Metastability of the Skyrmion Lattice in GdRu2Si2 Revealed by Ultrasound

J. Sourd1, D. A. Mayoh2, G. Balakrishnan2, J. Wosnitza1,3, and S. Zherlitsyn1

PDF

Phys. Rev. Lett. 137, 066703 – Published 7 August, 2026

DOI: https://doi.org/10.1103/1nhc-ds19

Abstract

We report on the low-temperature magnetoelastic properties of the skyrmion-lattice compound GdRu2Si2 under magnetic fields applied along the [001] axis. Our sound-velocity measurements reveal a series of pronounced anomalies related to the skyrmion-lattice phase. The emergence of hysteresis and steplike features indicates intrinsic metastability of the skyrmion lattice in GdRu2Si2, deviating from other skyrmion-lattice compounds. Analysis of multiple elastic modes allows us to disentangle the compressional and shear responses, with the latter showing a stronger sensitivity to the metastability of the skyrmion lattice.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (33)

  1. A. Bogdanov and D. Yablonskii, Thermodynamically stable “vortices” in magnetically ordered crystals. The mixed state of magnets, Zh. Eksp. Teor. Fiz. 95, 178 (1989) [Sov. Phys. JETP 68, 101 (1989)].
  2. A. Bogdanov and A. Hubert, Thermodynamically stable magnetic vortex states in magnetic crystals, J. Magn. Magn. Mater. 138, 255 (1994).
  3. S. Mühlbauer, B. Binz, F. Jonietz, C. Pfleiderer, A. Rosch, A. Neubauer, R. Georgii, and P. Böni, Skyrmion lattice in a chiral magnet, Science 323, 915 (2009).
  4. B. Kolech, Magnetic skyrmions and quasi particles: A review on principles and applications, in Vortex Simulation and Identification (IntechOpen Limited, London, 2023).
  5. S. Gao, H. Rosales, F. Gomez Albarracin, V. Tsurkan, G. Kaur, T. Fennell, P. Steffens, M. Boehm, P. Čermák, A. Schneidewind et al., Fractional antiferromagnetic skyrmion lattice induced by anisotropic couplings, Nature (London) 586, 37 (2020).
  6. N. Khanh, T. Nakajima, X. Yu, S. Gao, K. Shibata, M. Hirschberger, Y. Yamasaki, H. Sagayama, H. Nakao, L. Peng et al., Nanometric square skyrmion lattice in a centrosymmetric tetragonal magnet, Nat. Nanotechnol. 15, 444 (2020).
  7. Y. Nii, A. Kikkawa, Y. Taguchi, Y. Tokura, and Y. Iwasa, Elastic stiffness of a skyrmion crystal, Phys. Rev. Lett. 113, 267203 (2014).
  8. A. E. Petrova and S. M. Stishov, Field evolution of the magnetic phase transition in the helical magnet MnSi inferred from ultrasound studies, Phys. Rev. B 91, 214402 (2015).
  9. H. Oike, A. Kikkawa, N. Kanazawa, Y. Taguchi, M. Kawasaki, Y. Tokura, and F. Kagawa, Interplay between topological and thermodynamic stability in a metastable magnetic skyrmion lattice, Nat. Phys. 12, 62 (2016).
  10. L. Bannenberg, H. Wilhelm, R. Cubitt, A. Labh, M. Schmidt, E. Lelièvre-Berna, C. Pappas, M. Mostovoy, and A. Leonov, Multiple low-temperature skyrmionic states in a bulk chiral magnet, npj Quantum Mater. 4, 11 (2019).
  11. A. Chacon, L. Heinen, M. Halder, A. Bauer, W. Simeth, S. Mühlbauer, H. Berger, M. Garst, A. Rosch, and C. Pfleiderer, Observation of two independent skyrmion phases in a chiral magnetic material, Nat. Phys. 14, 936 (2018).
  12. G. Wood, D. Khalyavin, D. Mayoh, J. Bouaziz, A. Hall, S. Holt, F. Orlandi, P. Manuel, S. Blügel et al., Double-Q ground state with topological charge stripes in the centrosymmetric skyrmion candidate GdRu2Si2, Phys. Rev. B 107, L180402 (2023).
  13. G. Wood, J. Stewart, D. Mayoh, J. Paddison, J. Bouaziz, S. Tobin, O. Petrenko, M. Lees, P. Manuel, J. Staunton et al., A magnon band analysis of GdRu2Si2 in the field-polarized state, npj Quantum Mater. 10, 39 (2025).
  14. B. Lüthi, Physical Acoustics in the Solid State (Springer, Berlin, Heidelberg, 2006), Vol. 148.
  15. A. Hauspurg, S. Zherlitsyn, T. Helm, V. Felea, J. Wosnitza, V. Tsurkan, K. Choi, S. Do, M. Ye, W. Brenig et al., Fractionalized excitations probed by ultrasound, Phys. Rev. B 109, 144415 (2024).
  16. J. Kindervater, I. Stasinopoulos, A. Bauer, F. Haslbeck, F. Rucker, A. Chacon, S. Mühlbauer, C. Franz, M. Garst, D. Grundler et al., Weak crystallization of fluctuating skyrmion textures in MnSi, Phys. Rev. X 9, 041059 (2019).
  17. K. Adachi, H. Wilhelm, M. Schmidt, and M. Carpenter, Elastic and anelastic behavior associated with magnetic ordering in the skyrmion host Cu2OSeO3, Phys. Rev. B 109, 144413 (2024).
  18. M. Birch, R. Takagi, S. Seki, M. Wilson, F. Kagawa, A. Štefančič, G. Balakrishnan, R. Fan, P. Steadman, C. Ottley et al., Increased lifetime of metastable skyrmions by controlled doping, Phys. Rev. B 100, 014425 (2019).
  19. M. Wilson, M. Birch, A. Štefančič, A. Twitchett-Harrison, G. Balakrishnan, T. Hicken, R. Fan, P. Steadman, and P. Hatton, Stability and metastability of skyrmions in thin lamellae of Cu2OSeO3, Phys. Rev. Res. 2, 013096 (2020).
  20. J. Grumbach, J. Sourd, M. Deeb, A. Miyata, H. Suwa, T. Gottschall, A. Hauspurg, A. Chattopadhyay et al., Contrasting magnetic behavior in MnSc2X4 (X=S, Se) spinel compounds investigated by magnetoelastic studies, Phys. Rev. B 129, 147201 (2025).
  21. H. Yoshimochi, R. Takagi, J. Ju, N. Khanh, H. Saito, H. Sagayama, H. Nakao, S. Itoh, Y. Tokura, T.-h. Arima et al., Multistep topological transitions among meron and skyrmion crystals in a centrosymmetric magnet, Nat. Phys. 20, 1001 (2024).
  22. M. Ruderman and C. Kittel, Indirect exchange coupling of nuclear magnetic moments by conduction electrons, Phys. Rev. 96, 99 (1954).
  23. T. Kasuya, A theory of metallic ferro-and antiferromagnetism on Zener’s model, Prog. Theor. Phys. 16, 45 (1956).
  24. K. Yosida, Magnetic properties of Cu-Mn alloys, Phys. Rev. 106, 893 (1957).
  25. S. Hayami and Y. Motome, Multiple-Q instability by (d-2)-dimensional connections of Fermi surfaces, Phys. Rev. B 90, 060402(R) (2014).
  26. S. Hayami, R. Ozawa, and Y. Motome, Effective bilinear-biquadratic model for noncoplanar ordering in itinerant magnets, Phys. Rev. B 95, 224424 (2017).
  27. J. von Boehm and P. Bak, Devil’s stairs and the commensurate-commensurate transitions in CeSb, Phys. Rev. Lett. 42, 122 (1979).
  28. J. Rossat-Mignod, P. Burlet, H. Bartholin, O. Vogt, and R. Lagnier, Specific heat analysis of the magnetic phase diagram of CeSb, J. Phys. C 13, 6381 (1980).
  29. S. Imajo, N. Matsuyama, T. Nomura, T. Kihara, S. Nakamura, C. Marcenat, T. Klein, G. Seyfarth, C. Zhong, H. Kageyama et al., Magnetically hidden state on the ground floor of the magnetic devil’s staircase, Phys. Rev. Lett. 129, 147201 (2022).
  30. M. V. Sapozhnikov and O. L. Ermolaeva, Two-dimensional skyrmion lattice in a nanopatterned magnetic film, Phys. Rev. B 91, 024418 (2015).
  31. S. Hayami, S. Z. Lin, and C. D. Batista, Bubble and skyrmion crystals in frustrated magnets with easy-axis anisotropy, Phys. Rev. B 93, 184413 (2016).
  32. A. Singh, J. Li, S. Montoya, S. Morley, P. Fischer, S. Kevan, E. Fullerton, D. Yao, T. Datta, and S. Roy, Periodicity staircase in a centrosymmetric Fe/Gd magnetic thin film system, npj Quantum Mater. 9, 2 (2024).
  33. J. Sourd, D. A. Mayoh, G. Balakrishnan, M. Uhlarz, J. Wosnitza, and S. Zherlitsyn, Magnetoelastic properties in the high-temperature magnetic phase of the skyrmion compound GdR2Si2, Phys. Rev. B 113, 134416 (2026).
