard Space Flight Center, Nancy Grace Roman Space Telescope, https://roman.gsfc.nasa.gov/index.html (2025) (accessed: April 22, 2025).
  83. Z. Haiman et al., arXiv:2306.14990.
  84. Y. Shvartzvald et al., Astrophys. J. 964, 74 (2024).
  85. E. Barausse, K. Dey, M. Crisostomi, A. Panayada, S. Marsat, and S. Basak, Phys. Rev. D 108, 103034 (2023).
  86. A. P. S. Crotts, Astrophys. J. Lett. 399, L43 (1992).
  87. G. F. Lewis and R. A. Ibata, Astrophys. J. 549, 46 (2001).
  88. R. Gil-Merino and G. F. Lewis, Astrophys. J. 643, 260 (2006).
  89. P. C. Peters, Phys. Rev. 136, 1224 (1964).
  90. S. J. Aarseth, IAU Symp. 246, 437 (2008).
  91. A. Sesana, F. Haardt, and P. Madau, Astrophys. J. 686, 432 (2008).
  92. I. Berentzen, M. Preto, P. Berczik, D. Merritt, and R. Spurzem, Astrophys. J. 695, 455 (2009).
  93. M. Iwasawa, S. An, T. Matsubayashi, Y. Funato, and J. Makino, Astrophys. J. Lett. 731, L9 (2011).
  94. M. Bonetti, A. Rasskazov, A. Sesana, M. Dotti, F. Haardt, N. W. C. Leigh, M. Arca Sedda, G. Fragione, and E. Rossi, Mon. Not. R. Astron. Soc. 493, L114 (2020).
  95. F. M. Khan and K. Holley-Bockelmann, Mon. Not. R. Astron. Soc. 508, 1174 (2021).
  96. A. Mastrobuono-Battisti, P. Amaro Seoane, M. J. Fullana i Alfonso, C. Omarov, D. Yurin, M. Makukov, G. Omarova, and G. Ogiya, Astron. Astrophys. 693, A22 (2025).
  97. A. Gualandris, F. M. Khan, E. Bortolas, M. Bonetti, A. Sesana, P. Berczik, and K. Holley-Bockelmann, Mon. Not. R. Astron. Soc. 511, 4753 (2022).
  98. P. Goldreich and R. Sari, Astrophys. J. 585, 1024 (2003).
  99. J. Cuadra, P. J. Armitage, R. D. Alexander, and M. C. Begelman, Mon. Not. R. Astron. Soc. 393, 1423 (2009).
  100. A. A. C. Roedig, M. Dotti, A. Sesana, J. Cuadra, and M. Colpi, Mon. Not. R. Astron. Soc. 415, 3033 (2011).
  101. M. Siwek, L. Z. Kelley, and L. Hernquist, Mon. Not. R. Astron. Soc. 534, 2609 (2024).
  102. N. Chen, D. Mukherjee, T. Di Matteo, Y. Ni, S. Bird, and R. Croft, Open J. Astrophys. 7, 28 (2024).
  103. Y. Zhou, D. Mukherjee, N. Chen, T. Di Matteo, P. H. Johansson, A. Rantala, C. Partmann, U. N. Di Carlo, S. Bird, and Y. Ni, Astrophys. J. 980, 79 (2025).
  104. D. Mukherjee, Y. Zhou, N. Chen, U. N. Di Carlo, and T. Di Matteo, Astrophys. J. 981, 203 (2025).
  105. V. Manikantan, V. Paschalidis, and G. Bozzola, Astrophys. J. Lett. 984, L47 (2025).
