Multiphysics analysis of cryogenically cooled photocathode in a continuous wave SRF injector cavity

Dmitry Bazyl*, Klaus Floettmann, Elmar Vogel, and Igor Zagorodnov

  • *Contact author: dmitry.bazyl@desy.de
PDF

Phys. Rev. Accel. Beams 29, 013402 – Published 20 January, 2026

DOI: https://doi.org/10.1103/9jyv-hfxy

Abstract

The paper evaluates the thermal regime of a cryogenically cooled copper photocathode integrated into a continuous-wave superconducting radio-frequency injector cavity with direct thermal contact. Such a photoinjector layout is being developed at DESY and has recently demonstrated a record-high 50  MV/m axial electric field in radio-frequency tests, marking an important milestone. To address the thermal effect of the picosecond excitation laser, we first develop a two-temperature model to describe the temperature of the emitting surface at cryogenic temperatures and solve it numerically. Subsequently, we present a one-temperature model of the bulk photocathode coupled with an electromagnetic model of the injector cavity. For the current injector design, we predict a negligible impact of the laser on the intrinsic quality factor of the cavity, identifying instead the cryogenic stability of the copper cathode as the primary operational limit. To overcome cooling challenges, we propose an improved configuration of the cathode plug. For the proposed geometry, the multiphysics analysis confirms stable performance at a nominal 2 W laser power, sufficient for 100 pC beams at 1 MHz under optimistic quantum efficiency assumptions. Operation at higher laser loads will benefit from further dedicated cryogenic analysis.
