Development and testing of a permanent magnet spiral inflector

A. H. Barnard* and J. L. Conradie

  • *Contact author: ah.barnard@ilabs.nrf.ac.za
PDF

Phys. Rev. Accel. Beams 29, 074602 – Published 10 July, 2026

DOI: https://doi.org/10.1103/z11n-5c7g

Abstract

A proof-of-concept permanent magnet spiral inflector was constructed and used to successfully inject and accelerate protons in the Solid Pole Cyclotron 2 at iThemba LABS. This article describes the design, construction, and testing of the inflector and discusses its application to other cyclotrons.
