Generalization of the Froissart-Stora formula to piecewise-linear spin-orbit resonance crossings

Joseph P. Devlin1,*, Georg H. Hoffstaetter1,2, and Desmond P. Barber3,4

  • *Contact author: jpd285@cornell.edu
PDF

Phys. Rev. Accel. Beams 29, 074702 – Published 27 July, 2026

DOI: https://doi.org/10.1103/sxkc-zrh5

Abstract

Spin-polarized beams are important for some nuclear and high-energy physics experiments, such as those planned for the future Electron-Ion Collider. However, maintaining polarization during the acceleration of a charged-particle beam is difficult because the periodic nature of circular accelerators leads to spin-orbit resonances where the spin-precession frequency is a sum of integer multiples of the orbital frequencies. Usually, the dominant depolarization mechanisms are first-order spin-orbit resonances, and the depolarization associated with crossing such a resonance can be computed using the Froissart-Stora formula. However, accelerating polarized hadron beams to high energy requires special magnet structures called Siberian snakes. When these are implemented to maintain a spin-precession frequency of one-half the revolution frequency, there will be no first-order spin-orbit resonance crossings. The dominant depolarization mechanisms are then higher-order spin-orbit resonances. The Froissart-Stora formula can be applied to higher-order resonances when the slope of the amplitude-dependent spin tune (ADST) is constant. However, the slope of the ADST often changes at the moment of resonance crossing. This work introduces a generalization of the Froissart-Stora formula which is applicable when the slope changes in this manner. The applicability of this formula is demonstrated through tracking simulations of a higher-order resonance crossing in both a toy model and the Relativistic Heavy Ion Collider. It is additionally shown that the Froissart-Stora formula is mathematically equivalent to the Landau-Zener formula for the diabatic transition probability in two-level systems with a linearly increasing energy gap and constant coupling. This work, therefore, also extends the Landau-Zener formula to the case of changing slope.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (49)

  1. C. Montag et al., The EIC accelerator: Design highlights and project status, in Proceedings of the 15th International Particle Accelerator Conference, IPAC-2024, Nashville, TN (JACoW, Geneva, Switzerland, 2024), pp. 214–217.
  2. H. Huang et al., RHIC polarized proton operation, in Proceedings of the 24th Particle Accelerator Conference, PAC-2011, New York (IEEE, New York, 2011), pp. 41–45.
  3. J. D. Jackson, Classical Electrodynamics, 3rd ed. (Wiley, New York, 1999).
  4. L. H. Thomas, The kinematics of an electron with an axis, Philos. Mag. 3, 1 (1927).
  5. V. Bargmann, L. Michel, and V. L. Telegdi, Precession of the polarization of particles moving in a homogeneous electromagnetic field, Phys. Rev. Lett. 2, 435 (1959).
  6. M. Froissart and R. Stora, Depolarisation d’un faisceau de protons polarises dans un synchrotron, Nucl. Instrum. Methods 7, 297 (1960).
  7. J. P. Devlin and G. H. Hoffstaetter, Various methods for computing dominant spin-orbit resonance strengths in storage rings, in Proceedings of the 15th International Particle Accelerator Conference, IPAC-2024, Nashville, TN (JACoW, Geneva, Switzerland, 2024), pp. 1129–1132.
  8. G. H. Hoffstaetter and M. Vogt, Strength of higher-order spin-orbit resonances, Phys. Rev. E 70, 056501 (2004).
  9. G. H. Hoffstaetter, High-Energy Polarized Proton Beams (Springer, New York, 2006).
  10. M. Vogt. Bounds on the maximum attainable equilibrium spin polarization of protons at high energy in HERA, Ph.D. thesis, Universität Hamburg, 2000.
  11. K. Yokoya, The action-angle variables of classical spin motion in circular accelerators, DESY, Technical Report No. 86-057, 1986.
  12. D. P. Barber, K. Heinemann, and G. Ripken, A canonical 8-dimensional formalism for classical spin-orbit motion in storage rings I. A new pair of canonical spin variables, Z. Phys. C 64, 117 (1994).
  13. D. P. Barber, K. Heinemann, and G. Ripken, A canonical 8-dimensional formalism for classical spin-orbit motion in storage rings II. Normal forms and the n-axis, Z. Phys. C 64, 143 (1994).
  14. Y. S. Derbenev and A. M. Kondratenko, Diffusion of particle spins in storage rings, Sov. Phys. JETP 35, 230 (1972); https://jetp.ras.ru/cgi-bin/dn/e_035_02_0230.pdf.
  15. G. H. Hoffstaetter, M. Vogt, and D. P. Barber, Higher-order effects in polarized proton dynamics, Phys. Rev. ST Accel. Beams 2, 114001 (1999).
  16. D. P. Barber, J. A. Ellison, and K. Heinemann, Quasiperiodic spin-orbit motion and spin tunes in storage rings, Phys. Rev. ST Accel. Beams 7, 124002 (2004).
  17. D. P. Barber and G. Ripken, Handbook of Accelerator Physics and Engineering, 3rd ed., edited by A. W. Chao, H. Weise, M. Tigner and F. Zimmermann (World Scientific, Singapore, 2023).
  18. K. Heinemann and G. H. Hoffstätter, Tracking algorithm for the stable spin polarization field in storage rings using stroboscopic averaging, Phys. Rev. E 54, 4240 (1996).
  19. K. Yokoya, An algorithm for calculating the spin tune in circular accelerators, DESY, Technical Report No. 99-006, 1999.
  20. E. Hamwi, J. P. Devlin, M. G. Signorelli, and G. H. Hoffstaetter, Aspects of stroboscopic averaging for the invariant spin field, in Proceedings of the 6th North American Particle Acceleration Conference, NAPAC2025, Sacramento, CA (JACoW, Geneva, Switzerland, 2025), pp. 368–370.
  21. E. D. Courant and R. D. Ruth, Acceleration of polarized protons in circular accelerators, BNL, Technical Report No. 51270, 1980.
  22. S. R. Mane, Exact solution of the Derbenev-Kondratenko n^ axis for a model with one resonance, Fermilab, Technical Report No. TM-1515, 1988).
  23. G. H. Hoffstaetter, H. S. Dumas, and J. A. Ellison, Adiabatic invariance of spin-orbit motion in accelerators, Phys. Rev. ST Accel. Beams 9, 014001 (2006).
  24. V. S. Morozov, Z. B. Etienne, M. C. Kandes, A. D. Krisch, M. A. Leonova, D. W. Sivers, V. K. Wong, K. Yonehara, V. A. Anferov, H. O. Meyer, P. Schwandt, E. J. Stephenson, and B. von Przewoski, First spin flipping of a stored spin-1 polarized beam, Phys. Rev. Lett. 91, 214801 (2003).
  25. S. Y. Lee, Spin Dynamics and Snakes in Synchrotrons (World Scientific, Singapore, 1997).
  26. C. Steier, W. v. Drachenfels, F. Frommberger, M. Hoffmann, D. Husmann, J. Keil, and S. Nakamura, Acceleration of polarized electrons in ELSA, in Proceedings of the 6th European Particle Accelerator Conference, Stockholm (1998).
  27. B. W. Montague, Polarized beams in high energy storage rings, Phys. Rep. 113, 1 (1984).
  28. S. R. Mane, Approximate formula for the asymptotic polarization for passage across two overlapping spin resonances, Nucl. Instrum. Methods Phys. Res., Sect. A 524, 80 (2004).
  29. M. Abramowitz and I. A. Stegun, Handbook of Mathematical Functions, 9th ed. (Dover, New York, 1965).
  30. H. Morse and P. M. Feshbach, Methods of Theoretical Physics (McGraw Hill, New York, 1953).
  31. A. Turrin, Dynamics of traversing an avoided level crossing, Phys. Lett. 87A, 455 (1982).
  32. L. D. Landau, Zur theorie der energieübertragung. II, Phys. Z. Sowjetunion 2, 46 (1932).
  33. C. Zener, Non-adiabatic crossing of energy levels, Proc. R. Soc. A 137, 696 (1932).
  34. E. C. G. Stückelberg, Theorie der unelastischen stösse zwischen atomen, Helv. Phys. Acta 5, 369 (1932).
  35. E. Majorana, Atomi orientati in campo magnetico variabile, Nuovo Cimento 9, 43 (1932).
  36. B. Zwiebach, Mastering Quantum Mechanics: Essentials, Theory, and Applications (The MIT Press, Cambridge, MA, 2022).
  37. S. R. Mane, Electron-spin polarization in high-energy storage rings. I. Derivation of the equilibrium polarization, Phys. Rev. A 36, 105 (1987).
  38. S. R. Mane, Electron-spin polarization in high-energy storage rings. II. Evaluation of the equilibrium polarization, Phys. Rev. A 36, 120 (1987).
  39. E. Forest, From Tracking Code to Analysis (Springer, Tokyo, 2016).
  40. A. W. Chao, Matrix formalism for spin dynamics near a single depolarization resonance, Phys. Rev. ST Accel. Beams 8, 104001 (2005).
  41. J. P. Devlin, A generalization of the Froissart-Stora formula, Bachelor’s thesis, Cornell University, 2025.
  42. J. P. Devlin, G. H. Hoffstaetter, and D. P. Barber, An extended Froissart-Stora formula for changing crossing speed, in Proc. NAPAC2025 (JACoW Publishing, Geneva, Switzerland, 2025), pp. 364–367.
  43. Wolfram Research, Inc., Mathematica, version 14.1, Champaign, IL, (2024).
  44. S. R. Mane, Exact solutions for the spin tune for model storage rings, Nucl. Instrum. Methods Phys. Res., Sect. A 480, 328 (2002).
  45. E. Hamwi, J. P. Devlin, G. H. Hoffstaetter, and D. P. Barber, Modeling interference of two first-order resonances with two Siberian snakes using machine learning, in Proceedings of the 15th International Particle Accelerator Conference, IPAC-2024, Nashville, TN (JACoW, Geneva, Switzerland, 2024), pp. 682–685.
  46. D. Sagan, Bmad: A relativistic charged particle simulation library, Nucl. Instrum. Methods Phys. Res., Sect. A 558, 356 (2006).
  47. D. Sagan, A superconvergent algorithm for invariant spin field stroboscopic calculations, in Proceedings of the 9th International Particle Accelerator Conference, IPAC-2018, Vancouver, BC, Canada (JACoW, Geneva, Switzerland, 2018), pp. 145–148
  48. Y. Luo, W. Fischer, and S. White, Analysis and modeling of proton beam loss and emittance growth in the Relativistic Heavy Ion Collider, Phys. Rev. Accel. Beams 19, 021001 (2016).
  49. J. Devlin, G. Hoffstaetter, and D. Barber, Data for Two-Slope Froissart-Stora Paper, 10.5281/zenodo.20412238 (2026).
