Features of magnetized motion of electrons in electron cooling devices

V. B. Reva*, M. I. Bryzgunov, V. M. Panasyuk, and V. V. Parkhomchuk

  • *Contact author: V.B.Reva@inp.nsk.su
PDF

Phys. Rev. Accel. Beams 29, 104601 – Published 21 October, 2026

DOI: https://doi.org/10.1103/hvvp-yz5n

Abstract

In electron coolers devices, at low energies the electron beam is immersed in a continuous solenoid, which provides a cold and tightly focused beam in the cooling and transport sections. At low energies, the electron motion satisfies the adiabatic criterion when the typical length of the magnetic field variation is much larger than the Larmor spiral length. At relativistic energies, this condition generally cannot be fulfilled, so a special method of transporting the electron beam is required. This article describes one such method, which involves the use of special “resonant” elements to guide the electron beam along the desired trajectory.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (33)

  1. V. V. Parkhomchuk and A. N. Skrinsky, Electron cooling: Physics and prospective applications, Rep. Progr. Phys. 54, 919 (1991).
  2. I. N. Meshkov, Electron cooling: Status and perspectives, Phys. Part. Nucl. 25, 631 (1994), https://inspirehep.net/literature/389221.
  3. V. V. Parkhomchuk and A. N. Skrinskiĭ, Electron cooling: 35 years of development, Phys.-Usp. 43, 433 (2000).
  4. N. S. Dikansky, I. N. Meshkov, V. V. Parkhomchuk, and A. N. Skrinsky, Development of techniques for the cooling of ions, Phys. Usp. 61, 424 (2018).
  5. S. Nagaitsev, D. Broemmelsiek, A. Burov, K. Carlson, C. Gattuso, M. Hu, T. Kroc, L. Prost, S. Pruss, M. Sutherland, C. W. Schmidt, A. Shemyakin, V. Tupikov, and A. Warner, Experimental demonstration of relativistic electron cooling, Phys. Rev. Lett. 96, 044801 (2006).
  6. S. Seletskiy, M. Blaskiewicz, A. Drees, A. Fedotov, W. Fischer, X. Gu, R. Hulsart, D. Kayran, J. Kewisch, C. Liu, M. Minty, V. Ptitsyn, V. Schoefer, A. Sukhanov, P. Thieberger, and H. Zhao, Obtaining transverse cooling with nonmagnetized electron beam, Phys. Rev. Accel. Beams 23, 110101 (2020).
  7. S. Seletskiy, M. Blaskiewicz, A. Drees, A. Fedotov, W. Fischer, D. M. Gassner, X. Gu, R. Hulsart, D. Kayran, J. Kewisch, C. Liu, K. Mernick, R. Michnoff, T. Miller, M. Minty, G. Robert-Demolaize, V. Schoefer, H. Song, P. Thieberger, and P. Wanderer, Accurate setting of electron energy for demonstration of first hadron beam cooling with rf-accelerated electron bunches, Phys. Rev. Accel. Beams 22, 111004 (2019).
  8. D. Kayran et al., High-brightness electron beams for linac-based bunched beam electron cooling, Phys. Rev. Accel. Beams 23, 021003 (2020).
  9. A. V. Fedotov, W. Fischer, X. Gu, D. Kayran, J. Kewisch, M. G. Minty, V. Schoefer, S. Seletskiy, and H. Zhao, Electron cooling of colliding ion beams in RHIC: Status and perspectives, in Proc. COOL2021, Novosibirsk, Russia (2021), pp. 42–47, https://proceedings.jacow.org/cool2021/papers/s601.pdf.
  10. A. Fedotov et al., Experimental demonstration of hadron beam cooling using radio-frequency accelerated electron bunches, Phys. Rev. Lett. 124, 084801 (2020).
  11. V. B. Reva, M. I. Bryzgunov, V. V. Parkhomchuk, A. Halama, V. Kamerdzhiev, and P. Niedermayer, COSY experience of electron cooling, in Proc. COOL2019, Novosibirsk, Russia (2019), pp. 1–5, https://proceedings.jacow.org/cool2019/papers/mox01.pdf.
  12. J. Li, L. J. Mao, X. D. Yang, J. C. Yang, M. T. Tang, L. X. Zhao, H. Zhao, Z. K. Huang, and S. X. Wang, Preliminary design of electron target for SRing at HIAF, in Proc. COOL2017, Bonn, Germany (2017), pp. 40–43, https://proceedings.jacow.org/cool2017/papers/tup08.pdf.
  13. H. Danared, G. Andler, L. Bagge, C. J. Herrlander, J. Hilke, J. Jeansson, A. Källberg, A. Nilsson, A. Paál, K.-G. Rensfelt, U. Rosengård, J. Starker, and M. af Ugglas, Electron cooling with an ultracold electron beam, Phys. Rev. Lett. 72, 3775 (1994).
  14. D. A. Orlov, M. Lestinsky, D. Schwalm F.Sprenger, A. S. Terekhov, and A. Wolf, Ultra-cold electron beams for the Heidelberg TSR and CSR, AIP Conf. Proc. 821, 478 (2006).
  15. V. Bocharov et al., HIRFL-CSR electron cooler commissioning, Nucl. Instrum. Methods Phys. Res., Sect. A 532, 144 (2004).
  16. G. Tranquille, M. Chanel, V. Prieto Ch. Carly, R. Sautier, A. Bubley, V. Parkhomchuk, V. Reva, M. Brizgunov, M. Vedenev, and V. Panasyuk, Comissioning of the LEIR electron cooler with Pb+54 ions, in Proc. RuPAC2006, Novosibirsk, Russia (2006), pp. 25–27, https://proceedings.jacow.org/r06/PAPERS/WEBO01.pdf.
  17. M. Bryzgunov et al., Status of the electron cooler for NICA booster and results of its commissioning, in Proc. COOL2019, Novosi-birsk, Russia (2019), pp. 22–25, https://proceedings.jacow.org/cool2019/papers/tux01.pdf.
  18. P. Beller, K. Beckert, B. Franzke, C. Kozhuharov, F. Nolden, and M. Steck, Observation of a reduction of recombination between ions and electrons, Nucl. Instrum. Methods Phys. Res., Sect. A 532, 427 (2004).
  19. V. B. Reva and M. I. Bryzgunov, Features of the longitudinal electron friction force in experiments on COSY synchrotron, Phys. Part. Nucl. Lett. 21, 291 (2024).
  20. J. Dietrich, V. V. Parkhomchuk, V. B. Reva, and M. A. Vedenev, The proposed 2 MeV electron cooler for COSY, AIP Conf. Proc. 821, 299 (2006).
  21. V. B. Reva et al., Commissioning COSY cooler with electron beam at Novosibirsk, in Proc. COOL13, Murren, Switzerland (2013), pp. 79–83, https://proceedings.jacow.org/COOL2013/papers/tupm2ha01.pdf.
  22. I. N. Meshkov, A. Sharapa, and A. Shemyakin, Formation of an electron beam with an extremely small phase volume, Sov. J. Tech. Phys. 59, 146 (1989), https://journals.ioffe.ru/articles/viewPDF/30775.
  23. V. I. Kudelainen, I. N. Meshkov, and R. A. Salimov, The formation of an intense electron beam in a longitudinal magnetic field, Sov. Tech. Phys. 16, 1821 (1971).
  24. M. I. Bryzgunov, V. S. Kamerdzhiev, V. V. Parkhomchuk, and V. B. Reva, Features of cooling dynamics in a high-voltage electron cooling system of the COSY, Tech. Phys. 60, 1227 (2015).
  25. K. Aulenbacher, J. Dietrich, and W. Klag, Status of the Turbine-driven HV generator for a relativistic electron cooler, in Proc. COOL2019, Novosibirsk, Russia (2019), pp. 11–13, https://proceedings.jacow.org/cool2019/papers/moy02.pdf.
  26. K. Aulenbacher, J. Dietrich Th. Beiser, and W. Klag, Sustaining competences for electron cooling at HESR, in Proc. COOL2023, Montreux, Switzerland (2023), pp. 37–39, https://proceedings.jacow.org/cool2023/papers/thpam1r2.pdf.
  27. E. V. Ahmanova, A. G. Kobets, I. N. Meshkov, R. V. Pivin, A. U. Rudakov, A. V. Shabunov, A. V. Smirnov, N. D. Topilin, S. L. Yakovenko Yu.A.Tumanova, A. V. Ivanov, V. V. Parkhom-chuk, A. A. Filippov, M. P. Kokurkin, NYu Lysov, and M. M. Pashin, Electron cooler for the NICA collider, in Proc. COOL2013, Murren, Switzerland (2013), pp. 113–115, https://proceedings.jacow.org/COOL2013/papers/weppo08.pdf.
  28. V. B. Reva, M. I. Bryzgunov, A. V. Bubley, A. D. Goncharov, N. S. Kremnev, V. M. Panasyuk, V. V. Parkhomchuk, V. A. Polukhin, and A. A. Putmakov, High voltage cooler NICA status and ideas, in Proc. COOL2017, Bonn, Germany (2017), pp. 25–27, https://proceedings.jacow.org/cool2017/papers/tum21.pdf.
  29. M. A. Tiunov, Full calculation of three-dimensional quasistationary electromagnetic fields in the strong skin-effect approximation using the boundary integral equation method, Sib. J. Phys. 9, 36 (2014).
  30. Y. S. Derbenev, Advanced optical concepts for electron cooling, Nucl. Instrum. Methods Phys. Res., Sect. A 441, 223 (2000).
  31. A. Burov, S. Nagaitsev, A. Shemyakin, and Y. Derbenev, Optical principles of beam transport for relativistic electron cooling, Phys. Rev. Accel. Beams 3, 094002 (2000).
  32. A. V. Fedotov, X. Gu, D. Kayran, J. Kewisch, and S. Seletskiy, Experience and challenges with electron cooling of colliding ion beams in RHIC, in Proc. NAPAC2022, Albuquerque, NM, USA (2022), pp. 325–328, https://proceedings.jacow.org/napac2022/papers/tuzd5.pdf.
  33. V. Parkhomchuk and I. Ben-Zvi, Electron cooling for RHIC, BNL C-A/AP/47 April 2001, https://www.rhichome.bnl.gov/AP/ap_notes/ap_note_47.pdf.
